Part 1: AC7A035 Core Board Introduction
AC7A035 (core board model, the same below) FPGA core board, it is
based on XILINX's ARTIX-7 series 35T XC7A35T-2FGG484I. It is a
high-performance core board with high speed, high bandwidth and high
capacity. It is suitable for high-speed data communication, video image
processing, high-speed data acquisition etc.
This AC7A200 core board uses two pieces of MICRON's
MT41J256M16HA-125 DDR3 chip, each DDR has a capacity of 4Gbit; two
DDR chips are combined into a 32-bit data bus width, and the read/write data
bandwidth between FPGA and DDR3 is up to 25Gb; such a configuration can
meet the needs of high bandwidth data processing.
The AC7A035 core board expands 146 standard IO ports of 3.3V level, 15
standard IO ports of 1.5V level, and 4 pairs of GTP high speed RX/TX
differential signals. For users who need a lot of IO, this core board will be a
good choice. Moreover, the routing between the FPGA chip and the interface is
equal length and differential processing, and the core board size is only 2.36
inch *2.36 inch, which is very suitable for secondary development.

ARTIX-7 FPGA Development Board AC7A035 User Manual
5 / 29
www.alinx.com
Figure 1-1: AC7A035 Core Board (Front View)
Figure 1-2: AC7A035 Core Board (Rear View)

ARTIX-7 FPGA Development Board AC7A035 User Manual
6 / 29
www.alinx.com
Part 2: FPGA Chip
As mentioned above, the FPGA model we use is XC7A35T-2FGG484I,
which belongs to Xilinx's Artix-7 series. The speed grade is 2, and the
temperature grade is industry grade. This model is a FGG484 package with
484 pins. Xilinx ARTIX-7 FPGAchip naming rules as below
Figure 2-1: The Specific Chip Model Definition of ARTIX-7 Series
Figure 2-2: FPGA chip on board
The main parameters of the FPGA chip XC7A35T are as follows
Name
Specific parameters
Logic Cells
33,280
Slices
5,200

ARTIX-7 FPGA Development Board AC7A035 User Manual
7 / 29
www.alinx.com
CLB flip-flops
41,600
Block RAM（kb）
1,800
DSP Slices
90
PCIe Gen2
1
XADC
1 XADC, 12bit, 1Mbps AD
GTP Transceiver
4 GTP, 6.6Gb/s max
Speed Grade
-1
Temperature Grade
Industrial
FPGA power supply system
Artix-7 FPGA power supplies are VCCINT, VCCBRAM, VCCAUX, VCCO, VMGTAVCC and
VMGTAVTT. VCCINT is the FPGAcore power supply pin, which needs to be connected
to 1.0V; VCCBRAM is the power supply pin of FPGA Block RAM, connect to 1.0V;
VCCAUX is FPGA auxiliary power supply pin, connect 1.8V; VCCO is the voltage of
each BANK of FPGA, including BANK0, BANK13~16, BANK34~35. On
AC7A035 FPGA core board, BANK34 and BANK35 need to be connected to
DDR3, the voltage connection of BANK is 1.5V, and the voltage of other BANK
is 3.3V. The VCCO of BANK15 and BANK16 is powered by the LDO, and can be
changed by replacing the LDO chip. VMGTAVCC is the supply voltage of the FPGA
internal GTP transceiver, connected to 1.0V; VMGTAVTT is the termination voltage
of the GTP transceiver, connected to 1.2V.
The Artix-7 FPGA system requires that the power-up sequence be power
by VCCINT, then VCCBRAM, then VCCAUX, and finally VCCO. If VCCINT and VCCBRAM have the
same voltage, they can be powered up at the same time. The order of power
outages is reversed. The power-up sequence of the GTP transceiver is VCCINT,
then VMGTAVCC, then VMGTAVTT. If VCCINT and VMGTAVCC have the same voltage, they
can be powered up at the same time. The power-off sequence is just the
opposite of the power-on sequence.

