ALLMARINE AMCW-250 User manual

Shanghai Allmarine Industry Co.,Ltd.
Operation Manual
PNEUMATIC CASUALTY WINCH
Shanghai Allmarine Industry Co.,Ltd.
Block 4,Xinjian Yi Road, Jiading District, Shanghai
Tel: [phone]

Shanghai Allmarine Industry Co.,Ltd.
www.allmarine.com.cn
[e-mail]
ATTENTION !
Read Manual before work !
Hoist men must use with anti-falling device !
Never load the overweight !
紧急伤员吊机
由高强度铝合金三角架，气动马达，减速机，防坠器等关键部件组成。
具有移动方便，高度可调，提升速度快，断气自动停止等优点
广泛应用于船舶提升伤员或物资等。
Pneumatic Casualty Winch
Built with Aluminmim alloy frame, equipped with Winch and Anti-falling Device
Use: Tankers and Freighters for hoisting injured men and various materials from
tanks, holds,etc.
BEFORE WORK
1．Be sure all nuts,bolts,hook are tightly secured prior to use.
2. Be sure the Wire(Part 5) always in good condition.
INTRODUCTION
A) Automatic Brakes: The brakes systems will automatically stop
when air source break off or overweight.
B) Suitable for ship repair, oil drilling, warehouse, mines, worksho
ps and other explosion-proof areas to use

Shanghai Allmarine Industry Co.,Ltd.
HOW TO USE
1. At least need 3 men work together to install the winch.
2. Open the 3 legs(Part 1),adjust the suitable height of legs, each legs fix
by 2pcs of fastener(Part 7), At last fix by Chain(Part 5).
3. Install the winch (Part 2), fix by 2pcs of fastener(Part 7).
4. Connect the air source to air motor(Air pressure 7bar), turn on the
Switch(Part 6) to up or down the wire.
5. The switch can adjust lifting speed.
TECHNICAL DATA
Model
型号
Unit
AMCW-250
Lifting Capacity
提升重量
Kg
250
Test Capacity
检测重量
KG
300
Wire Rope Dia.
钢丝绳直径
mm
5
Wire Rope Length
钢丝绳长度
m
20
Air Hose Diam
气管内径
mm
19
Air Consumption
耗气量
M3/min
2.2
Working Pressure
工作气压
bar
6-7
Weight
重量
kg
63
CTN SIZE
包装尺寸
M

Shanghai Allmarine Industry Co.,Ltd.
DRAWING
1：可调支撑架 2。马达和变速器 3。 钢丝绳 4。 防坠器 5。防滑链条 6。开关 7。固定栓 8个
MAINTENANCE
1. The air motor should inspect by 3 moth. When maintenance, the
lubrication should be injected from motor air inlet, then turning on the air
source, making the motor running, repeat it three times and paying
attention to the grease come out from oil outlet.

Shanghai Allmarine Industry Co.,Ltd.
2．The winch used frequently should be inspected completely at least
once a year. It must be washed and checked within stipulated period even
in normal operation.
3．Wire rope should be inspected frequently, if found the abrasion
exceeds the technical specification limits, it should be removed and
replaced immediately
