Datasheet | Switches
AT-8000S/48
Layer 2 Stackable Fast Ethernet Switch
A
T-8000S/48
48-port stackable 10/100TX L2 switch
with 2 active SFP bays (unpopulated) and
2standby 10/100/1000T ports (RJ-45)
Overview
One of a series of stackable switches from
Allied Telesis, the AT-8000S/48 provides high
performance Layer 2 switching in an affordable
fixed configuration platform.This switch offers
48 10/100 ports, two fixed 1Gbps SFP slots
plus two integrated stacking connectors that
deliver a total of 4Gbps stacking bandwidth.The
stacking capability integrated into this platform
is configured as a resilient ring topology
designed to provide high reliability and simpli-
fied management for higher port density
applications.
Ideal Branch Office and Wiring
Closet Connectivity
Powerful line rate performance and stackability
make this switch ideal for branch offices or the
wiring closet of larger offices. The state-of-the-
artQoS capability of this product ensures reli-
able delivery of advanced network services
such as voice while effectively controlling the
continually increasing traffic needs found in
today’s networks.
Easy Access Networking
Featuring an industry standard CLI and Allied
Telesis’ intuitive yet fully featured WEB interface
the advanced features of the 8000S/48 are
accessible to a wide range of system adminis-
trators. The well known CLI and WEB inter-
faces significantly reduce learning time and
minimize the cost of deployment.
Secure Management
Only authorized administrators can access the
management interface of the AT-8000S series.
Protocols such as SSL, SSH and SNMP v3
facilitate this protection of your networkwith
local or remote connections.
Securing the Network Edge
To ensure the protection of your data, it is
important to control access to your network.
Protocols such as 802.1x portbased authenti-
cation guarantee that only known users are
connected to the network. Unknown users
who physically connect can be isolated to a
pre-determined part of your network offering
guests such benefits as Internet access while
ensuring the integrity of your private network
data.
Key Features
Easy,Well Known Management
•Industry Standard CLI
•Simple intuitive, full features Allied Telesis
Web Interface
•Secure encrypted WEB and CLI management
with SSH v2 and SSL
•SNMP
Affordable Truly Stackable 10/100
Switching Platform
•Single IP address Stack management
•4Gig Resilient Ring Stacking Architecture
•Across Stack Link Aggregation
•Across Stack VLAN configuration
•Across Stack Port Mirroring
•Redundant standbystack master
All the QoS Needed in the Wiring Closet
for Today’s Voice and Data Networking
•8Priorities assigned to 4 queues
•802.1p for Layer 2 QoS
•DSCP (Diffserv) for Layer 3 QoS
•802.1p to DSCP remarking traffic ready for
transport to the Layer 3 core of the network
Securing the Network at its Most
Vulnerable Point
•802.1x and RADIUS network login: for advanced
control of user authentication and accountability
•Guest VLAN: to ensure visitors or unauthorized
users connect only to services defined by IT. E.g.
Internet
•TACACS+: for ease of management security
administration

Allied Telesis www.alliedtelesis.com
AT-8000S/48 |Layer 2 Stackable Fast Ethernet Switch
System Configuration
WxDxH 440mm x 257mm x 43.2mm
(17.32” x 10.11” x 1.70”)
Weight 3.38kg (7.45lb)
Mounting 19” rack-mountable hardware
included
System Capacity
64MB RAM
16MB Flash Memory
400Mhz CPU
Up to 4,096 VLAN ID
8,000 MAC address
Performance
Wire speed switching on all Ethernet ports
14,880pps for 10Mbps Ethernet
148,800pps for 100Mbps fast Ethernet
1,488,000pps for 1000Mbps Gigabit Ethernet
Ethernet throughput 6.8Gbps
Chipset switching capacity 17.6Gbps
MTBF 314,322 hours
Store and forward mode
Non blocking switch fabric
Auto-MDI/MDI-X
Port speed
10/100-TX RJ-45
10/100/1000TX RJ-45
100-FX, 1000-SX, 1000-LX SFP slot
RS232 DB9 pin, male port
Internal power supply and fan
Interface Standards
802.3 10Base-T & 10Base-FL
802.3u 100Base-TX & 100base-FX
802.3z 1000base-SX
802.3ab 1000Base-T
General Standards
802.1d Bridging
802.3x BackPressure/ Flow Control
Redundancy Standards
802.1D Spanning Tree Protocol
802.1W Rapid Spanning Tree
802.1s Multiple Spanning Tree
802.3ad LACP Link Aggregation
(with up to 8 members per group
and up to 8 groups per device)
Static port trunk
Quality of Services (QoS)
QoS in layer 2 (802.1p compliant Class of Service)
Traffic prioritization using 802.1p, ToS, DSCP fields
Map 802.1p priorities to CoS queues to prioritize traffic
at Egress.