ARTIX-7 FPGA Development Board AC7A035 User Manual
8 / 29
www.alinx.com
Part 3: Active Differential Crystal
The AC7A035 core board is equipped with two Sitime active differential
crystals, one is 200MHz, the model is SiT9102-200.00MHz, the system main
clock for FPGAand used to generate DDR3 control clock; the other is 125MHz,
model is SiT9102 -125MHz, reference clock input for GTP transceivers.
Part 3.1: 200Mhz Active Differential clock
G1 in Figure 3-1 is the 200M active differential crystal that provides the
development board system clock source. The crystal output is connected to the
BANK34 global clock pin MRCC (R4 and T4) of the FPGA. This 200Mhz
differential clock can be used to drive the user logic in the FPGA. Users can
configure the PLLs and DCMs inside the FPGA to generate clocks of different
frequencies.
Figure 3-1: 200Mhz Active Differential Crystal Schematic
Figure 3-2: 200Mhz Active Differential Crystal on the Core Board

ARTIX-7 FPGA Development Board AC7A035 User Manual
9 / 29
www.alinx.com
200Mhz Differential Clock Pin Assignment
Signal Name
FPGA PIN
SYS_CLK_P
R4
SYS_CLK_N
T4
Part 3.2: 125MHz Active Differential Crystal
G2 in Figure 3-3 is the 125MHz active differential crystal, which is the
reference input clock provided to the GTP module inside the FPGA. The crystal
output is connected to the GTP BANK216 clock pins MGTREFCLK0P (F6) and
MGTREFCLK0N (E6) of the FPGA.
Figure 3-3: 125MHz Active Differential Crystal Schematic
Figure 3-4: 125MHz Active Differential Crystal on the Core Board

ARTIX-7 FPGA Development Board AC7A035 User Manual
10 / 29
www.alinx.com
125MHz Differential Clock Pin Assignment
Net Name
FPGA PIN
MGT_CLK0_P
F6
MGT_CLK0_N
E6
Part 4: DDR3 DRAM
The FPGA core board AC7A035 is equipped with two Micron 4Gbit
(512MB) DDR3 chips (8Gbit in totally), model is MT41J256M16HA-125
(compatible with MT41K256M16HA-125). The DDR3 SDRAM has a maximum
operating speed of 400MHz (data rate 800Mbps). The DDR3 memory system
is directly connected to the memory interface of the BANK 34 and BANK35 of
the FPGA. The specific configuration of DDR3 SDRAM is shown in Table 4-1.
Bit Number
Chip Model
Capacity
Factory
U5,U6
MT41J256M16HA-125
256M x 16bit
Micron
Table 4-1: DDR3 SDRAM Configuration
The hardware design of DDR3 requires strict consideration of signal
integrity. We have fully considered the matching resistor/terminal resistance,
trace impedance control, and trace length control in circuit design and PCB
design to ensure high-speed and stable operation of DDR3. Figure 4-1 details
the hardware connection of DDR3 DRAM

ARTIX-7 FPGA Development Board AC7A035 User Manual
11 / 29
www.alinx.com
FPGA
DDR3
(MT41J256M16
HA)
Data[31:16]
U5
U1
BANK
34/35
DDR3
(MT41J256M16
HA)
U6
Data[15:0]
Addr/control
Figure 4-1: The DDR3 DRAM Schematic
Figure 4-2: The DDR3 on the Core Board
DDR3 DRAM pin assignment:
Net Name
FPGA PIN Name
FPGA P/N
DDR3_DQS0_P
IO_L3P_T0_DQS_AD5P_35
E1
DDR3_DQS0_N
IO_L3N_T0_DQS_AD5N_35
D1
DDR3_DQS1_P
IO_L9P_T1_DQS_AD7P_35
K2

