Owner’s Manual
Universal TV Floor Stand 32"-65"

IMPORTANT INFORMATION!
We advise that before starting the assembly of this product that you familiarise yourself with the
instructions and the parts list in this leaflet.
Do not over tighten any part of this assembly.
Do not place hot or cold objects on to or close next to any glass surface unless the object is
sufficiently insulated to prevent contact.
Do not strike the glass with hard or pointed items.
Do not sit or stand upon horizontal glass surfaces.
Do not use washing powders or other substances containing abrasives when cleaning the glass.
Do use a damp cloth with diluted washing up liquid for cleaning the glass surfaces.
WARNING: Wherever possible distribute weight evenly.
Maximum TV weight and shelf capacities
40kg
88lbs
10kg
22lbs
20kg
44lbs

Boxed Parts
Mx4
TV Screws, Reducers and Spacers
M6
16mm
M8
16mm
Tools Recommended
Dx2
F
C
Bx2
E
A
I
Jx4 Kx2 Lx4
Nx6 Ox4 Px2 Qx4 Rx2 STx4
SP1X4 RE1X4 RE2X4
16mm
M4
TV1X4
25mm
M4
TV2X4
16mm
M6
TV3X4
25mm
M6
TV4X4
16mm
M8
TV5X4
25mm
M8
TV6X4
M6
M10
Hx2
G

Put a piece of material underneath
the glass to prevent damage.
!
75 -
660mm
X
75 -
400mm
Y
!
If width X is greater than 660mm or height Y
greater than 400mm STOP installation now and
contact the customer help line
You are provided with 3 diameters of TV fixing
screws, M4, M6 and M8. Determine the screw
diameter that fits and remember for step 9.
TV Fixing Holes
Measure the TV fixing holes Width and Height
2
Jx4
A
Jx4
1
M4 = TV1-2
M6 = TV3-4
M8 = TV5-6

M8
16mm
Place column C on a raised
surface to help fit parts D
i ii
3
4
Dx2
Nx4
C
Nx4
C
Dx2
Lx2
Lx2
Bx2
Bx2
F
C
A
E
M10

Fully tighten
Hand tighten only
5
Lx2
Kx2
!
Kx2
6
R
!
L
R
L!
!
Lx2
M10

M6
16mm
Please consider the size of your TV before
fixing plate . See below for guide.G
Recommended for Medium to Large TV.
Recommended for Large to Extra Large TV.
7
Qx4 Tx4 Sx1
!
Tx4 Qx4
G
Mx4
i
Mx4
M6

M8
16mm
Do not over tighten
Nx2 Px2 Ox4
!
Nx2
Px2
Ox4 I
8

TV TV
TV
TV
SP1
For TVs with flat/unobstructed back For TVs with irregular/obstructed back
After completing step 9 you will have fittings left over, please keep for future reference.
No Spacers Spacers
WARNING
9
!

Attach the bracket to the back of your TV using suitable screw, reducer and spacer combinations.
If you have any issues fitting to the back of your TV with the supplied screws, please call the customer
services helpline.
TV1 - TV6
RE1
RE2
TV1-TV2 TV3-TV4
TV5-TV6
SP1If required
Do you need RE1 or RE2?
Top

10
iii
