Algo 8186 User manual

8186 SIP Horn Speaker
Document 90-00079 Algo Communication Products Ltd [phone]
2016-12-08 4500 Beedie St Burnaby BC Canada V5J 5L2 [email protected]
Page 1 www.algosolutions.com
8186 SIP Horn Speaker
FW Version 1.3.1
Installation & Configuration
Order Codes
8186 SIP Horn Speaker

8186 SIP Horn Speaker
Document 90-00079 Algo Communication Products Ltd [phone]
2016-12-08 4500 Beedie St Burnaby BC Canada V5J 5L2 [email protected]
Page 2 www.algosolutions.com
Table of Contents
ABOUT THE ALGO 8186 SIP HORN SPEAKER...........................................................................................9
GETTING STARTED - QUICK INSTALL & TEST .........................................................................................10
INSTALLATION & MOUNTING ..............................................................................................................11
WEB INTERFACE...................................................................................................................................12
SIP PAGING: ONE SPEAKER ..................................................................................................................13
SIP PAGING: MULTIPLE SPEAKERS (USING MULTICAST) .......................................................................14
SIP PAGING: MULTIPLE SPEAKERS (USING INDIVIDUAL SIP EXTENSIONS) ............................................15
MULTICAST PAGE ZONES ..................................................................................................................... 16
POLYCOMTM GROUP PAGING ...............................................................................................................17
SIP RING EVENT ...................................................................................................................................18
SIP ACTIVATED NOTIFICATION ALERTS.................................................................................................18
WIRING CONNECTIONS........................................................................................................................ 18
CONNECTING INPUT DEVICES TO 8186 .....................................................................................................18
NETWORK CONNECTION........................................................................................................................19
TERMINAL BLOCK RELAY IN....................................................................................................................20
TERMINAL BLOCK RELAY OUT .................................................................................................................20
TERMINAL BLOCK RESET ........................................................................................................................ 20
BLUE LED INDICATOR ...........................................................................................................................20
WEB INTERFACE LOGIN........................................................................................................................ 21
STATUS..............................................................................................................................................21
BASIC SETTINGS TAB –SIP.................................................................................................................... 22
SIP DOMAIN (PROXY SERVER)................................................................................................................22
RING/ALERT MODE..............................................................................................................................23
RING EXTENSION .................................................................................................................................23
PAGE EXTENSION .................................................................................................................................23
AUTHENTICATION ID ............................................................................................................................23
AUTHENTICATION PASSWORD.................................................................................................................23
BASIC SETTINGS TAB –FEATURES ........................................................................................................24
RING/ALERT TONE...............................................................................................................................24
RING/ALERT VOLUME...........................................................................................................................25
RING LIMIT.........................................................................................................................................25
PAGE SPEAKER VOLUME........................................................................................................................25
PAGE MODE.......................................................................................................................................25
PAGE TIMEOUT ...................................................................................................................................25
PAGE TONE ........................................................................................................................................25
G.722 SUPPORT..................................................................................................................................25
AMBIENT NOISE COMPENSATION ............................................................................................................26
AUTOMATIC GAIN CONTROL (AGC)......................................................................................................... 26