ARTIX-7 FPGA Development Board AC7A035 User Manual
12 / 29
www.alinx.com
DDR3_DQS1_N
IO_L9N_T1_DQS_AD7N_35
J2
DDR3_DQS2_P
IO_L15P_T2_DQS_35
M1
DDR3_DQS2_N
IO_L15N_T2_DQS_35
L1
DDR3_DQS3_P
IO_L21P_T3_DQS_35
P5
DDR3_DQS3_N
IO_L21N_T3_DQS_35
P4
DDR3_DQ[0]
IO_L2P_T0_AD12P_35
C2
DDR3_DQ [1]
IO_L5P_T0_AD13P_35
G1
DDR3_DQ [2]
IO_L1N_T0_AD4N_35
A1
DDR3_DQ [3]
IO_L6P_T0_35
F3
DDR3_DQ [4]
IO_L2N_T0_AD12N_35
B2
DDR3_DQ [5]
IO_L5N_T0_AD13N_35
F1
DDR3_DQ [6]
IO_L1P_T0_AD4P_35
B1
DDR3_DQ [7]
IO_L4P_T0_35
E2
DDR3_DQ [8]
IO_L11P_T1_SRCC_35
H3
DDR3_DQ [9]
IO_L11N_T1_SRCC_35
G3
DDR3_DQ [10]
IO_L8P_T1_AD14P_35
H2
DDR3_DQ [11]
IO_L10N_T1_AD15N_35
H5
DDR3_DQ [12]
IO_L7N_T1_AD6N_35
J1
DDR3_DQ [13]
IO_L10P_T1_AD15P_35
J5
DDR3_DQ [14]
IO_L7P_T1_AD6P_35
K1
DDR3_DQ [15]
IO_L12P_T1_MRCC_35
H4
DDR3_DQ [16]
IO_L18N_T2_35
L4
DDR3_DQ [17]
IO_L16P_T2_35
M3
DDR3_DQ [18]
IO_L14P_T2_SRCC_35
L3
DDR3_DQ [19]
IO_L17N_T2_35
J6
DDR3_DQ [20]
IO_L14N_T2_SRCC_35
K3
DDR3_DQ [21]
IO_L17P_T2_35
K6
DDR3_DQ [22]
IO_L13N_T2_MRCC_35
J4
DDR3_DQ [23]
IO_L18P_T2_35
L5
DDR3_DQ [24]
IO_L20N_T3_35
P1
DDR3_DQ [25]
IO_L19P_T3_35
N4
DDR3_DQ [26]
IO_L20P_T3_35
R1
DDR3_DQ [27]
IO_L22N_T3_35
N2
DDR3_DQ [28]
IO_L23P_T3_35
M6
DDR3_DQ [29]
IO_L24N_T3_35
N5
DDR3_DQ [30]
IO_L24P_T3_35
P6

ARTIX-7 FPGA Development Board AC7A035 User Manual
13 / 29
www.alinx.com
DDR3_DQ [31]
IO_L22P_T3_35
P2
DDR3_DM0
IO_L4N_T0_35
D2
DDR3_DM1
IO_L8N_T1_AD14N_35
G2
DDR3_DM2
IO_L16N_T2_35
M2
DDR3_DM3
IO_L23N_T3_35
M5
DDR3_A[0]
IO_L11N_T1_SRCC_34
AA4
DDR3_A[1]
IO_L8N_T1_34
AB2
DDR3_A[2]
IO_L10P_T1_34
AA5
DDR3_A[3]
IO_L10N_T1_34
AB5
DDR3_A[4]
IO_L7N_T1_34
AB1
DDR3_A[5]
IO_L6P_T0_34
U3
DDR3_A[6]
IO_L5P_T0_34
W1
DDR3_A[7]
IO_L1P_T0_34
T1
DDR3_A[8]
IO_L2N_T0_34
V2
DDR3_A[9]
IO_L2P_T0_34
U2
DDR3_A[10]
IO_L5N_T0_34
Y1
DDR3_A[11]
IO_L4P_T0_34
W2
DDR3_A[12]
IO_L4N_T0_34
Y2
DDR3_A[13]
IO_L1N_T0_34
U1
DDR3_A[14]
IO_L6N_T0_VREF_34
V3
DDR3_BA[0]
IO_L9N_T1_DQS_34
AA3
DDR3_BA[1]
IO_L9P_T1_DQS_34
Y3
DDR3_BA[2]
IO_L11P_T1_SRCC_34
Y4
DDR3_S0
IO_L8P_T1_34
AB3
DDR3_RAS
IO_L12P_T1_MRCC_34
V4
DDR3_CAS
IO_L12N_T1_MRCC_34
W4
DDR3_WE
IO_L7P_T1_34
AA1
DDR3_ODT
IO_L14N_T2_SRCC_34
U5
DDR3_RESET
IO_L15P_T2_DQS_34
W6
DDR3_CLK_P
IO_L3P_T0_DQS_34
R3
DDR3_CLK_N
IO_L3N_T0_DQS_34
R2
DDR3_CKE
IO_L14P_T2_SRCC_34
T5
Part 5: QSPI Flash
The FPGA core board AC7A035 is equipped with one 128Mbit QSPI

