3 General aspects of the API
The purpose of AVT Vimba APIs is to enable programmers to interact with AVT cameras independent of the
interface technology (1394, Gigabit Ethernet). To achieve this, Vimba API utilizes different transport
layers to connect to the various camera interfaces and is therefore considered generic in terms of camera
interfaces. For accessing functionality of either Vimba or the connected cameras, you have two ways of
control: the generic functions on the one hand and feature access to Vimba, the transport layers, and the
cameras on the other. This manual deals only with the functional part.
4 Module Version
As new features are introduced to Vimba API, your software remains backward compatible. Use
VmbVersionQuery to check the version number of Vimba C API.
5 Module Initialization
Using Vimba API always begins with a call to VmbStartup. Before using any Vimba API functions (other
than VmbVersionQuery), you must initialize the API with this call. When you have finished using Vimba
API, call VmbShutdown to free resources. These two API functions must always be paired. It is possible,
although not recommended, to call the pair several times within the same program.
Vimba C API - Programmer's Manual
7 / 19

6 List available cameras
6 List available cameras
For a quick start see ListCameras example of the Vimba SDK.
VmbCamerasList will enumerate all cameras recognized by the underlying transport layers. With this
command, the programmer can fetch all static details of a camera such as its ID, its model and vendor
name or the ID of the interface (e.g. the network or 1394 adapter) it is connected to. For 1394 cameras
this attempt is straightforward, as opposed to GigE; due to its asynchronous nature, listing cameras over
the network is a two-step process. First a device discovery request has to be sent out before Vimba API
can be aware of all GigE devices that answered that request. Vimba API puts the developer in charge of
deciding how to send out discovery packets. However, this can be achieved through the command features
GeVDiscoveryAllOnce and GeVDiscoveryAllAuto, whereby the latter constantly emits discovery commands.
To stop discovery, use the command feature GeVDiscoveryAllNone. Note that these features can be applied
to all network interfaces as well as to one particular interface only. See Listing 1for an example.
Listing 1: Get Cameras
1bool bGigE ;
2VmbUint32_t nCount ;
3VmbCameraInfo_t *pCameras ;
4
5// We ask Vimba for the presence of a GigE transport layer
6VmbError_t err = VmbFeatureBoolGet( gVimbaHandle , " GeVTLIsPresent ", &bGigE );
7if ( VmbErrorSuccess == err )
8{
9if (true == bGigE )
10 {
11 // We query all network interfaces using the global Vimba handle
12 err = VmbFeatureCommandRun ( gVimbaHandle , " GeVDiscoveryAllOnce" );
13 // Wait for the discovery packets to return
14 Sleep( 200 );
15 }
16 }
17 if ( VmbErrorSuccess == err )
18 {// Get the amount of connected cameras
19 err = VmbCamerasList( NULL , 0, &nCount , sizeof * pCameras );
20
21 if ( VmbErrorSuccess == err )
22 {
23 // Allocate accordingly
24 pCameras = new VmbCameraInfo_t[ nCount ];
25 // Get the cameras
26 err = VmbCamerasList( pCameras , nCount , &nCount , sizeof *pCameras );
27 // Print out each camera 's name
28 for ( VmbUint32_t i=0; i<nCount ; ++i )
29 {
30 std :: cout << pCameras [i ]. ca meraNa me << std :: endl ;
31 }
32 }
33 }
The VmbCameraInfo_t struct provides the entries listed in Table 1for obtaining information about a
camera.
To get notified whenever a camera is detected, disconnected, or changes its open state, use
VmbFeatureInvalidationRegister to register a callback that gets executed on the according event.
Vimba C API - Programmer's Manual
8 / 19

6 List available cameras
Struct Entry Purpose
const char* cameraIdString The unique ID
const char* cameraName The name
const char* modelName The model name
const char* serialString The serial number
VmbAccessMode_t permittedAccess The mode to open the camera
const char* interfaceIdString The ID of the interface the camera is connected to
Table 1: VmbCameraInfo_t struct
Use the global Vimba handle for registration. The function pointer to the callback function has to be of
type VmbInvalidationCallback*. Note that the continuous sending of discovery packages has to be
turned on to enable Vimba to recognize GigE camera events. Please note that VmbShutdown blocks until
all callbacks have finished execution. Below you find a list of functions that cannot be called within the
callback routine.
•VmbStartup
•VmbShutdown
•VmbFeatureIntSet (and any other VmbFeature*Set function)
•VmbFeatureCommandRun
Vimba C API - Programmer's Manual
9 / 19

