Allied Telesis AT-FS713FC/xx User manual

AT-FS713FC/xx
AT-FS717FC/xx
10/100 Mbps Ethernet Switches
Installation Guide
PN 613-50268-00 Rev A

Copyright  2001 Allied Telesyn International Corp.
960 Stewart Drive Suite B, Sunnyvale CA 94085, USA
All rights reserved. No part of this publication may be reproduced without prior written permission
from Allied TelesynInternational Corp.
Ethernet is a registered trademark of Xerox Corporation. All other product names, company names,
logos or other designations mentioned herein are trademarks or registered trademarks of their
respective owners.
Allied Telesyn International Corp. reserves the right to make changes in specifications and other
information contained in this document without prior written notice. The information provided
herein is subject to change without notice. In no event shallAllied Telesyn International Corp. be
liable for any incidental, special, indirect, or consequential damages whatsoever, including but not
limited to lost profits,arising out of or related tothis manual or the information contained herein,
even if Allied Telesyn International Corp. has been advised of, known, or should have known, the
possibility of such damages.

iii
Electrical Safety and Emission Compliance
Statement
Standards: This product meets the following standards.
RFI Emission FCC Part 15 (Class A), EN55022 (Class A),
EN61000-3-2, EN61000-3-3
$ 1
WARNING:Inadomesticenvironmentthisproductmaycauseradiointerferenceinwhichcasetheuser
may be required to take adequate measures.
$ 2
Immunity EN55024
$ 3
Electrical Safety UL 1950 (UL/cUL), EN60950 (TUV), EN60825
$ 4
Important: Appendix A contains translated safety statements for installing this equipment. When you
see the
$ , go to Appendix A for the translated safety statement in your language.
Wichtig: Anhang A enthält übersetzte Sicherheitshinweise für die Installation dieses Geräts. Wenn Sie
$ sehen, schlagen Sie in Anhang A den übersetzten Sicherheitshinweis in Ihrer Sprache nach.
Vigtigt: TillægA indeholderoversattesikkerhedsadvarsler, dervedrørerinstallationafdetteudstyr. Når
Desersymbolet
$ ,skalDeslåopitillægAogfindedeoversattesikkerhedsadvarsleriDeresegetsprog.
Belangrijk: Appendix A bevat vertaalde veiligheidsopmerkingen voor het installeren van deze
apparatuur. Wanneer u de
$ ziet, raadpleeg Appendix A voor vertaalde veiligheidsinstructies in uw
taal.
Important: L'annexe A contient les instructions de sécurité relatives à l'installation de cet équipement.
Lorsque vous voyez le symbole
$ , reportez-vous à l'annexe A pour consulter la traduction de ces
instructions dans votre langue.
Tärkeää: Liite A sisältää tämän laitteen asentamiseen liittyvät käännetyt turvaohjeet. Kun näet
$ -
symbolin, katso käännettyäturvaohjetta liitteestäA.
Importante: l’Appendice A contiene avvisi di sicurezza tradotti per l’installazione di questa
apparecchiatura.Ilsimbolo
$ ,indicadiconsultarel’AppendiceAperl’avvisodisicurezzanellapropria
lingua.
Viktig: Tillegg A inneholder oversatt sikkerhetsinformasjon for installering av dette utstyret. Nårduser
$ , åpner dutil Tillegg A for åfinne den oversatte sikkerhetsinformasjonen påønsket språk.
Importante: O Anexo A contém advertências de segurança traduzidas para instalar este equipamento.
Quando vir o símbolo
$ , leia a advertência de segurança traduzida no seu idioma no Anexo A.
Importante: ElApéndiceAcontienemensajesdeseguridadtraducidosparalainstalacióndeesteequipo.
Cuando vea el símbolo
$ , vaya al Apéndice A para ver el mensaje de seguridad traducido a su idioma.
Obs! Bilaga A innehålleröversatta säkerhetsmeddelanden avseende installationen av denna utrustning.
När du ser
$ , skall du gåtill Bilaga A för att läsa det översattasäkerhetsmeddelandet påditt språk.
U.S. Federal Communications Commission
RADIATED ENERGY
Note: This equipment has been tested and found to comply with the limits for a Class A digital device
pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against
harmful interference when the equipment is operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance
with this instruction manual, may cause harmful interference to radio communications. Operation of
thisequipment in a residentialarea islikely to causeharmfulinterference inwhichcasethe user willbe
required to correct the interference at his own expense.
Note: Modifications or changes not expressly approved of by the manufacturer or the FCC, can void
your right to operate this equipment.
Industry Canada
This Class A digital apparatus meets all requirements of the Canadian Interference-Causing
Equipment Regulations.
Cet appareil numérique de la classe A respecte toutes les exigences du Règlement sur le matériel
brouilleur du Canada.