8186 SIP Horn Speaker
Document 90-00079 Algo Communication Products Ltd [phone]
2016-12-08 4500 Beedie St Burnaby BC Canada V5J 5L2 [email protected]
Page 3 www.algosolutions.com
MULTICAST IP ADDRESSES ...................................................................................................................27
BASIC SETTINGS TAB - MULTICAST (MASTER SETTINGS) ......................................................................28
MULTICAST MODE (MASTER/SENDER SELECTED) .......................................................................................28
NUMBER OF ZONES ..............................................................................................................................29
MULTICAST TYPE .................................................................................................................................29
ZONE SELECTION MODE ........................................................................................................................29
MASTER SINGLE ZONE ..........................................................................................................................29
SPEAKER PLAYBACK ZONES.....................................................................................................................30
BASIC SETTINGS TAB - MULTICAST (SLAVE SETTINGS)..........................................................................31
MULTICAST MODE (SLAVE SELECTED)....................................................................................................... 31
NUMBER OF ZONES ..............................................................................................................................31
MULTICAST TYPE -REGULAR .................................................................................................................. 32
SLAVE ZONES ......................................................................................................................................32
MULTICAST TYPE –POLYCOM GROUP PAGING/PUSH-TO-TALK...................................................................... 32
ADDITIONAL FEATURES TAB –INPUT/OUTPUT ....................................................................................34
ALGO 1202 CALL BUTTON.....................................................................................................................34
ALGO 1203 CALL SWITCH......................................................................................................................34
ACTION –PLAY TONE ...........................................................................................................................35
ACTION -MAKE SIP VOICE CALL .............................................................................................................36
ACTION -MAKE A SIP CALL WITH TONE....................................................................................................36
ACTION WHEN TAMPER DETECTED (SUPERVISION)......................................................................................36
SPEAKER VOLUME/MUTE ...................................................................................................................... 37
CALL BUTTON .....................................................................................................................................37
DIALING EXTENSION .............................................................................................................................37
INTERVAL BETWEEN TONES ....................................................................................................................37
MAXIMUM TONE DURATION..................................................................................................................37
CALL MODE ........................................................................................................................................37
OUTBOUND RING LIMIT ........................................................................................................................38
RINGBACK TONE ..................................................................................................................................38
MAXIMUM CALL DURATION...................................................................................................................38
OUTPUT LIGHT ....................................................................................................................................38
HEARTBEAT LIGHT................................................................................................................................ 38
OUTPUT RELAY....................................................................................................................................38
ADDITIONAL FEATURES TAB –EMERGENCY ALERTS ............................................................................39
ADDITIONAL FEATURES TAB –MORE PAGE EXTENSIONS..................................................................... 41
ADDITIONAL FEATURES TAB –MORE RING EXTENSIONS .....................................................................43
ADVANCED SETTINGS TAB - NETWORK ................................................................................................44
PROTOCOL .........................................................................................................................................44
VLAN MODE...................................................................................................................................... 44
VLAN ID ...........................................................................................................................................45
VLAN PRIORITY ..................................................................................................................................45
DIFFERENTIATED SERVICES (6-BIT DSCP VALUE) .........................................................................................45
ADVANCED SETTINGS TAB –ADMIN .................................................................................................... 46

8186 SIP Horn Speaker
Document 90-00079 Algo Communication Products Ltd [phone]
2016-12-08 4500 Beedie St Burnaby BC Canada V5J 5L2 [email protected]
Page 4 www.algosolutions.com
PASSWORD.........................................................................................................................................46
CONFIRMATION ...................................................................................................................................46
DEVICE NAME (HOSTNAME)...................................................................................................................47
INTRODUCTION SECTION ON STATUS PAGE ................................................................................................47
WEB INTERFACE SESSION TIMEOUT.......................................................................................................... 47
PLAY TONE AT STARTUP ........................................................................................................................47
LOG LEVEL.......................................................................................................................................... 47
LOG SIZE ............................................................................................................................................47
LOG METHOD .....................................................................................................................................47
LOG SERVER .......................................................................................................................................47
WEB INTERFACE PROTOCOL ...................................................................................................................47
SNMP SUPPORT (V1GET ONLY) ............................................................................................................. 48
SA-ANNOUNCE SUPPORT ......................................................................................................................48
SA-ANNOUNCE SERVER ........................................................................................................................48
LOCAL MANAGEMENT PORT................................................................................................................... 48
ADVANCED SETTINGS TAB –TIME........................................................................................................49
TIME ZONE.........................................................................................................................................49
NTP TIME SERVERS..............................................................................................................................49
DEVICE DATE/TIME..............................................................................................................................49
ADVANCED SETTINGS TAB –PROVISIONING........................................................................................50
MD5 CHECKSUM................................................................................................................................. 51
GENERATING A GENERIC CONFIGURATION FILE ............................................................................................ 51
GENERATING A SPECIFIC CONFIGURATION FILE.............................................................................................52
ADVANCED SETTINGS TAB –TONES .....................................................................................................53
UPLOADING CUSTOM AUDIO FILES ..........................................................................................................53
TONE FILES INCLUDED IN MEMORY .......................................................................................................... 54
ADVANCED SETTINGS TAB –ADVANCED AUDIO ..................................................................................55
DYNAMIC RANGE COMPRESSION (DRC) ...................................................................................................55
DYNAMIC RANGE COMPRESSION GAIN .....................................................................................................55
SPEAKER FILTER G.711 .........................................................................................................................55
MICROPHONE FILTER G.711 .................................................................................................................. 56
SPEAKER FILTER G.722 .........................................................................................................................56
MICROPHONE FILTER G.722 .................................................................................................................. 56
SPEAKER NOISE FILTER ..........................................................................................................................56
MICROPHONE NOISE FILTER ...................................................................................................................56
ADVANCED SETTINGS TAB –ADVANCED SIP ........................................................................................57
OUTBOUND PROXY ..............................................................................................................................57
STUN SERVER ....................................................................................................................................57
REGISTER PERIOD (SECONDS)..................................................................................................................57
KEEP-ALIVE METHOD............................................................................................................................58
DIFFERENT PORTS FOR EXTENSIONS .........................................................................................................58
SERVER REDUNDANCY FEATURE ..............................................................................................................58
BACKUP SERVER #1.............................................................................................................................. 58
BACKUP SERVER #2.............................................................................................................................. 58

