ALLEN & HEATH XONE:96 User manual

Production Method
Document Number
AH-M0833
Production Line
XONE
Product
XONE:96
Assembly Stage
Final Assembly
Title
XONE:96 Complete Assembly
Issue Date
05/06/2018
Revision No.
3
Page No.
1of 7
XONE:96
COMPLETE
ASSEMBLY

Production Method
Document Number
AH-M0833
Production Line
XONE
Product
XONE:96
Assembly Stage
Final Assembly
Title
XONE:96 Complete Assembly
Issue Date
05/06/2018
Revision No.
3
Page No.
2of 7
A. Equipment & Tools List:
Description
i.
Pozi 0 screwdriver
ii.
T8 Torx screwdriver
iii.
T10 Torx Screwdriver
B. Parts List:
(A&H P/N)
Description
Qty
a.
AH-M0830
XONE_96 base & rear sub-assembly
1
b.
AH-M0832
XONE_96 Top Panel sub-assembly
1
c.
AB8592
SCREW M3X5 TRUNC CSK TORX (ii)
16
d.
AB4393
SCREW 2.5X6 PAN POZI (i)
2
e.
AB7422
SCREW 2.7X9 AB TORX BK UH (ii)
8
f.
AH-M0828
XONE_96 front sub-assembly
1
g.
AN8362
Serial number label
1
h.
AN7014
ROHS (orange) label
1
i.
ECN4002
WFMA ORANGE EARTH LEAD 0.25m
1
j.
AL4396
PHONO SHORTING PLUG
8
C. Update Information Notes:
Step No.
Description
Reason
1
(NEW!)
Implementation of ECN4002
Add & connect 1 off 1 WFMA ORANGE EARTH LEAD 0.25m
ECN

Production Method
Document Number
AH-M0833
Production Line
XONE
Product
XONE:96
Assembly Stage
Final Assembly
Title
XONE:96 Complete Assembly
Issue Date
05/06/2018
Revision No.
3
Page No.
3of 7
D. Assembly Instructions:
1
Pick 1 WFMA ORANGE EARTH LEAD 0.25m [ECN4002] and connect the blade connector to the
Connector PCBA on the XONE_96 base & rear sub-assembly [REF: AH-M0830] and the female
connector to the Slave PCBA screw on XONE_96 Top Panel sub-assembly [REF: AH-M0832].
2
Turn the Top Panel sub-assembly onto the base & rear sub-assembly, connect the PCBA XONE:96
CONNECTOR Ribbon Cable to the PCBA XONE:96 SLAVE Connector and connect the PCBA
XONE:96 DUAL USB Ribbon Cable and Power Cable to the PCBA XONE:96 PSU & INLET
Connectors.

Production Method
Document Number
AH-M0833
Production Line
XONE
Product
XONE:96
Assembly Stage
Final Assembly
Title
XONE:96 Complete Assembly
Issue Date
05/06/2018
Revision No.
3
Page No.
4of 7
3
Secure the front panel with the base & rear panel with
4 off SCREW M3X5 TRUNC CSK TORX [AB8592], 2 off SCREW 2.5X6 PAN POZI [AB4393] and
8 off SCREW 2.7X9 AB TORX BK UH [AB7422].
4
Pick 1 off XONE_96 front sub-assembly [REF: AH-M0828], connect the PCBA XONE:96 CUE B
Ribbon Cable to the PCBA XONE:96 HEADPHONE connector, mount inside the base panel and
secure with 6 off SCREW M3X5 TRUNC CSK TORX [AB8592].

Production Method
Document Number
AH-M0833
Production Line
XONE
Product
XONE:96
Assembly Stage
Final Assembly
Title
XONE:96 Complete Assembly
Issue Date
05/06/2018
Revision No.
3
Page No.
5of 7
5
Secure the top panel to the rest of the unit with 6 off SCREW M3X5 TRUNC CSK TORX [AB8592].
THE PRODUCT IS NOW READY TO BE TESTED!

Production Method
Document Number
AH-M0833
Production Line
XONE
Product
XONE:96
Assembly Stage
Final Assembly
Title
XONE:96 Complete Assembly
Issue Date
05/06/2018
Revision No.
3
Page No.
6of 7
6
After the product has passed the test and ready for packing, pick 8 off PHONO PLUG SHORTING
GOLD [AL4396] and connect them on the Rear Panel’s PHONO RCAs.
7
Pick 1 off Serial number label [AN8362] and 1 off ROHS (orange) label [AN7014] and attach
them to the base of the unit as shown below.

Production Method
Document Number
AH-M0833
Production Line
XONE
Product
XONE:96
Assembly Stage
Final Assembly
Title
XONE:96 Complete Assembly
Issue Date
05/06/2018
Revision No.
3
Page No.
7of 7
8
Finally, before packing the unit make sure that all the KNOBS and FADERS are turned off or to the
minimum value as shown in the image below.
