Allied Telesis www.alliedtelesis.com
Datasheet | Switches
AT-8000S/16
Layer 2 Managed Fast Ethernet Switch
A
T-8000S/16
16 port standalone 10/100TX Layer 2 switch
with 1 active SFP bay (unpopulated) and
1standby 10/100/1000T port (RJ-45)
Overview
The small form factor AT-8000S/16 provides
line-rate Layer 2 switching in an affordable,
fixed-configuration platform. Featuring easy
installation and exceptional reliability, this
10/100 switch comes with one Gigabit uplink
port with the option of the integrated copper
10/100/1000 portor a 100 or 1000 SFP slot
for fiber connectivity.
Ideal Workgroup and
Remote Office Connectivity
Designed for the smaller workgroup or remote
office this highly featured switch mirrors the
advanced feature set of the larger 8000S series
stackable products while offering the benefits of
silent operation and a portdensity aimed at
right priced functionality.
Easy Access Networking
Featuring an industry standard CLI and Allied
Telesis’ intuitive yet fully featured Web interface
the advanced features of the AT-8000S/16 are
accessible to a wide range of system
administrators. The well known CLI and Web
interfaces significantly reduce learning time and
minimizethe cost of deployment.
SecureManagement
Only authorized administrators can access the
management interface of the 8000S series.
Protocols such as SSL, SSH and SNMP v3
facilitate this protection of your network with
local or remote connections.
Securing the Network Edge
To ensure the protection of your data, it is
important to control access to your network.
Protocols such as IEEE 802.1x port-based
authentication guarantee that only known users
are connected to the network. Unknown users
who physicallyconnect can be isolated to a
pre-determined part of your network offering
guests such benefits as Internet access while
ensuring the integrity of your private network
data.
Gigabit and Fast Ethernet SFP
Support
All switches in the 8000S family support both
Gigabit and Fast Ethernet Small Form-factor
Pluggables (SFPs).This makes the 8000S series
an ideal family for environments where Gigabit
fiber switches will be phased in over time.The
8000S familyallows for connectivity to the
legacy 100FX hardware until it is upgraded to
Gigabit. Support for both speeds of SFPs allows
organizations to staywithin budget as they
migrate to faster technologies.
Key Features
Easy,Well Known Management
•Industry standard CLI
•Simple intuitive, full featured Allied Telesis
Web interface
•Secure encrypted Web and CLI management
with SSH v2 and SSL
•SNMP
•Twolevel access privileges
All the QoS Needed in the Wiring Closet
for Today’sVoice and Data Networking
•Eight priorities assigned to four queues
•IEEE 802.1p for Layer 2 QoS
•DSCP (DiffServ) for Layer 3 QoS
•IEEE 802.1p to DSCP remarking traffic ready for
transportto the Layer 3 core of the network
•Layer 2 and Layer 3 ACL
Securing the Network at its Most
Vulnerable Point
•IEEE 802.1x and RADIUS network login: for
advanced control of user authentication and
accountability
•Guest VLAN: to ensure visitors or unauthorized
users connect only to services defined by IT. E.g.
Internet
•TACACS+: for ease of management security
administration
•Layer 2 and Layer 3 ACL
•Port MAC address security options
Small Form Factor
•Standalone switch for remote locations
or where stacking is not required
•Silent operation (fanless)

Allied T
elesis www.alliedtelesis.com
AT-8000S/16 |Layer 2 Managed Fast Ethernet Switch
System Configuration
Dimensions 33cm x 23cm x 4.3cm
(W x D x H) (13” x 9.1” x 1.7”)
Weight 1.95kg (4.29lb)
Mounting 19” rack-mountable hardware
included
System Capacity
64MB RAM
16MB flash memory
400Mhz CPU
Up to 4,096 VLAN ID
8,000 MAC address
Performance
Wirespeed switching on all Ethernet ports for all packet
sizes
Throughput 3.87Mpps
Switching capacity 5.2Gbps
MTBF 447,901.90 hours
Store and forward mode
Non-blocking switch fabric
Auto MDI/MDI-X
Port speed:
10/100TX RJ-45
10/100/1000T RJ-45
100FX, 1000SX, 1000LX SFP slot
RS232 DB9 pin, male port
Internal power supply – no fan
Interface Standards
IEEE 802.3 10T and 10FL
IEEE 802.3u 100TX and 100FX
