Alpha Data ADM-XRC-5T2-ADV User manual

ADM-XRC-5T2-ADV
PCI Mezzanine Card
•JPEG2000 Video Compression
•Multi-Gigabit Serial I/O
User Guide
Version 1.0

ADM-XRC-5T2-ADV User Manual
Copyright © 2008 Alpha Data Parallel Systems Ltd. All rights reserved.
This publication is protected by Copyright Law, with all rights reserved. No
part of this publication may be reproduced, in any shape or form, without prior
written consent from Alpha Data Parallel Systems Limited
Alpha Data
4 West Silvermills Lane
Edinburgh EH3 5BD
UK
Phone: [phone]
Fax: [phone]
Email: [email protected]
Alpha Data
2570 North First Street, Suite 440
San Jose, CA 95131
USA
Phone: [phone]
Fax: [phone]
Email: [email protected]
EMI
This equipment generates, uses, and can radiate electromagnetic energy. It
may cause or be susceptible to electromagnetic interference if not installed
and used with adequate EMI protection for specific applications.
ADM-XRC-5T2-ADV User Manual
Version 1.0

ADM-XRC-5T2-ADV User Manual
Table of Contents
1. Introduction........................................................................................................................1
1.1. Specifications............................................................................................................1
2. Hardware Installation.........................................................................................................2
2.1. Motherboard requirements........................................................................................2
2.2. Handling instructions.................................................................................................2
2.3. Installing the ADM-XRC-5T2-ADV onto a PMC motherboard ..................................2
2.4. Installing the ADM-XRC-5T2-ADV if fitted to an ADC-PMC .....................................2
2.5. Installing the ADM-XRC-5T2-ADV if fitted to an ADC-EMC .....................................2
3. Software Installation ..........................................................................................................2
4. Board Description ..............................................................................................................3
4.1. Local Bus...................................................................................................................4
4.2. Flash Memory............................................................................................................5
4.2.1. Board Control Flash..........................................................................................5
4.2.2. User FPGA Flash .............................................................................................5
4.3. Health Monitoring......................................................................................................5
4.4. JTAG.........................................................................................................................6
4.5. Clocks........................................................................................................................7
4.5.1. LCLK.................................................................................................................7
4.5.2. REFCLK ...........................................................................................................8
4.5.3. PCIe Reference Clock......................................................................................8
4.5.4. User MGT Clocks.............................................................................................8
4.5.5. FCN MGT Clock...............................................................................................8
4.5.6. Rear (Pn4) Clocks............................................................................................8
4.5.7. PCI Clocks........................................................................................................8
4.6. User FPGA................................................................................................................9
4.6.1. Configuration....................................................................................................9
4.6.2. I/O Bank Voltages...........................................................................................10
4.6.3. Memory Interfaces..........................................................................................10
4.7. FCN Interface – MGT Links ....................................................................................11
4.7.1. Copper Mating Cables....................................................................................11
4.7.2. Optical Mating Cables ....................................................................................11
4.7.3. Example Gigabit I/O Applications...................................................................12
4.7.4. Front Panel multi-gigabit I/O Control & Status Signals ..................................12
4.8. Pn4 I/O....................................................................................................................13
4.8.1. Pn4 Signalling Voltage ...................................................................................13
4.9. XMC Interface .........................................................................................................13
4.9.1. Primary XMC Connector, P15........................................................................13
4.10. ADV212 Interface....................................................................................................14
4.10.1. Signal Description...........................................................................................14
4.10.2. JPEG Processor Interface Pin Locations.......................................................15
5. Design Examples.............................................................................................................16
5.1. Revision History ......................................................................................................17
ADM-XRC-5T2-ADV User Manual
Version 1.0

ADM-XRC-5T2-ADV User Manual
ADM-XRC-5T2-ADV User Manual
Version 1.0
Table of Tables
Table 1 Local Bus Interface Signal List.................................................................................... 4
Table 2 Voltage and Temperature Monitors............................................................................. 5
Table 3 MGT Clock Connections ............................................................................................. 8
Table 4 User FPGA I/O Bank Voltages.................................................................................. 10
Table 5 DDR Memory Bank Configuration............................................................................. 10
Table 6 FCN Interface - MGT Links ....................................................................................... 11
Table 7 Board Control Signals ............................................................................................... 12
Table 8 Optical Module Control Signals.................................................................................. 12
Table 9 Pn4 to FPGA Assignments........................................................................................ 13
Table 10 Pn4 I/O Voltage Selection....................................................................................... 13
Table 11 XMC P15 Connections............................................................................................ 14
Table of Figures
Figure 1 ADM-XRC-5T2-ADV Block Diagram.......................................................................... 3
Figure 2 Local Bus Interface .................................................................................................... 4
Figure 3 JTAG Header ............................................................................................................. 6
Figure 4 Clock Structure........................................................................................................... 7

