ALFAtron ALF-TPUH405PT-WP User manual

www.alfatronelectronics.com
ALFATRON ELECTRONICS GmbH GERMANY
ALF-TPUH405PT-WP
2x1 Auto 4K Wall plate with HDBaseT Transmitter

Alfatron ALF-TPUH405PT-WP
Preface
Read this user manual carefully before using this product. Pictures shown in this
manual are for reference only, different model and specifications are subject to real
product.
This manual is only for operation instruction only, not for any maintenance usage. The
functions described in this version are updated till February, 2020. Any changes of
functions and parameters since then will be informed separately. Please refer to the
dealers for the latest details.
FCC Statement
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. It has been tested and found to comply with the limits for a
Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a commercial
installation.
Operation of this equipment in a residential area is likely to cause interference, in which
case the user at their own expense will be required to take whatever measures may be
necessary to correct the interference
Any changes or modifications not expressly approved by the manufacture would void
the user’s authority to operate the equipment.
Do not dispose of this product with the normal household waste at the end of
its life cycle. Return it to a collection point for the recycling of electrical and
electronic devices. This is indicated by the symbol on the product, user
manual or packaging. The materials are reusable according to their
markings. By reusing, recycling or other forms of utilisation of old devices
you make an important contribution to the protection of our environment. Please
contact your local authorities for details about collection points.

Alfatron ALF-TPUH405PT-WP
SAFETY PRECAUTIONS
To ensure the best from the product, please read all instructions carefully before using
the device. Save this manual for further reference.
 Unpack the equipment carefully and save the original box and packing material for
possible future shipment
 Follow basic safety precautions to reduce the risk of fire, electrical shock and injury
to persons.
 Do not dismantle the housing or modify the module. It may result in electrical shock
or burn.
 Using supplies or parts not meeting the products’ specifications may cause
damage, deterioration or malfunction.
 Refer all servicing to qualified service personnel.
 To prevent fire or shock hazard, do not expose the unit to rain, moisture or install
this product near water.
 Do not put any heavy items on the extension cable in case of extrusion.
 Do not remove the housing of the device as opening or removing housing may
expose you to dangerous voltage or other hazards.
 Install the device in a place with fine ventilation to avoid damage caused by
overheat.
 Keep the module away from liquids.
 Spillage into the housing may result in fire, electrical shock, or equipment damage.
If an object or liquid falls or spills on to the housing, unplug the module immediately.
 Do not twist or pull by force ends of the optical cable. It can cause malfunction.
 Do not use liquid or aerosol cleaners to clean this unit. Always unplug the power to
the device before cleaning.
 Unplug the power cord when left unused for a long period of time.
 Information on disposal for scrapped devices: do not burn or mix with general
household waste, please treat them as normal electrical wastes.

Alfatron ALF-TPUH405PT-WP
Table of Contents
1. Introduction .................................................................................................................1
1.1 Product Introduction...........................................................................................1
1.2 Features ............................................................................................................1
1.3 Package List ......................................................................................................1
2. Panel Description........................................................................................................2
2.1 Front Panel ........................................................................................................2
2.2 Rear Panel.........................................................................................................3
3. System Connection.....................................................................................................4
4. Button Control.............................................................................................................5
5. RS232 Control ............................................................................................................6
5.1 RS232 Control Connection ................................................................................6
5.2 RS232 Control Software ....................................................................................7
5.3 RS232 Commands ............................................................................................8
5.3.1 Control Mode Switching...........................................................................8
5.3.2 Signal Switching ......................................................................................8
5.3.3 VGA Scaling Configuration ......................................................................8
5.3.4 HDCP Compliance...................................................................................9
5.3.5 VGA Image Adjusting...............................................................................9
5.3.6 EDID Configuration................................................................................11
5.3.7 Device Configuration .............................................................................11
6. Specification .............................................................................................................12
7. Panel Drawing ..........................................................................................................13
8. Troubleshooting & Maintenance ...............................................................................14
9. Warranty ...................................................................................................................15

