Alphasonik VIVID User manual

VIVID
PORTABLE BLUETOOTH SPEAKER

SETTING THE PACE SINCE 1976
ALPHASONIK WAS FOUNDED IN 1976 WITH ONE MISSION, TO BRING
STATE OF THE ART PERFORMANCE TO THE AUDIO ENTHUSIAST.
In these early years we pioneered such ground-breaking technologies
which remain a benchmark in high-end audio.
Today, the new Alphasonik is committed to pushing the envelope
with regards to technology, quality and value. Our electronics feature
audiophile parts and circuit topology designed to let the full musical
experience come through, loud and clear. Our loudspeakers
employ the latest high technology materials and processes such as
carbon reinforced woven glass and titanium vapor deposition to deliver
your music with tremendous impact, dynamics and resolution.
We stand behind our quality with one of the best warranties in
consumer electronics. Compare Alphasonik products against
anything the competition has to offer. We’re condent you will
come to one conclusion...
ALPHASONIK HAS NO EQUAL.

TABLE OF CONTENTS
INTRODUCTION..............................................................................3
SPECIFICATIONS............................................................................4
FUNCTIONS...............................................................................5 - 6
WARRANTY................................................................................7 - 8

INTRODUCTION
Thank you for purchasing this Alphasonik product. Alphasonik
products are specically engineered and designed for the audio
environment. This manual contains important information about
installation and set-up procedures. With proper care and
installation, your new product will provide you with many years of
high performance listening enjoyment.

SPECIFICATIONS
Power Output: 5Watts x 2
Frequency response: 90Hz ~1 8kHz
Impedance: 4-ohms
Sensitivity: 80dB±2dB
S/N Ratio: ≥ 65dB
Distortion: ≤ 0.5%
Power supply: Built-in battery or micro USB 5V
Size: 9.05” x 2.87” x 3.89” (230 x 73 x 99mm)
Battery operating time: 5 - 6 hours
Weight: 1.18lbs (539g)

FUNCTIONS
Features:
1. Bluetooth Function: Bluetooth V2.1+EDR
2. Built-in Microphone, for hands free support
3. Aux in, compatible with all 3.5mm Audio Device
4. Built-in 2000mah Li-battery
5. Micro USB input for charging
Package Content:
1. Portable Speaker x 1
2. Micro USB Charging Cable x 1
3. 3.5mm Audio Cable x 1
4. Instructions Manual x 1
Button Identication:
5. “-”: -PREV / Vol-
6. “+”: +NEXT / Vol+
7. “O”: Pause / Play / Disconnect Device
Charging:
Use the USB port to charge the device, when the unit is charging
the LED indicator next to the charging port will illuminate red. Once
charge is complete the LED indicator will turn off.
When the battery level is low an audible alarm will notify you to
recharge the speaker. Connect the device to the charging port to
charge the speaker. You can use the speaker while connected to
the charging port and the charger will continue to recharge

FUNCTIONS CONTINUED
Bluetooth Mode:
1. Press and hold down the “O” button to turn the speaker
ON/OFF. When in Bluetooth mode, the LED indicator will
illuminate Blue and the LED will blink.
2. Search your compatible device in bluetooth settings for
“VIVID” and select it to connect to the speaker. The blinking
light will stay illuminated when pairing is successful.
3. Momentarily Press the “O” to pause or play media. Pressing
and holding the “O” button down will disconnect the
bluetooth speaker.
4. Selecting the “+” / “-”. buttons momentarily will increase and
decrease the volume. Pressing and holding the “+” / “-”
button will change the media track.
Handfree Function:
5. While in Bluetooth mode, when receiving a phone call, you
can momentarily press the “O” button on the speaker to
answer the incoming call and press again to end the call.
AUX Mode:
When using AUX mode insert a 3.5mm cable, the LED on the
speaker will illuminate Red to conrm the device is now in AUX mode.

WARRANTY
Alphasonik, warrants this product against all defects in material and
workmanship for a period of one (1) year from the date of original
purchase provided it was purchased from an Authorized Alphasonik
Dealer.
The conditions of this warranty and the extent of the responsibility
of Alphasonik, under this warranty are as follows:
1. DATED PROOF OF PURCHASE IS REQUIRED FOR
WARRANTY SERVICE OF THIS PRODUCT. Information
about Alphasonik authorized warranty service may also be
obtained at www.alphasonik.com or by emailing Alphasonik
at [email protected].
2. This warranty will become void if service is performed by any
one other than an approved Alphasonik Warranty Service
Center.
3. This warranty does not apply to any product which has been
subjected to misuse, neglect or accident, or which has had
the warranty seal broken, serial number altered, defaced or
removed, or which has been connected, installed adjusted
or repaired other than in accordance with the instructions
furnished by Alphasonik.
4. This warranty does not cover static, electrical interference,
adjustments or labor costs for the removal or reinstallation of
the unit for repair.
5. The sole responsibility of Alphasonik under this warranty
shall be limited to the repair or replacement thereof, at the
sole discretion of Alphasonik.

WARRANTY CONTINUED
6. If it becomes necessary to send the product or any defective
part to Alphasonik or an authorized service station, the
product must be shipped in its original or equivalent carton,
fully insured, with shipping charges prepaid. Alphasonik
will not assume any responsibility for any loss or damage
incurred in shipping.
7. This warranty is not transferable and protects the original
purchaser provided they reside and made their purchase
in the United States. International consumers may contact
their local retailer or distributor for warranty information.
8. ALL IMPLIED WARRANTIES, EXCEPT TO THE EXTENT
PROHIBITED BY APPLICABLE LAW, SHALL HAVE NO
GREATER DURATION THAN THE WARRANTY PERIOD
SET FORTH ABOVE. UNDER NO CIRCUMSTANCES
SHALL ALPHASONIK BE LIABLE FOR ANY LOSS OR
DAMAGE, DIRECT OR CONSEQUENTIAL, ARISING OUT
OF THE USE OR INABILITY TO USE THE PRODUCT.
BECAUSE SOME STATES DO NOT ALLOW LIMITATIONS
ON HOW LONG AN IMPLIED WARRANTY LASTS OR
EXCLUSIONS OR LIMITATIONS OF INCIDENTAL OR
CONSEQUENTIAL DAMAGES, THE ABOVE LIMITATIONS
OR EXCLUSIONS MAY NOT APPLY TO YOU.
9. THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS
AND YOU MAY ALSO HAVE OTHER RIGHTS THAT VARY
FROM STATE TO STATE.
10. Should you have any difculties with the performance of this
product during warranty or with any Alphasonik authorized
service center, you may contact Alphasonik by emailing us at
[email protected].