7 Opening a camera
7 Opening a camera
A camera must be opened to control it and to capture images. To open a camera, call VmbCameraOpen
and provide the ID of the camera as well as the desired access mode. GigE cameras may also be identified
by their IP or MAC address. When a camera has been opened successfully, a handle for further access is
returned. An example for opening a camera retrieved from the camera list is shown in Listing 2.
Listing 2: Open Camera
1VmbCameraInfo_t *pCameras ;
2VmbHandle_t hCamera ;
3
4// Get all known cameras as described in chapter " List available cameras"
5
6// Open the first camera
7if ( VmbErrorSuccess == VmbCameraOpen ( pCameras [0]. cameraIdString ,
8VmbAccessModeFull , hCamera ) )
9{
10 std ::cout << "Camera opened , handle [" << hCamera << "] retrieved .";
11 }
Listing 3shows how to close a camera using VmbCameraClose and the previously retrieved handle.
Listing 3: Close Camera
1if ( VmbErrorSuccess == VmbCameraClose( hCamera ) )
2{
3std :: cout << "Camera closed ." << std::endl;
4}
Vimba C API - Programmer's Manual
10 / 19

8 Feature Access
8 Feature Access
For a quick start see ListFeatures example of the Vimba SDK.
GenICam-compliant features control and monitor various aspects of the drivers and cameras. For more
details on features see the Vimba SDK Features, the 1394 Transport Layer Feature Description or the GigE
Vision Transport Layer Feature Description.
There are several feature types which have type-specific properties and allow type-specific functionality:
Integer, Float, Enum, String, Boolean, Raw data. Additionally, since not all the features are available all
the time, there is a general necessity for querying the accessibility of features. Vimba API provides its
own set of access functions for every feature data type. The data type of a feature as well as additional
static properties of a feature are held in the VmbFeatureInfo_t struct.
To start continuous acquisition, set the feature AcquisitionMode to Continuous and run the command
feature AcquisitionStart as shown in Listing 4.
Listing 4: Acquisition Start
1VmbHandle_t hCamera ;
2
3// Open the camera as shown in chapter " Opening a camera"
4
5if ( VmbErrorSuccess == VmbFeatureEnumSet ( hCamera , " AcquisitionMode ",
6"Continuous " ))
7{
8if ( VmbErrorSuccess = VmbFeatureCommandRun ( hCamera , " AcquisitionStart " ))
9{
10 std :: cout << "Acquisition successfully started" << std :: endl;
11 }
12 }
To read the image size in bytes, see Listing 5.
Listing 5: Payload Size
1VmbHandle_t hCamera ;
2
3// Open the camera as shown in chapter " Opening a camera"
4
5VmbInt64_t nPayloadSize;
6
7if ( VmbErrorSuccess == VmbFeatureIntGet ( hCamera , " PayloadSize ",
8&nPayloadSize ))
9{
10 std :: out << nPayloadSize << std::endl;
11 }
To simply query all available features of a camera, use VmbFeaturesList. This list does not change
while the camera is opened as shown in Listing 6.
Vimba C API - Programmer's Manual
11 / 19

