Alpine HDP-D90 User manual

Owner′s Manual
HDP-D90
14 CHANNEL AUDIO PROCESSOR AMPLIFIER

1 EN
Contents
Instructions
Instructions ........................................................ 1
Warning ....................................................... 1
Points for Safe Use ........................ 1
Copyright Notice ......................................... 3
Preparation work ........................................ 4
Accessory List ................................4
Connections and Functions ..........5
Connections and Functions ..........6
Indicators ...................................... 7
Computer S oftware .................................... 8
Precautions installation ............... 8
Computer S oftware Introduction .8
Connection and Temperature Display 9
Connection Settings ..................... 9
Temperature Display .................... 9
File Settings ..........................................9
Option Setting ......................................9
Signal Generator Settings ...........10
Signal Selection ................... 10
Volume ................................. 10
Sine Wave Frequency ........... 10
Output Signal Selection .......10
Input Link S ettings ......................10
Output Link S ettings ...................10
Built-in AMP .................................10
Firmware Up da te Settings ..........11
Restore Factory Settings .............11
Shutdown dela y setting ..............11
Language Settings ...................... 11
View A bout .................................. 11
Encrypti on Settings ........................... 11
Master volume s etting ................ 12
Function Page Selecti on .................... 12
Home Page .................................. 12
Main Source Selection ......... 13
Main Source Attenuation
Setting .................................. 13
Mix Source Selection ............13
Preset Sound Effect S ettings13
Enter EQ ...................................... 13
Type selection ...................... 13
Channel Mute Setting .......... 14
Link Settings ........................ 14
EQ Adjustment ..................... 14
Equalizer Settings ................ 15
Channel Settings ..................16
X-Over ................................... 16
Output EQ ................................... 16
Bridge Mode ......................... 16
Delay ............................................17
Mix ............................................... 17
RTA ...............................................17
Specifications ........................................... 19
Function Parameter .................................. 20
English

1 EN
Instr uc ti on s
Warning
Points for Safe Use
Please read t h is manu al carefully before
using the mac hine and sy stem components.
This manual contains instructions on how to
use t his product safely and effectively. If
failure to follow the i n structions in this
manual causes malfunctions, Alpine will not
assume any responsibility.
This manual uses various icons to explain
how to use t his product safely, and reminds
you to pay attention to th e dangers t h at may
be caused by improper connection and
operation. The meaning of these icons will be
explained below. A complete understanding
of t h e meaning of these icons is ver y
important for the correct use of this manual
and this system.
Do not use any f eatures that will distract yo u
while driv i n g
Any function that affects your concentration
should on ly be used after the car h a s come to a
complete stop. To use these function s , please
park your vehicle i n a safe place first.
Otherw is e, an accident may result.
Do n ot disas s e mb le or mod i f y
Otherw i s e, it may cause an accident, fire or
electric sh ock.
The vo lum e must be main t a i n ed a t a level
where the noise outside t h e car can b e heard
while driv i n g
Inaudible eme rgency vehi cle sirens and road
warning si g n a ls (train intersections, etc.) are
very dangerous an d may cause accidents. In
addition, excessive volume may cause hearing
loss.
This prod uct is only s uitable for cars wi t h 12V
negative gro und ing
Otherw i s e, it may cause a fire and other
accidents.
Smal l obje cts s u c h as bolts or scr ews sho uld be
kept out o f the r each of c h ild ren
Swallowing small objects may cause serious
injury. Once swallowed by mistake, please
immediately med i ca l.
When replacin g the fuse , yo u must choose a
fuse with t h e co rrect am pe re va l u e
Otherw i s e, it may cause a fire or electric shock.
Do n ot blo ck the vent ilation ho les or heat sink
Otherw i s e, it may cause in ternal h eat build-u p
and may cause a fire.
This product ca n on l y be use d in 12V mobile
appl ications
If use d in non-designed applications, it may
cause fire, electric s hock or other injuries.
Make th e correct conn ect ion
If it is n ot connected properl y, it may cause fire
or product damage.
Before wiring , disconne ct the cable fr om the
negative termi na l o f th e b attery
Otherw i s e, i t may cause electric shock or injury
due to ele ctrical short circuit .
Warning
It is ver y dangerous to operate this system
while driving. The user should stop before
operating the software.
Road conditions and laws take precedence over
the information displayed on the map: When
driving, you should abide by actual traffic
restrictions and conditions.
This software is specially designed for this
machine and cannot be used in combination
with other hardware.
Warning
This symbol indicates important instructions.
Failure to heed these instructions can result in
serious injury or even death.

