alphatronics UNii User manual

Alphatronics BV l Boekdrukker 5-7 l 3861 SE Nijkerk l Tel.: [phone] l [email protected]
User manual
Handleiding voor de gebruiker
English page 4
Nederlands pagina 21

User manual UNii Rev.2.11 – 14-07-2022 2
EN
Table of contents
INTRODUCTION...............................................................................................................................................................................4
Purpose of this manual _________________________________________________________________________________________4
General guidelines for use of the system ________________________________________________________________________4
Keypad...............................................................................................................................................................................................5
Keys____________________________________________________________________________________________________________5
Proximity sensor________________________________________________________________________________________________5
Display...............................................................................................................................................................................................6
Card reader.......................................................................................................................................................................................6
Sections and Groups......................................................................................................................................................................6
Operation ..........................................................................................................................................................................................7
Arming _________________________________________________________________________________________________________7
Disarming ______________________________________________________________________________________________________7
Hot keys ________________________________________________________________________________________________________7
Status __________________________________________________________________________________________________________7
Menu ___________________________________________________________________________________________________________8
Arming with a tag_______________________________________________________________________________________________8
Information_____________________________________________________________________________________________________8
Time switches __________________________________________________________________________________________________8
Test mode______________________________________________________________________________________________________8
Installer authorised _____________________________________________________________________________________________8
Audible signals of the system.......................................................................................................................................................8
User Menu ........................................................................................................................................................................................9
Information_____________________________________________________________________________________________________9
Notifications____________________________________________________________________________________________________9
Open inputs ____________________________________________________________________________________________________ 9
Section status __________________________________________________________________________________________________9
Event log _______________________________________________________________________________________________________9
System info_____________________________________________________________________________________________________9
UNii manager key_______________________________________________________________________________________________9
Overtime _______________________________________________________________________________________________________9
(Un)-Bypass ____________________________________________________________________________________________________9
Users__________________________________________________________________________________________________________10
Add user_______________________________________________________________________________________________________10
Edit existing user ______________________________________________________________________________________________10
Change name__________________________________________________________________________________________________10
Change code __________________________________________________________________________________________________10
Change code functionality _____________________________________________________________________________________10

User manual UNii Rev.2.11 – 14-07-2022 3
EN
Change language ______________________________________________________________________________________________11
Change profile _________________________________________________________________________________________________11
Add tag________________________________________________________________________________________________________11
Remove tag ___________________________________________________________________________________________________11
Advanced settings ........................................................................................................................................................................11
Keypad settings _______________________________________________________________________________________________11
LED brightness ________________________________________________________________________________________________11
Display brightness _____________________________________________________________________________________________11
Key volume ____________________________________________________________________________________________________11
Buzzer volume_________________________________________________________________________________________________11
Proximity sensor_______________________________________________________________________________________________11
Doorbell _______________________________________________________________________________________________________11
mySmartControl _______________________________________________________________________________________________11
Change Date/Time_____________________________________________________________________________________________12
System test menu _____________________________________________________________________________________________12
Access installer________________________________________________________________________________________________12
Input test ______________________________________________________________________________________________________12
General ............................................................................................................................................................................................12
mySmartControl _______________________________________________________________________________________________12
Screensaver ___________________________________________________________________________________________________13
Alarm in a 24-hour zone _______________________________________________________________________________________13
Protection against the ‘unauthorised’ entering of PIN codes ____________________________________________________13
Menu overview ________________________________________________________________________________________________14
Definitions.......................................................................................................................................................................................15
European norms and security classes......................................................................................................................................15
APPENDIX A: DETECTOR DEPLOYMENT (can be filled in by the installer)........................................................................16