8 Feature Access
Listing 6: Get Features
1VmbFeatureInfo_t *pFeatures ;
2VmbUint32_t nCount = 0;
3VmbHandle_t hCamera ;
4
5// Open the camera as shown in chapter " Opening a camera"
6
7// Get the amount of features
8VmbError_t err = VmbFeaturesList ( hCamera , NULL , 0, &nCount , sizeof * pFeatures );
9
10 if ( VmbErrorSuccess == err && 0 < nCount )
11 {
12 // Allocate accordingly
13 pFeatures = new VmbFeatureInfo_t[ nCount ];
14
15 // Get the features
16 err = VmbFeaturesList ( hCamera , pFeatures , nCount , &nCount ,
17 sizeof *pFeatures );
18
19 // Print out their name and data type
20 for (int i=0; i< nCount ; ++i )
21 {
22 std :: cout << "Feature " << pFeatures[i].name;
23 std :: cout << " of type : " << p Features [i ]. featur eDa taT ype << std :: endl ;
24 }
25 }
Table 2introduces basic features of all cameras. A feature has a name, a type, and access flags such as
read-permitted and write-permitted.
Feature Type Access Flags Description
AcquisitionMode Enumeration R/W The acquisition mode of the camera. Value set: Con-
tinuous, SingleFrame, MultiFrame.
AcquisitionStart Command Start acquiring images.
AcquisitionStop Command Stop acquiring images.
PixelFormat Enumeration R/W The image format. Possible values are e.g.: Mono8,
RGB8Packed, YUV411Packed, BayerRG8, …
Width Uint32 R/W Image width, in pixels.
Height Uint32 R/W Image height, in pixels.
PayloadSize Uint32 R Number of bytes in the camera payload, including
the image.
Table 2: Basic features found on all cameras
Make sure to set the PacketSize feature of GigE cameras to a value supported by your network card. The
command feature GVSPAdjustPacketSize configures GigE cameras to use the largest possible packets.
Please note that the automatic adjustment might not lead to the expected results in a multiple camera
scenario (many cameras connected to one GigE interface). Here the available bandwidth has to be shared
between all cameras. See the feature StreamBytesPerSecond for this. Furthermore, the maximum packet
Vimba C API - Programmer's Manual
12 / 19

8 Feature Access
size might not be available by all connected cameras. If you experience problems streaming even when
the available bandwidth is equally shared between all cameras, try to reduce the packet size.
To get notified whenever a feature's value changes, use VmbFeatureInvalidationRegister to
register a callback that gets executed on the according event. For camera features, use the camera
handle for registration. The function pointer to the callback function has to be of type
VmbInvalidationCallback*. Please note that VmbShutdown only returns after all callbacks have
finished execution. Below you find a list of functions that cannot be called within the callback routine.
•VmbStartup
•VmbShutdown
•VmbFeatureIntSet (and any other VmbFeature*Set function)
•VmbFeatureCommandRun
Feature Type Operation Function
Enumeration Set VmbFeatureEnumSet
Get VmbFeatureEnumGet
Range VmbFeatureEnumRangeQuery
Other VmbFeatureEnumIsAvailable,VmbFeatureEnumAsInt,
VmbFeatureEnumAsString,VmbFeatureEnumEntryGet
Integer Set VmbFeatureIntSet
Get VmbFeatureIntGet
Range VmbFeatureIntRangeQuery
Other VmbFeatureIntIncrementQuery
Float Set VmbFeatureFloatSet
Get VmbFeatureFloatGet
String Set VmbFeatureStringSet
Get VmbFeatureStringGet
Range VmbFeatureStringMaxlengthQuery
Boolean Set VmbFeatureBoolSet
Get VmbFeatureBoolGet
Command Set VmbFeatureCommandRun
Get VmbFeatureCommandIsDone
Raw data Set VmbFeatureRawSet
Get VmbFeatureRawGet
Range VmbFeatureRawLengthQuery
Table 3: Functions for reading and writing a Feature
Vimba C API - Programmer's Manual
13 / 19