ADM-XRC-5T2-ADV User Manual
ADM-XRC-5T2-ADV User Manual
1. Introduction
The ADM-XRC-5T2-ADV is a high performance PCI Mezzanine Card (PMC) designed for
supporting development of applications using the Virtex-5 FF1738 Family of FPGA Devices.
•Virtex5 LXT: LX110T, LX155T, LX220T or LX330T
•Virtex 5 SXT: SX240T
•Virtex 5 FXT: FX100T, FX130T, or FX200T
The card uses an FPGA PCI bridge developed by Alpha-Data supporting PCI-X and PCI. A
high-speed multiplexed address/data bus connects the bridge to the target (user) FPGA.
The card can also be fitted with a Primary XMC connector to provide high-speed serial links
to the user FPGA.
The board is an application specific version of the ADM-XRC-5T2 and features JPEG2000
video compression capabilities and multi-gigabit serial links using 2 FCN x4 Fibre Channel
connectors.
1.1. Specifications
The ADM-XRC-5T2-ADV supports high performance PCI-X / PCI operation without the need
to integrate proprietary cores into the FPGA.
•Physically conformant to VITA 42 XMC Standard
•Physically conformant to IEEE P1386-2001 Common Mezzanine Card standard (with
XMC connector removed)
•8-lane PCIe / Serial RapidIO connections to User FPGA (via XMC connector)
•8 additional MGT links to User FPGA. (via front-panel) A cost-effective solution to
applications requiring high-speed data communications such as Infiniband TA, 10G
Ethernet, 4x Fibre Channel and others.
•High performance PCI and DMA controllers
•Local bus speeds of up to 80 MHz
•Up to four independent banks of 64Mx32 DDRII SDRAM (1GB total)
•Two banks of 2Mx18 DDRII SSRAM (8MB total)
•User clock programmable between 31.25MHz and 625MHz
•Stable low-jitter 200MHz clock for precision IO delays
•User front panel gigabit serial I/O – 8 lanes in 2 FCN connectors
•4 JPEG2000 codecs (Analog Devices ADV212) which can be operated individually or
in 2 tandem banks to provide compression /decompression of video data
•User rear panel PMC connector with 32 free IO signals
•Programmable I/O voltage rear interfaces
•Supports 3.3V PCI or PCI-X at 64 bits
Version 1.0
Page 1

ADM-XRC-5T2-ADV User Manual
ADM-XRC-5T2-ADV User Manual
2. Hardware Installation
This chapter explains how to install the ADM-XRC-5T2-ADV onto a PMC motherboard.
2.1. Motherboard requirements
The ADM-XRC-5T2-ADV is a 3.3V only PCI device and is not compatible with systems that
use 5V PCI signalling levels.
The board must be installed in a PMC motherboard that supplies +5.0V and +3.3V power to
the PMC connectors. Ensure that the motherboard satisfies this requirement before powering
it up.
2.2. Handling instructions
Observe SSD precautions when handling the cards to prevent damage to components by
electrostatic discharge.
Avoid flexing the board.
2.3. Installing the ADM-XRC-5T2-ADV onto a PMC motherboard
Note: This operation should not be performed while the PMC motherboard is powered up.
The ADM-XRC-5T2-ADV must be secured to the PMC motherboard using M2.5 screws in the
four holes provided. The PMC bezel through which the I/O connector protrudes should be
flush with the front panel of the PMC motherboard.
2.4. Installing the ADM-XRC-5T2-ADV if fitted to an ADC-PMC
The ADM-XRC-5T2-ADV can be supplied for use in standard PC systems fitted to an ADC-
PMC carrier board. The ADC-PMC can support up to two PMC cards whilst maintaining host
PC PCI compatibility. If you are using a ADC-PMC refer to the supplied documentation for
information on jumper settings. All that is required for installation is a PCI slot that has enough
space to accommodate the full-length card. The ADC-PMC is compatible with 5V and 3V PCI
(32 and 64 bit) and PCI-X slots.
It should be noted that the ADC-PMC uses a standard bridge to provide a secondary PCI bus
for the ADM-XRC-5T2 and that some older BIOS code does not set up these devices
correctly. Please ensure you have the latest version of BIOS appropriate for your machine.
2.5. Installing the ADM-XRC-5T2-ADV if fitted to an ADC-EMC
The ADM-XRC-5T2-ADV can be supplied for use in standard PC systems fitted to an ADC-
EMC carrier board. The ADC-EMC can support up to two PMC cards whilst maintaining host
PCI-Express compatibility. If you are using a ADC-EMC refer to the supplied documentation
for information on jumper settings. All that is required for installation is a PCIe slot that has
enough space to accommodate the full-length card
3. Software Installation
Please refer to the SDK installation CD. The SDK contains drivers, examples for host control
and FPGA design and comprehensive help on application interfacing.
Version 1.0
Page 2

