Patch Release Note
Patch 86222-10
For Rapier Switches and AR800 Series
Modular Switching Routers
Introduction
This patch release note lists the issues addressed and enhancements made in
patch 86222-10 for Software Release 2.2.2 on existing models of Rapier L3
managed switches and AR800 Series L3 modular switching routers. Patch file
details are listed in Table 1.
This release note should be read in conjunction with the following documents:
■Release Note: Software Release 2.2.2 for Rapier Switches, AR300 and
AR700 Series Routers, and AR800 Series Modular Switching Routers
(Document Number C613-10313-00 Rev A) available from
www.alliedtelesyn.co.nz/documentation/documentation.html.
■Rapier Switch Documentation Set for Software Release 2.2.1 available on
the Documentation and Tools CD-ROM packaged with your switch, or
from www.alliedtelesyn.co.nz/documentation/documentation.html.
■AR800 Series Modular Switching Router Documentation Set for Software
Release 2.2.1 available on the Documentation and Tools CD-ROM
packaged with your switching router, or from www.alliedtelesyn.co.nz/
documentation/documentation.html.
WARNING: Using a patch for a different model or software release may cause
unpredictable results, including disruption to the network. Information in this
release note is subject to change without notice and does not represent a
commitment on the part of Allied Telesyn International. While every effort has
been made to ensure that the information contained within this document and
the features and changes described are accurate, Allied Telesyn International
can not accept any type of liability for errors in, or omissions arising from the
use of this information.
Table 1: Patch file details for Patch 86222-10.
Base Software Release File 86s-222.rez
Patch Release Date 29-Nov-2001
Compressed Patch File Name 86222-10.paz
Compressed Patch File Size 295536 bytes

2Patch Release Note
Patch 86222-10 for Software Release 2.2.2
C613-10319-00 REV J
Some switch chip register settings have been optimised to improve the
provision of CoS with the newer revision of switching silicon.
Features in 86222-09
Patch file details for Patch 86222-09 are listed in Table 2.
Patch 86222-09 includes all issues resolved and enhancements released in
previous patches for Software Release 2.2.2, and the following enhancements:
A new feature, STP forwarding, has been added. STP forwarding can be
enabled and disabled using the commands:
ENABLE SWI STPFORWARD
DISABLE SWI STPFORWARD
When STP forwarding is enabled, all STP forwarding is ignored and all
BDPUs received on a port are forwarded on all other ports.
The switch now delays sending link traps immediately after a restart to give
the link to the trap host time to come up. A similar change has been made
for the cold start trap. After a 10s delay, all interfaces which are UP have a
link trap generated for them. After that, link traps are sent as normal.
Processing invalid UDP packets caused a memory leak. This issue has been
resolved. Additional debugging facilities were added.
The default setting for the switch port parameter INFILTERING is now OFF,
as specified in IEEE802.1Q. A VLAN will still reject these packets if they are
not from valid VLAN member ports.
The IGMP snooping forwarding process now correctly selects outgoing
ports when DVMRP is managing the multicast routing information.
PCR: 01264 Module: SWI Network affecting: No
Table 2: Patch file details for Patch 86222-09.
Base Software Release File 86s-222.rez
Patch Release Date 27-Nov-2001
Compressed Patch File Name 86222-09.paz
Compressed Patch File Size 295444 bytes
PCR: 01189 Module: STP, SWI Network affecting: Yes
PCR: 01242 Module: CORE, SNMP Network affecting: No
PCR: 01244 Module: SWI, CORE, IPG Network affecting: No
PCR: 01246 Module: SWI Network affecting: No
PCR: 01247 Module: IPG Network affecting: No