User manual UNii Rev.2.11 – 14-07-2022 4
EN
INTRODUCTION
Purpose of this manual
The purpose of this manual is to help the user get familiar with the UNii intrusion system. The manual explains
about how to operate and control the control panel. Several of the special options explained in this manual can
only be executed by the main user (supervisor).
General guidelines for use of the system
Do not panic when the alarm goes off. Disarm the system with your PIN code, access tag or wireless remote
control (keyfob) and read the information that is shown on the display of the keypad.
The system works with a keypad that has an OLED display. The OLED displays information about the status of
your system. If the information on the display is not clear, first consult this user manual.
Never hand your PIN code, access tag or keyfob over to another user, this can lead to unpleasant situations.
If a malfunction occurs, first consult this user manual. If the fault persists, contact your installer immediately. Your
installer will give you further instructions.
Note important events (false alarm, user error, etc.) in a logbook including zone number, date, and time. During
annual maintenance, the installer may be able to take measures to prevent these situations in the future.
The UNii intrusion system is an advanced electronic device that has been professionally installed and
commissioned by a professional installer. This device is called the "control panel". The detection components,
optical and acoustic alarm devices such as strobe lights, sirens and alarm diallers are connected to the control
panel. The UNii is equipped with an integrated IP dialler that is connected to a free LAN port of your broadband
modem / router for reporting alarms to, for example, a monitoring station.
The UNii security alarm system is armed and disarmed via the connected keypad using a PIN code or access tag.
It is also possible to arm and disarm the security system via a (user) APP on the smartphone or tablet.
The system has been designed and tested according to the European standards regarding stability, reliability, and
insensitivity to external electrical interference.

User manual UNii Rev.2.11 – 14-07-2022 5
EN
Keypad
Below is a picture of the UNii keypad.
Keys
The numerical keys 0 to 9 are used to enter a PIN code or numerical values in the menus.
The keypad has 4 black function keys, these keys are located above the numeric keys and have no fixed function.
Depending on the status of the system, the operation being performed or the menu in which the user is located,
the function of the function key may change. The function of the key is indicated by a text directly above the key in
the display. The 3 left function keys can also be used as a shortcut. A hotkey can perform a specific action, such
as switching on a certain section immediately in the night situation or activating an output. Ask your installer
about the options.
The keypad has Navigation keys, the numeric keys 2, 4, 6 and 8 are next to numeric keys also a navigation key.
When navigation is possible or desired, the key illumination will go out under all other keys. With the navigation
keys, only the keys of the navigation directions that are currently possible will light up.
Proximity sensor
The keypad is equipped with a proximity sensor. The proximity sensor causes the key backlight illumination and
OLED display to light up as soon as movement is detected in the nearby vicinity of the keypad. The sensitivity of
the proximity sensor can be set by the supervisor in the user menu. See keyboard settings later on in this manual.
1. OLED display
2. Keys
3. Function keys
4. Proximity sensor
5. Card reader (optional)
6. Navigation keys

User manual UNii Rev.2.11 – 14-07-2022 6
EN
Display
In the picture below the OLED display of the UNii keypad is shown.
1. System name (2 lines)
2. Function of the function keys
3. Local Time
4. Indication that there is a message in the system.
5. Indication that the installer is authorised to enter the programming.
6. System is in test mode (contact your installer)
Card reader
The keypad of the UNii security system is available in 2 versions: a standard version and a luxury version with a
built-in card reader. The card reader is located directly under the numeric key 5. The card reader uses the latest
DESFire EV2 reading technology, the most secure reading technology at this moment. The reading distance of the
card reader is approximately 5 cm above the numeric key.
Sections and Groups
The UNii security system uses Sections and Groups.
A section is a part of the security system and can be armed and disarmed independently from the rest of the
system. An example of a section is for example, the ground floor of a residential house, a wing of an office
building or the warehouse of a company. Each section has a name that is programmed by the installer during
installation.
Groups can also be created above the section structure. A group can be created to arm or disarm multiple
sections simultaneously. An example of a group is complete floor of a building of the entire house, a group also
has a name that is programmed by the installer during installation.
Groups and sections can be armed and disarmed by a user by means of a PIN code or DESFire tag.