ADM-XRC-5T2-ADV User Manual
ADM-XRC-5T2-ADV User Manual
4. Board Description
The ADM-XRC-5T2-ADV follows the architecture of the ADM-XRC series and decouples the
“target” FPGA from the PCI interface, allowing user applications to be designed with minimum
effort and without the complexity of PCI design.
A separate Bridge / Control FPGA interfaces to the PCI bus and provides a simple Local Bus
interface to the target FPGA. It also performs all of the board control functions including the
configuration of the target FPGA, programmable clock setup and the monitoring of on-board
voltage and temperature.
DDR2 SDRAM, SSRAM and serial flash memory connect to the target FPGA and are
supported by Xilinx or third party IP.
IO functionality is provided using multi-gigabit I/O connectors and Pn4 signals.
Bridge / Control FPGA
(Virtex4 LX25)
Config Flash
Memory
(32MB)
User FPGA
Virtex5
LX220T/LX330T
(FFG1738)
System
Monitor
(LM87)
Power
Conversion
Dual
Lane
Link
Local Bus (64 bit)
PCI-X /
PCI64/66
Bridge
Config
Serial Flash
(4MB)
Programmable
Clocks
DDR-II
SDRAM
(256MB)
Pn1
Pn2
Pn3
JTAG
Pn15
XMC PCIe / Serial RapidIO (x8)
Front MGT
(x8)
DDR-II
SSRAM
(4MB)
2 x
ADV212
2 x
ADV212
DDR-II
SDRAM
(256MB)
DDR-II
SDRAM
(256MB)
DDR-II
SDRAM
(256MB)
DDR-II
SSRAM
(4MB)
Primary
Secondary
Pn14
I/O 32 User Defined I/O (16 LVDS pairs)
Figure 1 ADM-XRC-5T2-ADV Block Diagram
Version 1.0
Page 3

ADM-XRC-5T2-ADV User Manual
ADM-XRC-5T2-ADV User Manual
4.1. Local Bus
The ADM-XRC-5T2-ADV implements a multi-master local bus between the bridge and the
target FPGA using a 32- or 64-bit multiplexed address and data path. The bridge design is
asynchronous and allows the local bus to be run faster or slower than the PCI bus clock to
suit the requirements of the user design.
Figure 2 Local Bus Interface
Signal Type Purpose
lad[63:0] bidir Address and data bus.
lbe_l[7:0] bidir Byte qualifiers
lads_l bidir Indicates address phase
lblast_l bidir Indicates last word
lbterm_l bidir Indicates ready and requests new address phase
lready_l bidir Indicates that target accepts or presents new data
lwrite bidir Indicates a write transfer from master
ldreq_l[3:0] unidir DMA request from target to bridge
ldack_l[3:0] unidir DMA acknowledge from bridge to target
fhold unidir Target bus request
fholda unidir Bridge bus acknowledge
lreset_l unidir Reset to target
lclk unidir Clock to synchronise bridge and target
Table 1 Local Bus Interface Signal List
Version 1.0
Page 4

ADM-XRC-5T2-ADV User Manual
ADM-XRC-5T2-ADV User Manual
4.2. Flash Memory
The ADM-XRC-5T2-ADV is fitted with two separate Flash memories: one connected to the
Bridge / Control FPGA and the other to the User FPGA.
4.2.1. Board Control Flash
An Intel PC28F256P30 flash memory is used for storing a configuration bitstream for the User
FPGA. Once the Bridge / Control FPGA is configured, it checks for a valid bitstream in flash
and if present, automatically loads it into the User FPGA. This process can be inhibited by
setting a jumper on the JTAG connector. See the description of the “FBS” signal in Section
4.4 for further information.
Access to this flash device is only possible through control logic registers. The flash is not
directly mapped onto the local bus.
Programming, erasing and verification of the flash are supported by the ADM-XRC SDK and
driver. Utilities are provided to load bitstreams into the flash. These also verify the bitstream
is compatible with the target FPGA.
4.2.2. User FPGA Flash
An ST M25P32 flash memory with SPI interface is connected to the User FPGA for the
storage of application-specific information.
4.3. Health Monitoring
The ADM-XRC-5T2-ADV has the ability to monitor temperature and voltage of key parts of
the board to maintain a check on the operation of the board. The monitoring is implemented
by a National Semiconductor LM87 and is supported by the board control logic connected
using I2C.
The Control Logic scans the LM87 when instructed by host software and stores the current
voltage and temperature measurements in a blockram. This allows the values to be read
without the need to communicate directly with the monitor.
The following supplies and temperatures, as shown in Table 2, are monitored.
Monitor Purpose
1.0V User FPGA Core Supply
1.2V Bridge FPGA Core Supply
1.5V SRAM and ADV212 Core Supply
1.8V Memories, User FPGA Memory I/O,
Local Bus I/O
Config CPLD Core Supply
2.5V Source voltage for Front, Rear I/O
3.3V Board Input Supply
5.0V Board Input Supply
Pn4_VCCIO Either 2.5V or 3.3V Rear (Pn4) I/O Voltage
Temp1 User FPGA die temperature
Temp2 LM87 on die temperature for board/ambient
Table 2 Voltage and Temperature Monitors
Version 1.0
Page 5