Patch 86222-10 For Rapier Switches and AR800 Series Modular Switching Routers 3
Patch 86222-10 for Software Release 2.2.2
C613-10319-00 REV J
A configuration problem prevented trunking of gigabit ports at 100Mbit
speeds. This issue has been resolved. The A39 gigabit copper uplink
reverted to autonegotiation after a restart, even if it was configured to a
fixed speed. This issue has been resolved. When the port has been
configured for a fixed speed, the mode is now set to MDIX, not MDI.
When an M2 version of the AR020 PRI E1/T1 PIC was installed in a AR040
NSM it was not possible to select the T1 mode of operation regardless of the
jumper setting. This issue has been resolved.
A fatal error occurred when the firewall discarded disallowed multicast
packets. This issue has been resolved.
Features in 86222-08
Patch file details for Patch 86222-08 are listed in Table 3.
Patch 86222-08 includes all issues resolved and enhancements released in
previous patches for Software Release 2.2.2, and the following enhancements:
Tunnel creation failed when attempting to establish a point-to-point tunnel
from an ATR router (tunnel originator) to another vendor’s router. This
issue has been resolved.
When IGMP snooping was enabled, if a member left a group on a port, it
could not re-join the group on that port. This issue has been resolved.
Substantial changes have been made to PIM in more recent code releases.
These have been retrofitted to 2-2-2 in the patch. Note: these changes have
incorporated PCRs 01159 and 01190.
The PPPoE access concentrator did not stop RADIUS accounting when a
PADT termination was received without receiving a proper PPP
termination first. This issue has been resolved.
PCR: 01248 Module: SWI Network affecting: No
PCR: 01254 Module: PRI Network affecting: No
PCR: 01256 Module: Firewall Network affecting: No
Table 3: Patch file details for Patch 86222-08.
Base Software Release File 86s-222.rez
Patch Release Date 09-Nov-2001
Compressed Patch File Name 86222-08.paz
Compressed Patch File Size 291012 bytes
PCR: 01201 Module: L2TP Network affecting: Yes
PCR: 01233 Module: PIM Network affecting: No
PCR: 01236 Module: PPP Network affecting: No

4Patch Release Note
Patch 86222-10 for Software Release 2.2.2
C613-10319-00 REV J
The dot1dBridge MIB implementation now complies with RFC1493.
Features in 86222-07
Patch file details for Patch 86222-07 are listed in Table 4:
Table 4: Patch file details for Patch 86222-07
Patch 86222-07 includes all issues resolved and enhancements released in
previous patches for Software Release 2.2.2, and the following enhancements:
DHCP now correctly handles request messages containing request list
options not supported by the router.
The router would accept TCP sessions with destination address the same as
the subnet broadcast address for one of the router’s interfaces. Firewall-
generated packets destined for a subnet broadcast address on one of the
routers interfaces would cause a fatal error. These issues have been
resolved.
A watchdog timout occurred when the router received an HTTP message
with an over-length header. Normal HTTP requests would also occasionally
cause watchdog timeouts. These issues have been resolved.
The OSPF route filter was not filtering out external routes. This issue has
been resolved.
MD5 Authentication now works correctly with RIP packets.
The SET IP LOCAL command caused a fatal error if the router was
configured with a default route over an L2TP tunnel, because there was no
valid route to the remote IP address of the tunnel. This issue has been
resolved.
PCR: 01237 Module: SWI Network affecting: No
Base Software Release File 86s-222.rez
Patch Release Date 26-Oct-2001
Compressed Patch File Name 86222-07.paz
Compressed Patch File Size 250468 bytes
PCR: 01018 Module: DHCP Network affecting: No
PCR: 01160 Module: IPG,FIREWALL Network affecting: No
PCR: 01168 Module: HTTP Network affecting: No
PCR: 01182 Module: OSPF Network affecting: No
PCR: 01193 Module: IPG Network affecting: No
PCR: 01194 Module: L2TP, IPG Network affecting: No