8186 SIP Horn Speaker
Document 90-00079 Algo Communication Products Ltd [phone]
2016-12-08 4500 Beedie St Burnaby BC Canada V5J 5L2 [email protected]
Page 5 www.algosolutions.com
POLLING INTERVALS (SECONDS)...............................................................................................................58
POLL ACTIVE SERVER ............................................................................................................................58
AUTOMATIC FAILBACK ..........................................................................................................................59
POLLING METHOD ...............................................................................................................................59
ADVANCED SETTINGS TAB –ADVANCED MULTICAST...........................................................................60
AUDIO SYNC (SLAVE MODE) ..................................................................................................................60
MASTER OUTPUT CODEC (MASTER MODE) ............................................................................................... 60
MASTER OUTPUT PACKETIZATION TIME (MASTER MODE) ............................................................................61
ZONE DEFINITION ................................................................................................................................61
PAGE TONE AND PAGE VOLUME..............................................................................................................61
SYSTEM TAB - MAINTENANCE.............................................................................................................. 62
DOWNLOAD CONFIGURATION FILE........................................................................................................... 62
RESTORE CONFIGURATION FILE ...............................................................................................................62
RESTORE CONFIGURATION TO DEFAULTS ...................................................................................................62
REBOOT THE DEVICE .............................................................................................................................62
METHOD............................................................................................................................................63
FIRMWARE IMAGE ...............................................................................................................................63
MD5 CHECKSUM................................................................................................................................. 63
SYSTEM –SYSTEM LOG ........................................................................................................................63
SPECIFICATIONS................................................................................................................................... 64
FCC COMPLIANCE STATEMENT ............................................................................................................66

8186 SIP Horn Speaker
Document 90-00079 Algo Communication Products Ltd [phone]
2016-12-08 4500 Beedie St Burnaby BC Canada V5J 5L2 [email protected]
Page 6 www.algosolutions.com
Important Safety Information
This product is powered by a certified limited power source (LPS), Power
over Ethernet (PoE); through CAT5 or CAT6 connection wiring to an IEEE
802.3af compliant network PoE switch. The product is intended for
installation indoors or on outdoor perimeter of a building. If used in an
outdoor environment, additional protective measures must be taken
according to the installation manual. All wiring connections to the product
must be in the same building. If the product is installed beyond the
building perimeter or used in an inter-building application, the wiring
connections must be protected against overvoltage / transient. Algo
recommends that this product be installed by a qualified electrician.
If you are unable to understand the English language safety information
then please contact Algo by email for assistance before attempting an
installation [e-mail].
Consignes de Sécurité Importantes
Ce produit est alimenté par une source d’alimentation limitée certifiée
(alimentation par Ethernet); des câbles de catégorie 5 et 6 joignent un
commutateur réseau à alimentation par Ethernet homologué IEEE 802.3af.
Le produit est conçu pour être installé à l’intérieur ou dans une zone
adjacente à un édifice; selon le manuel d’installation, des mesures de
sécurité additionnelles s’avèrent alors nécessaires. Tout le câblage rattaché
au produit doit se trouver dans le même édifice. Si le produit est installé
au-delà du périmètre de l’édifice ou utilisé pour plusieurs édifices, le
câblage doit être protégé des surtensions transitoires. Algo recommande
qu’un électricien qualifié se charge de l’installation de ce produit.
Si vous ne pouvez comprendre les consignes de sécurité en anglais,
veuillez communiquer avec Algo par courriel avant d’entreprendre
l’installation au [e-mail].
Información de Seguridad Importante
Este producto funciona con una fuente de alimentación limitada (Limited
Power Source, LPS) certificada, Alimentación a través de Ethernet (Power
over Ethernet, PoE); mediante un cable de conexión CAT5 o CAT6 a un
conmutador de red con PoE en cumplimiento con IEEE 802.3af. El producto
se debe instalar en lugares cerrados o en el perímetro de un edificio al aire
libre. Si se utiliza en un ambiente al aire libre, se deben tomar medidas de
protección adicionales de acuerdo con el manual de instalación. Todas las
conexiones cableadas al producto deben estar en el mismo edificio. Si el