ADM-XRC-5T2-ADV User Manual
ADM-XRC-5T2-ADV User Manual
The ‘sysmon’ application is provided upon request that permits the reading of the health
monitor. The typical output of the monitor is shown below, provided by the SYSMON
program.
*** SysMon ***
FPGA Space Base Adr = 00900000
Control Space Base Adr = 00d00000
+1V0 Reading = 1.01 V
+1V2 Reading = 1.21 V
+1V8 Reading = 1.81 V
+2V5 Reading = 2.51 V
+3V3 Reading = 3.32 V
+5V Reading = 5.04 V
Pn4 Reading = 3.31 V
+1V5 Reading = 1.51 V
SysMon Int Temp = 33 deg. C
User FPGA Temp = 26 deg. C
4.4. JTAG
A JTAG header is provided to allow download of the FPGA using the Xilinx tools and serial
download cables. This also allows the use of ChipScope PRO ILA to debug an FPGA
design. It should be noted that four devices will be detected when the SCAN chain is
initialised.
TMS TDI TDO FBS TCK GND VCC
Figure 3 JTAG Header
The VCC supply provided on J5 to the JTAG cable is +3.3V and is protected by a poly fuse
with a rating of 350mA.
FBS
The FBS signal is an input to the control logic and provides control of the cold boot process.
By default with no link fitted, the control logic will load a bitstream from flash into the FPGA if
one is present. Shorting FBS to the adjacent GND pin will disable this process and can be
used to recover situations where rogue bitstreams have been stored in flash.
Version 1.0
Page 6

ADM-XRC-5T2-ADV User Manual
ADM-XRC-5T2-ADV User Manual
4.5. Clocks
The ADM-XRC-5T2-ADV is provided with numerous clock sources, as shown in Figure 4
below:
Zero-delay
Buffer
(PLL)
Bridge FPGA
(V4LX25)
PCI
Bus PCI RefClk
Femto-clock
ICS843034-01
Ctl
25.0 MHz
XTAL
26.5625 MHz
XTAL
User FPGA
Virtex5
LX220T /
LX330T
XTAL_CLK
Local BusLCLK
Bridge Config
(Coolrunner)
USERMGT_CLKA
USERMGT_CLKB
PCIe_RefClk (100 MHz)
200 MHz
Osc.
REFCLK_200M
PCI-X
CLK
PCI
CLK
FCN_MGTREF
Pn4 Connector
KEY
Global Clock Inputs
Clock Capable I/O
MGT Clock Inputs
156.25 MHz
Osc.
Figure 4 Clock Structure
4.5.1. LCLK
The Local Bus can be used at up to 80 MHz and all timing is synchronised to LCLK between
the Bridge and User FPGAs. LCLK is generated from a 200MHz reference by a DCM within
the bridge FPGA. The minimum LCLK frequency (determined by the DCM specification) is
32MHz.
The LCLK frequency is set by writing to the board control logic. (See SDK for details and
example application).
Note: If the user FPGA application includes a DCM driven by LCLK (or one of the other
programmable clocks), the clock frequency should be set prior to FPGA configuration.
Version 1.0
Page 7

