Omron Comp Air Elite NE-C30-E User manual

Compressor Nebuliser
Model NE-C30-E
• Instruction Manual
• Mode d’emploi
• Gebrauchsanweisung
• Manuale di istruzioni
• Manual de instrucciones
• Gebruiksaanwijzing
• РУКОВОДСТВО ПО ЭКСПЛУАТАЦИИ
TM
3
5
IM-NE-C30-E-02-11/06
EN
FR
DE
IT
ES
NL
AR
RU
NE-C30.book Page 1 Monday, October 23, 2006 3:11 PM

2
Before using the unit
Contents
Before using the unit
Introduction ................................................................................................... 3
Important safety instructions....................................................................... 4
1. Know your unit........................................................................................ 8
2. Guide to using the Comp Air Elite....................................................... 10
Operating instructions
3. Preparing the nebuliser for use........................................................... 11
3.1 Connecting the AC adapter................................................................ 11
3.2 Adding medication and assembling the parts .................................... 12
4. Taking medication ................................................................................ 16
Care and maintenance
5. Cleaning and daily disinfecting ........................................................... 19
5.1 Cleaning............................................................................................. 19
5.2 Disinfecting the nebulising parts ........................................................ 20
6. Maintenance and storage..................................................................... 21
7. Changing the air filter........................................................................... 22
8. Troubleshooting.................................................................................... 23
9. Technical data ....................................................................................... 25
10. Optional parts and accessories........................................................... 29
11. Using optional accessories ................................................................. 31
11.1 Using the optional rechargeable battery ............................................ 31
NE-C30.book Page 2 Monday, October 23, 2006 3:11 PM

3
EN
Introduction
Thank you for purchasing the OMRON Comp Air Elite.
This product was developed in conjunction with respiratory therapists for the
successful treatment of asthma, chronic bronchitis, allergies and other respiratory
disorders. The compressor forces air to the nebuliser. When the air enters the
nebuliser, it converts the prescribed medication into an aerosol of microscopic
droplets that can easily be inhaled.
The Comp Air Elite is a medical device. Operate this device only as instructed by
your doctor and/or respiratory therapist.
NE-C30.book Page 3 Monday, October 23, 2006 3:11 PM

4
Important safety instructions
Read all the information in the instruction manual and any other literature included
in the box before using the device.
When using an electrical product, especially when children are present, basic
safety precautions should always be followed including the following:
Warning:
Indicates a potentially hazardous situation which, if not avoided, could result in
serious injury.
(Usage)
• For type, dose, and regime of medication follow the instructions of your doctor or
respiratory therapist.
• Do not use only water in the nebuliser, for nebulising purposes.
• Clean and disinfect the nebuliser kit, mouthpiece and optional nosepiece or
masks before using them for the first time after purchase, if the device has not
been used for a long period of time, or if more than one person uses the same
device.
• Be sure to wash the parts after use, and ensure that they are thoroughly
disinfected and dried, and stored in a clean location.
• Keep the device out of the reach of unsupervised infants and children. The
device may contain small pieces that can be swallowed.
• Store the device and accessories in a clean location.
• Do not store the air tube while there is moisture or medication remaining inside it.
• Always rinse the nebulising parts with clean hot tap water after disinfecting them.
Never leave the cleaning solution in the medication tank or mouthpiece.
• Do not use or store the device where it may be exposed to noxious fumes or
volatile substances.
• Do not use the device where it may be exposed to flammable gas.
• Make sure that the nebuliser kit is clean before use.
• Always dispose of any remaining medication after use, and use fresh medication
each time.
• Do not use in anaesthetic or ventilator breathing circuits.
(Risk of electrical shock)
• When using the optional rechargeable battery, always charge the battery fully
using the battery charger specially designed for this device. If the battery is
frequently used without being fully charged, the capacity of the battery will be
reduced and the device may stop during use. In this case have an alternative
power source, such as the AC adapter ready.
NE-C30.book Page 4 Monday, October 23, 2006 3:11 PM