v
Table of Contents
Electrical Safety and Emission Compliance Statement ......................iii
Welcome to Allied Telesyn .........................................................................vii
Where to Find Web-based Guides ...................................................................vii
Document Conventions ....................................................................................vii
Contacting Allied Telesyn Technical Support................................................viii
Online Support .........................................................................................viii
Telephone and Fax Support.....................................................................viii
Technical Support E-mail Addresses ........................................................ ix
Returning Products ........................................................................................... ix
FTP Server......................................................................................................... ix
For Sales or Corporate Information .................................................................. x
Tell Us What You Think .................................................................................... x
Chapter 1
Overview .......................................................................................................... 1
Features .............................................................................................................. 4
Status LEDs ................................................................................................ 4
Twisted Pair Ports.............................................................................................. 5
Port Speed.................................................................................................... 5
Duplex Mode................................................................................................ 5
Auto MDI/MDI-X......................................................................................... 5
Fiber Optic Port.................................................................................................. 6
Port Speed.................................................................................................... 6
Duplex Mode................................................................................................ 6
MAC Address Table............................................................................................ 7
Store and Forward.............................................................................................. 7
Network Topologies ............................................................................................ 8
Workgroup Topology ................................................................................... 8
Ethernet Hub Workgroup Topology ........................................................... 9
Backbone Topology.................................................................................... 10

Table of Contents
vi
Chapter 2
Installing the Switch ...................................................................................11
Reviewing Safety Guidelines ...........................................................................11
Verifying the Package Contents ......................................................................12
Planning the Installation .................................................................................13
Selecting a Site .................................................................................................14
Installing the Switch On a Table or Desktop..................................................15
Wall-mounting the Switch ...............................................................................16
Warranty Registration .....................................................................................17
Chapter 3
Troubleshooting ...........................................................................................19
Appendix A
Technical Specifications ............................................................................21
Physical .............................................................................................................21
Temperature .....................................................................................................21
Electrical Rating ...............................................................................................21
Agency Certifications........................................................................................21
Fiber Optic Port Specifications ........................................................................22
Pinout Assignments..........................................................................................23
Appendix B
Translated Electrical Safety Emission Information ............................25
Appendix C
Technical Support Fax Order ...................................................................35
Incident Summary ............................................................................................35

vii
The guide contains instructions on how to install the AT-FS713FC/xx and
AT-FS717FC/xx Series Ethernet Switches.
Where to Find Web-based Guides
The Allied Telesyn web site at www.alliedtelesyn.com provides you with an
easy way to access the most recent documentation, software, and technical
information for all of our products. For product guides, select “Support &
Services” from our web site.
Document Conventions
This guide uses several conventions that you should become familiar with
before you begin to install the product.
Note
A note provides additional information.
Caution
A caution indicates that performing or omitting a specific action may
result in equipment damage or loss of data.
Warning
A warning indicates that performing or omitting a specific action may
result in bodily injury.
Welcome to Allied Telesyn