ADM-XRC-5T2-ADV User Manual
ADM-XRC-5T2-ADV User Manual
4.5.2. REFCLK
In order to make use of the IODELAY features of Virtex™-5, a stable low-jitter clock source is
required to provide the base timing for tap delay lines in each IOB in the User FPGA. The
ADM-XRC-5T2-ADV is fitted with a 200MHz LVPECL (LVDS optional) oscillator connected to
global clock resource pins. This reference clock can also be used for application logic if
required.
4.5.3. PCIe Reference Clock
A 100MHz PCIe reference clock input from the Primary XMC connector (Pn15) is connected
to one of the dedicated MGT clock inputs on the user FPGA. (See Table 3 for details of the
MGT clock connections.)
4.5.4. User MGT Clocks
A programmable, low-jitter clock source is provided by an ICS843034-01 “FemtoClocks”
frequency synthesiser. The synthesiser has two source crystals – one at 26.5625MHz (for
Fibre Channel applications) and another at 25.0MHz (suitable for PCIe, Gigabit Ethernet
etc.). The synthesiser also has two clock outputs.
”USERMGT_CLKA” is connected to an MGT clock input on the top-half of the user FPGA. It
may be used as an alternative to the PCIe reference for the MGTs connected to the Primary
XMC.
”USERMGT_CLKB” is connected to an MGT clock input on the bottom half of the user FPGA.
It may be used as the reference for the front user MGTs. (See Table 3 for details of the MGT
clock connections.)
Note: Either of these clocks can provide a programmable source for applications that do not
use MGTs.
4.5.5. FCN MGT Clock
A 156.25MHz precision oscillator is fitted on the ADM-XRC-5T2-ADV for Gigabit Serial I/O
applications. There are also 3 other options for clock inputs to the MGT tiles of the FPGA.
The oscillator frequency can be customised to suit applications requiring specific baud rates.
Contact the factory for details.
Clock Name GTP
No. FPGA Pin (P/N) Reference for:
PCIE_REFCLK 114 AD4 / AD3 Primary XMC (Pn15) MGTs
USERMGT_CLKA 118 AK4 / AK3 Primary XMC (Pn15) MGTs
FCN_MGTREF 124 C4 / C3 Front (CN2) user MGTs
USERMGT_CLKB 112 V4 / V3 Front (CN2) user MGTs
Table 3 MGT Clock Connections
4.5.6. Rear (Pn4) Clocks
Four pairs of signals from Pn4 are connected to clock-capable inputs that can be used for
regional clocking of the remaining Pn4 signals. See Table 9 for details.
4.5.7. PCI Clocks
The PCI Interface within the bridge FPGA requires a regional clock input for 66MHz PCI
operation or a global clock input for PCI-X. To comply with the single-load requirement in the
PCI specification, a zero-delay clock buffer is used to route the PCI clock to the two different
clock inputs.
Version 1.0
Page 8

ADM-XRC-5T2-ADV User Manual
ADM-XRC-5T2-ADV User Manual
The clock buffer has a PLL with a minimum input frequency of 24MHz, potentially causing
problems in applications that use the PCI 33MHz mode with a slow clock. In this case, the
buffer can be bypassed to provide full PCI 33MHz compatibility.
4.6. User FPGA
4.6.1. Configuration
The ADM-XRC-5T2-ADV performs configuration from the host at high speed using
SelectMAP. The FPGA may also be configured from flash or by JTAG via header J2.
Download from the host is the fastest way to configure the User FPGA with 8 bit SelectMAP
mode enabled. This permits an ideal configuration speed of up to 40MB/s.
The ADM-XRC-5T2-ADV can be configured to boot the User FPGA from flash on power-up if
a valid bit-stream is detected in the flash. Booting from flash will also configure the
programmable clocks.
Version 1.0
Page 9

ADM-XRC-5T2-ADV User Manual
ADM-XRC-5T2-ADV User Manual
4.6.2. I/O Bank Voltages
Bank Voltage Description
0 3.3V Configuration I/F
1, 4, 5, 6 1.5V DDRII SRAM
2 3.3V SelectMAP I/F, Serial Flash
3 3.3V Clocks
19, 21, 23, 25 1.8V DDRII DRAM
27, 29, 31, 33 1.8V DDRII DRAM (LX330T only)
18 2.5V or 3.3V Pn4 Interface
11, 13, 15, 17, 26 3.3V ADV212 Interface
12, 20, 24 1.8V Local Bus
Table 4 User FPGA I/O Bank Voltages
4.6.3. Memory Interfaces
The ADM-XRC-5T2-ADV has four independent banks of DDRII SDRAM when fitted with a
LX330T, SX240T or FX200T target FPGA. (Two banks with all smaller FPGAs) Each bank
consists of two memory devices in parallel to provide a 32 bit datapath. 1Gb Micron
MT47H64M16 devices are fitted as standard to provide 256MB per bank. The board will
support higher capacity devices when they become available.
The ADM-XRC-5T2-ADV has been designed for compatibility with Xilinx memory interface
cores.
Details of the signalling standards are given in the table below:
Name Direction I/O Standard
DDR_ad[15:0],
DDR_ba[2:0],
DDR_rasn,
DDR_casn,
DDR_wen,
DDR_csn,
DDR_cke,
DDR_odt
Output SSTL18_I_DCI
DDR_ck0,
DDR_ckn0 Output DIFF_SSTL18_II
DDR_dq[15:0] BiDir SSTL18_II
DDR_dm[1:0] Output SSTL18_II_DCI
DDR_dqs[1:0],
DDR_dqsn[1:0] BiDir DIFF_SSTL18_II
DDR_ck1,
DDR_ckn1 Output DIFF_SSTL18_II
DDR_dq[31:16] BiDir SSTL18_II
DDR_dm[3:2] Output SSTL18_II_DCI
DDR_dqs[3:2],
DDR_dqsn[3:2] BiDir DIFF_SSTL18_II
Table 5 DDR Memory Bank Configuration
Version 1.0
Page 10