2 EN
Do not let the cable be entang led with
sur roun d ing o bjects
Arrange the wires and cables in accordance
with the requirement s of the manua l to
prevent t h em from becoming obstructive while
driving. Cables or wires that obstruct or ha n g
on the steering whee l, shift lever, brake ped a l,
etc. are extremely dan gerous.
Do n ot sp lice cab les
Do not cut the cable insula tion to supply power
to other equipment. O t h er w ise, the current
carrying capacity of the wire will be exceeded,
resulting i n fire or elect ric shock.
Do n ot dam a g e the pipe or wir ing when drill i n g
When drilling holes in the chassis for
installation, be careful n ot to touch, damage or
obstruct the pipes, fuel lines, fuel tanks or
wires. If you don' t pa y attention, it can cause
fire.
Do not use bolts o r n uts in b rakes or steering
systems fo r grou n din g connectio ns
Never use bolts or nuts used in brakes or
steering systems (or any other sa fety -related
systems) or fuel tanks for installation or
grounding connections. The use of such parts
will cause th e car controller to fail, result i n g in
fire an d so on.
Do not install on th e s teering whe e l or gear
leve r, etc., which ma y hinde r the op e ration of
the c ar
Otherw i s e, i t will obstruct the front line of sight
or obstruct moving parts, etc., causing serious
accidents.
When the re is a problem , p lease stop using it
imme d iately
Otherw i s e, it may cause personal injury or
damage to the product. Please return this
product to an authorized Alpine dealer or the
nearest Alpine service center for repair.
As k pr ofessional s fo r w iring and installation
The wiring a n d installation of this product
require professional skills and experience. For
safety reasons , please contact the dealer where
you purchased the product for installation.
Use d esig nated accessories and install se c urely
Make sure to use only desi gn ated accessories.
The use of non-designated pa rts may cause
internal da m age to th e device, or it may not be
securely installed in place. This can cause parts
to loosen and cause da n ger or product failure.
Arrange the wires to avoid c rim p ing o r b eing
sq uee zed b y s h ar p m e tal ed ges
The arrangement of wires and cables sh ould be
far away from mov in g parts (such as seat tracks)
or sharp edges or corners. This will avoid
crimping and damage to th e wires. If th e wiring
passes through a metal hole, a rubbe r gasket
should be used to prevent the wire insula tion
from being cut by t h e edge of the metal hole.
Do n ot install in high hum i d ity or d usty
location s
Avoid installing the device in a location with
high humidity or dust. Moisture or dust invades
the devi ce and ca n cause product failure.
Precautions
Prod u ct cleaning
Please use a dry soft cloth to clean t h e product
regularly. If the dirt is difficult to remove, soa k
a soft cloth with water only. Any other solvent
may dissol ve.
temperature
Before turning on the mac hine, please make
sure that the temperature in the car is between
+60°C and -20 °C.
Maintai n
If you encounter a problem, do not repair it
yourself. Please return thi s product to an
authorized Alpine dea ler or the nearest A lpine
service center for repair.
Installation location
This machine can n ot be i n stalled in a n y of the
following places:
Notice
This symbol indicates important
instructions. Failure to heed these
instructions may result in injury or majo r
property damage.

3 EN
Near direct sunlight and h eat sources
Places with high humidity and n ear water
sources
Dusty places
Locations subject to severe vi bration
Copyright Notice
The Bluetooth® word mark and logo are registered trademarks held by Bluetooth SIG, Inc. Alpine
Electronics has obtained permission to use the word mark and logo, and other trademarks and trade
names belong to their respective owners.
*
Appropriate recycling channels should be adopted for the disposal of electronic products to reduce electronic waste pollution
.

4EN
Preparati o n work
Accessory List
Machine Screw×4
Self-tapping Screw×4
Mounting Brackets ×2
2×13P Input Cable
USB 2.0 Cable
External Bluetooth Module
Main Unit

5EN
Connections and Functions

6EN
Connections and Functions
①②③④⑤ Pre-Ou t jac k s
5 g roups of RCA aud io signal ou tput, which
can be connected to an external power
amplifier.
⑥ RCA Aud io Inp ut ja c ks
1 groups of RCA audio signal input, which
can be connected to the R CA audio signal
output of car audio player.
⑦ Hig h Level Inpu t Conn e ctor
Connect to the high-level ou t put of the car
audio player.
⑧ Coaxia l Inp u t jac k
Connect the car audio coaxial ca ble, switch
the audio source of the machine to the
digital signal in put, and play th e coaxial
digital signal.
⑨ Optical In p ut j ack
Connect the car audio optical fiber cable,
switch the audio source of the machin e to
the digital signal input, and play th e optical
digital signal.
⑩ Co ntro ller Conne ctor ( So ld separately)
System expansion interface.
⑪ USB 2 .0 co nnector
It can be connected to a computer via a USB
2.0 cable for detailed tuning operations and
settings.
⑫ Exte rna l Bluetooth connector
Choose hig h -definition Bluetooth as the
input signal, or connect HDP-D90 mobile
phone tuning software. After the connection
is successful, the Bluetooth is always on.
⑬ Power Su pply Terminal
Connect t h e car battery.
⑭ Fuse
Insert two 30A fuses.
⑮ Inp ut Sele ct Sw itch
When the switch is pulled to th e "ACC"
terminal, ACC starts the machine; when it is
pulled to the "HOST" terminal, the machine
is started by the high level input sig n a l
H1-/H1+.
⑯⑰ CH 1 -4 Sp ea ker O u tpu t Termina l s
The amplifier output of the machin e is
connected to the speaker.
⑱⑲ CH 5 -8 Sp ea ker O u tpu t Termina l s
The amplifier output of the machin e is
connected to the speaker.
⑳㉑ CH 9 -12 Sp eaker Out p ut Terminals
The amplifier output of the machin e is
connected to the speaker.
㉒ Exte rnal Power Ampl if ier ( S o ld s e parately)
Connect an external power amplifier.
㉓ Car Audio P laye r ( S o ld se parately)
Connect t h e car aud i o player.
To prevent extern a l noise from entering th e audio system.
The installation position of the machine and th e wiring arrangement should be at least 10cm
away from the automobile wiring harness.
Try to keep the battery power cord away from other wires.
Securely conn ect the ground wire to the bare metal contacts of the car chassis (remove any
paint, dirt or grease if n ecessary ).
If you want to attach an optional noise suppresso r, please try to keep it away from the
machine when connecting. Your Alpine dealer has various types of nois e suppresso rs, please
contact them for details.
Your Alpine dealer is profici en t i n noise prevention methods, please con s ult y our dealer for
details.