ARTIX-7 FPGA Development Board AC7A035 User Manual
14 / 29
www.alinx.com
FLASH, and the model is N25Q128, which uses the 3.3V CMOS voltage
standard. Due to the non-volatile nature of QSPI FLASH, it can be used as a
boot device for the system to store the boot image of the system. These
images mainly include FPGA bit files, ARM application code, soft core
application code and other user data files. The specific models and related
parameters of SPI FLASH are shown in Table 5-1.
Position
Model
Capacity
Factory
U8
N25Q128
128M Bit
Numonyx
Table 5-1: QSPI FLASH Specification
QSPI FLASH is connected to the dedicated pins of BANK0 and BANK14 of
the FPGAchip. The clock pin is connected to CCLK0 of BANK0, and other data
and chip select signals are connected to D00~D03 and FCS pins of BANK14
respectively. Figure 5-1 shows the hardware connection of QSPI Flash.
Figure 5-1: QSPI Flash Schematic

ARTIX-7 FPGA Development Board AC7A035 User Manual
15 / 29
www.alinx.com
QSPI Flash pin assignments:
Net Name
FPGA PIN Name
FPGA P/N
QSPI_CLK
CCLK_0
L12
QSPI_CS
IO_L6P_T0_FCS_B_14
T19
QSPI_DQ0
IO_L1P_T0_D00_MOSI_14
P22
QSPI_DQ1
IO_L1N_T0_D01_DIN_14
R22
QSPI_DQ2
IO_L2P_T0_D02_14
P21
QSPI_DQ3
IO_L2N_T0_D03_14
R21
Figure 5-2: QSPI FLASH on the Core Board
Part 6: LED Light on Core Board
There are 3 red LED lights on the AC7A200 FPGA core board, one of
which is the power indicator light (PWR), one is the configuration LED light
(DONE), and one is the user LED light. When the core board is powered, the
power indicator will illuminate; when the FPGA is configured, the configuration
LED will illuminate. The user LED light is connected to the IO of the BANK34,
the user can control the light on and off by the program. When the IO voltage
connected to the user LED is high, the user LED is illuminate. When the
connection IO voltage is low, the user LED will be extinguished. The schematic
diagram of the LED light hardware connection is shown in Figure 6-1:

ARTIX-7 FPGA Development Board AC7A035 User Manual
16 / 29
www.alinx.com
Figure 6-1: LED lights on the Core Board Schematic
Figure 6-2: LED lights on the Core Board

ARTIX-7 FPGA Development Board AC7A035 User Manual
17 / 29
www.alinx.com
User LEDs Pin Assignment
Part 7: JTAG Interface
The JTAG test socket J1 is reserved on the AC7A200 core board for JTAG
download and debugging when the core board is used alone. Figure 7-1 is the
schematic part of the JTAG port, which involves TMS, TDI, TDO, TCK. , GND,
+3.3V these six signals.
Figure 7-1: JTAG Interface Schematic
The JTAG interface J1 on AC7A200 FPGA core board uses a 6-pin
2.54mm pitch single-row test hole. If you need to use the JTAG connector to
debug on the core board, you need to solder a 6-pin single-row pin header.
Figure 7-2 shows the JTAG interface J1 on the AC7A200 FPGA core board.
Figure 7-2 JTAG Interface on Core Board
Signal Name
FPGA Pin Name
FPGA Pin Number
Description
LED1
IO_L15N_T2_DQS_34
W5
User LED

ARTIX-7 FPGA Development Board AC7A035 User Manual
18 / 29
www.alinx.com
Part 8: Power Interface on the Core Board
In order to make the AC7A200 FPGA core board work alone, the core
board is reserved 2-pin power supply interface J2. If the user wants to debug
the function of the core board separately (without the carrier board), the
external device needs to provide +5V to supply power to the core board.
Figure 8-1：Power Interface schematic on the Core Board
Figure 8-2：Power interface on the Core Board
Part 9: Board to Board Connectors pin assignment
The core board has a total of four high-speed board to board connectors.
The core board uses four 80-pin inter-board connecters to connect to the
carrier board. The IO port of the FPGA is connected to the four connecters by
differential routing. The pin spacing of the connectors is 0.5mm, insert to the
board to board connectors on the carrier board for high-speed data
communication.