viii
Contacting Allied Telesyn Technical Support
You can contact Allied Telesyn technical support online or by telephone, fax,
or e-mail.
Online Support
You can request technical support online by filling out the Technical Enquiry
Form or by accessing the Knowledge Base. You can use the Knowledge Base to
submit questions to our technical support staff and review answers to
previously asked questions.
To access the Knowledge Base, select “Support & Services”, then select “Help”
from www.alliedtelesyn.com. To access the Technical Enquiry Form, select
“Contact Us”from our web site.
Telephone and Fax Support
For technical support via fax, please fill out the “Technical Support Fax
Order”on page 35 and send it to the appropriate location listed below.
Americas
United States, Canada, Mexico,
Central America, South America
Tel: [phone], option 4
Fax: [phone]
Germany
Germany, Switzerland, Austria, Eastern
Europe
Tel: [phone]
Fax: [phone]
Asia
Singapore, Taiwan, Thailand, Malaysia,
Indonesia, Korea, Philippines, China,
India, Hong Kong
Tel: [phone]
Fax: [phone]
Italy
Italy, Spain, Portugal, Greece, Turkey,
Israel
Tel: [phone]
Fax: [phone]
Australia
Australia, New Zealand
Tel: [phone]
Fax: [phone]
Japan
Tel: [phone]
Fax: [phone]
France
France, Belgium, Luxembourg,
The Netherlands, Middle East, Africa
Tel: [phone]
Fax: [phone]
United Kingdom
United Kingdom, Denmark, Norway,
Sweden, Finland, Iceland
Tel: [phone]
Fax: [phone]

AT-FS713FC/xx and AT-FS717FC/xx Series Installation Guide
ix
Technical Support E-mail Addresses
United States and Canada
[e-mail]
Latin America, Mexico, Puerto Rico, Caribbean, and Virgin Islands
[e-mail]
Europe
[e-mail]
Returning Products
Products for return or repair must first be assigned a Return Materials
Authorization (RMA) number. A product sent to Allied Telesyn without a
RMA number will be returned to the sender at the sender’s expense.
To obtain an RMA number, contact Allied Telesyn’s Technical Support at one
of the following locations:
FTP Server
If you need management software for an Allied Telesyn managed device and
you know the file name of the software, you can download the software by
connecting directly to our FTP server at ftp.alliedtelesyn.com. At login,
enter ‘anonymous’as the user name and your e-mail address as the password.
United States and Canada
Toll-free: 1-800-428-4835, option 4
Fax: [phone]
Europe, Africa, and Middle East
Tel: [phone]
Fax: [phone]
Latin America, Caribbean, and Virgin
Islands
Tel: International code + 425-481-3852
Fax: International code + 425-481-3895
Puerto Rico
Tel: [phone], ext 3852 or
1-800-424-4284, ext 3852
Mexico
Toll-free: 800-424-5012, ext 3852
Fax: International code + 425-481-3895
Asia and Southeast Asia
Tel: [phone]
Fax: [phone]
Australia
Toll-free: 1-800-000-880
Fax: [phone]
New Zealand
Toll-free: 0800-45-5782

x
For Sales or Corporate Information
You can contact Allied Telesyn for sales or corporate information at the
location listed below:
Allied Telesyn International Corp.
19800 North Creek Parkway, Suite 200
Bothell, WA 98011
Tel: [phone]
Fax: [phone]
Tell Us What You Think
If you have any comments or suggestions on how we might improve this or
other Allied Telesyn documents, please fill out the General Enquiry Form
online. This form can be accessed by selecting “Contact Us”at
www.alliedtelesyn.com.

1
Chapter 1
Overview
The AT-FS713FC/xx and AT-FS717FC/xx Series Fast Ethernet Switches
include the following models:
These units are unmanaged Layer 2 switches. These switches can be used as a
‘bridge’between the different workgroups in your network or they can be used
to create small workgroups with dedicated 10/100 Mbps links to your network
devices. They can also be used to connect to other Ethernet switches so that
they can be part of a larger Ethernet network.
The AT-FS713FC/xx Series Switches feature twelve 10/100Base-TX twisted
pair ports and a 100Base-FX fiber optic port. The twisted pair ports have a
RJ-45 connector and a maximum operating distance of 100 meters (328 feet).
The fiber optic port has a FJ, LC, MT, SC, ST, or VF connector, depending on
the model, and a maximum operating distance of 2 kilometers (1.2 miles).
The AT-FS717FC/xx Series Switches feature sixteen 10/100Base-TX twisted
pair ports and a 100Base-FX fiber optic port. The twisted pair ports have a
RJ-45 connector and a maximum operating distance of 100 meters (328 feet).
The fiber optic port has a FJ, LC, MT, SC, ST, or VF connector, depending on
the model, and a maximum operating distance of 2 kilometers (1.2 miles).
The fiber optic port operates at 100 Mbps and features half- and full-duplex
operation. The twisted pair port operates at 10 or 100 Mbps and auto-
negotiates the duplex mode.
The AT-FS713FC/xx and AT-FS717FC/xx Series Switches are easy to install
and do not require software configuration or management.
qAT-FS713FC/FJ qAT-FS717FC/FJ
qAT-FS713FC/LC qAT-FS717FC/LC
qAT-FS713FC/MT qAT-FS717FC/MT
qAT-FS713FC/SC qAT-FS717FC/SC
qAT-FS713FC/ST qAT-FS717FC/ST
qAT-FS713FC/VF qAT-FS717FC/VF