8186 SIP Horn Speaker
Document 90-00079 Algo Communication Products Ltd [phone]
2016-12-08 4500 Beedie St Burnaby BC Canada V5J 5L2 [email protected]
Page 7 www.algosolutions.com
producto se instala fuera del perímetro del edificio o se utiliza en una
aplicación en varios edificios, las conexiones cableadas se deben proteger
contra sobretensión o corriente transitoria. Algo recomienda que la
instalación de este producto la realice un electricista calificado.
Si usted no puede comprender la información de seguridad en inglés,
comuníquese con Algo por correo electrónico para obtener asistencia antes
de intentar instalarlo: [e-mail].
Wichtige Sicherheitsinformationen
Dieses Produkt wird durch eine zertifizierte Stromquelle mit begrenzter
Leistung (LPS –Limited Power Source) betrieben. Die Stromversorgung
erfolgt über Ethernet (PoE –Power over Ethernet). Dies geschieht durch
eine Cat-5-Verbindung oder eine Cat-6-Verbindung zu einer IEEE 802.3af-
konformen Ethernet-Netzwerkweiche. Das Produkt wurde konzipiert für die
Installation innerhalb eines Gebäudes oder außerhalb eines Gebäudes. Bei
der Anwendung außerhalb eines Gebäudes müssen zusätzliche
Schutzmaßnahmen gemäß der Gebrauchsanweisung durchgeführt werden.
Alle Kabelverbindungen zum Produkt müssen im selben Gebäude bestehen.
Wenn das Produkt jenseits des Gebäudes oder für mehrere Gebäude
genutzt wird, müssen die Kabelverbindungen vor Überspannung und
Spannungssprüngen geschützt werden. Algo empfiehlt das Produkt von
einem qualifizierten Elektriker installieren zu lassenv.
Sollten Sie die englischen Sicherheitsinformationen nicht verstehen,
kontaktieren Sie bitte Algo per Email bevor Sie mit der Installation
beginnen, um Unterstützung zu erhalten. Algo kann unter der folgenden E-
Mail-Adresse erreicht werden: [e-mail].
安全须知
本产品由认证的受限电源（LPS），以太网供电（PoE），通过CAT5或CAT6线路联接
至IEEE 802.3af兼容的PoE网络交换机供电。本产品适用于室内或建筑物周边安装。如
用于室外环境，必须按照安装手册采用附加的保护措施。所有联接本产品的线路必须源
自同一建筑物。本产品如需用于超出建筑物周边范围或跨建筑物的安装，线路联接部分
必须有过压和瞬态保护。Algo建议本产品由专业电工安装。
如果您对理解英文版安全须知有问题，安装前请通过电子邮件和Algo联系，
[e-mail]。

