ALGE-Timing Photocell PR1a User manual

Manual
PR1a
Page 1
Photocell
Version-E23-10-31
Manual

Manual
PR1a
Page 2
Important Information
General
Before using your device read the complete manual carefully. It is part of the device and
contains important information about installation, safety and its intended use. This manual cannot cov-
er all conceivable applications. For further information or in case of problems that are mentioned not at
all or not sufficiently detailed, please contact your representative. You can find contact
details on our homepage www.alge-timing.com
Safety
Apart from the information of this manual all general safety and accident prevention regulations of the
legislator must be taken into account.
The device must only be used by trained persons. The setting-up and installation must only be exe-
cuted according to the manufacturer’s data.
Intended Use
The device must only be used for its intended applications. Technical modifications and any misuse
are prohibited because of the risks involved! is not liable for damages that are caused by
improper use or incorrect operation.
Cleaning
Please clean the outside of the device only with a smooth cloth. Detergents can cause damage. Never
submerge in water, never open or clean with wet cloth. The cleaning must not be carried out by hose
or high-pressure (risk of short circuits or other damage).
Liability Limitations
All technical information, data and information for installation and operation correspond to the latest
status at time of printing and are made in all conscience considering our past experience and
knowledge. Information, pictures and description do not entitle to base any claims. The manufacturer
is not liable for damage due to failure to observe the manual, improper use, incorrect repairs, technical
modifications, use of unauthorized spare parts. Translations are made in all conscience. We assume
no liability for translation mistakes, even if the translation is carried out by us or on our behalf.
Disposal
If a label is placed on the device showing a crossed out dustbin on wheels (see drawing),
the European directive 2002/96/EG applies for this device.
Please get informed about the applicable regulations for separate collection of electrical
and electronical waste in your country and do not dispose of the old devices as house-
hold waste. Correct disposal of old equipment protects the environment and humans
against negative consequences!
Copyright by GmbH
All rights reserved. Any duplication, either in full or in part, requires the prior written consent of the
copyright holder.

Manual
PR1a
Page 3
Declaration of Conformity
We declare that the following products comply with the requirements of the listed standards.
We, GmbH
Rotkreuzstrasse 39
A-6890 Lustenau
Declare under our sole responsibility, that the:
Photocell PR1a
is in conformity with the following standard(s) or other normative documents(s):
Safety: EN 60950-1:2006 + A11:2009
EMC: EN55022:2006+A1:2007
EN55024:1998+A1:2001+A2:2003
EN61000 3-2:2006 + A1:2009 + A2:2009
EN61000 3-3:2008
Additional Information:
The product herewith complies with the requirements of the Low Voltage Directive
73/23/EEC, also the EMC Directive 2004/108EG and accordingly carries the CE-marking.
Lustenau, 10.02.2010 GmbH
Albert Vetter
(General Manager)

Manual
PR1a
Page 4

Manual
PR1a
Page 5
Contents
1General.........................................................................................................................6
1.1 Functionality .........................................................................................................6
1.2 Photocell Features................................................................................................6
1.3 Type of photocell ..................................................................................................6
1.3.1 Reflection photocell PR1a-R:..............................................................................................................7
1.3.2 Reflection photocell PR1a-RT:............................................................................................................7
1.3.3 One-way photocell PR1a-d:................................................................................................................7
1.3.4 One-way photocell PR1a-dT:..............................................................................................................7
2Operating Modes.........................................................................................................7
2.1 Reflection Photocell – NORM ...............................................................................7
2.2 One-way Photocell................................................................................................8
3Power Supply ..............................................................................................................8
3.1 External supply from timing devices.............................................................8
3.2 External Supply ....................................................................................................8
3.3 Internal Battery .....................................................................................................8
3.3.1 Insert Batteries....................................................................................................................................9
3.3.2 Operating Time of Batteries................................................................................................................9
4Operating Mode Indication with LED.........................................................................9
5Alignment of Photocell .............................................................................................10
5.1 Reflection Photocell............................................................................................10
5.2 One-way Photocell..............................................................................................10
5.3 Setting of Dead Time..........................................................................................11
5.4 Synchronisation of two Photocells ......................................................................11
6Weather protection....................................................................................................11
7Technical Data...........................................................................................................12

Manual
PR1a
Page 6
1 General
The photocell PR1a combines highest precision and performance with smallest dimensions.
1.1 Functionality
The photocell transmitter sends a modulated light beam in infrared range. The receiver moni-
tors the light beam for disruptions. In case of a disruption of the infrared beam the receiver
releases a pulse. For multipurpose use the photocell can be operated in three different oper-
ation modes: reflection photocell, transmitter and receiver.
1.2 Photocell Features
Releasing accuracy 1/10.000 second
Diversity of types:
Reflection photocell
One-way photocell for large distances
Large photocell range:
Reflection photocell approx. 25 m
Transmitter and receiver photocell more than 150 m
Variable supply of the photocell:
Battery operation
Supply from timing device
External supply from 4 to 18 VDC
Battery condition indication with LED (green, yellow, red)
Indication of the photocell alignment with LED (green, yellow, red)
Synchronisation of two photocells (main and backup), to prevent interferences
Setting of dead time (approx. 20 ms to 2 s /factory setting = 20 ms)
1.3 Types of photocell
According to its type the photocell can consist of the following parts:
Photocell PR1a Reflector PR1a-Ref Mounting bracket BBG
Tripod TRI128 Photocell cable 001-10 Photocell cable 001-30