1
Alfatron ALF-TPUH405PT-WP
1. Introduction
1.1 Product Introduction
Connect, switch and extend HDMI and 1 VGA+ audio input to displays or projectors in
conference rooms, classrooms and control centers. Inputs are automatically switched
(or manually selected) to permit seamless transfer from one source to the next. Extend
signal up to 70 meters (230ft) over a single Category cable. Certified HDBaseT
technology for a complete professional installation including HD video, power, RS232
control. This device uses Power over HDBaseT (PoH) to provide the flexibility for
powering the transmitter from the receiver at the display over the same Category cable.
This product is used with HDBaseT 70M extender Receiver.
1.2 Features
 HDBaseT Alliance certified.
 Dual gang Decora form factor with matte anodized aluminum finish.
 Delivers full uncompressed HD video 3D and 4Kx2K (VESA resolutions up to
1920x1200@60Hz, and HDTV resolutions up to 2160p) over single Category cable
up to 70m (230ft).
 Supports key features of HDMI 1.4 including EPG, EDID, and HDCP.
 Built-in scaling function to automatically match signals to display nativeresolution.
 PoH (power over HDBaseT) allows powering from the receiver at the displayend.
 Locking features for input connectors.
1.3 Package List
 1 x 4K Wallplate HDBaseT Transmitter
 4 x Mounting Screws
 1 x 2-pin Pluggable Terminal Block
 1 x 4-pin Pluggable Terminal Block
 1 x Top Cover
 1 x User Manual
Note: Please confirm if the product and the accessories are all included, if not, please
contact with the dealers.

2
Alfatron ALF-TPUH405PT-WP
1
2 3
POWER
LINK
VGA
4
RESET
6
VGA IN
5
7
AUDIO IN
SOURCE/AUTO
HDMI
8
HDMI IN
FIRMWARE
9
2. Panel Description
2.1 Front Panel
No.
Name
Description
①POWER LED indicator glows red when power is applied.
②LINK
LED indicator glows green when an HDBaseT link is
established.
③HDCP
LED indicator glows green when an HDCP link is
established.
④RESET This button performs a soft reboot of the 4K Wallplate
HDBaseT Transmitter.
⑤
SOURCE/AUTO
Button switches sources and upon push and hold
changes mode between Auto and Manual source select.
LED indicator glows green when in Auto mode.
⑥ VGA & VGA IN

VGA – LED indicator glows green when the VGA input
is active, amber when a source is available, and does
not light when there is no source connected.
 VGA IN – HD 15 connector.
⑦AUDIO IN 3.5mm stereo audio connector supplies audio for the VGA
input.

3
Alfatron ALF-TPUH405PT-WP
⑧ HDMI & HDMI IN

HDMI - LED indicator glows when HDMI input is
active, amber when a source is available, and does
not light when there is no source connected.
 HDMI IN – HDMI connector with locking feature.
⑨
FIRMWARE
Micro-USB connector used to update firmware.
2.2 Rear Panel
No.
Name
Description
①HDBT OUT
HDBaseT output, connects with HDBaseT Receiver over a
single Category cable to deliver AV signals, support PoC.
②IN 12V input, connects with power adapter.
③OUT 12V output, connects with Control Panel to energize it.
④
RS232
Serial port for control ALF-TPUHD405PT-WP and the third-
party device via RS232 commands. Please refer to the 5.
RS232 Control for more details.
1
OUT
RS232
2
3
4
12V Tx Rx
HDBT OUT