IEEE 802.3z 1000SX
IEEE 802.3ab 1000T
General Standards
IEEE 802.1D Bridging
IEEE 802.3x BackPressure/ flow control
Redundancy Standards
IEEE 802.1D Spanning-Tree Protocol
IEEE 802.1W Rapid Spanning-Tree
IEEE 802.1s Multiple Spanning-Tree
IEEE 802.3ad LACP link aggregation
(with up to eight members per
group and up to eight groups per
device)
Static port trunk
Quality of Services (QoS)
QoS in Layer 2 (IEEE 802.1p compliant Class of
Service)
Traffic prioritization using IEEE 802.1p, ToS, DSCP fields
Map IEEE 802.1p priorities to CoS queues to prioritize
traffic at egress
Strict Scheduling and Weighted Round Robin
VLANs
IEEE 802.1Q VLAN tagging
Up to 256 VLANs
Port-based VLANs
MAC-based VLANs
Private VLANs
GARP VLAN Registration Protocol (GVRP)
Multicast Standards
RFC 1112 IGMP snooping (ver. 1)
RFC 2236 IGMP snooping (ver. 2)
RFC 3376 IGMP snooping (ver. 3)*
RFC 3376 IGMP querier
*Future release
Management and Monitoring
WEB, CLI, Serial
RFC 1157 SNMPv1/v2c
RFC 2570 SNMPv3
RFC 1213 MIB-II
RFC 1573 Evolution of MIB-II
RFC 1215 TRAP MIB
RFC 1493 Bridge MIB
RFC 2863 Interfaces group MIB
RFC 1643 Ethernet like MIB
RFC 1757 RMON 4 groups:
Stats, History, Alarms, Events
RFC 2674 IEEE 802.1Q MIB
RFC 1866 HTML
RFC 2068 HTTP
RFC 854 Telnet
RFC 783 TFTP
IP address allocation
RFC 951/ RFC 1542 BootP / DHCP
Manual
RFC 2030 SNTP (Simple Network Time Protocol)
Syslog event
Dual software images
Security
Management Security: user name
and password protection
SSHv2 Telnet management
SSLv3 Web management
RFC 1492 TACACS+
RFC 2138 RADIUS Authentication
IEEE 802.1x Port-based network access control
Guest VLANs
RFC 2865 IEEE 802.1x port-based network
access control
MAC-based network access control
ACL - Access Control Lists

USA Headquarters |19800 North Creek Parkway |Suite 100 |Bothell |WA 98011 |USA |T: [phone] |F: [phone]
European Headquarters |Via Motta 24 |6830 Chiasso |Switzerland |T: +41 91 69769.00 |F: +41 91 69769.11
Asia-Pacific Headquarters |11 Tai Seng Link |Singapore |534182 |T: [phone] |F: [phone]
www.alliedtelesis.com
©2008 Allied Telesis Inc. All rights reserved. Information in this document is subject to change without notice. All company names, logos, and product designs that are trademarks or registered trademarks are the property of their respective owners. 617-000174 Rev. I
AT-8000S/16 |Layer 2 Managed Fast Ethernet Switch
Fault Protection
Broadcast storm control
Power Characteristics
Voltage input 100-240V AC
Voltage output 12vDC
Current 0.75A
Power consumption 30W
Heat dissipation 102.45BTU/hour
Clock frequency 166MHz
Environmental Specifications
Operating temp 0°C to 45°C (32°F to 113°F)
Storage temp -25°C to 70°C (-13°F to 158°F)
Relative humidity 10% to 90% non-condensing
Storage humidity 5% to 95% non-condensing
Operating altitude Maximum 3,000m (9,843ft)
Electrical/ Mechanical Approvals
Safety UL 1950 (UL/cUL), EN60950 (TUV)
EMI FCC Class A, EN55022 Class A,
VCCI Class A, C-Tick, EN61000-3-2,
EN61000-3-3
Immunity EN55024
RoHS compliant
Package Description
One AT-8000S/16 switch
Power cord AC
Rack-mount kit
Rubber feet for desktop installation
RS232 management cable
Install guide and user guide in CD
Country of Origin
China
Ordering Information
AT-8000S/16-xx
16port standalone 10/100TX Layer 2 switch with 1
active SFP bay (unpopulated) and 1 standby
10/100/1000T port (RJ-45)
Where xx = 10 for US power cord
20 for no power cord
30 for UK power cord
40 for Australian power cord
50 for European0 power cord
Accessories
Small Form Pluggables (SFPs)
AT-SPFX/2
Multi-mode Fiber, 2km, 100FX, SFP, 1310nm
AT-SPFX/15
Single-mode Fiber, 15km, 100FX, SFP, 1310nm
AT-SPFX/40
Single-mode Fiber, 40km, 100FX, SFP, 1310nm
AT-SPTX
Copper, GbE Small Form-factor Pluggable (SFP)
AT-SPSX
Multi-mode Fiber, GbE Small Form-factor Pluggable (SFP)
850nm
AT-SPLX10
Single-mode Fiber, 10km, GbE SFP, 1310nm
AT-SPLX40
Single-mode Fiber, 40km, GbE SFP, 1310nm
AT-SPLX40/1550
Single-mode Fiber, 40km, GbE SFP, 1550nm
AT
-SPZX80
Single-mode Fiber, 80km, GbE SFP, 1550nm
AT-SPZX80/xxxx
Single-mode Fiber, CWDM, 80km GbE SFP
CWDM wavelengths:
Where xxxx = 1470
1490
1510
1530
1550
1570
1590
1610