8186 SIP Horn Speaker
Document 90-00079 Algo Communication Products Ltd [phone]
2016-12-08 4500 Beedie St Burnaby BC Canada V5J 5L2 [email protected]
Page 8 www.algosolutions.com
Important Safety Information
CAUTION
The 8186 Horn Speaker is capable of output levels in excess of 120dB
at 1 meter. Ensure nobody is in close proximity to the horn, especially
during installation and testing of the product.
INSTALLATION
The 8186 Horn Speaker should only be installed by a qualified
electrician. An improperly installed 8186 could fall from the wall or
ceiling and cause serious injury or death.
Local building codes may require one or more additional safety
measures, particularly in earthquake prone regions.
EMERGENCY COMMUNICATION
If used in an emergency communication application, the 8186 Horn
Speaker should be routinely tested. SNMP supervision is recommended
for assurance of proper operation. Contact Algo for other methods of
operational assurance including the use of the integrated microphone
for automated “sound to air” acoustic testing.
WET OR OUTDOOR ENVIRONMENTS
The 8186 Horn Speaker is intended for indoor or outdoor locations and
may be subjected to spray or weather provided the rear wiring cavity
is properly sealed to prevent water ingress.
Gaskets included with the 8186 Horn Speaker may be effective against
water ingress on some, but not all surfaces in which case additional
protective measures must be taken such as a perimeter sealant.
CAT5 or CAT6 connection wiring to an IEEE 802.3af compliant
network PoE switch must not leave the building perimeter
without adequate lightning protection.
Relay input and output connections must not leave the building
perimeter without adequate lightning protection.

8186 SIP Horn Speaker
Document 90-00079 Algo Communication Products Ltd [phone]
2016-12-08 4500 Beedie St Burnaby BC Canada V5J 5L2 [email protected]
Page 9 www.algosolutions.com
About the Algo 8186 SIP Horn Speaker
The 8186 SIP Horn Speaker is a SIP compliant and multicast capable
IP speaker suitable for voice paging, loud ringing, and
alert/notification applications, particularly wide-area and/or high
noise environments (e.g. warehouse, factory). When installed
properly, the 8186 can be used for outdoor applications.
An integrated microphone provides talkback capability and ambient
noise detection for automatic level control.
Dual SIP extensions provide both voice paging and notification (ring)
capability. One or both extensions can be registered with any
Communication Server (hosted or enterprise) that supports 3rd party
SIP Endpoints.
Multiple speakers in a SIP environment require only one speaker to
register as a SIP extension. Multicasting capabilities allow the SIP
registered speaker to ring/page and simultaneously stream multicast
audio to the other speakers. Any number and variety of Algo
speakers, paging adapters, and strobes can be configured in a
multicast.
The 8186 SIP Horn Speaker is configured using central provisioning
features or by accessing a web interface using browsers such as
Google Chrome, Firefox, or Internet Explorer.
What is Included
8186 SIP Horn Speaker
Mounting bracket
Gaskets
What is not Included
Optional Call Button/Wall Switch (Algo 1202 or 1203)
This Installation Guide (www.algosolutions.com/8186/guide)

8186 SIP Horn Speaker
Document 90-00079 Algo Communication Products Ltd [phone]
2016-12-08 4500 Beedie St Burnaby BC Canada V5J 5L2 [email protected]
Page 10 www.algosolutions.com
Getting Started - Quick Install & Test
This guide provides important safety information which should be
read thoroughly before permanently installing the speaker.
1. Connect the 8186 SIP Horn Speaker to an IEEE 802.3af compliant
PoE network switch. The blue LED will remain on until boot up is
completed –about 30 seconds.
2. After the blue light turns off, connect the reset terminals on the
back of the unit to hear the IP address over the speaker. The IP
address may also be discovered by downloading the Algo locator tool
to find Algo devices on your network: www.algosolutions.com/locator
3. Mount the speaker per the instructions in this guide.
4. Access the 8186 SIP Horn Speaker web page by entering the IP
address into a browser (Chrome, IE, Firefox etc.) and login using the
default password algo.
5. Enter the IP address for the SIP server into the SIP Domain field
under the BASIC SETTINGS > SIP tab.
6. Enter the page SIP extension and password. (Note the speaker
supports two types of SIP extensions. The page extension auto-
answers for voice page announcements. The ring extension plays an
audio WAV file over the speaker without answering.)
7. Make a call to the speaker by dialling the page SIP extension from a
telephone. The speaker should auto-answer, play the default pre-
announce audio file, and open a speech path.