Strict Scheduling and Weighted Round Robin
VLANs
IEEE 802.1Q VLAN Tagging
Up to 256 VLANs
Port-based VLANs
MAC-based VLANs
Private VLANs
GARP VLAN Registration Protocol (GVRP)
Multicast Standards
RFC1112 IGMP snooping (ver. 1)
RFC2236 IGMP snooping (ver. 2)
RFC 3376 IGMP snooping (ver.3)*
*Future Release
Management and Monitoring
WEB, CLI, Serial
RFC 1157 SNMPv1/v2c
RFC 2570 SNMPv3
RFC1213 MIB-II
RFC 1215 TRAP MIB
RFC1493 Bridge MIB
RFC 2863 Interfaces group MIB
RFC 1643 Ethernet like MIB
RFC 1757 RMON 4 groups:
Stats, History, Alarms, Events
RFC 2674 802.1Q MIB
RFC 1866 HTML
RFC 2068 HTTP
RFC 854 Telnet
RFC 783 TFTP
IP address allocation
RFC 951/ RFC 1542 BootP/ DHCP
Manual
RFC 2030 SNTP, Simple Network Time Protocol
Syslog Event
Dual Software Images
Stacking
Up to 6 units
Single chip appearance
Single IP management
Backup master
Full duplex link with 2Gbps performance
Trunking across stack
Port mirroring across stack
VLAN across stack
Security
Management Security: user name and
password protection
SSHv2 for Telnet management
SSLv3 for WEB management
RFC 1492 TACACS+
RFC 2138 RADIUS Authentication
IEEE 802.1x Port-based network access control
Guest VLANs
Fault Protection
Broadcast Storm Control

USA Headquarters |19800 North Creek Parkway |Suite 200 |Bothell |WA 98011 |USA |T: [phone] |F: [phone]
European Headquarters |Via Motta 24 |6830 Chiasso |Switzerland |T: +41 91 69769.00 |F: +41 91 69769.11
Asia-Pacific Headquarters |11 Tai Seng Link |Singapore |534182 |T: [phone] |F: [phone]
www.alliedtelesis.com
©2006 AlliedTelesis Inc. All rights reserved. Information in this document is subject to change without notice. All company names, logos, and product designs that are trademarks or registered trademarks are the property of their respective owners. 617-000176 Rev. C
AT-8000S/48 |Layer 2 Stackable Fast Ethernet Switch
Power Characteristics
Voltage input 100- 240VAC
Voltage output 12VDC
Current 1.5A
Power consumption 54W
Heat dissipation 184.41 BTU/hour
Clock Frequency 166MHz
Environmental Specifications
Operating Temp 0°C to 45°C (32F to 113F)
Storage Temp -25°C to 70°C (-13F to 158F)
Relative Humidity 10% to 90% non-condensing
Storage Humidity 5% to 95% non-condensing
Operating Altitude maximum 3,000m (9,843ft)
Electrical/ Mechanical Approvals
Safety UL 1950 (UL/cUL), EN60950 (TUV)
EMI FCC Class A, EN55022 Class A,
VCCI Class A, C-Tick, EN61000-3-2,
EN61000-3-3
Immunity EN55024
RoHS compliant
Package Description
One AT-8000S/48 switch
Power cord AC
Rackmount kit
Rubber feet for desktop installation
RS232 management cable
Stacking cable
Install guide and user guide in CD
Country of Origin
China
Ordering Information
AT-8000S/48-xx
48-port stackable 10/100TX L2 switch with
2active SFP bays (unpopulated) and 2 standby
10/100/1000T ports (RJ-45)
Where xx = 10 for U.S. power cord
20 for no power cord
30 for U.K. power cord
40 for Australia power cord
50 for Europe power cord