4
Alfatron ALF-TPUH405PT-WP
3. System Connection
Usage Precautions
 System should be installed in a clean environment and has a prop temperature and
humidity.
 All of the power switches, plugs, sockets and power cords should be insulated and
safe.
 All devices should be connected before power on.
Overview:
Installation
①If installing in a back-box, it is recommended that the4K Wallplate HDBaseT
Transmitter be installed in a 4-5/8” square box at a minimum. The 4-5/8”square
box has sufficient space to terminate the cables with jacks behind the unit when
fully installed.
②Run one twisted pair cable from the4K Wallplate HDBaseT Transmitter location to
the location where the HDBaseT Receiver will be located (somewhere nearthe
display device).See the installation instructions for the 70M HDBaseT Receiver.
③If using the Control Panel, run another twisted pair cable from the 4K Wallplate

5
Alfatron ALF-TPUH405PT-WP
HDBaseT Transmitter location to the location that the Control Panel will be
mounted.
④All twisted pair cables should be terminated with jacks. This allows the permanent
link between the two devices to be tested.
⑤Use the appropriate category rated patch cable to connect the HDBaseT link to
the HDBT OUT connector.
⑥If using the Control Panel, use the supplied adapter cable to connect with the
second cable and follow the installation instructions for the HDBaseTReceiver
and Control Panel.
Note: We recommends Category 6A cabling with alien crosstalk prevention technology
for the performance of HDBaseT link.
4. Button Control
SOURCE/AUTO Button
Press and hold the SOURCE/AUTO button for approximately 3 seconds. When the
button lights up green the 4K Wallplate HDBaseT Transmitter is in AUTO mode. This
mode automatically selects the last video source connected to the 4K Wallplate
HDBaseT Transmitter and outputs it to the display. Press and hold again for
approximately 3 seconds, the light will go out, and the device will be in Manual mode
which will allow the user to momentarily press the button to toggle between the two
sources.

6
Alfatron ALF-TPUH405PT-WP
5. RS232 Control
5.1 RS232 Control Connection
There are two RS232 control modes switching via sending 50779% or 50780%.
①Control this Wallplate HDBaseT Transmitter and far-end third-party device (such
as Projector) device by local PC, and the connection diagram shown asbelow:
②Control the Wallplate HDBaseT Transmitter by the remote PC which is connected
with Receiver
The RS232 control mode can be chosen via RS232 commands, please refer to the
5.3.1 RS232 mode switching for more details.

7
Alfatron ALF-TPUH405PT-WP
5.2 RS232 Control Software
 Installation: Copy the control software file to the control PC.
 Uninstallation: Delete all the control software files in corresponding file path.
Basic Settings:
First, connect 4K Wallplate HDBaseT Transmitter with all input devices and output
devices needed, then to connect it with a computer which is installed with RS232
control software. Double-click the software icon to run this software.
Here we take the software CommWatch.exe as example. The icon is showed as
below:
The interface of the control software is showed as below:
Please set the parameters of COM number, bound rate, data bit, stop bit and the parity
bit correctly, and then you are able to send command in Command Sending Area.
Parameter Configuration area
Command Sending area
Monitoring area, indicates if
the command sent works.

8
Alfatron ALF-TPUH405PT-WP
5.3 RS232 Commands
Communication protocol: RS232 Communication Protocol
Baud rate: 9600 Data bit: 8 Stop bit: 1 Parity bit: none
5.3.1 Control Mode Switching
Command Function Feedback Example
50779%
Switch to RS232 mode 1（Default）,
control scaler switcher and the far-end
third-party device.
RS232 Mode 1: RS232
Control Scaler & Remote.
50780% Switch to RS232 mode 2, control the
scaler switcher from remote.
RS232 Mode 2:RS232 &
Remote Control Scaler
5.3.2 Signal Switching
Command Function Feedback Example
50770% Enable auto-switching Auto Switching
50771% Disable auto-switching Manual Switching
50701% Switch to HDMI input Switch to HDMI
50704% Switch to VGA input Switch to VGA
5.3.3 VGA Scaling Configuration
The default output resolution for VGA is 1920x1080. Below is a list of the output
resolutions the built-in scaler can output.
Command Function Feedback Example
50632% Check the output resolution Resolution: xx
50619% Change the resolution to 1360X768 HD Resolution: 1360x768
50626% Change the resolution to 1024X768
XGA
Resolution: 1024x768
50627% Change the resolution to 1280X720
720P
Resolution: 1280x720
50628% Change the resolution to 1280X800
WXGA
Resolution: 1280x800
50629% Change the resolution to 1920X1080
1080P
Resolution: 1920x1080