Patch 86222-10 For Rapier Switches and AR800 Series Modular Switching Routers 5
Patch 86222-10 for Software Release 2.2.2
C613-10319-00 REV J
Debug messages are no longer generated when a Q.931 Advise of Charge
Notification message is received.
TCP sessions would get stuck in the FINWAIT2 state if the remote host did
not send a FIN message when required. The router now starts a timer when
a TCP session enters the FINWAIT2 state and will automatically close the
session if the timer expires.
The SET IP FILTER command was not correctly handling the ICMPTYPE
and ICMPCODE parameters. This issue has been resolved.
The router will now accept DHCP messages that are greater than or equal
to 576 bytes in size, and reject any message smaller than 576 bytes. This
operation conforms to RFC 1541.
ISAKMP quick mode exchanges are now committed if any traffic is received
over the newly generated SA. This improves stability in very lossy networks
where the commit message may get lost.
ISAKMP debugging caused a fatal error when the debugging mode was set
to ALL and PFS was enabled. This issue has been resolved.
PPPoE interfaces with IDLE set to ON would not retry active discovery
when more data was received if active discovery had previously failed. This
issue has been resolved.
A memory loss occurred when certificates were used by ISAKMP. This issue
has been resolved.
ISAKMP heartbeats are no longer transmitted if the lower layer interface is
down. This stops ISAKMP heartbeats from bringing up links in dial-up
environments.
In some conditions it was possible for ISAKMP packets to be lost and not
retransmitted. Incoming ISAKMP messages are now validated before
stopping retransmission of the previous message.
The COS_DST bit on ARL for L3 interface should be 0x4 (higher priority) for
CPU ports. This has been corrected.
PCR: 01197 Module: Q931 Network affecting: No
PCR: 01198 Module: TCP Network affecting: No
PCR: 01199 Module: IPG Network affecting: No
PCR: 01202 Module: DHCP Network affecting: No
PCR: 01203 Module: ISAKMP Network affecting: No
PCR: 01204 Module: ISAKMP Network affecting: No
PCR: 01205 Module: PPP Network affecting: No
PCR: 01206 Module: ISAKMP Network affecting: No
PCR: 01207 Module: ISAKMP Network affecting: No
PCR: 01209 Module: ISAKMP Network affecting: No
PCR: 01211 Module: SWI Network affecting: No

6Patch Release Note
Patch 86222-10 for Software Release 2.2.2
C613-10319-00 REV J
The Trigger Facility was generating a trap with variable { 0 0 }, and was not
documented in the ATI enterprise MIB. This issue has been resolved. The
MIB object triggerLastTriggerActivated ({ enterprises(1) alliedTelesyn(207)
mibObjects(8) brouterMib(4) atrouter(4) modules(4) trigger(53) 1 }) has been
defined, to record the trigger number of the last trigger activated, and this
variable is now transmitted in the trigger activation trap triggerTrap.
In a Rapier G6, fitted with a fibre uplink module with all ports active,
switching traffic between port 1 and the uplink caused the traffic flow to
cease after a period of time depending on the volume of traffic. This issue
has been resolved.
The Rapier did not include the message age of the received BDPU message
in the message age of the BDPU it transmitted. Also, the message age of the
message transmitted BDPU could be less than that of the received BDPU,
which contravenes IEEE 802.3d. This issue has been resolved.
Reception of incorrectly tagged packets was causing corruption of the ARL
table, eventually causing the switch to lock up. This issue has been resolved.
Tagged packets with invalid VLAN identifiers are now discarded. The
INFILTERING parameter of the SET SWITCH PORT command now
defaults to ON.
Flow control performance has been improved.
The IPsec SA ID now wraps correctly at the 16 bit (ID = 65535) boundary.
The ID is also checked to verify that it is free before it is used.
If PPPoE AC services were not deleted in the same order they were added,
the DELETE command would return an “ operation successful” message
but the service would still appear in the output of the SHOW PPP PPPOE
command. This issued has been resolved.
The CREATE CONFIG command did not include all required L3FILTER
parameters in the generated script file.
The L3 table on the Rapier G6 is now cleared when a switch port goes down
to ensure the L3 and ARP tables are consistent.
PCR: 01213 Module: TRG, SNMP Network affecting: No
PCR: 01214 Module: SWI Network affecting: No
PCR: 01216 Module: STP Network affecting: No
PCR: 01219 Module: VLAN,SWI Network affecting: No
PCR: 01221 Module: SWI Network affecting: No
PCR: 01225 Module: IPSEC Network affecting: No
PCR: 01227 Module: PPP Network affecting: No
PCR: 01229 Module: SWI Network affecting: No
PCR: 01232 Module: SWI Network affecting: No