5
Important safety instructions
EN
• Do not use the main unit, AC adapter, optional rechargeable battery, or optional
battery charger while they are wet, or connect them to a power outlet or other
devices with wet hands.
• The compressor, AC adapter, and optional rechargeable battery and charger are
not waterproof. Do not spill water, or other liquids, on these parts. If liquid does
spill on these parts, immediately unplug the power cord and wipe off the liquid
with gauze or other absorbent material.
• Do not immerse the main unit in water or other liquid.
• Do not use or store the device in humid locations, such as a bathroom.
• Do not short circuit the battery terminals on the rechargeable battery. Make sure
battery terminals do not come in contact with keys, coins or other metal objects.
• When using the carrying bag to carry the device and optional rechargeable
battery, do not place hair pins or other metal objects in the bag.
• Use only original OMRON AC adapter for AC power outlet. Use of unsupported
AC adapter may damage the device.
• Do not operate the unit with a damaged cord or plug.
• Keep the power cord away from heated surfaces.
Read and follow the “Important information regarding Electro Magnetic
Compatibility (EMC)” in the Technical Data Section.
Caution:
Indicates a potentially hazardous situation which if not avoided, may result in minor
or moderate injury, or physical damage.
(Usage)
• Provide close supervision when this device is used by, on, or near children or
invalids.
• Make sure that the parts are attached correctly.
• Make sure that the vaporiser head is correctly installed before use.
• Make sure that the air filter is correctly attached.
• Make sure that the air filter is clean. If the air filter has changed colour, or has
been used on average for more than 60 days, replace it with a new one.
• Do not spill liquid or medication on the compressor.
• Do not tilt the nebuliser kit so that it is at an angle of greater than 45°, or shake it
while in use.
• Do not use or store the device while the air tube is creased.
• Use only original nebulising parts, air tube, air filter and filter cover.
• Do not add more than 7 ml of medication to the medication tank.
• Do not carry or leave the nebuliser kit while the medication tank contains
medication.
NE-C30.book Page 5 Monday, October 23, 2006 3:11 PM

6
Important safety instructions
• Do not leave the unit unattended with infants or persons who cannot express
their consent.
• Do not subject the device or the parts to any strong shocks such as dropping the
device on the floor.
• Do not distort the vaporiser head, or jab the nozzle of the medication tank with a
pin etc.
• Do not cover the compressor, optional rechargeable battery and charger with a
blanket or towel etc., during use.
• Do not insert fingers or objects inside the compressor.
• Do not disassemble or attempt to repair the compressor, AC adapter, optional
rechargeable battery or charger.
• Do not leave the device or its parts where is will be exposed to extreme
temperatures or changes in humidity, such as in a vehicle during the summer, or
where it will be exposed to direct sunlight.
• Do not block the air filter cover.
• When sterilising parts by boiling, make sure that the container does not boil dry.
• Never place, or attempt to dry the compressor, AC adapter or nebulising parts in
a microwave oven.
• Do not use the device while sleeping or if drowsy.
• To avoid injury to the nose mucosa, do not squeeze the nosepiece into the back
of the nose.
• Do not block the slit between the cap and the inhalation air inlet.
• Do not use a microwave oven or hair dryer to dry the nebulising parts.
• Approved for human use only.
(Risk of electrical shock)
• Always unplug the AC adapter from the power outlet after use and before
cleaning.
• Plug the device into the appropriate voltage outlet. Do not overload power outlets
or use extension cords.
• Always read the instructions included with optional parts, such as the
rechargeable battery and charger, before using them.
• Always remove the optional battery and AC adapter from the device after use
and before cleaning.
• Do not misuse the cord of the AC adapter.
• Do not wind the cord of the AC adapter around the main unit or AC adapter.
• Changes or modifications not approved by OMRON Healthcare will void the user
warranty.
NE-C30.book Page 6 Monday, October 23, 2006 3:11 PM