9 Image Acquisition and Capture
9 Image Acquisition and Capture
For a quick start see SynchronousGrab example of the Vimba SDK.
To obtain an image from your camera, first setup Vimba API to capture images, then start the acquisition
on the camera. These two concepts – capture and acquisition – while related, are independent operations
as it is shown below (the bracketed tokens refer to the example at the end of this chapter).
To capture images sent by the camera, follow these steps:
1. VmbFrameAnnounce – Make a frame known to the API so that it can allocate internal resources (1).
2. VmbCaptureStart – Start the capture engine of the API. Prepare the capture stream (2).
3. VmbCaptureFrameQueue – Queue (an already announced) frame. As images arrive from the
camera, they are placed in the next frame's buffer in the queue, and returned to the user (3).
4. When done, VmbCaptureEnd – Stop the capture engine and close the image capture stream.
5. If frames have been announced before, call VmbFrameRevokeAll eventually.
None of the steps above have a direct effect on the camera. To start image acquisition, follow these steps:
1. Set feature AcquisitionMode (e.g. to Continuous).
2. Run command feature AcquisitionStart (4).
To stop image acquisition, run command feature AcquisitionStop.
Normally, image capture is initialized and frame buffers are queued before the command AcquisitionStart
is run, but the order can vary depending on the application. To guarantee that a particular image is
captured, ensure that the frames are queued before AcquisitionStart.
9.1 Image Capture
Images are captured using frame buffers that are given to Vimba in calls to the asynchronous function
VmbCaptureFrameQueue (3). As long as the frame queue holds a frame whose buffer is large enough to
contain the image data, it is filled with the incoming image. Allocating a frame's buffer is left to the API,
although it is possible to allocate a piece of memory yourself that you then pass to the API. In both cases
first query the needed amount of memory through the feature PayloadSize (A) or calculate it yourself.
Allocate memory according to the payload size, declare a VmbFrame_t and let its buffer point to this
block of memory (B). After that, announce the frame (1), start the capture engine (2), and queue the
frame you have just created with VmbCaptureFrameQueue (3), so it can be filled when acquisition has
started.
Before a queued frame can be used or modified, the application needs to know when the image capture is
complete. Two mechanisms are available: either block your thread until capture is complete using
VmbCaptureFrameWait for just a single image, or register a callback (C) that gets executed when
capturing is complete. Use the camera handle for registration. The function pointer to the callback
function has to be of type VmbFrameCallback*. Within the callback routine, queue the frame again after
you have processed it. Below, you find a list of functions that cannot be called within the callback routine.
•VmbStartup
Vimba C API - Programmer's Manual
14 / 19

9 Image Acquisition and Capture
•VmbShutdown
•VmbCameraOpen
•VmbCameraClose
•VmbFrameAnnounce
•VmbFrameRevoke
•VmbFrameRevokeAll
•VmbCaptureStart
•VmbCaptureStop
NOTE: Always check that VmbFrame_t.receiveStatus equals VmbFrameStatusComplete when a
frame is returned to ensure the data is valid.
Many frames can be placed on the frame queue, and their image buffers will be filled in the same order
they were queued. To capture more images, keep submitting new frames (frames that you have processed
can be re-queued) as the old frames complete. Most applications need not queue more than two or three
frames at a time.
If you want to cancel all the frames on the queue, call VmbCaptureQueueFlush.
9.2 Image Acquisition
Image acquisition is set up with the features AcquisitionMode, AcquisitionStart (4). For stopping
acquisition, feature Acquisition is normally used.
Listing 7shows a minimal streaming example (without error handling for the sake of simplicity).
Vimba C API - Programmer's Manual
15 / 19

9 Image Acquisition and Capture
Listing 7: Streaming
1#define FRAME_COUNT 3 // We choose to use 3 frames
2VmbError_t err; // Every Vimba function returns an error code that the
3// programmer should always check for VmbErrorSuccess
4VmbHandle_t hCamera // A handle to our opened camera
5VmbFrame_ t frames [ FRAM E_COUNT ]; // A list of frames for streaming
6VmbUInt64_t nPLS; // The payload size of one frame
7
8// The callback that gets executed on every filled frame
9void VMB_CALL FrameDoneCallback( const VmbHandle_t hCamera , VmbFrame_t *pFrame )
10 {
11 if ( VmbFrameStatusComplete == pFrame ->receiveStatus )
12 {
13 std :: cout << "Frame successfully received " << std::endl;
14 }
15 else
16 {
17 std :: cout << "Error receiving frame " << std :: endl ;
18 }
19 VmbCaptureFrameQueue ( hCamera , pFrame , FrameDoneCallback );
20 }
21
22 // Get all known cameras as described in chapter " List available cameras"
23 // and open the camera as shown in chapter " Opening a camera"
24
25 // Get the required size for one image
26 err = VmbFeatureIntGet ( hCamera , " PayloadSize ", &nPLS ); (A)
27 for (int i =0; i< FRAME_COUNT ; ++i )
28 {
29 // Allocate accordingly
30 frames[i]. buffer = new char[ nPLS ]; (B)
31 frames [i ]. buff erS ize = nPLS ; (B)
32 // Anounce the frame
33 VmbFrameAnnounce( hCamera , frames[i], sizeof(VmbFrame_t ) ); (1)
34 }
35
36 // Start capture engine on the host
37 err = VmbCaptureStart ( hCamera ); (2)
38
39 // Queue frames and register callback
40 for (int i =0; i< FRAME_COUNT ; ++i )
41 {
42 VmbCaptureFrameQueue ( hCamera , frames [i], (3)
43 FrameDoneCallback ); (C)
44 }
45
46 // Start acquisition on the camera
47 err = VmbFeatureCommandRun ( hCamera , "AcquisitionStart" ); (4)
Vimba C API - Programmer's Manual
16 / 19

