Allergan REVOLVE System User manual

REVOLVE™System Components
REVOLVE™System Unit Parts
User Provided Components
Sterile barrier
inside box contains:
REVOLVE™
System
Vacuum
Connecon Tubing
Irrigaon Tubing
Elbow is removable
on this end
5. Lactated Ringer’s
Soluon
Handle
1. Liposucon Tube
2. Connect to
medical grade
vacuum source
with clamp.
3/8” post-use blue elbow
1/4” post-remove blue elbow
3. Waste Canister
REVOLVE™Canister
Vent Port
Vacuum Port
Paent Port
Luer Port
Handle
Waste
Canister
4. Catheter-p Syringe
or Luer Lock Syringe
Minimum ll:
100 ml
Maximum ll:
350 ml
Volume inside mesh
Disposable
Adapter
Temperature
Strip
REVOLVE
TM
SySTEM — MaTERiaLS
REVOLVETM
adVancEd adipOsE systEm

Connect to
medical grade
vacuum source.
Waste
Canister
Connecng Tube
Liposucon Tube
Luer
Port
Paent
Port
Step 1: Harvest
Step 3: Transfer – IMMEDIATELY aer Step 2
1. Leave REVOLVE™ System in tray.
2. Connect Vacuum Port to
Waste Canister with connecng tube.
3. Connect Liposucon Tube to
elbow (yellow) on Paent Port.
4. Hold device rmly to prevent pping.
5. Harvest ssue into REVOLVE™
System using liposucon. Minimum
harvest volume inside of mesh 100 ml.
L00-7037 Rev E
A. Catheter-p Syringe
(Recommended method of extracon.)
1. KEEP VENT PORT OPEN.
2. Insert Catheter-
p Syringe into
Paent Port.
3. Tilt Canister
toward syringe,
gently shake Canister
to slide ssue toward
syringe, then
extract ssue.
B. Luer Lock Syringe
1. Replace cap on Paent Port, open
Vent Port.
2. KEEP VENT PORT OPEN.
3. Aach Luer Lock
Syringe to Luer Port.
4. Tilt canister toward
Syringe, gently shake
Canister to slide
ssue toward syringe,
then extract ssue.
If a syringe becomes clogged during
extracon, push syringe plunger
toward Canister to release clog and
then connue to extract.
4. Transfer to Luer Lock Syringe
via disposable adapter.
Warning: Do not overghten luer connecons
Temperature Strip
Note: Temperature strips will provide a visual indicaon of the Lactated Ringer’s Soluon temperature aer it has been warmed to the appropriate temperature.
Do not apply the temperature strip before warming the soluon.
1. Remove liner from self-adhesive backing and ensure that the applicaon surface of the Lactated Ringer’s Soluon is clean and dry before applying.
2. Green indicates the temperature. If green is not visible, the temperature will be mid way between the illuminated blue and tan windows.
3. The temperature will only display if the Lactated Ringer’s Soluon is between 35°C-41°C.
1. Remove
Liposucon Tube
4.
4. Irrigaon Tubing
6.
3.
2.
7.
5.
37-39°C Lactated
Ringer’s Soluon.
Fluid must be warmed.
Step 2: Wash, Filter and Concentrate
1. Disconnect/clamp Liposucon Tube from Paent Port.
2. Disconnect Vacuum at Vacuum Port OR turn o sucon pump.
3. Open Vent Port. Leave open for the rest of the procedure.
4. Apply temperature strip to conrm Lactated Ringer’s Soluon is between 37-39 degrees.
Connect only warm (37-39°C) Lactated Ringer’s Soluon to Paent Port using
irrigaon tubing. MAINTAIN TEMPERATURE UP TO AND THROUGHOUT
WASHING PROCESS.
5. Fill Canister with approximately 300-350ml of warm (37-39°C)
Lactated Ringer’s Soluon.
6. Rotate handle quickly for at least 15 seconds.
7. Reconnect Vacuum to Vacuum Port OR turn on sucon
pump, and remove uid below mesh.
8. Repeat steps 5-7 two more mes.
9. Aer third wash, maintain vacuum for 60 seconds to remove all uids.