7
Important safety instructions
EN
General Safety Precautions:
• Inspect the device and parts before using them each time, and check that there
are no problems. In particular, be sure to check the following:
- That the vaporiser head, nozzle or air tube are not damaged.
- That the nozzle is not blocked.
- That the compressor operates normally.
• When using this device, there will be some noise and vibration caused by the
pump in the compressor. There will also be some noise caused by the emission
of compressed air from the nebuliser kit. This is normal and does not indicate a
malfunction, or reduce the working life of the device.
• Limit use to 20 minutes at a time, and allow a 40 minute interval before using the
device again.
• Operate the device only as intended. Do not use the device for any other
purpose.
• Do not use the device at temperatures greater than +40°C.
• Do not spill liquid or medication on the battery connector, optional rechargeable
battery or charger connectors, or allow them to become dusty. Immediately wipe
off the liquid or dust with gauze or other absorbent material.
• Make sure that the air tube is securely attached to the compressor (main unit)
and nebulising parts, and does not come loose. Twist the air tube slightly when
inserting it into the connectors to avoid the tube disconnecting during use.
• The AC adapter is provided so that the unit can be completely isolated from the
power source. To completely isolate the unit from the power source unplug the
AC adapter from the power source.
Read and follow the “Correct Disposal of This Product” in the Technical Data
Section when disposing of the device and any used accessories or optional parts.
Save these instructions for future reference.
NE-C30.book Page 7 Monday, October 23, 2006 3:11 PM

8
1. Know your unit
A. Compressor (Main Unit)
A1. Power Indicator
A2. Power Switch
A3. Charge Indicator
A4. Air Connector
A5. Filter Cover (* Air filter inside.)
A6. Nebuliser Kit Holder
A7. AC Adapter Jack
A8. Battery Connector
B. Air Tube (PVC, 207cm)
B1. Air Plug
B2. Air Plug
C. Nebulising Parts
D. Inhalation Attachments
D1. Mouthpiece
D2. Adult Mask (PVC)
D3. Child Mask (PVC)
D4. Nosepiece
E. Nebuliser Kit
E1. Cap
E2. Inhalation Air Inlet
E3. Inhalation Top
E4. Vaporiser Head
E5. Medication Tank
E6. Nozzle
E7. Air Tube Connector
3
5
3
5
A7 A8
B
E1
E3
E2
E6
E4
E5
D2 D3D1
A C D
E
A4 A5
A2
A3
A1
A6
E7
B1
B2
D4
Rear View Bottom View
NE-C30.book Page 8 Monday, October 23, 2006 3:11 PM

9
1. Know your unit
EN
Accessories
Material of attachment
• Also applicable Section 10. Optional parts and accessories.
F. Spare Air Filters x 5
G. AC Adapter
G1. Power Connector
G2. Power Cord
H. Carrying Bag
I. Instruction Manual
J. Warranty Card
Nebuliser Kit, Mouthpiece, Nosepiece, Adapter for
Child Mask (SEBS): Polypropylene
Adult Mask (PVC), Child Mask (PVC): PVC
Adult Mask (SEBS), Child Mask (SEBS): SEBS
Air Tube: PVC and Polypropylene
Air Filter: Polyester
Air Filter Cover: ABS
F
G
H
I J
G1
G2
NE-C30.book Page 9 Monday, October 23, 2006 3:11 PM

10
2. Guide to using the Comp Air Elite
Preparing the Nebuliser for Use (Section 3)
Note: Clean and disinfect the nebuliser kit and applicable inhalation
attachments before using the device for the first time, or if it has not
been used for more than one week.
Taking Medication (Section 4)
Notes:
• Do not tilt the nebuliser kit so that it is at an
angle of greater than 45°.
• Do not crease or fold the air tube.
max
5
3
max
5
3
max
5
3
max
5
3
Cleaning Parts After Use (Section 5)
Note: Failure to clean the nebulising parts
after use may lead to infection.
How the nebuliser kit works
The compressed air from the
compressor is forced through the
nozzle, as it does so, it is mixed with
the medication in the vaporiser head
and forced upwards. The medication
is then turned into a fine aerosol and
directed upwards by the baffle,
where it is broken down into many
smaller aerosol particles.
Baffle
Aerosol
Vaporiser
Head
Medication
Compressed Air
Aerosol
Medication
Nozzle
NE-C30.book Page 10 Monday, October 23, 2006 3:11 PM