ADM-XRC-5T2-ADV User Manual
ADM-XRC-5T2-ADV User Manual
4.7. FCN Interface – MGT Links
Eight lanes of user MGT (GTP) links are routed to the front panel connectors. Lanes 0 – 3
are routed through J5, lanes 4 - 7 are routed through J4.
Signal FPGA Pin GTP Number FCN J5 Pin
FCN_TX0_P AA2 112B S16
FCN_TX0_N Y2 “ S15
FCN_RX0_P Y1 “ S1
FCN_RX0_N W1 “ S2
FCN_TX1_P T2 112A S14
FCN_TX1_N U2 “ S13
FCN_RX1_P U1 “ S3
FCN_RX1_N V1 “ S4
FCN_TX2_P R2 116B S12
FCN_TX2_N P2 “ S11
FCN_RX2_P P1 “ S5
FCN_RX2_N N1 “ S6
FCN_TX3_P K2 116A S10
FCN_TX3_N L2 “ S9
FCN_RX3_P L1 “ S7
FCN_RX3_N M1 “ S8
Signal FPGA Pin GTP Number FCN J4 Pin
FCN_TX4_P J2 120B S16
FCN_TX4_N H2 “ S15
FCN_RX4_P H1 “ S1
FCN_RX4_N G1 “ S2
FCN_TX5_P D2 120A S14
FCN_TX5_N E2 “ S13
FCN_RX5_P E1 “ S3
FCN_RX5_N F1 “ S4
FCN_TX6_P B1 124B S12
FCN_TX6_N B2 “ S11
FCN_RX6_P A2 “ S5
FCN_RX6_N A3 “ S6
FCN_TX7_P B6 124A S10
FCN_TX7_N B5 “ S9
FCN_RX7_P A5 “ S7
FCN_RX7_N A4 “ S8
Table 6 FCN Interface - MGT Links
4.7.1. Copper Mating Cables
Suitable cables are available from Fujitsu “microGiGaCN Cable I/O” range of 8-pair cables
in a variety of lengths and styles e.g. FCD-ZZ00001.
Molex provide an alternative source with their ‘LaneLink’ cables e.g. 74526 -1002
4.7.2. Optical Mating Cables
The optical interface uses external modules which plug in to the standard FCN style
connector. These modules (e.g. EMCORE QTR3432) convert the electrical signals to optical
format. Inter-module connection uses MJ3MM12RPR-10-0 (available from Fiberconnections
Inc.) or similar
Please note that these items are not normally supplied by Alpha Data.
Version 1.0
Page 11

ADM-XRC-5T2-ADV User Manual
ADM-XRC-5T2-ADV User Manual
4.7.2.1. Important Notes on using Optical Modules
Optical modules provide a signal (‘sense_l’) indicating that they are present; however the
presence of optical modules cannot be distinguished from a copper connection by relying on
this signal alone.
Whilst the optical module supplies are disabled by default and protected by current limiting,
the method shown in the example code should always be used to ensure that supplies do not
drive into the short circuit presented when a copper cable is fitted.
Caution
This equipment uses Class 1 Laser devices; such devices are not considered to be
hazardous when used for their intended purpose. Use of controls, adjustments or
performance of procedures other than those specified herein may result in hazardous
laser light exposure.
4.7.3. Example Gigabit I/O Applications
•Dual Infiniband 4x ( 4 lanes at 2.5Gb/s over copper or optical fibre)
•Dual 10Gb/s Ethernet CX4 ( 4 lanes at 3.125Gb/s over copper or optical fibre)
•Dual 10Gb/s FibreChannel ( 4 lanes at 3.1875Gb/s over copper or optical fibre)
•Dual 4 x OC-48 SONET
4.7.4. Front Panel multi-gigabit I/O Control & Status Signals
Signal Pin
Location Description
BREFCK_ENA
B AC38 -high to enable the 156.25MHz oscillator on the board (pull-up on board)
STATUS_1 AC40 -Infiniband STATUS led (yellow) connector 1
ATTEN_1 AM42 -Infiniband ATTEN led (green) connector 1
STATUS_2 AC39 -Infiniband STATUS led (yellow) connector 2
ATTEN_2 AM41 -Infiniband ATTEN led (green) connector 2
Table 7 Board Control Signals
Signal FCN Pin Connector 1 (J5)
FPGA Pin Connector 2 (J4) FPGA Pin Description
SENSE G7 AR5 AM6 low indicates that an opto module
has been fitted
FAULT G6 AT6 AN5 low indicates that no data detected
on the opto Rx channel
ODIS G2 AT7 AN6 low to disable Tx on any module
fitted on the channel
PSUEN G8 (3V3
Pwr) AP7 AP6 high to enable the opto power supply
OC_L - AP5 AL7 low indicates overcurrent on opto
supply
Table 8 Optical Module Control Signals
Version 1.0
Page 12