2
Figure 1 illustrates the front and back panels of an AT-FS713FC/xx Series
Switch.
Figure 1 AT-FS713FC/xx Series Switch (AT-FS713FC/MT Model)
Figure 2 illustrates the front and back panels of an AT-FS717FC/xx Series
Switch.
Figure 2 AT-FS717FC/xx Series Switch (AT-FS717FC/ST Model)
1197531
121313 10 8 6 4 2
LNK/
ACT
100M
LNK/
ACT
LNK/
ACT
100M PWR
100FX
DUPLEX
FD
100FX 10/100TX
HALF
FULL
AT-FS713FC/MT
10Base-T/ 100Base-TX 12 Port Fast Ethernet Switch with 100FX Uplink
1357911
24681012 13
120-240V 50-60Hz 0.5A
Front Panel
Back Panel
Duplex Switch
Power Plug
LEDs
10/100Base-TX Ports 100Base-FX Port
111315 9 7 5 3 1
12141617 108642
LNK/
ACT
100M
LNK/
ACT
100M PWR
LNK/
ACT
FD
100FX 10/100TX
17
100FX
DUPLEX
HALF
FULL
AT-FS717FC/ST
10Base-T/ 100Base-TX 16 Port Fast Ethernet Switch with 100FX Uplink
1357 9111315
2 4 6 8 10 12 14 16
120-240V 50-60Hz 0.5A
17
TX RX
Front Panel
Back Panel
Duplex Switch
Power Plug
LEDs
10/100Base-TX Ports 100Base-FX Ports

AT-FS713FC/xx and AT-FS717FC/xx Series Installation Guide
3
Table 1 lists the maximum operating distances for the AT-FS713FC/xx Series
Switches.
Table 1 AT-FS713FC/xx Series Maximum Operating Distances
Table 2 lists the maximum operating distances for the AT-FS717FC/xx Series
Switches.
Table 2 AT-FS717FC/xx Series Maximum Operating Distances
Model
10/100Base-TX 100Base-FX
Connector Maximum
Operating Distance Connector Maximum
Operating Distance
AT-FS713FC/FJ RJ-45 100 m (328 ft) FJ 2 km (1.2 mi)
AT-FS713FC/LC RJ-45 100 m (328 ft) LC 2 km (1.2 mi)
AT-FS713FC/MT RJ-45 100 m (328 ft) MT 2 km (1.2 mi)
AT-FS713FC/SC RJ-45 100 m (328 ft) SC 2 km (1.2 mi)
AT-FS713FC/ST RJ-45 100 m (328 ft) ST 2 km (1.2 mi)
AT-FS713FC/VF RJ-45 100 m (328 ft) VF 2 km (1.2 mi)
Model
10/100Base-TX 100Base-FX
Connector Maximum
Operating Distance Connector Maximum
Operating Distance
AT-FS717FC/FJ RJ-45 100 m (328 ft) FJ 2 km (1.2 mi)
AT-FS717FC/LC RJ-45 100 m (328 ft) LC 2 km (1.2 mi)
AT-FS717FC/MT RJ-45 100 m (328 ft) MT 2 km (1.2 mi)
AT-FS717FC/SC RJ-45 100 m (328 ft) SC 2 km (1.2 mi)
AT-FS717FC/ST RJ-45 100 m (328 ft) ST 2 km (1.2 mi)
AT-FS713FC/VF RJ-45 100 m (328 ft) VF 2 km (1.2 mi)

