Almot 870N Instruction manual

S.G. Eleronica S.r.l - Via E. Ferrari , 28 - 30037 Scorzè (VE) Italy - Tel [phone] Fax [phone] - www.almot.it - [e-mail]
870N
CONTROL UNIT
FOR MOTORS 230 VAC AWNINGS, SHUTTERS, VASISTAS, LIGHTS
INSTRUCTION MANUAL AND USE
ENGLISH
Version 2 10.05.2018

S.G. Eleronica S.r.l - Via E. Ferrari , 28 - 30037 Scorzè (VE) Italy - Tel [phone] Fax [phone] - www.almot.it - [e-mail]
WARNING READ CAREFULLY THE FOLLOWING SAFETY INDICATIONS BEFORE TO START THE INSTALLA-
TION OF THIS DEVICE; THEY ARE USEFUL TO PREVENT ANY ELECTRICAL CONTACT, INJURY AND OTHER
PROBLEMS. KEEP THIS MANUAL FOR OTHER CONSULTATIONS.
The control units are intended exclusively to the control of the weather for the automac movement of
the awnings, shuers, vasistas and lights. The use for applicaons which are dierent from the ones indi-
cated must be authorized by the manufacturer, aer the technical test of the applicaon.
 The installaon of the device must be made by technical and qualied sta.
 Aer having removed the packaging, check that the device is intact.
 Plasc bags, styrofoam, small metallic components as nails, clips, etc. have to be kept out of reach of
children, because they might be dangerous.
 Before to connect the device, verify that the electrical supply that you use, has the same features
indicated in the label with the technical infos, applied on the device.
 This device has been intended just and exclusively for the use for which it has been programmed
and the manufacturer can not be held accountable for the damages caused by its improper use.
 The installaon of the device has to be made according to the instrucons of the manufacturer. Non
-compliance with these rules can compromise the safety.
 The implementaon of the electrical installaon of voltage supply has to be made according to the
current rules.
 To avoid any danger of injuries or death caused by the voltage supply, before implemenng any ope-
raon of wiring or regulaon, turn o the voltage from the supply line.
 To assure an eecve separaon from the net we suggest to install a momentary bipolar switch
(buon) approved. At the beginning of the command line a general omnipolar switch of supply with
input of the contact of at least 3mm, must be installed.
 Do not clean or wash the device with solvent or jets of water. Do not immerse into water.
 Warning: in case of damage or malfuncon, turn o the device from the general switch and call a
qualied technician.
 Every repair have to be implemented only by qualied sta in an help centre authorized by the ma-
nufacturer.
 Before implemenng any operaon of cleaning or maintenance, be sure to disconnect the device
from the net. For further safety we suggest to remove the electrical connecon.
 Request always and exclusively the use of original replacements. The non-compliance with this rule
could compromise the safety and undo the benets of the warranty applied on the device.
 In case of problems or doubts during the intallaon of the funconing, address to your retailer of
trust or directly to the manufacturer.
1. SAFETY INTICATIONS

S.G. Eleronica S.r.l - Via E. Ferrari , 28 - 30037 Scorzè (VE) Italy - Tel [phone] Fax [phone] - www.almot.it - [e-mail]
2.0 TECHNICAL DATAS
PARAMETERS 870
VOLTAGE SUPPLY 230 VAC/50Hz
MAX POWER OUTGOING 500 W
TEMPERATURE OF EXERCISE -20 / +70°C
PROTECTION FUSE PTC
WORKING TIME* 40/60/120 SEC
WIND THERSHOLD 12—25—35 Km/h
MAX TX MEMORIZABLES 15
RX RADIO FREQUENCY 433,92 Mhz
PROTECTION DEGREE IP 55
SIZE 115 x 35 x 23 mm
1
2.1 COMPOSITION OF THE PRODUCT AND DIAGRAM OF CONNECTION
CONTROL UNIT 870N
Seng: AWNING
08880870N: control unit for the
managing of shuers, awnings,
vasistas and light.
*Working me:
 Vasistas: 40 / 120 Sec.
 Shuer: 40 / 120 Sec.
 Awning: 60 / 120 Sec.
1 = +12V
2 = OPEN/STOP or STEP BY STEP
3 = CLOSE or CLOSE/STOP
4 = COMMON
Seng: SHUTTER