ADM-XRC-5T2-ADV User Manual
ADM-XRC-5T2-ADV User Manual
4.8. Pn4 I/O
Up to 16 pairs of differential or 32 single-ended signals are available on Pn4 and are sourced
from Bank 18 of the User FPGA. All of the signal traces are routed as 100 Ohm differential
pairs and each pair is matched in length. The worst case difference in trace length between
any two pairs is 10mm. The pairs are distinguished by the signals names listed below and
follow the pattern +/-: 1/3, 2/4, 5/7, 6/8…
Signal FPGA Pin Pn4 Pin Pn4 Pin FPGA Pin Signal
PN4_P1 AF11 1 2 AE9 PN4_P2
PN4_N1 AF12 3 4 AE10 PN4_N2
PN4_P3 AF9 5 6 AD8 PN4_P4
PN4_N3 AF10 7 8 AE8 PN4_N4
PN4_P5 AF7 9 10 [CC] AF5 PN4_P6
PN4_N5 AE7 11 12 [CC] AF6 PN4_N6
PN4_P7 AC5 [CC] 13 14 [CC] AB7 PN4_P8
PN4_N7 AC6 [CC] 15 16 [CC] AB6 PN4_N8
PN4_P9 AG4 [CC] 17 18 AD10 PN4_P10
PN4_N9 AH4 [CC] 19 20 AD11 PN4_N10
PN4_P11 AH6 21 22 AC8 PN4_P12
PN4_N11 AH5 23 24 AC9 PN4_N12
PN4_P13 AB9 25 26 AL5 PN4_P14
PN4_N13 AB8 27 28 AK5 PN4_N14
PN4_P15 AB11 29 30 AJ7 PN4_P16
PN4_N15 AC10 31 32 AK7 PN4_N16
Table 9 Pn4 to FPGA Assignments
In Table 9, pins marked [CC] are clock capable and may be used to access the regional
clocking resources in the FPGA.
Banks 18 is fitted with resistors to allow DCI terminations on Pn4 signals.
4.8.1. Pn4 Signalling Voltage
The signalling voltage on the Pn4 connector (and User FPGA Bank 18) is selectable by
switch SW2B.
Switch 2B Pn4 voltage
Open 2.5V
Closed 3.3V
Table 10 Pn4 I/O Voltage Selection
It should be noted that the switch does not directly route power. The switch position is
monitored by the board control logic which, in turn, sets a power multiplexer to be either 2.5V
or 3.3V.
4.9. XMC Interface
4.9.1. Primary XMC Connector, P15
The MGT (GTP) links connected between the user FPGA and the Primary XMC connector,
P15, are compatible with PCI Express and Serial RapidIO. Depending upon the carrier card,
they may also be used for user-specific applications.
Version 1.0
Page 13

ADM-XRC-5T2-ADV User Manual
ADM-XRC-5T2-ADV User Manual
Signal FPGA Pin
GTP
Number P15 Pin
PCIE_TX0_P AB2 114A A1
PCIE_TX0_N AC2 “ B1
PCIE_RX0_P AC1 “ A11
PCIE_RX0_N AD1 “ B11
PCIE_TX1_P AG2 114B D1
PCIE_TX1_N AF2 “ E1
PCIE_RX1_P AF1 “ D11
PCIE_RX1_N AE1 “ E11
PCIE_TX2_P AH2 118A A3
PCIE_TX2_N AJ2 “ B3
PCIE_RX2_P AJ1 “ A13
PCIE_RX2_N AK1 “ B13
PCIE_TX3_P AN2 118B D3
PCIE_TX3_N AM2 “ E3
PCIE_RX3_P AM1 “ D13
PCIE_RX3_N AL1 “ E13
PCIE_TX4_P AP2 122A A5
PCIE_TX4_N AR2 “ B5
PCIE_RX4_P AR1 “ A15
PCIE_RX4_N AT1 “ B15
PCIE_TX5_P AW2 122B D5
PCIE_TX5_N AV2 “ E5
PCIE_RX5_P AV1 “ D15
PCIE_RX5_N AU1 “ E15
PCIE_TX6_P BA1 126A A7
PCIE_TX6_N BA2 “ B7
PCIE_RX6_P BB2 “ A17
PCIE_RX6_N BB3 “ B17
PCIE_TX7_P BA6 126B D7
PCIE_TX7_N BA5 “ E7
PCIE_RX7_P BB5 “ D17
PCIE_RX7_N BB4 “ E17
Table 11 XMC P15 Connections
4.10. ADV212 Interface
The ADV212 is a single-chip JPEG 2000 codec from Analog Devices. It is targeted for video and
high bandwidth image compression applications that can benefit from the enhanced quality and
features provided by the JPEG 2000 (J2K)—ISO/IEC15444-1 image compression standard. The
ADM-XRC-5T2-ADV features 4 ADV212 devices which can all operate independently or in 2 banks
of 2 for full frame capabilities.
4.10.1. Signal Description
See the ADV212 data sheet and associated literature for a full description of the operation of
these pins.
Signals common to each ADV212 bank
addr<1> to <3> -ADV212 address bus
mclk -ADV212 system clock
vclk -ADV212 video data bus clock
hdat<0> to <31> -ADV212 host data bus
field -ADV212 field sync for video mode
hsync -ADV212 horizontal sync for video mode
vsync -ADV212 vertical sync for video mode
jpeg_reset_l -asynchronous processor reset for ADV212’s
scomm5 -synchronisation signal for multi-chip operation
Version 1.0
Page 14