4
Features
qLEDs for unit and port status
qAuto MDI/MDI-X for the twisted pair ports
qHalf- or full-duplex operation on the fiber optic port
qAuto-negotiation of the duplex mode on the twisted pair ports
qRJ-45 twisted pair connectors
qFJ, LC, MT, SC, ST, or VF fiber optic connector
qStore and forward Ethernet packet handling
qMAC address table with a capacity of 4,000 addresses
Status LEDs
Table 3 defines the LEDs on the AT-FS713FC/xx and AT-FS717FC/xx Series
Switches.
Table 3 LEDs
LED Color Description
PWR Green The switch is receiving power.
FD Green
OFF
The fiber optic port is operating in full-duplex mode.
The fiber optic port is operating in half-duplex mode.
100M Green
OFF
The twisted pair port is operating at 100 Mbps.
The twisted pair port is operating at 10 Mbps.
LNK/ACT Green
Blinking Green
OFF
The port has established a valid link with the end-node
connected to the port.
Activity is detected on the port.
The port has not established a link with the end-node.

AT-FS713FC/xx and AT-FS717FC/xx Series Installation Guide
5
Twisted Pair Ports
The AT-FS713FC/xx and AT-FS717FC/xx Series Switches have twelve and
sixteen 10/100Base-TX twisted pair ports, respectively.
Port Speed
The twisted pair ports are compliant with the 10Base-T and 10Base-TX
standards and are capable of either 10 Mbps or 100 Mbps operation. The ports
are IEEE 802.3u auto-negotiation compliant. The speed of the port is set
automatically by the switch after determining the speed of the end-node
connected to the port. Auto-negotiation is designed to ensure that each port on
the switch and the end-node connected to each port are operating at the same
speed and that they are communicating at the highest possible common speed
of the devices.
Duplex Mode
The twisted pair ports on the switches can operated in either half- or full-
duplex mode and are set automatically through auto-negotiation. If the end-
node is capable of full-duplex mode, the twisted pair port is set to full-duplex.
If the end-node is capable of half-duplex mode, the port is set to half-duplex.
Auto MDI/MDI-X
An RJ-45 twisted pair port on a 10 Mbps or 100 Mbps Ethernet network
device can have one of two possible wiring configurations: MDI or MDI-X. The
RJ-45 port on a PC, router, or bridge is typically wired as MDI, while the
twisted pair port on a switch or hub is usually MDI-X.
To connect two 10 Mbps or 100 Mbps network devices together that have
dissimilar port wiring configurations, such as MDI to MDI-X, you would
usually use a straight-through twisted pair cable. To connect two network
devices that have the same wiring configuration, such as MDI to MDI, you
would usually use a crossover cable.
The AT-FS713FC/xx and AT-FS717FC/xx Series Switches feature automatic
MDI/MDI-X. Each port automatically determines the configuration of the port
on the device to which it is connected and then configures itself appropriately.
For example, if a port on a switch is connected to a port on a bridge, which is
typically wired as MDI, the port on the switch automatically configures itself
as MDI-X. This feature allows you to use either crossover cables or straight-
through cables when connecting devices to these switches.

6
Fiber Optic Port
The AT-FS713FC/xx and AT-FS717FC/xx Series Switches have one
100Base-FX fiber optic port. The fiber optic port has a FJ, LC, MT, SC, ST, or
VF connector, depending on the model.
Port Speed
The fiber optic port is compliant with the 100Base-FX standard and has a
fixed operating speed of 100 Mbps. The end-node connected to the fiber optic
port on the switch must also be able to operate at 100 Mbps.
Duplex Mode
Duplex mode refers to the way an end-node sends and receives data on the
network. An end-node can operate in either half- or full-duplex mode,
depending on its capabilities. An end-node that is operating in half-duplex
mode can either send data or receive data, but it cannot do both at the same
time. An end-node that is operating in full-duplex mode can send and receive
data simultaneously. The best network performance is achieved when an end-
node can operate at full-duplex, since the end-node is able to send and receive
data simultaneously.
The AT-FS713FC/xx and AT-FS717FC/xx Series Switches can operate in
either half- or full-duplex mode. To set the duplex mode on the fiber optic port,
slide the 100FX DUPLEX switch UP (half-duplex) or DOWN (full-duplex). The
switch can operate with end-nodes capable of either half-duplex mode or full-
duplex mode.