Patch 86222-10 For Rapier Switches and AR800 Series Modular Switching Routers 7
Patch 86222-10 for Software Release 2.2.2
C613-10319-00 REV J
A switch port that was transmitting STP BPDUs and also mirroring its
transmit traffic to the mirror port caused a fatal error. This issue has been
resolved.
Features in 86222-06
Patch file details for Patch 86222-06 are listed in Table 5.
Patch 86222-06 includes all issues resolved and enhancements released in
previous patches for Software Release 2.2.2, and the following enhancements:
The power supply voltages of the base board PHYs on a Rapier G6 are
controlled by a PHY register value, which was incorrectly set. This issue has
been resolved.
In PIM Dense Mode, if a data stream started before PIM hello messages
were exchanged, the receiver did not get the data stream. This issue has
been resolved.
The Rapier G6 base ports sometimes experienced spurious link up or link
down events. This issue has been resolved.
Features in 86222-05
Patch file details for Patch 86222-05 are listed in Table 6.
Patch 86222-05 includes all issues resolved and enhancements released in
previous patches for Software Release 2.2.2, and the following enhancements:
PCR: 01234 Module: SWI Network affecting: No
Table 5: Patch file details for Patch 86222-06.
Base Software Release File 86s-222.rez
Patch Release Date 30-Aug-2001
Compressed Patch File Name 86222-06.paz
Compressed Patch File Size 226776 bytes
PCR: 01188 Module: SWI Network affecting: No
PCR: 01190 Module: PIM Network affecting: No
PCR: 01192 Module: SWI Network affecting: No
Table 6: Patch file details for Patch 86222-05.
Base Software Release File 86s-222.rez
Patch Release Date 24-Aug-2001
Compressed Patch File Name 86222-05.paz
Compressed Patch File Size 223728 bytes

8Patch Release Note
Patch 86222-10 for Software Release 2.2.2
C613-10319-00 REV J
A39 copper uplink modules in the Rapier G6 sometimes experienced
spurious link up or link down events. This issue has been resolved.
The enterprise MIB now supports objects for power supply monitoring.
Certificates containing GeneralisedTime with the year in YYYY format are
now parsed correctly. The keyUsage field of certificates is now parsed
correctly when only one byte has been specified. The CRL update time is now
displayed correctly in hours. If the username and password parameters are
present the location parameter must be present and appear before the
username and password parameters. Certificates with signatures of 257 bytes
are now correctly parsed. Certificates added from a configuration script are
now processed correctly.
A fatal error occurred if an IPv6 interface was deleted while packets were
being transmitted. The number of current interfaces was not being updated
correctly when a new IPv6 interface was added. As a result, after multiple
additions and deletions, no more IPv6 interfaces could be added. These
issues have been resolved.
The CREATE CONFIG command now adds PKI certificates to the script in
the same order that they were originally added to the certificate database.
PKI certificates are now periodically checked (once per hour) to verify that
they are still valid.
IPCOMP SA’s which have the reserved CPI “3” are no longer deleted by
ISAKMP delete messages.
When a VLAN was created and then destroyed on the G6 or G6F, the
VTABLE was corrupted. This has been fixed.
DHCP failed to send request messages when it was in a rebinding or
renewing state. This issue has been resolved.
In some extreme traffic conditions the switch could lock up, preventing
switching of any traffic. This issue has been resolved.
PCR: 01148 Module: SWI Network affecting: No
PCR: 01157 Module: CORE Network affecting: No
PCR: 01162 Module: PKI Network affecting: No
PCR: 01170 Module: IPv6 Network affecting: No
PCR: 01176 Module: PKI Network affecting: No
PCR: 01177 Module: PKI Network affecting: No
PCR: 01178 Module: IPSEC Network affecting: No
PCR: 01179 Module: SWI Network affecting: No
PCR: 01181 Module: DHCP Network affecting: No
PCR: 01185 Module: SWI Network affecting: No