9
Alfatron ALF-TPUH405PT-WP
50620% Change the resolution to1920X1200
WUXGA
Resolution: 1920x1200
50621% Change the resolution to1600X1200
UXGA
Resolution: 1600x1200
5.3.4 HDCP Compliance
Command Function Feedback Example
50790% Set the HDCP status of HDMI output
socket to Active
HDCP Active
50791% Set the HDCP status of HDMI output
socket to On
HDCP On
50792% Set the HDCP status of HDMI output
socket to Off
HDCP Off
50793%
Check HDCP status
HDCP Off/ HDCP On/
HDCP Active (default)
5.3.5 VGA Image Adjusting
Command Function Feedback Example
50636% Check the brightness Brightness: xx (xx=00～99)
502xx% Set the brightness to xx. Brightness: xx (xx=00～99)
50637% Check the contrast Contrast: xx (xx=00～99)
503xx% Set the contrast to xx. Contrast: xx (xx=00～99)
50638% Check the saturation Saturation: xx (xx=00～99)
504xx% Set the saturation to xx. Saturation: xx (xx=00～99)
50639% Check sharpness Sharpness: xx (xx=00～99)
505xx% Set the sharpness to xx. Sharpness: xx (xx=00～99)
50606% Auto-adjust the input parameter VGA Input Auto

10
Alfatron ALF-TPUH405PT-WP
50640%
Check the color temperature
Color Temperature: xx (xx
can be medium, warm,
user, or cool.)
50607%
Adjust the color temperature
Color Temperature: xx (xx
can be medium, warm,
user, or cool.)
50635%
Check the image aspect ratio Aspect Ratio: xx (xx can be
16:9, 4:3, or auto.)
50608%
Set the aspect ratio Aspect Ratio: xx (xx can be
16:9, 4:3, or auto.)
50633%
Check the picture mode
Picture Mode: xx (xx can
be dynamic, standard, mild,
or user.)
50614% Set the picture mode
Picture Mode: xx (xx can
be dynamic, standard, mild,
or user.)
50707%
Check the present resolution and
polarity
1920x1080
Hpolarity:1
Vpolarity:0
50705% Change the horizontal polarity to the
opposite
Hpolarity:0/1
50706% Change the vertical polarity to the
opposite
Vpolarity:0/1
50678%
Enable screen output adjusting Enter Output Position
Adjust
50679% Disable screen output adjusting Exit Output Position Adjust
50670% Move the image to left Output Position Adjust X xx
50671% Move the image to right Output Position Adjust X xx
50672% Move the image up Output Position Adjust Y xx
50673% Move the image down Output Position Adjust Y xx

11
Alfatron ALF-TPUH405PT-WP
50674% Pull left from right side (decrease image
width)
Output Width Adjust xx
50675% Stretch right from right side (increase
image width)
Output Width Adjust xx
50676% Stretch upwards from bottom side
(decrease image height)
Output Height Adjust xx
50677% Stretch downwards from bottom side
(increase image height)
Output Height Adjust xx
5.3.6 EDID Configuration
Command Function Feedback Example
50772% EDID pass-through (default) EDID: bypass mode
50773% Set EDID data to 1080P PCM 2.0ch EDID:1080P&PCM 2ch
50774% Set EDID data to 1080P Dolby 5.1 EDID:1080P&5.1ch
50775% Set EDID data to 1080P3D Dolby 5.1 EDID:1080P3d&5.1ch
50776% Set EDID data to 1080i PCM 2.0ch EDID:1080i&PCM 2ch
50777% Set EDID data to 4Kx2K PCM 2.0ch EDID:4K&PCM 2ch
50778%
Check EDID data
EDID: bypass mode
EDID:1080P&PCM 2ch
EDID:1080P&5.1ch
EDID:1080P3d&5.1ch
EDID:4K&PCM 2ch
50799% Program EDID file, send EDID data
within 10s
Waiting for edid within 10
secs!
Note: EDID commands are for HDMI sources only.
5.3.7 Device Configuration
Command Function Feedback Example
50698% Software upgrading
50699% Check the software version Version Vx.x.x
50617% Restore factory default