AT-FS713FC/xx and AT-FS717FC/xx Series Installation Guide
7
MAC Address Table
Up to 4,000 MAC addresses can be stored in the switch’s MAC address table.
The switch’s self-learning feature will learn all new addresses in real-time
after power-up. If the source address of an incoming packet is not found in the
MAC address table, the switch will update the table with the new address.
The switch also has an automatic address aging feature that will delete a
source address from the table if it has not seen a frame from the end-node
with that address within five minutes. This prevents the table from becoming
filled with addresses of end-nodes that are no longer active.
The switch forwards all multicast, broadcast, and unicast packets when the
MAC address table has exceeded its storage limit.
Store and Forward
The AT-FS713FC/xx and AT-FS717FC/xx Series Switches support store and
forward switching at Fast Ethernet full-wire speed in 100 Mbps, half- or full-
duplex mode. Packets entering each port are stored in buffers. Once the full
packet is received, the switch will forward or discard the packet, depending on
its destination address and error status. This ensures that only error-free
packets destined for another segment will be transferred across the switch,
reducing network load. For example, if the packet entering from Port 1 is
destined for an end-node on Port 2, the switch forwards the frame if the frame
does not contain any errors. If the packet from Port 1 is destined for an end-
node also connected to Port 1, the packet is discarded.
The switch will discard CRC errors, misaligned, runt, and under-oversized
packets. When the packet has dribble bits at the end, the switch will truncate
to octet boundary and check for a good FCS before forwarding.

8
Network Topologies
The AT-FS713FC/xx or AT-FS717FC/xx Series Switches can be used in
several network topologies. Some of these topologies are described below.
Workgroup Topology
Figure 3 illustrates a workgroup topology where each end-node is connected
directly to a port on an AT-FS713FC/SC switch, giving each end-node a
dedicated 10 Mbps or 100 Mbps link.
Figure 3 Power Workgroup Topology
1357911
TX RX
24681012 13
120-240V 50-60Hz 0.5A
AT-FS713FC/SC
100 Mbps
10 Mbps

AT-FS713FC/xx and AT-FS717FC/xx Series Installation Guide
9
Ethernet Hub Workgroup Topology
Figure 4 illustrates an Ethernet hub workgroup topology where an
AT-FS713FC/SC is used to connect together four 10/100 Mbps Ethernet hubs.
This allows the switch to function as a bridge between the different
workgroups by controlling the flow of data between the workgroups. The
switch transfers an Ethernet frame from hub-to-hub only when the
destination end-node for the frame is on a different hub than the end-node
that originated the frame. This reduces the amount of unnecessary data traffic
in each workgroup. This frees up bandwidth and improves network
performance.
Figure 4 Ethernet Hub Workgroup Topology
1357911
TX RX
24681012 13
120-240V 50-60Hz 0.5A
54321
6
7
8
54321
6
7
8
54321
6
7
8
54321
6
7
8
AT-FS713FC/SC
Ethernet Hub Ethernet Hub
Ethernet Hub Ethernet Hub
100 Mbps
10 Mbps

10
Backbone Topology
If your network consists of several AT-FS713FC/xx or AT-FS717FC/xx Series
Switches, then you will probably want to connect them together to form an
integrated network. Here the fiber optic ports can be extremely useful. You
can use the ports to create a fiber optic backbone. With a maximum operating
distance of 2 kilometers (1.2 miles), the ports can be used to connect together
switches that are physically far apart. Figure 5 shows an AT-FS713FC/ST
switch and an AT-FS717FC/ST switch interconnected using the fiber optic
ports to create a backbone topology.
Figure 5 Backbone Topology
1357 9111315
2468 10121416
120-240V 50-60Hz 0.5A
17
TX RX
1357911
TX RX
2 4 6 8 10 12 13
120-240V 50-60Hz 0.5A
AT-FS713FC/ST
AT-FS717FC/SC
100 Mbps (Fiber Optic)
100 Mbps (Twisted Pair)
10 Mbps