S.G. Eleronica S.r.l - Via E. Ferrari , 28 - 30037 Scorzè (VE) Italy - Tel [phone] Fax [phone] - www.almot.it - [e-mail]
2.1 COMPOSITION OF THE PRODUCT AND DIAGRAM OF CONNECTION
2
CONTROL UNIT 870N
2.2 FUNZIONI DIP SWITCH 870N
DIP 1 DIP 2 DIP 3 FUNCTION
OFF OFF OFF SETTING AWNING: INPUT ANEMOMETER and INPUT STEP BY STEP. Working me 60 se-
conds. REGULATION WIND THERSHOLD BY TX
ON OFF OFF SETTING VASISTAS: INPUT RAIN SENSOR and INPUT OPEN/CLOSE and CLOSE/STOP. Wor-
king me 40 seconds.
OFF ON OFF SETTING SHUTTER: INPUT. OPEN/STOP and CLOSE/STOP. Working me 40 seconds.
OFF OFF ON SETTING AWNING: INPUT ANEMOMETER and INPUT STEP BY STEP. Working me 120
seconds. REGULATION WIND THERSHOLD BY TX
ON OFF ON SETTING VASISTAS: INPUT RAIN SENSOR and INPUT OPEN/CLOSE and CLOSE/STOP. Wor-
king me 120 seconds.
OFF ON ON SETTING SHUTTER: INPUT. OPEN/STOP and CLOSE/STOP. Working me 120 seconds.
ON ON OFF LIGHTS SETTING: INPUT ON/OFF LIGHT 1 and ON/OFF LIGHT 2.
ON ON ON LIGHTS SETTING: INPUT ON/OFF LIGHT 1 and ON/OFF LIGHT 2.
WARNING: USE THE LIGHT SETTING IF THE LIGHTS ARE PRESENTS, RISK OF DAMAGING THE CONTROL UNIT IF THE MOTOR
GETS CONNECTED
Seng: VASISTAS
Seng: LIGHTS

S.G. Eleronica S.r.l - Via E. Ferrari , 28 - 30037 Scorzè (VE) Italy - Tel [phone] Fax [phone] - www.almot.it - [e-mail] 3
DIP 4 FUNCTION
OFF Sengs of the working mes STANDARD.
ON Sengs of the TEST mings of work (the wor-
king mes are reduced to 10—12 seconds).
2.3 FUNCTIONS DIP SWITCH 870N
3.0 GENERAL RULES OF FUNCTIONING
 During the wiring strictly respect the diagram of connecon, a wrong connecon could damage the
installaon. Follow the diagram more appropriate to the installaon. (paragraph 2.1)
 Do not use, for the command, stable posion switches.
 Do not exceed 50 mt of cable between the control unit and the anemometer.
 Aer supplying the control unit (in case of installaon on an awning) posion the awning on half of
the run, rotate the sensor and check that aer the alarm happened (ashing red led), the awning goes up
(closing). In case that it goes backwards, invert the wires on the MOTOR OPENS clamp, to the MOTOR
CLOSES clamp.
 Posion the sensor in an opmal posion for receiving the wind, as close to the awning as possible.
 If during the installaon, with the connuous opening and closing of the awning, shuer or vasistas,
the motor gets stuck, this is not because of a damage of the board, but because of the thermic protector
contained in the motor. Wait unl the motor has cooled down and try again.
4. 0 PROGRAMMING FIRST TX MASTER BY REMOTE (IF THERE IS NO TX STORED)
4.1 PROGRAMMING OF OTHER TX BY MASTER TRANSMITTER
DIP 5 FUNCTION
OFF Funconing of the command switches IMPUL-
SIVE.
ON Funconing command switches to DEAD
MAN.
1) Supply the control unit 2) The motor will do
two short opposite
movements which indi-
cate that there are no
TX stored in the control
unit’s memory
3) Within a few seconds
press the STOP switch of
the TX to memorize.
4) The motor will do two
short movements which
indicate that the TX has
been memorized. Release
the STOP of the
TX.
5) Programming accompli-
shed.
1) When the control unit
has been supplied, press
and hold the hidden
switch of the TX master
already stored.
2) The motor will do
two short movements
which indicate the
storing has begun.
4) Within a few se-
conds press the STOP
switch of the TX to
memorize.
5) The motor will do
two short move-
ments which indicate
that the TX has been
memorized.
6) Programming
accomplished.
3) Release the hidden
switch of the TX.