12
Alfatron ALF-TPUH405PT-WP
6. Specification
Input & Output
Input
(1) HDMI, (1) VGA, (1) AUDIO, (1) 12V POWER
Input Connector
(1) 19-pin Type A female HDMI, (1) HD-15 VGA,
(1) 3.5mm mini jack, (1) 2-pin Pluggable Terminal Block
Output (1) HDBaseT, (1) 12V POWER
Output Connector
(1) RJ45, (1) 2-pin Pluggable Terminal Block
Transmission Mode HDBaseT
Control Parts
Control Ports
(1) FIRMWARE, (1) RS232
Control Connector (1) Micro USB, (1) 3-pin Pluggable Terminal Block
General
Video Resolution
VGA - up to 1920 x 1080@60Hz;
HDMI - up to 4Kx 2K
Audio Impedance >10KΩ
Frequency Response 20Hz~20KHz
SNR
>85db@20Hz~20KHz
Transmission Distance 1080p ≤ 70m; 4Kx2K ≤ 40m
Bandwidth
10.2Gbps
HDMI Standard
HDMI 1.4 and HDCP 1.4
Power Supply Input:100V~240V AC; Output: 12VDC 2A
Max Consumption
9.6W
Work Temperature
-10 ~ +40
℃
Reference Humidity 10% ~ 90%
Dimension (W*H*D) 104.5mm x 89.0mm x 44.0 mm
Net Weight 238g

13
Alfatron ALF-TPUH405PT-WP
7. Panel Drawing
32.0mm
POWER
LINK VGA
RESET
VGA IN
SOURCE/AUTO
AUDIO IN
HDMI
HDMI IN
FIRMWARE
89.0 mm
OUT
RS232
12V Tx Rx
HDBT OUT
104.5 mm
66.0 mm
47.0 mm
69.0 mm

14
Alfatron ALF-TPUH405PT-WP
8. Troubleshooting & Maintenance
Problems
Causes
Solutions
Color losing or no video
signal output in HDMI
display
The connecting cables
may not be connected
correctly or it may be
broken
Check whether the cables
are connected correctly
and in working condition.
No HDMI signal output in
the device while local
HDMI input is in normal
working state
Output image with
snowflake
POWER
indicator doesn’t
work or no respond to any
operation
Loose or failed power
cord connection
Ensure the power cord
connection is good
Static becomes stronger
when connecting the
video connectors
bad grounding
Check the grounding and
make sure it is connected
well.
Cannot be controlled by
front panel buttons
The unit may have
already been broken
Send it to authorized
dealer for repairing.
If your problem persists after following the above troubleshooting steps, seek further
help from authorized dealer or our technical support.

