Alfaled AFT-20 User manual

●Touch panel 1/ 2/ 3/ 4 zone dimming switch RF remote.
●Each zone can remote control multiple receivers, including Alfaled’s 2.4G LED controller, dimming driver or smart lamp.
●Ultra sensitive high strength glass touch panel.
●Touch keys with chord tones and LED indicator.
●Free installation, no wiring, removable.
●AAA x 2 attery powered.b
Technical Parameters
Model No.: AFT-20, AFT-20-1, AFT-20-2, AFT-20-3
1-4 Zone dimming switch/ Glass touch panel/ W ireless remote 30m distance/ AAA x 2 battery
Features
Wall Mounted Touch Panel
LVD RED
AFT-20AFT-20-3AFT-20-2
AFT-20-1
1 Zone sw itch 2 Zone sw itch 3 Zone sw itch 4 Zone sw itch
Input and Output
W arranty
5 years
W arranty
Operation temperature
Case temperature (Max.)
Environment
IP20
IP rating
Ta: -30
O
C ~+5 5
O
C
Tc: +85
O
C
Output signal RF 2.4GHz( )
W orking voltage 3VDC AA A x 2( )
W orking current ＜20mA
Standby current ＜2 0 μA
Standby time 1 year
Remote distance 30m
S afety a nd E M C
EMC standard (EMC) EN301 489,EN 62479
Radio Equipment(RED) EN300 328
Certification CE,EMC,LVD,RED
EN60950
Safety standard(LVD)
User Manual Ver 1.0.2 2018.11.01 Page 1
www.alfaled.sk

AFT-16AFT-16-3
AFT-16-2
AFT-16-1
Mechanical Structures and Installations
ON key
Short press: Turn on the light of each zone.
Long press(1-6s): Dimming up when light is on.
OFF key
Short press: Turn off the light of each zone.
Long press(1-6s): Dimming down w hen light is on.
Long press(5s) : Turn on or turn off tone w hen light is off.
Zone1
Zone1
Zone2
Zone1
Zone2
Zone3
Zone1
Zone2
Zone3
Zone4
AFT-20, AFT-20-1, AFT-20-2, AFT-20-3 Wall Mounted Touch Panel
Key function
Typical base as below:
European style 86 siz e
Touch panel Baseplate Base
Uninstall
Installation diagram:
86 .00 mm
86 .00 mm
61 .00 mm
61 .00 mm
20 .50 mm
Installation rack
Battery compartments
User Manual Ver 1.0.2 2018.11.01 Page 2
www.alfaled.sk

Touch Panel work as RF remote (two match ways)
Use the controller’s Match key
Match:
Short press match key, immediately press ON
key of the touch panel.
Use Power Restart
Match:
Switch off the power of the receiver, then switch on power again,
immediately short press ON key 3 times on the touch panel.
The light blinks 3 times means match is successful.
.
Delete:
Switch off the power of the receiver, then switch on power again,
immediately short press ON key 5 times on the touch panel.
The light blinks 5 times means all matched remotes w ere deleted.
Delete:
Press and hold match key for 5s to delete all match,
The light blinks 5 times means all matched remotes
were deleted.
End user can choose the suitable match/ delete w ays. Tw o options are offered for selection:
S afety informa ti on
1.Read all instructions carefully before y ou begin this installation.
2.W hen installing battery, pay attention to the battery positive and negative polarity.
A long time w ithout the remote control, remove the battery.
W hen remote distance becomes smaller and insensitive, replace the battery.
3. If no response from the receiver, please re-match the remote.
4.Gently handle remote, bew are of falling.
5. For indoor and dry location use only.
User Manual Ver 1.0.2 2018.11.01 Page 3
www.alfaled.sk
AFT-20, AFT-20-1, AFT-20-2, AFT-20-3 Wall Mounted Touch Panel
