Datasheet | integrated Multiservice Access Platform
FX10LX
AT-TN107-A 10 Port 100Mbps LX FTTx Service Module
Fiber to the Home/Business over
Dual Fiber
The FX10LX is one of three Allied Telesis
FTTH/B service modules for the iMAP product
family.This card provides 10 ports at 100Mbps
(full-duplex) over two fibers(Single-mode). Also
available are Single-mode single fiber and Multi-
mode dual fiber variations. The Gigabit feed
into the iMAP backplane allows the FX10
modules to operate completely at wirespeed.
The additional Layer 2+ switching allows
Service Providersto meet the demands of
multi-cast IP video,Video on Demand, voice and
data services. With the FX10 modules, you can
be assured future bandwidth needs of HDTV
will be addressed as consumer demand
increases.
Allied Telesis’ OAM solution allows for individual
full configuration and monitoring of each port.
The FX10 modules provide configuration tools
to:
•Control or limit subscriber access
•Enforce port security rules
•Limit services to a port
•Manage QoS across the card
•Support network double-tagging
•Control ingress or egress service rates
A multitude of applications can be supported
with the fiber-based 100Mbps access interfaces
including:
•FTTH for Voice,Video and Data Services
•FTTB for IP PBX, Ethernet and VPN services
•Campus LAN network uplinks
Whether it is derived voice or HDTV IP Video,
the FX10 will satisfy all bandwidth and mission
critical services with ease.
Part of Allied Telesis’ IP Broadband
Access Family
Whether it is broadband ADSL2+, FTTH, POTS
or T1/E1 circuits, the iMAP family is the ideal
platform for last mile service delivery.The
FX10LX line card can be used with any of the
iMAP family of carrier grade, IP Multiservice
Access platforms:
•iMAP 9700 (9RU, 17 service slots)
•iMAP 9400 (3RU, 7 service slots)
•MiniMAP 9100 (1RU, 3 service slots)
Provisioning, management, and diagnostics of
subscriber ports can be accomplished from
either the iMAP command line interface or the
NMS.
The FX10LX has been designed to survivethe
most rugged environmental conditions. It can be
confidentlydeployed in either a central office or
in outdoor enclosures withstanding extremes of
heat, cold, and light exposure.
Allied T
elesis provides a large portfolio of FTTx,
Ethernet and xDSL transport and access
equipment. In addition, Allied Telesis provides a
complete set of xDSL and FTTx CPE solutions
in the form of Multiservice Gateways, Layer 2/
Layer 3 switches, routers or media converters
to terminate the broadband link.
Key Features
Port-based
•VLANs
•VLAN translation
•Double-tagging (HVLAN)
•Filtering
•Ingress Metering
•Egress port rate limiting
•Countings
•Classification and remarking
•RMON
QoS
•Four Queues
•Priority scheduling
Security
•MAC limiting (up to 64)
•MAC flooding – VLAN-based
Services
•STP and RSTP
•Video-optimized
•Upstream forwarding only
Support for
•Business services
•Residential service
•Dual fiber, Single-mode
AT-TN107-A 10 Port 100Mbps LX FTTx Service Module

USA Headquarters |19800 North Creek Parkway |Suite 200 |Bothell |WA 98011 |USA |T: [phone] |F: [phone]
European Headquarters |Via Motta 24 |6830 Chiasso |Switzerland |T: +41 91 69769.00 |F: +41 91 69769.11
Asia-Pacific Headquarters |11 Tai Seng Link |Singapore |534182 |T: [phone] |F: [phone]
www.alliedtelesis.com
©2006 AlliedTelesis Inc. All rights reserved. Information in this document is subject to change without notice. All company names, logos, and product designs that are trademarks or registered trademarks are the property of their respective owners. 617-000047 Rev. D
FX10LX |AT-TN107-A 10 Port 100Mbps LX FTTx Service Module
Interface Specifications
Number of ports: 10
AT-TN107: Single-mode, Dual Fiber
TxRx 1310nm
16dB Optical Budget
SFF with LC Connector
Backplane capacity: 1Gbps
Physical design: Front Access
Protocols and Specifications
IEEE 802.1d,w Rapid Spanning Tree
IEEE 802.1D Bridging
IEEE 802.1Q VLAN Bridging
IEEE 802.1p Prioritization
IEEE 802.3ah EFM OAM
IEEE 802.3ad Link Aggregation
IETF RFC 1112 IP Multicasting/IGMP Snooping v1
IETF RFC 2236 IP Multicasting/IGMP Snooping v2
DHCP Relay Agent option 82 (RFC 3046)
Power Requirements
Maximum power 37W
Environmental Conditions
Operating Temp: -40C to 65C
Storage Temp: -40C to 75C
Relative Humidity: 5% to 95%, non-condensing
Regulatory Approvals
FCC Part 15 Class A/ANSI C63.4
EN 300 386 V1.3.1:2001-09/EN 55022:1998, Class A
VCCI Class A; ITE/ CISPR 22:1997 Class A
EN 300 386 V1.3.1:2001-09/EN 55022:1998, Class A
EN 300 386 V1.3.1:2001-09/EN 61000-4-3:1998
EN 300 386 V1.3.1:2001-09/EN 6100-4-6:1996
EN 300 386 V1.3.1:2001-09/EN 61000-4-4:1995
EN 300 386 V1.3.1:2001-09/EN 61000-4-5:1995
EN 300 386 V1.3.1:2001-09/EN 61000-4-2:1999
UL/cUL 60950: IEC60950
NEBS Level 3, GR-1089 Issue 3, GR63 Issue 2
USDA RUS
Ordering Information
iMAP 9x00 Chassis
Model Description Part #
iMAP 9700 17-slot chassis with DC power with faceplates AT-TN-250GF
iMAP 9700 17-slot chassis with DC power without faceplates AT-TN-250G
iMAP 9400 7-slot chassis with DC power with faceplates AT-TN-251GF
iMAP 9400 7-slot chassis with DC power without faceplates AT-TN-251G
MiniMAP 9101 3-slot mini chassis with DC power AT-TN-9101-A-80
MiniMAP 9102 3-slot mini chassis with AC power AT-TN-9102-A-XX*
*Where XX = 10 for U.S. power cord
=20 for no power cord
=30 for U.K. power cord
FX10LX
Model Description Part #
FX10LX 10ports, 100Mbps LX Single-mode, Dual fiber AT-TN-107-A
iMAP Common Control
Model Description Part #
CFC24 24GbE switch controller card AT-TN-401-B
GE3 3x GbE WAN interface card AT-TN-301-A
CFC56 56 GbE switch controller card AT-TN-407-A
XE1 10GbE WAN interface card AT-TN-308-A
CFC12 12GbE switch controller card AT-TN-408-A
Related iMAP FTTX Line Cards
Model Description Part #
FTTX (MM) 10-port100Mbps multimode fiber line card AT-TN-104-A
FTTX (SM, Single Fiber) 10-port100Mbps singlemode, single fiber line card AT-TN-109-A
GE8 8-port GbE line card AT-TN-117-A
GEPON2 2-port GEPON line card AT-TN-118-A
Filler Full size service slot filler plate AT-TN-M000-A
Related FTTX CPE
Model Description Part #
RG613LH intelligent Multiservice Gateway, 3x LAN, 2x FXS,
Dual fiber WAN interface
AT-RG613LH-10
=40 for Australia power cord
=50 for Europe power cord
Allied Telesis’ iMAP family of integrated
Multiservice Access Platforms