ARTIX-7 FPGA Development Board AC7A035 User Manual
19 / 29
www.alinx.com
Board to Board Connectors CON1
The 80-pin board to board connectors CON1, which are used to connect
with the VCCIN power supply (+5V) and ground on the carrier board, extend
the normal IOs of the FPGA. It should be noted here that 15 pins of CON1 are
connected to the IO port of BANK34, because the BANK34 connection is
connected to DDR3. Therefore, the voltage standard of all IOs of this BANK34
is 1.5V. The IOs of BANK 13 is not existed in XC7A35T chipset, it is designed to
compatible with XC7A100T/XC7A200T chipset, please do not use these IO in
AC7A035 board.
Pin Assignment of Board to Board Connectors CON1
CON1
PIN
Net
Name
FPGA
PIN
Voltage
Level
CON1
PIN
Net
Name
FPGA
PIN
Voltage
Level
PIN1
VCCIN
-
+5V
PIN2
VCCIN
-
+5V
PIN3
VCCIN
-
+5V
PIN4
VCCIN
-
+5V
PIN5
VCCIN
-
+5V
PIN6
VCCIN
-
+5V
PIN7
VCCIN
-
+5V
PIN8
VCCIN
-
+5V
PIN9
GND
-
Ground
PIN10
GND
-
Ground
PIN11
NC
-
NC
PIN12
NC
-
NC
PIN13
NC
-
NC
PIN14
NC
-
NC
PIN15
NC
-
NC
PIN16
B13_L4_P
AA15
3.3V
PIN17
NC
-
NC
PIN18
B13_L4_N
AB15
3.3V
PIN19
GND
-
Ground
PIN20
GND
-
Ground
PIN21
B13_L5_P
Y13
3.3V
PIN22
B13_L1_P
Y16
3.3V
PIN23
B13_L5_N
AA14
3.3V
PIN24
B13_L1_N
AA16
3.3V
PIN25
B13_L7_P
AB11
3.3V
PIN26
B13_L2_P
AB16
3.3V
PIN27
B13_L7_P
AB12
3.3V
PIN28
B13_L2_N
AB17
3.3V
PIN29
GND
-
Ground
PIN30
GND
-
Ground
PIN31
B13_L3_P
AA13
3.3V
PIN32
B13_L6_P
W14
3.3V
PIN33
B13_L3_N
AB13
3.3V
PIN34
B13_L6_N
Y14
3.3V
PIN35
B34_L23_P
Y8
1.5V
PIN36
B34_L20_P
AB7
1.5V
PIN37
B34_L23_N
Y7
1.5V
PIN38
B34_L20_N
AB6
1.5V

ARTIX-7 FPGA Development Board AC7A035 User Manual
20 / 29
www.alinx.com
PIN39
GND
-
Ground
PIN40
GND
-
Ground
PIN41
B34_L18_N
AA6
1.5V
PIN42
B34_L21_N
V8
1.5V
PIN43
B34_L18_P
Y6
1.5V
PIN44
B34_L21_P
V9
1.5V
PIN45
B34_L19_P
V7
1.5V
PIN46
B34_L22_P
AA8
1.5V
PIN47
B34_L19_N
W7
1.5V
PIN48
B34_L22_N
AB8
1.5V
PIN49
GND
-
Ground
PIN50
GND
-
Ground
PIN51
XADC_VN
M9
Analog
PIN52
NC
PIN53
XADC_VP
L10
Analog
PIN54
B34_L25
U7
1.5V
PIN55
NC
-
NC
PIN56
B34_L24_P
W9
1.5V
PIN57
NC
-
NC
PIN58
B34_L24_N
Y9
1.5V
PIN59
GND
-
Ground
PIN60
GND
-
Ground
PIN61
B16_L1_N
F14
3.3V
PIN62
NC
-
NC
PIN63
B16_L1_P
F13
3.3V
PIN64
NC
-
NC
PIN65
B16_L4_N
E14
3.3V
PIN66
NC
-
NC
PIN67
B16_L4_P
E13
3.3V
PIN68
NC
-
NC
PIN69
GND
-
Ground
PIN70
GND
-
Ground
PIN71
B16_L6_N
D15
3.3V
PIN72
NC
-
NC
PIN73
B16_L6_P
D14
3.3V
PIN74
NC
-
NC
PIN75
B16_L8_P
C13
3.3V
PIN76
NC
-
NC
PIN77
B16_L8_N
B13
3.3V
PIN78
NC
-
NC
PIN79
NC
-
NC
PIN80
NC
-
NC
Figure 9-1: Board to Board Connectors CON1 on the Core Board
Board to Board Connectors CON2
The 80-pin female connection header CON2 is used to extend the normal
IO of the BANK13 and BANK14 of the FPGA. The voltage standards of both