User manual UNii Rev.2.11 – 14-07-2022 7
EN
Operation
Arming
To arm the system, press the function button "Arm", You will now be asked to enter a valid PIN code. Once the
valid PIN code has been entered, the section or group for which the user is authorized will be displayed and can be
armed. An open circle is shown in front of the name of the section or group, this indicates that the section or
group is disarmed, if the circle is flashing the section or group is not ready to be armed. If the circle is closed, then
the section or group is already armed.
Select the section or groups to be armed by using the "Select" function key, a tick () will appear behind each
section or group. Multiple section or groups can be selected. When all section or groups are selected press the
"Arm" function key to arm the selected sections or groups.
After starting the arming procedure, the exit delay is heard (if set) via the buzzer of the keypad. The buzzer beeps
faster during the last 5 seconds of the exit time. Opening a delayed zone after the exit time has expired will start
the entry procedure.
If an arming cannot be successfully completed (e.g., if an input remains open) then the system will not be armed.
At that moment, a double beep will be heard via the buzzer of the keypad and on the loudspeaker output of the
UNii.
In addition to using a PIN code, it is also possible to arm with a tag/card if the keypad is equipped with a built-in
card reader. For arming with a tag/card, see "Arming with a tag" later in this manual.
NB. When the system is configured by the installer for arming without a PIN-code, the step to request a PIN-code
will be skipped.
Disarming
To disarm the system, press the function button "Disarm", you will now be asked to enter a valid PIN code. After
entering a valid code, the sections or group that can be disarmed are displayed. A closed circle is displayed in
front of the name of the section or group, indicating that the section or group is armed. Use the "Select" function
key to select the section or group to be disabled, a tick () will appear after each section or group. Multiple
sections or groups can be selected. If all sections or groups are selected press the "Disarm" function key to
disarm the selected sections or groups.
Hot keys
The 3 left function keys can also be used as a hotkey. For example, your installer can program a hotkey to be used
to arm certain sections in the night mode or activate an output to open the gate. Ask your installer about the
options.
Status
The section statuses of the system can be viewed using the section function key. An open circle means section or
group disarmed, a flashing circle means section or group not ready to arm, and a closed circle means section or
group armed.

User manual UNii Rev.2.11 – 14-07-2022 8
EN
Menu
This function key opens the user menu where several functions and menus can be found. See the “User
menu” chapter for more explanation about individual functions and menus.
Arming with a tag
If the keypad is equipped with a built-in card reader, it is possible to arm and disarm the system using a DESFire
EV2 tag or card. Depending on the tag settings (direct arm/disarm or normal), the tag will work as if a normal
(PIN) code has been entered and the user must first select the relevant sections or groups and press the "arm"
function key to arm. If direct is programmed the system will be armed immediately if all sections or groups linked
to the tag are disarmed. If one or more sections or groups are already armed, the system will disarm, arming will
be done by presenting the tag again.
Information
If information is present, the system will indicate this by showing the "i" symbol on the right-hand side of the
display and an audible beep via the buzzer of the keypad. With function key 3 (info) the information can be
displayed and possibly deleted. When all messages have been deleted, the "i" symbol will disappear from the
display.
Time switches
The system can be programmed to arm and disarm automatically, for an explanation see chapter "Time switch" in
the User menu.
Test mode
When the installer has placed the system in the test mode, the ‘!’ Symbol is shown in the display. For more
information consult your installer.
Installer authorised
If the installer is authorized by the supervisor (main user code) to access the system, a tool symbol is shown on
the right of the display. The supervisor has the choice to give the installer only installer rights or to give installer +
user rights. A time limit can also be entered for how long the installer has authorization for the system.
If the installer is not authorized by the supervisor, he cannot do anything in the system.
Audible signals of the system
Alarm: Alarm siren sound will be heard via the connected siren or speaker.
Fire: Slow-whoop fire sound will be heard via the connected siren or speaker.
Key stroke: Short tone 0,5 seconds.
Trouble buzzer: ●□●□● short tone every 10 seconds
(can de set to no sound during the night).
Entry buzzer: Constant tone (during programmed time).
Exit buzzer: □□□●□●□●□intermitted tone (last 5 seconds faster).
Tones ●= 0,5 sec. tone
= 1 sec. tone
□= pause