Patch 86222-10 For Rapier Switches and AR800 Series Modular Switching Routers 9
Patch 86222-10 for Software Release 2.2.2
C613-10319-00 REV J
When large numbers of sessions were being handled the firewall would
become overly aggressive in restricting new sessions. The Active TCP Opens
field in the output of the SHOW FIREWALL POLICY would show a very
high number (42 ×108). This issue has been resolved.
If the IGMP table was empty and a timeout was set, a fatal error occurred.
This issue has been resolved.
Features in 86222-04
Patch file details for Patch 86222-04 are listed in Table 7.
Patch 86222-04 includes all issues resolved and enhancements released in
previous patches for Software Release 2.2.2, and the following enhancements:
Message protection validation failures would occur intermittently. This
issue has been resolved.
ISAKMP now interoperates with other vendor’s products in aggressive
mode exchanges.
Support has been added for the 8624XL-80 switch with -48VDC power
supply.
In a dual policy configuration, the firewall would lock up under load. The
firewall would also mistakenly report SYN attacks. These issues have been
resolved.
The CREATE CONFIG command generated duplicate PIM interface
configuration command lines. This issue has been resolved.
Certificates containing GeneralisedTime with the year in YYYY format are
now parsed correctly. The keyUsage field of certificates is now parsed
PCR: 01186 Module: FIREWALL Network affecting: No
PCR: 01187 Module: IPG Network affecting: No
Table 7: Patch file details for Patch 86222-04.
Base Software Release File 86s-222.rez
Patch Release Date 24-Aug-2001
Compressed Patch File Name 86222-04.paz
Compressed Patch File Size 220220 bytes
PCR: 01124 Module: PKI Network affecting: No
PCR: 01136 Module: ISAKMP Network affecting: No
PCR 01138 Module: CORE, SWI Network affecting: No
PCR: 01152 Module: FIREWALL Network affecting: No
PCR: 01159 Module: PIM Network affecting: No
PCR: 01162 Module: PKI Network affecting: No

10 Patch Release Note
Patch 86222-10 for Software Release 2.2.2
C613-10319-00 REV J
correctly when only one byte has been specified. The CRL update time is now
displayed correctly in hours. If the username and password parameters are
present the location parameter must be present and appear before the
username and password parameters.
The DHCP server now correctly allocates addresses to clients running
Apple Open Transport 2.5.1 or 2.5.2.
Both public and private access could be configured on the same interface on
a policy. This issue has been resolved.
RSA encryption is now periodically suspended to ensure other processes
get some CPU time during large RSA calculations.
The CREATE ISAKMP command now checks that the key specified by the
LOCALRSAKEY parameter actually exists in the ENCO module.
The INTERFACE parameter of the CREATE TRIGGER and SET TRIGGER
commands now supports Ethernet interfaces. Ethernet interface events can
now generate triggers.
The Telnet server’s listen port can now be configured to a number in the
range 1 to 65535, excluding any ports already assigned as listen ports.
The CREATE CONFIG command sometimes generated scripts for rule
commands with GBLIP=0.0.0.0 when this was not necessary. This issue has
been resolved.
Features in 86222-03
Patch file details for Patch 86222-03 are listed in Table 8.
Patch 86222-03 includes all issues resolved and enhancements released in
previous patches for Software Release 2.2.2, and the following enhancements:
PCR: 01165 Module: DHCP Network affecting: No
PCR: 01166 Module: FIREWALL Network affecting: No
PCR: 01167 Module: ENCO Network affecting: No
PCR: 01169 Module: ISAKMP Network affecting: No
PCR: 01171 Module: ETH, TRIGGER Network affecting: No
PCR: 01173 Module: Telnet Network affecting: No
PCR: 01174 Module: Firewall Network affecting: No
Table 8: Patch file details for Patch 86222-03.
Base Software Release File 86s-222.rez
Patch Release Date 8-Aug-2001
Compressed Patch File Name 86222-03.paz
Compressed Patch File Size 205828 bytes

