dun-bri GROUP 708.005 User manual
WARNING
Ensure that only suitably trained personnel attempt to install this device or devices. Failure to install the device
properly could result in damage to the vehicle, injury or even death.
Installation Guide:
Single Camera Reversing Kit (708.005)
Page 1
Rev. 07/17
Preparing for installation
Carefully remove the camera system and examine the
contents for damage that may have occurred during transit. If
damage is found or if anything is missing, contact the Dun-Bri
Group for advice. Do not use broken or damaged devices or
parts. The contents should include;
1x 5” TFT LCD monitor
1x Monitor sun shield
1x Reversing camera
1x Mounting bracket
1x Remote control unit
1x Camera connection cable
1x Power connection cable
1x Heat shrink tube for camera connection
Installation and mounting
1. Choose a suitable location for the camera that is free of
obstructions and at low-risk from accidental damage.
Mount the camera using the bracket attached. Using
the heat shrink tubing provided, cover the connection
between the camera and the cable.
2. Route the camera connection cable from the camera to
the location where you will be installing the monitor.
3. Mount the camera monitor, connect the camera cable and
attach the sun shield.
4. Route and install the power cable harness to a suitable
connection. The harness will be fitted with a 3 Amp mini
blade fuse. Ensure all connections are secure. Refer to
Fig 1. for further cable information and colour coding.
5. Check all connections and power up the monitor to check
correct functionality of the reversing camera.
Using the system menu and changing settings
There are a number of options and settings available from the
menu, accessible from the monitor. To access them, press
on the Menu button. See Fig 2. for location information and
symbol key. Further information on the settings available to
you, and what your options are are also included in Fig 2.
Further help and assistance
For further help and technical support, please call Dun-Bri
Group directly on 01763 274185.
!
Do not install and/or operate this safety product unless you have read and
understand the safety information contained in this guide.
1
Where applicable, proper installation combined with operator training in the use, care and maintenance of reversing safety devices are
essential to ensure the safety of personnel and the public.
Some warning devices can require high electrical voltages and/or currents. Use caution when working with live electrical connections.
This product must be properly earthed via a reliable connection. A poor earth connection and/or shorting of connections can cause high
current arcing, which can cause personal injury and/or severe vehicle damage, including fires.
Proper placement of the device(s) with the correct installation with maximise the performance of the device. Ensure that any switching or
control units used with the device are placed within easy reach of the operator so that he/she can operate the device without losing eye contact
with the road, particularly important during manoeuvres.
It remains the responsibility of the driver to ensure that all features of this product work correctly. In use, the device should be free of
obstructions from vehicle components, for example, the tailgate, people, vehicles or other obstructions.
Where applicable, the use of this or any other safety device does not ensure all drivers can or will observe or react to a hazard during
manoeuvres. It is your responsibility to be sure you can proceed safely before perfoming such actions. It is always recommended that you
utilise a trained banksman.
1.
2.
3.
4.
5.
6.
CAUTION: AIR BAGS
Many vehicles are now fitted with side and curtain air bag
systems in addition to those traditionally fitted within the front
of the vehicle. Ensure that you do not drill into the cables or
sensors and accidentally trigger the devices during fitting.
G
WARNING: ROOF SUPPORTS
There will be a roof support member(s) that spans the
distance between the driver’s side and the passenger’s side
of the compartment. Do not drill through or into this member.
Ensure that you adjust the cable route accordingly.
!
dun-bri
DIM CAM M/N D/N POWER MENU DOWNU PI R
POWER
POWER
VIDEO
MODE
MODE
SELECT
MENU
VIDEO
SELECT
TFT LCD
MONITOR MOBILE
Page 2
Rev. 07/17
Installation Guide:
Single Camera Reversing Kit (708.005)
1
2
3
4
5
6
Fig 1.
Power harness connection diagram
Cable identification
Red: Power (fused @ 3A)
Black: Earth
White: Trigger AV 1
Brown: Trigger AV 2
Camera: AV1
Camera: AV2
Monitor
Vehicle connections
Red: Connect to ignition live feed
Black: Connect to chassis earth point
White: Connect to + terminal on input signal
Brown: Connect to + terminal on input signal
Camera: Connect to extension lead
Camera: Connect to extension lead
Monitor: Connect to feed from monitor
Please note: Camera triggers are positive switching. When
fitting camera and monitor make sure to line up the arrows
marked on the connectors.
1
2
3
4
5
6
7
Page 3
Rev. 07/17
Installation Guide:
Single Camera Reversing Kit (708.005)
Fig 2.
Monitor key and configuration information
Monitor button symbol key
1. Automatic low light sensor
2. Camera selection
3. Mirror/normal display
4. Dimmer manual setting
5. Power on/off
6. Main menu
7. Select down/volume down
8. Select up/volume up
9. Remote control receiver
dun-bri
DIMC AM M/ND /N POWERM ENU DOWNU PI R
1 2 34567 8 9
dun-bri
DIMC AM M/N D/NP OWER MENU DOWN UP IR
6Display menu
: Brightness
: Contrast
: colour
: Volume
: Language
: Dimmer
: park off/on
: Cam 1 timer
: Cam 1 normal/mirror
: Cam scan
To scroll though menu press menu
Press menu to select, to access sub-menu
press menu and use up /down to
change settings.
Adjustment 1-100
standard 50
Adjustment 1-100
standard 50
Adjustment 1-100
standard 50
Adjustment 1-100
standard 50
English
German
French
Spanish
Polish
portuguese
Italian
Chinese
Nederlands
manual setting dimmer
function... auto/off
Parking aid on/off
shows space awarness
marker when reversing
When using reverse triggers
set camera on timer for
3-5seconds before turning off
Reverse camera image when
using camera 2 on front of
vehicle
Scan between each camera fitted
Settings: 2,4,6,8,10 seconds
Page 4
Rev. 07/17
Watermill Industrial Estate
Aspenden Road
Buntingford SG9 9JS
United Kingdom
Customer Service & Support
UK 01763 274185
Outside UK +44 17632 74185
www.dun-bri-group.com
Installation Guide:
Single Camera Reversing Kit (708.005)
Technical specifications
Monitor specifications
Aspect Ratio: 16:9 image
Resolution: 640x480 dpi
Brightness: 430cd/m2
Power supply: 12-24v DC
Audio: Built in speaker
Operating temp: -20C~70°C.RH95% Max
Storage temp: -30C~+80°C.RH95% MAX
Camera specifications
Image sensor: 1/3” Sony CCD
TV system: NTSC/PAL
IP rating: IP68
Vibration rate: 10G
Night vision: Fitted
Audio function: Fitted
Effective pixels: N:510(H) x 492(H) pixels
P: 500(H) x 582(V) pixels
Horiz. resolution: 700TV line
Video output: 1.0vp-p, 75 Ohms
Minim. illumination: 0.1LUX/F1.2
Built-in lens: F:2.8mm
Power supply: DC12v (+/-10%)
Lens angle (degree): 120
Operating temp: -20C~70°C.RH95% Max
Storage temp: -30C~+80°C.RH95% MAX