8186 SIP Horn Speaker
Document 90-00079 Algo Communication Products Ltd [phone]
2016-12-08 4500 Beedie St Burnaby BC Canada V5J 5L2 [email protected]
Page 11 www.algosolutions.com
Installation & Mounting
The 8186 SIP Horn Speaker can be wall or ceiling mounted.
Concealed wiring may enter from the wall into the wiring cavity.
Alternatively, surface wiring may enter through a channel from the
bottom edge. The channel is intended for cabling 0.2" or 5mm in
diameter and is intentionally snug to protect against moisture
ingress.
The 8186 SIP Horn Speaker can be mounted in any orientation but
both the bracket and housing identify TOP. This keeps the bracket
wiring channel on the bottom and the RJ45 jack on the top side.
The mounting plate may be used to mount over flush or surface
mounted electrical boxes or mud rings and fits securely to a 2 gang
electrical box for installation with wiring conduit.
The 8186 SIP Horn Speaker is rated IP65 for wet locations however
care must be taken to ensure that water does not enter the wiring
cavity. The supplied gaskets or sealant must be used to protect the
wiring cavity in wet environments. In dry indoor environments the
gaskets are not required. If the wall gasket is used with surface
wiring then the gasket should be attached after placing the cable into
the wiring channel.
The 8186 SIP Horn Speaker should not be installed beyond a building
perimeter without adequately protecting the building wiring from
lightning surges.

8186 SIP Horn Speaker
Document 90-00079 Algo Communication Products Ltd [phone]
2016-12-08 4500 Beedie St Burnaby BC Canada V5J 5L2 [email protected]
Page 12 www.algosolutions.com
Web Interface
The 8186 SIP Horn Speaker is configurable using the web interface or
provisioning features.
After boot up the blue light will turn off and the speaker will have
obtained an IP address. If there is no DHCP server the 8186 SIP Horn
Speaker will default to the static IP address 192.168.1.111.
Connect and hold the reset terminals (on the back of the unit) to
hear the IP address over the speaker. The reset terminals will not
cause a reset unless connected during power up.
The IP address may also be discovered by downloading the Algo
locator tool to find Algo devices on your network:
www.algosolutions.com/locator
Enter the IP address (e.g. 192.168.1.111) into a browser such as
Google Chrome, Firefox, or Internet Explorer (other than IE9). The
web interface should be visible and the default password will be algo
in lower case letters.

8186 SIP Horn Speaker
Document 90-00079 Algo Communication Products Ltd [phone]
2016-12-08 4500 Beedie St Burnaby BC Canada V5J 5L2 [email protected]
Page 13 www.algosolutions.com
SIP Paging: One Speaker
The 8186 SIP Horn Speaker can be registered as a third party SIP
extension with a hosted or enterprise Communications Server
supporting 3rd party SIP endpoints.
To register the speaker with the SIP server, use the Basic Settings 
SIP tab in the web interface to enter the Communication Server IP
address, extension, username, and password. This information will be
available from the IT Administrator.
If VLAN is used, navigate to the Advanced Settings Network tab
to set VLAN options.
(Note, once the speaker is using VLAN you will need to be on the same
VLAN to access the web interface.)
The speaker may now be accessed by dialling its assigned extension
from a telephone, device, or client. The speaker will auto-answer, play
the default WAV pre-announce tone, and allow voice paging until
disconnected.
There are a number of configurable speaker options:
Increase or Decrease Speaker Volume
Enable AGC (automatic gain control)
Enable Ambient Noise Monitoring (speaker volume adapts to
background noise)
Enable Talkback
Customize pre-announce tone WAV file
The best voice paging quality and intelligibility will be obtained using
the G.722 wideband audio codec. Most current IP telephones support
G.722 which is sometimes referred to as “HD” voice or audio.

