Allnet ALL7008 User manual

ALL7008
User’s Manual

1
Table of Contents
System
Chapter 1
Administration ……………………………………………. 5
Admin ……………………………………………………... 7
Permitted IPs ……………………………………………..
9
Logout ………………………………………………….….
10
Software Update ………………………………………….
11
Chapter 2
Configure …………………………………………………..
13
Setting ………………………………………………….….
18
Date/Time ………………………………………………….
23
Multiple Subnet ………………………………...…………
24
Route Table ………………………………………………... 27
DHCP ………………………………………………………. 36
DDNS ……………………………………………...………..
38
Host Table ……………………………………………….… 40
Language ……………………………………………..……... 41
Interface
Chapter 3
Interface …………………………………………………...
43
LAN ………………………………….…………………….
48
WAN ………………………………….……………………
49
DMZ …………………………….…………………………
57
Policy Object
Chapter 4
Address ……………………………………………………. 59
Example ………………………………….………………… 62

2
Chapter 5
Service ………………………………………………….….
69
Custom ………………………………….…………………
72
Group ………………………………….…………………..
76
Chapter 6
Schedule …………………………………………………. 79
Chapter 7
QoS ………………………………………………….…….
83
Example ………………………………….……………….
87
Chapter 8
Authentication ……………………………………………
91
Auth User ………………………………….……………..
97
Auth User Group ………………………………….……..
101
RADIUS ………………………………….………………
105
POP3 Server ………………………………….…………. 126
Chapter 9
Content Blocking ………………………………………… 129
URL ………………………………….……………………
133
Script ……………………………….…………………….
136
P2P ………………………….……………………………
138
IM …………………………….……………………………
140
Download …………………………….…………………...
142
Chapter10
Virtual Server………………………………………………...
145
Example ……………………………….…………………..
149
Chapter11
VPN ……………………………………………………….
165
Example……………………………………………………..
172
Chapter12
Policy……………………………………………….………..
275
Example ………………………………….……………….
281

3
Mail Security
Chapter13
Configure …………………………………………………..
301
Mail Relay …………………………………………………
304
Chapter14
Anti-Spam ………………………………………………….
309
Example ………………………………….………………..
324
Chapter15
Anti-Virus ………………………………………………......
365
Example ………………………………….………………..
371
Anti-Attack
Chapter16
Alert Setting ……………………………………………….
381
Internal Alert ………………………………………………
386
Chapter17
Atack Alarm ………………………………………………. 391
Internal Alarm ……………………………………………..
393
External Alarm ……………………………………………… 394
Monitor
Chapter18
LOG ……………………………………………….………..
397
Traffic Log ……………………….…………………………
399
Event Log ……………………….…………………………
404
Connection Log ……………………….………………….
407
Log Backup ……………………….………………………
410
Chapter19
Alarm ……………………………………………….………
413
Traffic Alarm ……………………….………………………
414
Chapter20
Statistics …………………………………………….……..
417
WAN ……………………….……………………………….
419
Policy ……………………….………………………………
421

4
Chapter21
Status …………………………………………….…………
423
Interface ……………………….…………………………..
424
Authentication ……………………….……………………
426
ARP Table ……………………….………………………...
427
DHCP Clients ……………………….…………………….
428

5
Chapter 1 Administration
“System” is the managing of settings such as the privileges of packets that pass
through the ALL7008 and monitoring controls. The System Administrators can
manage, monitor, and configure the ALL7008 settings. But all configurations are
“read-only” for all users other than the System Administrator; those users are not
able to change any setting of the ALL7008.

6
Define the required fields of Administrator
Administrator Name:
The username of Administrators and Sub Administrator for the ALL7008.
The admin user name cannot be removed; and the sub-admin user can be
removed or configure.
The default Account: admin; Password: admin
Privilege:
The privileges of Administrators (Admin or Sub Admin). The username of
the main Administrator is Administrator with reading / writing privilege.
Administrator also can change the system setting, log system status, and to
increase or delete sub-administrator. Sub-Admin may be created by the
Admin by clicking New Sub Admin. Sub Admin have only read and
monitor privilege and cannot change any system setting value.
Configure:
Click Modify to change the “Sub-Administrator’s” password or click
Remove to delete a “Sub Administrator.”

7
Adding a new Sub Administrator
STEP 1﹒In the Admin WebUI, click the New Sub Admin button to create a
new Sub Administrator.
STEP 2﹒In the Add New Sub Administrator WebUI (Figure 1-1) and enter the
following setting:
Sub Admin Name: sub_admin
Password: 12345
Confirm Password: 12345
STEP 3﹒Click OK to add the user or click Cancel to cancel it.
Figure1-1 Add New Sub Admin

8
Modify the Administrator’s Password
STEP 1﹒In the Admin WebUI, locate the Administrator name you want to edit,
and click on Modify in the Configure field.
STEP 2﹒The Modify Administrator Password WebUI will appear. Enter the
following information:
Password: admin
New Password: 52364
Confirm Password: 52364 (Figure1-2)
STEP 3﹒Click OK to confirm password change.
Figure1-2 Modify Admin Password

9
Add Permitted IPs
STEP 1﹒Add the following setting in Permitted IPs of Administration:
(Figure1-3)
Name: Enter master
IP Address: Enter 163.173.56.11
Netmask: Enter 255.255.255.255
Service: Select Ping and HTTP
Click OK
Complete add new permitted IPs (Figure1-4)
Figure1-3 Setting Permitted IPs WebUI
Figure1-4 Complete Add New Permitted Ips
To make Permitted IPs be effective, it must cancel the Ping and WebUI selection
in the WebUI of ALL7008 that Administrator enter. (LAN, WAN, or DMZ Interface)
Before canceling the WebUI selection of Interface, must set up the Permitted IPs first,
otherwise, it would cause the situation of cannot enter WebUI by appointed Interface.
