allgood 2461N Manual

@lgood �
Installation instructions:
Servicing instructions
The minimum service period for the
dryer should be every 3 months or
more frequent intervals as experience
dictates:
1. Isolate the Hand Dryer from the
electricity supply before servicing.
2. Remove dust, fluff and any other
build up of foreign matter from
inlet and outlet grille areas
(Illustration 3).
T: 020 7387 9951 4 www.allgood.co.uk
Fi x ing In st r uct i o n s: 2461 N S u r face mou n ted ha n d d r ye r
FI2461N
Issue 03-08/22
@lgood �
IMPORTANT
Read these instructions before
commencing with the installation.
DO NOT install this product in areas where the
following may be present or occur:
 Corrosive or flammable gases, liquids or vapours.
 Ambient temperatures higher than 40
°
( or less
than -5
°
C.
 Possible obstructions which would hinder the
access or removal of the hand dryer.

A. All wiring to be in accordance with
the current I.E.E. Regulations, or the
appropriate standards of your
country and MUST be installed by a
suitably qualified person.
B. 
with a local isolator switch capable
of disconnecting all poles, having a
contact separation of at least 3mm.
C. Ensure that mains supply (Voltage,
Frequency, and Phase) complies
with
the rating label.
D. The Hand Dryer should only be used
in conjunction with fixed wiring.
E. The Hand Dryer should not be used
where it is liable to be subject
to
direct water spray for prolonged
periods of time.
F. This appliance can be used by
children aged 8 and above and
persons with reduced physical,
sensory
or mental capabilities or lack
of experience and knowledge if they
have been given supervision or
instruction concerning use of the
appliance in a safe way and
understand the hazards involved.
Children should be supervised to
ensure that they do not play with
the appliance.Cleaning and user
maintenance shall not be made by
children without supervision.
G. 
T: 020 7387 9951 1 www .allgood.co.uk
Fi x ing In st r uct i o n s: 2461 N S u r face mou n ted ha n d d r ye r
FI2461N
Issue 03-08/22
1. Drill 7mm dia. x 50mm deep four places
using template FT2461N supplied to
mark up position (For fitting to masonry).
2. Insert nylon plugs.
3. Locate Dryer sub assy ; insert screws
through black nylon collar, plain washer,
grommet, into plugs and fully tighten.
4. Connect the wiring to
the unit as outlined in the Wiring
Instructions (Page 2).
5. Locate cover over back plate ledge, pull
down, roll back and tighten screws from
underneath (Illustration 2).
IMPORTANT
After installation or servicing, units must be checked, and
only left when electrically and mechanically safe.
2. 3.

WARNING 
Wiring instructions
Always ensure that the inst

llation conforms
to the current edition of
the I.E.E. wiring regulationsi BS 7671
(UK) or the appropriate standards in
I
your country. Ensure that th  unit is
separately fused with a suitably rated
fuse and that it is connected to the supply
with a double pole i
 olating switch having a
contact sep,aration of
at least 3mm. Care should
 e taken
that single insulated condu(tors cannot come
into contact with the mounting
surface.
 lease connect the terminal block (see
illustration 1) as follows:
1. Connect the live wire (coloured red or
brown) to the terminal marked T.
2. Connect the neutral wire (coloured black
or blue) to the terminal marked 'N'.
3. Connect the earth wire (coloured green
and yellow) to the terminal marked '-4,-'.
T : 020 7 38 7 99 5 1 2 www .allgood.co.ukIMPORTANT 
Mounting instructions
The Hand Dryer must be fixed to a solid supporting wall. The recommended distance 'Y'
from finished floor (FFL) level to the bottom of the unit should be as follows:-
To ensure ease of installation and subsequent
maintenance, the horizontal distance to any
adjacent wall should not be less than 0.2
metres.
To install follow the steps on p4:
T : 020 7 38 7 99 5 1 3 www .allgood.co.uk
Fi x ing In st r uct i o n s: 2461 N S u r face mou n ted ha n d d r ye r
FI2461N
Issue 03-08/22
Fi x ing In st r uct i o n s: 2461 N S u r face mou n ted ha n d d r ye r
FI2461N
Issue 03-08/22
 Male washrooms 1168mm
 Female washrooms 1118mm
 Disabled washrooms 1016mm
 Children aged 14-17 1118mm
 Children aged 11-13 1016mm
 Children aged 8-10 914mm
 Children aged 4-7 672mm
1.