15
Alfatron ALF-TPUH405PT-WP
9. Warranty
1.1 This limited warranty covers defects in materials and workmanship in this product.
1.2 Should warranty service be required, proof of purchase must be presented to the
Company. The serial number on the product must be clearly visible and not have been
tampered with in any way whatsoever.
1.3 This limited warranty does not cover any damage, deterioration or malfunction
resulting from any alteration, modification, improper or unreasonable use or maintenance,
misuse, abuse, accident, neglect, exposure to excess moisture, fire, improper packing and
shipping (such claims must be presented to the carrier), lightning, power surges, or other
acts of nature. This limited warranty does not cover any damage, deterioration or
malfunction resulting from the installation or removal of this product from any installation,
any unauthorized tampering with this product, any repairs attempted by anyone
unauthorized by the Company to make such repairs, or any other cause which does not
relate directly to a defect in materials and/or workmanship of this product. This limited
warranty does not cover equipment enclosures, cables or accessories used in conjunction
with this product.
This limited warranty does not cover the cost of normal maintenance. Failure of the
product due to insufficient or improper maintenance is not covered.
1.4 The Company does not warrant that the product covered hereby, including, without
limitation, the technology and/or integrated circuit(s) included in the product, will not
become obsolete or that such items are or will remain compatible with any other product
or technology with which the product may be used.
1.5 Only the original purchaser of this product is covered under this limited warranty. This
limited warranty is not transferable to subsequent purchasers or owners of this product.
1.6 Unless otherwise specified, the goods are warranted in accordance with the
manufacturer’s product specific warranties against any defect attributable to faulty
workmanship or materials, fair wear and tear being excluded.
1.7 This limited warranty only covers the cost of faulty goods and does not include the
cost of labor and travel to return the goods to the Company’s premises.
1.8 In the event of any improper maintenance, repair or service being carried out by any
third persons during the warranty period without the Company’s written authorization, the
limited warranty shall be void.
1.9 A 7 (seven) year limited warranty is given on the aforesaid product where used
correctly according to the Company’s instructions, and only with the use of the Company’s
components.
1.10 The Company will, at its sole option, provide one of the following three remedies to
whatever extent it shall deem necessary to satisfy a proper claim under this limited warranty:

16
Alfatron ALF-TPUH405PT-WP
1.10.1 Elect to repair or facilitate the repair of any defective parts within a reasonable
period of time, free of any charge for the necessary parts and labor to complete the repair
and restore this product to its proper operating condition.; or
1.10.2 Replace this product with a direct replacement or with a similar product deemed by
the Company to perform substantially the same function as the original product; or
1.10.3 Issue a refund of the original purchase price less depreciation to be determined
based on the age of the product at the time remedy is sought under this limited warranty.
1.11 The Company is not obligated to provide the Customer with a substitute unit during
the limited warranty period or at any time thereafter.
1.12 If this product is returned to the Company this product must be insured during
shipment, with the insurance and shipping charges prepaid by the Customer. If this
product is returned uninsured, the Customer assumes all risks of loss or damage during
shipment. The Company will not be responsible for any costs related to the removal or
re-installation of this product from or into any installation. The Company will not be
responsible for any costs related to any setting up this product, any adjustment of user
controls or any programming required for a specific installation of this product.
1.13 Please be aware that the Company’s products and components have not been tested
with competitor’s products and therefore the Company cannot warrant products and/or
components used in conjunction with competitor’s products.
1.14 The appropriateness of the goods for the purpose intended is only warranted to the
extent that the goods are used in accordance with the Company’s installation,
classification, and usage instructions.
1.15 Any claim by the Customer which is based on any defect in the quality or condition of
the goods or their failure to correspond with specification shall be notified in writing to the
Company within 7 days of delivery or (where the defect or failure was not apparent on
reasonable inspection by the Customer) within a reasonable time after discovery of the
defect or failure, but, in any event, within 6 months of delivery.
1.16 If delivery is not refused, and the Customer does not notify the Company accordingly,
the Customer may not reject the goods and the Company shall have no liability and the
Customer shall pay the price as if the goods had been delivered in accordance with the
Agreement.
1.17 THE MAXIMUM LIABILITY OF THE COMPANY UNDER THIS LIMITED WARRANTY
SHALL NOT EXCEED THE ACTUAL PURCHASE PRICE PAID FOR THE PRODUCT