S.G. Eleronica S.r.l - Via E. Ferrari , 28 - 30037 Scorzè (VE) Italy - Tel [phone] Fax [phone] - www.almot.it - [e-mail] 4
4.3 REGULATION OF THE WIND BY TX (IF SET BY DIP SWITCH)
4.2 DELETING A TX BY TRANSMITTER
1) Press and hold the
PROGRAMMING
switch of a TX already
stored.
2) Aer some se-
conds the motor will
do TWO short oppo-
site movements.
3) Release the PRO-
GRAMMING switch of
the TX already stored.
4) Press IMMEDIATLY
the STOP switch of the
TX to store.
5) The motor will do
TWO short opposite
movements.
6) RESET accompli-
shed.
1) Press and hold
the PROGRAM-
MING switch of a
TX already stored.
2) Aer some se-
conds the motor will
do TWO short oppo-
site movements.
3) Aer some seconds
the motor will do TWO
further short opposite
movements.
4) Release the PRO-
GRAMMING switch of
the TX altready stored.
5) If the CLIMB switch
is pressed, 15 km/h
will be set. Choose
just one switch.
6) If the STOP
switch is pressed,
25 km/h will be set.
Choose just one
switch .
7) If you pree the
DESCENT switch, 35
km/h will be set.
Choose just one
switch.
8) Once you pressed the
wanted switch, the mo-
tor will do TWO short
opposite movements of
conrmaon.
9) REGULATION OF
THE WIND SPEED
ACCOMPLISHED.
4.4 INVERSION OF THE MOTOR MOVEMENT BY TX
1) Press and hold the
PROGRAMMING
switch of the TX al-
ready stored.
2) Aer a few seconds
the motor will do TWO
short opposite move-
ments. 1 BEEP
3) Aer a few seconds
the motor will do
TWO further short
opposite movements.
2 BEEP
4) Aer a few seconds
the motor will do TWO
further short opposite
movements. 3 BEEP
5) Release the PRO-
GRAMMING switch of
the TX altready stored.
6) INVERSION OF
THE MOTION AC-
COMPLISHED.

S.G. Eleronica S.r.l - Via E. Ferrari , 28 - 30037 Scorzè (VE) Italy - Tel [phone] Fax [phone] - www.almot.it - [e-mail] 5
4.5 MEMORIZATION OF A TX BY CONTROL UNIT CENTRALE 870N
4.7 RESET OF ALL THE TX BY CONTROL UNIT 870N
4.8 RESET TOTALE
4.6 DELETING A TX BY CONTROL UNIT 870N
1) When the control unit
has been supplied, press
and holdthe P1 switch for
3 seconds and release.
2) The control unit will
make a long sound.
4) Press IMMEDIATLY the
STOP switch of the TX to
memorize.
5) The motor will do TWO
short opposite move-
ments.
6) PROGRAMMING ac-
complished
BEEEEEEP
1) When the control unit
has been supplied, press
and holdthe P1 switch for
3 seconds and release.
2) The control unit will
make a long sound.
4) Press IMMEDIATLY the
STOP switch of the TX to
delete.
5) The motor will do TWO
short opposite move-
ments.
6) RESET accomplished
BEEEEEEP
1) When the control unit
has been supplied, press
and hold the P1 switch .
2) Aer many seconds,
The motor will do TWO
short opposite move-
ments.
3) Release the programming
P1 switch.
6) RESET accomplished
1) Close the contact
between the COM
input and the PP
input of the control
unit 870N
2) Supply the control
unit.
3) Aer many se-
conds, The motor will
do FOUR short oppo-
site consecuve mo-
vements.
4) OPEN the contact
between the COM input
and the PP input of the
control unit 870N
5) Aer many se-
conds, The motor will
do ONE further short
opposite movement.
6) Aer some se-
conds the motor
will do TWO further
short opposite mo-
vements.

S.G. Eleronica S.r.l - Via E. Ferrari , 28 - 30037 Scorzè (VE) Italy - Tel [phone] Fax [phone] - www.almot.it - [e-mail] 6
6.0 COMPLIACE CERTIFICATE ON THE EU DIRECTIVES
S.G. Eleronica S.r.l. - Via Ferrari 28
30037 Scorzè, Venezia - ITALY
P. IVA 02272310273
Tel. [phone] - Fax. [phone]
www.almot.it - [email protected]
COMPLIACE DECLARATION
(direcve 89/392 CEE, annex II, parte B)
S. G. Eleronica srl declares that the following control unit:
08880870N
Are in compliance with the rules set out in the direcves 89/336/EEC, 92/31/EEC, 93/68/EEC about the
electromagnec compability. The following harmonised standards have been aplied:
EN 60335-1, EN 60204-1, EN 55014, EN 6100-3-2, EN 6100-3-3, EN 6100-4-2, EN 6100-4-4, ENV 50140,
EN 50081-1, EN 50082-1
Declares at the same me that it is forbidden to put into service the abovemenoned products before
that the machine to which they are incorporated or are part of, has not been idened and has not been
declared in accordance with the condions requested by the direcve 89/392 CEE and to the naonal le-
gislaon of applicaon, that is unl the material in queson of this declaraon will not be kept together
with the nal machine.
Scorzè, 10/05/2018
Sign of the Legal Representave
Sandro Zono
5.0 WARNINGS ABOUT THE FUNCTIONING
- In case that you are using a sun/wind radio sensor (940), for a correct use of the SUN funcon the aw-
ning has to do a complete cycle, without any interrupon from the nal user (ex. Half opening or vice-
versa).
- Always connect just one control unit at the me, to avoid any accidental storing on other control units.
