Datasheet | Switches
AT-FS708
Unmanaged Fast Ethernet Switches
AT-FS708-xx
8-port 10/100TX unmanaged switch
with internal power supply
High Performance
Providing powerful 10/100 switching solutions
for desktop and small network environments,
the Allied Telesis AT-FS700 series of unmanaged
switches features full auto-negotiating 10/100
ports.These ports enable the switches to
detect the speed and duplex modes of attached
devices, enabling them to automatically configure
for the best possible performance.
Flexibility
Available as 5-, 8-, 16-, or 24-port models, the
ATFS700 Series meets a multitude of power
requirements with both internal and external
power-supply options. Also, wall-, desk-, and
rack-mounting options giveusers ultimate
flexibility in selecting the model that meets
their physical deployment requirements.
Simplified Installation
Fully auto-configuring AT-FS700 Series switches
require minimal set-up by the user. Auto-sensing
ports enable seamless and simple connectivity
between existing 10Mbps Ethernet and 100Mbps
Fast Ethernet UTP devices—and all units can
be installed in minutes. Every AT-FS700 Series
models is equipped with MDI/MDIX ports for
simple connection to other hubs and switches.
Finally, easy to read front panel LEDs show ongoing
switch status and simplify troubleshooting.
Quality & Reliability
Allied Telesis is a worldwide leader in unmanaged
Ethernet switches. Shipping more than 250,000
unmanaged switches each year, Allied Telesis
offers proven reliability and industry recognized
quality.
Key Features
•810/100TX ports
•Wirespeed technology
•Non-blocking architecture
•Auto-negotiation ports
•Auto MDI/MDIX ports
•Transparent to VLAN packets
•Half- & full-duplex flowcontrol
•External or internal power supply option
•Sturdy metal case
•Rack mountable

USA Headquarters |19800 North Creek Parkway |Suite 200 |Bothell |WA 98011 |USA |T: [phone] |F: [phone]
European Headquarters |Via Motta 24 |6830 Chiasso |Switzerland |T: +41 91 69769.00 |F: +41 91 69769.11
Asia-Pacific Headquarters |11 Tai Seng Link |Singapore |534182 |T: [phone] |F: [phone]
www.alliedtelesis.com
©2007 AlliedTelesis Inc. All rights reserved. Information in this document is subject to change without notice. All company names, logos, and product designs that are trademarks or registered trademarks are the property of their respective owners. 617-00572-00 Rev. C
AT-FS708 |Unmanaged Fast Ethernet Switches
Performance
14,800pps for 10Mbps Ethernet
148,000pps for 100Mbps Fast Ethernet
MAC Addresses Up to 1K
Packet Buffer 256K
Half/Full-Duplex
Auto Negotiation
Auto MDI/MDI-X on all ports
Interface Connections
10/100TX RJ-45
Power Characteristics
Frequency 50 to 60Hz
100-240vAC, .4A
Environmental Specifications
Operating Temp 0ºC to 40ºC (32ºF to 104ºF)
Non-operating Temp -25ºC to 70ºC (-13ºF to 158ºF)
Operating Humidity 5% to 80% non-condensing
Storage Humidity 5% to 95% non-condensing
Technical Specifications
Physical Characteristics
Dimensions 3.6cm x 24.9cm x 11.6cm
(1.4" x 9.8" x 4.6")
Weight 0.9kgs (2.0lbs)
Wall-mount or Desktop
All units come with Wall & 19” Rack mount brackets
Standards & Compliance
IEEE 802.3 10T Ethernet
IEEE 802.3u 100TX Fast Ethernet
IEEE 802.3x Flow Control
Electrical/Mechanical Approvals
UL 1950
CSA 22.2 No. 950
FCC/EN55022 Class B
VCCI Class B
EN60950 (TUV)
EN55024
CE
Ordering Information
AT-FS708-xx
8-port 10/100TX unmanaged switch with
internal power supply
Where xx = 10 for U.S. power cord
=20 for no power cord
=30 for U.K. power cord
=40 for Australia power cord
=50 for Europe power cord
