T101 Portable Power Supply Quick Start Guide
How To Use The Power Supply
Using with DC 12V Devices
Note: The power supply will automatically turn off after 30 seconds if it
does not detect a connected device.
Using with AC Devices
Connect the AC appliance to one of the T101 power supply's AC outlet.
ab
d
c
Using with USB Devices Using the LED Flashlight
1. Turn on
Double press " " button to switch on the LED lamp.
2. Change light modes
Double press " " button to switch between modes Flashlight / Blink / SOS.
2. To turn off
Long press " " button 3 seconds to switch off the LED lamp.
Connect the USB cable to one of the T101 power supply's USB
sockets. Connect the other end to your USB device.
LED Lamp
USB C
Connect the DC appliance to the power supply's 5.5mm 12V DC port,
press the " " button to switch on DC output. Long press the " " button
for 3 seconds to switch off.
Long press button for 3 seconds to switch on the power button and the
unit will start providing power to your appliances. Long press the button for
3 seconds to switch off.
"AC"
Press the button to turn on USB output. Long press the button for
3 seconds to switch off.
" "
Note: The power supply will automatically turn off after 30 seconds if it
does not detect a connected device.

T101 Portable Power Supply Quick Start Guide
Charging The Power Supply
With an AC Power Source With a Vehicle Charging Cable
ab
Charging by solar panel (Solar Panel is not included,
recommend to choose 18V/35W~ 40W solar panels)
With Solar Panel
c
Connect one end of the charging lead to the DC Input Port.
Start your vehicle's engine and connect the other end of the charging lead to
your vehicles auxiliary/cigarette lighter port.
Charging by Cigarette Lighter Adapter
Warning: The AC output ports can not be used when charging the power station
For any support or comments concerning our products,
please send an email to: [email protected] or toll free number in the USA: 800-473-5156
AC outlet
AC Adapter (charger) 15V/2A
Charging by AC Adapter
Input Charging
DC 13V~22V/2.0A Max
Using the included AC Wall Charger, plug the unit into any wall outlet to
charge the unit. You will know the unit is charging when "IN" ton the LED
display is blinking. The unit is fully charged when "IN" stop blinking and
LED display displays "100%". After the unit is fully charged, please
remove the AC wall charger in time.
Place your solar panel where it will get as much direct sunlight as possible.
Plug the output of the solar panel into the input of the unit to start charging.
You will know the unit is charging when the "IN" on the LED display is blinking.
The unit is fully charged when "IN" stop blinking and LED display displays "100%".