ADM-XRC-5T2-ADV User Manual
ADM-XRC-5T2-ADV User Manual
Individual signals to each ADV212 codec
ack_l - ADV212 acknowledge signal
cs_l - ADV212 chip select signal
dack_l<0> to <1> - ADV212 DMA acknowledge signals
dreq_l<0> to <1> - ADV212 DMA request signals
irq_l - ADV212 interrupt request signal
rd_l - ADV212 read enable for host interface operation
we_l - ADV212 write enable for host interface operation
vdat<0> to <11> - ADV212 video data bus
scom4 - ADV212
LCODE Output in Encode Mode
4.10.2. JPEG Processor Interface Pin Locations
Bank Signals Bank 1 (A & B) Bank 2 (C & D)
adv_addr<0> W35 AJ38
adv_addr<1> M41 AJ37
adv_addr<2> AA34 AH40
adv_addr<3> Y34 AH38
adv_mclk T37 AJ42
vclk Y42 AK8
field F41 AT5
hsync E40 AG12
vsync F40 AG9
jpeg_reset_l L42 AN41
scomm5 AF42 AF37
adv_hdata<0> AA39 AR40
adv_hdata<1> AA41 AT40
adv_hdata<2> AA40 AB34
adv_hdata<3> AA37 AP40
adv_hdata<4> AL42 AC34
adv_hdata<5> AD42 AC35
adv_hdata<6> Y39 AN40
adv_hdata<7> Y40 AN39
adv_hdata<8> AB41 AD35
adv_hdata<9> Y38 AM39
adv_hdata<10> W40 AM38
adv_hdata<11> AB42 AF39
adv_hdata<12> W38 AL41
adv_hdata<13> V39 AL39
adv_hdata<14> AD38 AD36
adv_hdata<15> Y37 AK38
adv_hdata<16> U38 AK37
adv_hdata<17> T41 AG37
adv_hdata<18> AE40 AP42
adv_hdata<19> P38 AG38
adv_hdata<20> N41 AC41
adv_hdata<21> W37 AC36
adv_hdata<22> R39 AB38
adv_hdata<23> L40 AF40
adv_hdata<24> M42 AE38
adv_hdata<25> M39 AR42
adv_hdata<26> K38 AP38
adv_hdata<27> L39 AE39
adv_hdata<28> L41 AD40
adv_hdata<29> M38 AT42
adv_hdata<30> G39 AU42
adv_hdata<31> K39 AD37
Version 1.0
Page 15

ADM-XRC-5T2-ADV User Manual
ADM-XRC-5T2-ADV User Manual
Individual Codec
Signals A B C D
vdat<0> J40 AA42 AV5 AM8
vdat<1> K42 AB36 AU6 AM7
vdat<2> K40 AB37 AV6 AN8
vdat<3> J38 W36 AR8 AL10
vdat<4> J42 AA35 AR7 AL6
vdat<5> J41 AA36 AN4 AJ8
vdat<6> H39 V40 AN9 AJ11
vdat<7> H40 W42 AL9 AH11
vdat<8> H41 W41 AM9 AH9
vdat<9> G41 U41 AG8 AH10
vdat<10> F42 U39 AH8 AJ10
vdat<11> G42 V41 AP8 AG11
dack_l<0> H38 T40 AM37 AK42
dack_l<1> F39 U42 AE37 AJ40
dreq_l<0> E39 T42 AN38 AK39
dreq_l<1> G38 T39 AL37 AT41
irq_l R38 N39 AR39 AP41
scomm4 AH41 AB39 AU41 AF41
cs_l Y35 N40 AV41 AG42
rd_l R37 P40 AU39 AD41
we_l P37 P41 AV40 AE42
ack_l N38 R40 AT39 AG41
5. Design Examples
Example UCF, HDL files and Application software are available from Alpha Data for
purchasers of this card.
Version 1.0
Page 16