8186 SIP Horn Speaker
Document 90-00079 Algo Communication Products Ltd [phone]
2016-12-08 4500 Beedie St Burnaby BC Canada V5J 5L2 [email protected]
Page 14 www.algosolutions.com
SIP Paging: Multiple Speakers (Using
Multicast)
Multicast features in the 8186 SIP Horn Speaker require that only
ONE of the speakers be registered as a SIP extension. Additional
speakers may be added as multicast Slaves receiving a stream from
the SIP registered Master speaker. Please note that any number and
combination of Algo speakers, paging adapters and strobes can be
part of a multicast.
The Master speaker will page normally while simultaneously
streaming audio to the Slave speakers. The Slave speakers do not
require SIP extensions and do not need to register with the SIP
Communication Server.
To enable multicast streaming from the SIP speaker, go to its web
interface and navigate to the Basic Settings Multicast tab.
Choose multicast mode “Master/Sender” and zone “All Call”. The
multicast addresses pre-populated in the table will work in most
cases.
To enable multicast monitoring in the other speakers, go to the web
interface for each speaker and again navigate to the Basic Settings
Multicast tab. This time though, choose multicast mode
“Slave/Receiver”. There is no need to select a zone as the speaker
will automatically monitor the “All Call”zone IP address.
The page pre-announce tone is generated from the Master. The
following options are valid for each multicast Slave speaker:
Increase or Decrease Speaker Volume
Enable Ambient Noise Monitoring (speaker volume adapts to
background noise)
Talkback can only be used for the SIP registered Master speaker.
When paging with talkback enabled, only the area near the Master
speaker is covered for talkback. The microphones in the
multicast/Slave speakers are disabled except for ambient noise
monitoring.

8186 SIP Horn Speaker
Document 90-00079 Algo Communication Products Ltd [phone]
2016-12-08 4500 Beedie St Burnaby BC Canada V5J 5L2 [email protected]
Page 15 www.algosolutions.com
SIP Paging: Multiple Speakers (Using
Individual SIP extensions)
In some cases it may be desirable for every speaker to have a SIP
extension. Multicast may still be used to page multiple speakers but
each speaker can also be called individually or generate a call when
appropriately configured.
A speaker configured as a SIP Multicast Slave will give its highest
priority to a page using its SIP extension.
Communication Servers with the capability of dialling many SIP
extensions simultaneously for paging may be able to create zones by
calling “page groups”in order to page telephone speakers in
conjunction with overhead speakers.

8186 SIP Horn Speaker
Document 90-00079 Algo Communication Products Ltd [phone]
2016-12-08 4500 Beedie St Burnaby BC Canada V5J 5L2 [email protected]
Page 16 www.algosolutions.com
Multicast Page Zones
The 8186 SIP Horn Speaker supports nine “basic” multicast zones.
zones are defined by the multicast IP addresses.
Somewhat arbitrarily, these zones are defined below but may be
used in other ways. The important consideration is that there is a
priority hierarchy –streaming activity on a zone higher on the list will
be treated as a higher priority than a zone lower on the list –with
music being the lowest priority.
Priority
All Call
Zone 1
Zone 2
Zone 3
Zone 4
Zone 5
Zone 6
Music
There are two options for Paging to multiple zones: “DTMF Selectable
Mode” or via multiple page extensions.
The “DTMF Selectable Mode” offers a dynamic page zone selection
and requires only the master device to have a registered SIP
Extension. To page, dial the SIP extension of the master device and
then dial the desired DTMF page zone (e.g. 1, 2, etc.) on the keypad.
Note: DTMF codes for zones 10 and higher start with an “*”.

8186 SIP Horn Speaker
Document 90-00079 Algo Communication Products Ltd [phone]
2016-12-08 4500 Beedie St Burnaby BC Canada V5J 5L2 [email protected]
Page 17 www.algosolutions.com
Alternatively, multiple SIP extensions can be registered on the
master device. Each extension is mapped to a unique zone, allowing
zones to be called directly (for instance from speed-dial keys)
without the use of DTMF. See “Additional Features > More Page
Extensions”.
“Expanded” zones can also be enabled in the “Basic Settings >
Multicast” tab, allowing up to 50 zones in total. These have the same
behaviours as the basic zones, but are hidden by default to simplify
the interface.
PolycomTM Group Paging
The 8186 SIP Horn Speaker has been designed to support Polycom
Group Paging.
The 8186 SIP Horn Speaker can be added to a Polycom Group Page
so that voice paging is heard over Polycom telephone speakers and
overhead paging simultaneously.
Polycom Group Paging can be configured on the Basic Settings 
Multicast tab.
The 8186 SIP Horn Speaker may be accessed remotely via SIP and
may generate a multicast page within the LAN sending voice page to
both Algo paging speakers and Polycom telephones. Audio delay may
be added to the 8186 SIP Horn Speaker to synchronize with voice
page over the Polycom telephone speakers.

