Honeywell 5816WMBR User manual

11/08 N6527-5
N6527-5
5816WMBR Exterior of box
File: N6527-5_Blueline_5816WMBR_instruct_exterior.eps
ASSEMBLED IN MEXICO
© 2008 Honeywell International Inc.
All Rights Reserved
Listed
BP547
343P
Field proven
5800 wireless technology
+

A
A
LATCH ALIGN
MAGNET
WITH MARKS
TAMPER
SWITCH
LOCKING
TAB
RELEASE
WINDOW
BREAKOUT
FOR SURFACE
WIRING
LOOP 1
TERMINALS
1/2"
MAX.
MAGNET
BATTERY
REED
SWITCH
(LOOP 2)
FEDERAL COMMUNICATIONS
COMMISSION STATEMENTS:
The user shall not make any
changes or modifications to the
equipment unless authorized by the
Installation Instructions or User's
Manual.Unauthorized changes or
modifications could void the user's
authority to operate the equipment.
FCC / IC Statement: This device
complies with Part 15 of the FCC
Rules, and RSS 210 of IC.
Operation is subject to the
following two conditions: (1)This
device may not cause harmful
interference (2)This device must
accept any interference received,
including interference that may
cause undesired operation.
Perforation (1/4" x 1/8")
CUS
ÊN6527-5SŠ
5816WMBR
Wireless Door/Window
Transmitter
w/ Magnet
5816WMBR
5816WMBR
Wireless Door/Window
Transmitter w/ Magnet
Compatible with 5800 wireless technology
Includes two unique zones
Easy open case
Battery included
Magnet included
5816WMBR
Wireless Door/Window Transmitter w/ Magnet
Compatible with 5800 wireless technology
Includes two unique zones
Easy open case
Battery included
Magnet included
5816WMBR
Wireless Door/Window Transmitter w/ Magnet
<<< Open Carton Along Perforations >>>

N6527-5
5816WMBR Interior of box
File: N6527-5_Blueline_5816WMBR_instruct_interior.eps
Battery Information
FOR DOCUMENTATION AND ONLINE SUPPORT http://www.security.honeywell.com/hsc/resources/MyWebTech
FOR WARRANTY INFORMATION GO TO: http://www.security.honeywell.com/hsc/resources/wa
See inside of
carton for
installation
instructions.
See inside of
carton for
installation
instructions.
REFER TO THE INSTALLATION
INSTRUCTIONS FOR THE CONTROL
WITH WHICH THIS DEVICE IS USED,
FOR DETAILS REGARDING
LIMITATIONS OF THE ENTIRE
ALARM SYSTEM.
1.
2.
MAGNET
ALIGNMENT
STRIP
CASE
LOCKING
TAB
CONCEALED
WIRING
ENTRY HOLE
PLATE
MOUNTING
HOLES (2)
CASE
HOLDING
POSTS (2)
NOTE
5816 HAS 2
UNIQUE
ZONES
5816 provides two zones: a
magnetic reed with a max 1/2"
gap (Loop 2) and a wired norm-
ally closed contact (Loop 1).
Slide case onto mount-
ing plate posts until
locking tab clicks.
To replace the cover,
engage the hooks
along one edge and
snap shut.
For enrollment, refer
to the Control Panel
documentation. 
NOTE: For UL instal-
lations, 5816 shall be
enrolled as Type "RF"
(supervised RF).
Remove the transmitter’s
cover using the finger latch.
Disengage the mounting plate
from the unit by releasing the
locking tab (see diagram).
Mount 5816 either directly to
the surface or by using the
mounting plate. NOTE: If
using as a door contact,
mount 5816 to the frame and
mount the magnet to the door.
If using NC Wired Loop: Feed
the wires through the
concealed wiring hole on the
mounting plate, or run wiring
through the thin "breakout"
area in the case wall, then
connect the loop to the unit’s
terminals (see diagram on
reverse; no connection is
needed if the wired loop is not
used.) For UL installations: a
contact may not be more than
3 feet from 5816.
4.
3.
5.
6.
Installation
Replace battery only with:
Panasonic CR123A, Duracell
DL123A, Sanyo CR123A,
or ADEMCO 466.
Observe correct polarity.
BATTERY CAUTION: Risk of fire,
explosion and burns. Do not
recharge, disassemble, heat above
212 F (100 C) or incinerate.
Dispose of used batteries properly.
Keep away from children.
IMPORTANT! Do not mount
the transmitter on or near
metal objects, as this may
affect transmission range. It is
also good practice to avoid
locating the transmitter near
wiring (AC, telephone, HVAC,
computer data cables, etc.
If using reed, mount
magnet (5899 or
equiv.) near the
alignment marks (see
diagram).
Install battery as
shown (see diagram)
Perforation (1/4 x 1/8)