10 Additional configuration: List available interfaces
10 Additional configuration: List
available interfaces
VmbInterfacesList will enumerate all interfaces (GigE or 1394 adapters) recognized by the
underlying transport layers.
See Listing 8for an example.
Listing 8: Get Interfaces
1VmbUint32_t nCount ;
2VmbInterfaceInfo_t *pInterfaces;
3
4// Get the amount of connected interfaces
5VmbInterfacesList( NULL , 0, &nCount , sizeof * pInterfaces );
6
7// Allocate accordingly
8pInterfaces = new VmbInterfaceInfo_t[ nCount ];
9
10 // Get the interfaces
11 VmbInterfacesList( pCameras , nCount , &nCount , sizeof *pInterfaces );
The VmbInterfaceInfo_t struct provides the information about an interface as listed in Table 4.
Struct entry Purpose
const char* interfaceIdString The unique ID
VmbInterface_t interfaceType The camera interface type
const char* interfaceName The name
const char* serialString The serial number
VmbAccessMode_t permittedAccess The mode to open the interface
Table 4: VmbInterfaceInfo_t struct
To get notified whenever an interface is detected or disconnected, use
VmbFeatureInvalidationRegister to register a callback that gets executed on the according event.
Use the global Vimba handle for registration. The function pointer to the callback function has to be of
type VmbInvalidationCallback*. Please note that VmbShutdown blocks until all callbacks have
finished execution. Below you find a list of functions that cannot be called within the callback routine.
•VmbStartup
•VmbShutdown
•VmbFeatureIntSet (and any other VmbFeature*Set function)
•VmbFeatureCommandRun
Vimba C API - Programmer's Manual
17 / 19

11 Error Codes
11 Error Codes
All Vimba API functions return an error code of type VmbErrorType.
Typical errors are listed with each function in the Vimba C Function Reference Manual. However, any of the
error codes listed in Table 5might be returned.
Error Code Int Value Description
VmbErrorSuccess 0 No error
VmbErrorInternalFault -1 Unexpected fault in Vimba or driver
VmbErrorApiNotStarted -2 Startup was not called before the current comand
VmbErrorNotFound -3 The designated instance (camera, feature etc.) cannot be
found
VmbErrorBadHandle -4 The given handle is not valid
VmbErrorDeviceNotOpen -5 Device was not opened for usage
VmbErrorInvalidAccess -6 Operation is invalid with the current access mode
VmbErrorBadParameter -7 One of the parameters is invalid (usually an illegal pointer)
VmbErrorStructSize -8 The given struct size is not valid for this version of the API
VmbErrorMoreData -9 More data available in a string/list than space is provided
VmbErrorWrongType -10 Wrong feature type for this access function
VmbErrorInvalidValue -11 The value is not valid; either out of bounds or not an incre-
ment of the minimum
VmbErrorTimeout -12 Timeout during wait
VmbErrorOther -13 Other error
VmbErrorResources -14 Resources not available (e.g. memory)
VmbErrorInvalidCall -15 Call is invalid in the current context (e.g. callback)
VmbErrorNoTL -16 No transport layers are found
VmbErrorNotImplemented -17 API feature is not implemented
VmbErrorNotSupported -18 API feature is not supported
VmbErrorIncomplete -19 A multiple registers read or write is partially completed
Table 5: Error codes returned by Vimba
Vimba C API - Programmer's Manual
18 / 19

12 Function reference
12 Function reference
For a complete list of all methods, see the Vimba C Function Reference Manual
Vimba C API - Programmer's Manual
19 / 19