8186 SIP Horn Speaker
Document 90-00079 Algo Communication Products Ltd [phone]
2016-12-08 4500 Beedie St Burnaby BC Canada V5J 5L2 [email protected]
Page 18 www.algosolutions.com
SIP Ring Event
Set Monitoring Mode to "Monitor Ring". When a call is made to the
SIP extension the 8186 SIP Horn Speaker will play the selected WAV
file from memory. Often, the 8186 SIP Horn Speaker will be part of a
hunt group or ring group to ring in conjunction with a telephone.
SIP Activated Notification Alerts
In addition to voice paging, the 8186 SIP Horn Speaker can play
audio files for emergency, safety, and security announcements,
customer service, shift changes, etc.
Audio WAV files can be stored in speaker memory and played over
the speaker in response to ring or input relay, and also multicast to
other Algo SIP endpoints on the network. See “Additional Features >
Emergency Alerts” and “Additional Features > Input/Output” for more
details.
Wiring Connections
Connecting Input Devices to 8186
The input relay to the 8186 SIP Horn
Speaker can be prompted by any normally
open or normally closed switch, as well as
the Algo 1202 Call Button or Algo 1203 Call
Switch. The input switches can be
connected to the back of the 8186 SIP Horn
Speaker via a Terminal Block Relay In.

8186 SIP Horn Speaker
Document 90-00079 Algo Communication Products Ltd [phone]
2016-12-08 4500 Beedie St Burnaby BC Canada V5J 5L2 [email protected]
Page 19 www.algosolutions.com
1202 Call Button: A pair of wires from the
terminal block on the back of the 8186 SIP Horn
Speaker can connect to the centre pair of the
modular connector at the back of the Call
Button.
1203 Call Switch: A pair of wires can be run from
the back of the device via a screw output
connector to the 8186 SIP Horn Speaker via the
Relay In.
Network Connection
Connect RJ45 jack from PoE network switch or non-PoE network
and 48V 350 mA IEEE 802.3af compliant power injector.
There are two lights on the Ethernet jack:
Green light: On when Ethernet is working, flickers off to indicate
activity on the port.
Amber light: Off when successful 100Mbps link is established.
Typically on only briefly at power up.
Under normal conditions, the Amber light will turn on immediately
after the Ethernet cable is first connected. This indicates that PoE
power has been successfully applied. Once the device connects to the
network, it will switch to the Green light instead, which will typically
flicker indicating traffic on the network.

8186 SIP Horn Speaker
Document 90-00079 Algo Communication Products Ltd [phone]
2016-12-08 4500 Beedie St Burnaby BC Canada V5J 5L2 [email protected]
Page 20 www.algosolutions.com
Terminal Block Relay In
By default, these terminals are inactive. Connection options are a
normally closed switch, normally open switch, 1202 Call Button, 1203
Call Switch, or EOL resistor termination.
Terminal Block Relay Out
By default these terminals provide a contact closure when the 8186
SIP Horn Speaker is active.
Terminal Block Reset
A terminal block reset on the back of the unit can only be used to
reset the 8186 SIP Horn Speaker at time of power up. To reset,
reboot or power cycle the 8186 SIP Horn Speaker. Wait until the
blue LED flashes, then connect the reset terminals and hold until
the blue LED begins a double flash pattern. Release the reset
connection and allow the unit to complete its boot process. Do not
connect the reset terminals until the blue LED begins
flashing.
A reset will set all configuration options to factory default including
the password.
Once booting has completed, connecting the reset terminals will
cause the speaker to annunciate its IP address over the speaker.
Blue LED Indicator
The blue LED by default will be on when the speaker is active. The
blue LED will also be on during power up and boot process.
The blue LED can also provide a heartbeat with a flash every 60
seconds to indicate that the speaker is powered and connected to the
network.
If the 8186 SIP Horn Speaker is in talkback mode the blue LED will
be flashing.