Patch 86222-10 For Rapier Switches and AR800 Series Modular Switching Routers 11
Patch 86222-10 for Software Release 2.2.2
C613-10319-00 REV J
DNS response packets with corrupt length fields were causing a fatal error.
This issue has been resolved.
IP NAT caused a fatal error when an ARP wait timer timed out and tried to
send a host unreachable message. This issue has been resolved.
The router was restarting after a “teardrop” attack on the STT listen port.
This issue has been resolved.
The entry aging process now works correctly even when there are large
numbers of firewall entries to be aged.
The command SHOW IP DEBUG=nwas entered, where nwas one greater
than the number of items in the IP debug queue resulted in a fatal error. This
issue has been resolved.
Features in 86222-02
Patch file details for Patch 86222-02 are listed in Table 9.
Patch 86222-02 includes all issues resolved and enhancements released in
previous patches for Software Release 2.2.2, and the following enhancements:
When an interface on the firewall was configured with a global IP address
of 0.0.0.0, outgoing packets from the private interface to the public interface
sometimes caused a fatal error. This issue has been resolved.
Re-validation of temporary CA certificates now works correctly.
A fatal error occurred when IGMP received a Join message and attempted
to forward the Join message to other switch ports. This issue has been
resolved.
PCR: 01112 Module: IPG Network affecting: No
PCR: 01139 Module: IPG Network Affecting: No
PCR: 01147 Module: STT Network affecting: No
PCR: 01150 Module: FIREWALL Network affecting: No
PCR: 01153 Module: IPG Network affecting: No
Table 9: Patch file details for Patch 86222-06.
Base Software Release File 86s-222.rez
Patch Release Date 26-Jul-2001
Compressed Patch File Name 86222-02.paz
Compressed Patch File Size 202564 bytes
PCR: 01081 Module: FIREWALL Network affecting: No
PCR: 01126 Module: PKI Network affecting: No
PCR: 01128 Module: IPG Network affecting: No

12 Patch Release Note
Patch 86222-10 for Software Release 2.2.2
C613-10319-00 REV J
The SHOW CPU command sometimes displayed incorrect CPU utilisation
figures. Typically a value of about 74% was reported when in fact the CPU
was almost idle. This issue has been resolved.
Port parameters can now be set correctly using the Layer 3 Switch GUI.
Clicking the Apply button on a Layer 3 Switch GUI page caused the switch
to lock up if no configuration file was set, but boot.cfg was present. This
issue has been resolved.
A fatal error occurred when UDP received a packet with very long UDP
packet length. This issue has been resolved.
Features in 86222-01
Patch file details for Patch 86222-01 are listed in Table 10.
Patch 86222-01 includes the following enhancement for Software Release 2.2.2:
The DHCP server identified the wrong port numbers for incoming DHCP
requests causing DHCP replies to be sent to the wrong port. This issued has
been resolved.
The IP flow cache occasionally generated a watchdog fatal error. This issued
has been resolved.
Deleting entries from an L3 table occasionally resulted in a watchdog fatal
error. This issued has been resolved.
PKI enrolment no longer causes message validation to fail.
PCR: 01131 Module: CORE Network affecting: No
PCR: 01134 Module: GUI Network affecting: No
PCR: 01135 Module: GUI,INST Network affecting: No
PCR: 01137 Module: IPG Network affecting: No
Table 10: Patch file details for Patch 86222-01.
Base Software Release File 86s-222.rez
Patch Release Date 11-Jul-2001
Compressed Patch File Name 86222-01.paz
Compressed Patch File Size 187124 bytes
PCR: 01100 Module: DHCP Network affecting: No
PCR: 01102 Module: IPG Network affecting: No
PCR: 01102 Module: SWI Network affecting: No
PCR: 01106 Module: PKI Network affecting: No

Patch 86222-10 For Rapier Switches and AR800 Series Modular Switching Routers 13
Patch 86222-10 for Software Release 2.2.2
C613-10319-00 REV J
Repeated addition and deletion of an address with the VALID parameter set
to or from an IPV6 interface caused a fatal error. This issue has been
corrected. The VALID parameter specifies the life of the address, and
defaults to INFINITE. The address is deleted when the lifetime expires. The
PREF parameter specifies the time that the address is the preferred address
of the interface, and defaults to INFINITE. PREF must be less than or equal
to VALID. IPV6 now checks and ensures that if either PREF or VALID is
specified, PREF is less than or equal to VALID. When an address is deleted
the timers are now correctly cleared.
IP sometimes passed the wrong port number to PIM, causing PIM to
process the wrong port number in its routing table. This issued has been
resolved.
Availability
Patches can be downloaded from the Software Updates area of the Allied
Telesyn web site at www.alliedtelesyn.co.nz/support/updates/patches.html. A
licence or password is not required to use a patch.
PCR: 01119 Module: IPV6 Network affecting: No
PCR: 01120 Module: IPG Network affecting: No

14 Patch Release Note
Patch 86222-10 for Software Release 2.2.2
C613-10319-00 REV J
