AllMounts AS0364T User manual

ISSUED: DEC. 201470kg(154lbs)RATED70kg(154lbs)RATEDVideo Wall MountINSTALLATION MANUALCAUTION: DO NOT EXCEED RATED LISTED WEIGHT. SERIOUS INJURY OR PROPERTY DAMAGE MAY OCCUR!200x200400x200/400x400600x400 /300x300
AS0364T
70"MAX
Maintenance• Check that the bracket is secure and safe to use at regular intervals(at least every three months). • Please contact your distributor if you have any questions.9. Lock the Pop-out Module with the Plastic Locking PiecesI

2Component ChecklistIMPORTANT: Ensure that you have received all parts according to the component checklist prior to installation. If any parts are missing or faulty, telephone your local distributor for a replacement.Package MPackage WST6.3x55(x6)W-A concrete anchor W-B(x6)D6 washer (x6)W-C1NOTE: Read the entire instruction manual before you start installation and assembly.WARNINGM5x14 M-A(x4)M6x14 M-B(x4)washer M-F(x4)M8x20 M-C(x4)big M-H spacer (x4)M6x30 M-D(x4)M8x30 M-E(x4)small spacer (x8)M-G • Do not begin the installation until you have read and understood all the instructions and warnings contained in this installation sheet. If you have any questions regarding any of the instructions or warnings, please contact your local distributor.• This mounting bracket was designed to be installed and utilised ONLY as specified in this manual. Improper installation of this product may cause damage or serious injury.• This product should only be installed by someone with good mechanical ability who has basic building experience and fully understands this manual. • Make sure that the supporting surface will safely support the combined weight of the equipment and all attached hardware and components.• Always use an assistant or mechanical lifting equipment to safely lift and position the equipment.• Tighten screws firmly, but do not over tighten. Over tightening can cause damage to the items, This greatly reduces their holding power.• This product is intended for indoor use only. Using this product outdoors could lead to product failure and personal injury.antiskid block (x2)Hplastic locking piece (x2)Iwall plate A(x1)pop-out module B(x1)M8x12 (x8)GM8 nut (x8)Fadapter bracket (x2)CVESA adapter (x2)DVESA adapterE (x2)

431. For Solid Brick and Concrete Wall MountingDrill pilot holes2XX√Screw the wall plate onto the wall60mm(2.4")60mm(2.4")ø 10mm(ø 3/8") Mark the exact location of mounting holes1Installers must verify that the supporting surface will safely support the combined weight of the equipment and all attached hardware and components.WARNING2. For Video Wall Installation (Mounting space as shown below)X=Length of displayY=Height of display3. Installing the Pop-out ModulePlease take off the caps before installation.W-CW-AW-BW-BXX
Y+5mmY+5mm
B

Hang the pop-out module onto thewall plate. Secure it by tighteningboth screws.4. Installing the Adapter Brackets65600400orTop of the displayTVTVTV4-1 For Flat Back Screens M-AM-BM-CM-FEGFCDFor the VESA:400x400 600x400Attach the VESA adapters to the adapter bracketsusing the appropriate screws and nuts so that thehole pattern can be expanded to the VESA 400x400and 600x400.DE

Knobs for micro-adjustmentof in and out.Screws for micro-adjustmentof up and down.Handles for tilt adjustment.874-2. For Bump-out or Recessed Back ScreensTVTVTVTighten all screws but do not over tighten.· Position the adapter brackets as close as possible to the center of the display.· Screw the adapter brackets onto the display.Note: Choose the appropriate screws, washers and spacers (if necessary) according to the type of screen.M-CM-FM-GM-CM-D/M-E/M-FM-GM-D/M-EM-FM-HM-D/M-EM-FM-GM-Hororor5. Hooking the Display onto the Pop-out ModuleNote: Before hooking the display, make sure the knobs are rotated to the unlock position.· Lift the display carefully and hook the display onto the pop-out module. Rotate the knobs to the lock position to secure the display.· Use the padlock to prevent the display from being stolen.( Padlock is not included)6. AdjustmentPush the display toleft or right to enablefast alignment.

109LeftRightLeftRightLeftRightLeftRightLeftRightLeftRightLeftRightLeftRight

1211LeftRightLeftRightPush the display inward and then release it, the display will be pop-out.Kickstands provide tilt access for easy cables management and maintenance.wallwallwall7. Level the DisplayswallAdjust the display to keep level in vertical and horizontal directions.

14131.2mmNote: Use the plastic lockingpiece to measure and keep a1.2 mm gap between displays.I
1.2mm
3142Note: Install/adjustthe displays by thenumerical ordergiven.8. Fixing the Brackets Position with the Antiskid BlocksHInstall the both antiskid blocks as close to the adapter brackets as possible.Tighten screws on the antiskid blocks using a proper screwdriver to prevent display from moving.I