User manual UNii Rev.2.11 – 14-07-2022 9
EN
User Menu
In this chapter the different programming options and functions of the (user) menu are explained. Depending on
the rights (set in the profile of users), some options may or may not be visible.
Information
The following functions are available under the "Information" sub-menu:
Notifications
The notifications menu shows the alarm and / or system events that are still present in the system's memory. The
messages can be deleted using the "Delete all" function key, provided the alarm situation has been removed. If
notifications cannot be deleted, a new notification will be given.
Open inputs
Using this menu option, it is possible to see which inputs (sensors) are still open (in alarm).
Section status
The status section is displayed in this option. An open circle indicates section is disarmed, a flashing circle
indicates section not ready to arm, a closed circle means section armed.
Event log
The last 1000 system events are stored in the Event log menu and cannot be deleted. By selecting a log line with
function key "Select", detailed information can be displayed if available.
System info
This screen shows the software version of the system and the IP address.
UNii manager key
This screen shows the unique key of your UNii security system. The installer needs this key to connect to the UNii
manager tool to program the system.
Overtime
With this option an overtime time can be programmed for the automatic arming function, if used. Select the
correct time switch from the list and enter the time you would like the system to stay disarmed.
(Un)-Bypass
A list of inputs is displayed in the bypass menu, a selected input can be bypassed or un-bypassed. By bypassing
an input, it is temporarily disabled. Not all inputs can be bypassed, this is determined by the installer during
installation.

User manual UNii Rev.2.11 – 14-07-2022 10
EN
Users
In the user menu you can, if permitted, modify your own user settings, or create a new user (only possible for
supervisors). Depending on the UNii control panel model, the system has a maximum of 2,000 users. A code
consists of 6 digits, with which 999,999 different code combinations can be made. A code with only 000000 is
invalid.
In the usermenu the following main options are available:
-Change own data.
-Edit existing user.
-Add user.
Add user
Only possible for a user with administrator rights (Default this is User 1), this is normally only the supervisor of the
system. A new user code can be created with this option. You will be asked twice to enter the new (PIN) code.
After the (PIN) code has been created, the user settings can be changed via the "Change own data" or via the "Edit
existing user"
Edit existing user
Only possible for a user with administrator rights (Default this is User 1). If the 'Change existing user' is selected, a
list of users is shown in the display. Use the arrow up (key 2) and arrow down (key 8) to find the desired user and
press the key or "Select" function key to view and / or modify the settings for this user.
If tags are used to arm and disarm the system, the user can also be searched in the system by presenting his /
her tag. Once the list of users is displayed press the "Search" function key and present the tag to the reader on the
keypad, the display will now jump to the user associated with this tag. Press the key or "Select" function key to
view and / or modify the settings for this user.
The following user settings are present in the ‘Change own data’ of ‘Edit existing user’ menu’s:
Change name
Change the username. The username is displayed in the logbook and reported to a monitoring station.
Change code
Change the PIN-code you use to arm/disarm the system. The code cannot be changed to a code that already
exists or to a duress code. The code 000000 code is an invalid code.
Change code functionality
Changing the function of the (PIN) code. Options are:
•Code Direct arm and disarm
•Code to menu.
Code Direct arm and disarm ensures that all sections or groups linked to this user code are armed or disarmed
directly, Code to menu instructs the user to first select the section or groups and use the 'arm' or 'disarm' function
keys to arm or disarm the sections or groups.