7EN
Indicators
① Power and Protection In d icator
Within 2 seconds of booting, th e indicator
light wil l show red;
In the protection state, the i n dicator light
shows red light ;
When work i n g normally, the i n dicator light
shows blue light ;
When shutting down, the indicator light is
off.
② Hi- Res Sig nal Ind icator
When the optical fiber/coaxial i n pu t signal is
Hi-Res standard signal, t h e indicator light is
always on (red light );
When there is no Hi -R es standard signal for
analog input and optical/coaxi a l input
signal, the in dicator light is off.
③ Internal Ampl ifier I ndi cator
When the Internal power amplifier is t urne d
on, the indicator light is always on (red
light);
When the Internal power amplifier is t urne d
off, t he in dicator light goes out.

8EN
Computer S oftware
Precautions installation
The software can only be used under the Microsoft ® Wind ows® operating system.
Operating system: Windows XP, Windows Vista, Windows 7,Windows 8,Windows 10
CPU：1.6GHz or higher
Memory card: 1GB or high er
Hard Disk: 512MB or more free space
Computer screen resolution: 1280 *7 68 or higher
Before connecting t h e HDP-D90 machine to the computer, please install the HDP-D90 comp uter
software correctly.
After installing the HDP-D90 s oftware, you can tune and set the HDP-D90 machine on th e
computer.
*This function is mainly for manu facturers and distributors.
Computer Software Introduction
1
The host is powered on.
2
Connect one en d of the USB 2.0 cable to
the “USB” port of the host, and connect
the other end to the USB port of the
computer.
3
Double-click the HDP-D90 software icon to
open the software.
① Online switch.
② Temperature display.
③ Load or save the tuning file.
④ Select t he function setting.
⑤ Encryption and decryption of tuning
data.
⑥ Adjust the total volume.

9EN
⑦ Function page selection.
⑧ Editing area of function page
Connection and Temperature Di splay
Setting items:
Connection and temperature display
Setting content:
Connection/disconnected/temperat ure
display
Connection Settings
1Connect the USB cable and ope n the
software, it wil l automatically go online .
After the connection is successful , the
connection icon will show green [ ]。
2After online , click the connection icon to
disconnect. When not online, the connection
icon will displ a y red [ ], and click the
connection icon again to go online again.
Temperature Display
Detect the temperature on the surface of the
machine a nd display the current temperature
value.
File S ettings
Click [File] to enter th e loading or sa v i n g s cene
file page.
Load or save presets fil e page
Setting items:File
Setting content:Load PC Preset/Save a s PC
Preset/Load All Presets /Sa v e All Presets
Load PC Preset
The scene file previously sa v ed on the
computer can be loaded as t h e current
machine working scene.
Save a s PC Preset
The current machine wor k scene file can be
saved to the computer for later recall.
Load All Presets
Load the file s of the ent ire mac h ine previously
saved on the computer to the machin e
(including the current working scene, machine
preset scene, output ch a n n el configuration
data, etc.), and copy all the machine data that
has been debug ged to the currentl y con n ected
machine.
Save A ll Presets
Save all data on th e current online machine as
a computer file (including the current working
scene, machin e preset scene, output channel
configuration data, etc.) for later recall when
the whol e machine is copied.
Option Setting
Click [O ption] to enter the setting page.
Setting page
<Setting item>
Signal generator
Signal sele ction
Volume
Sine wave frequency
Output signal selection
Input link s ettings
Output link s ettings
Built-in AMP
Firmware up da te

10 EN
Restore factory settings
Shutdown dela y
Language
About
Signal G enerator Settings
Select [Signa l Generator] from the option pa ge
to enter t h e sign a l generator setting page.
Signal generator page
Test whether the output sign al is n orma l when
there is no mus i c playing.
Signal Selection
Setting item: sign al selection
Setting content: OFF (initial setting)/pink
noise/white noise/sinuso id/sinusoid (positive
half-cycle)
Volume
Setting item: volum e
Setting content: -60dB~0dB (Ini t i a l setting:
-24dB)
Sine Wave Frequency
Setting item: sin e wave freque n cy
Setting content: 20Hz~40kH z (initial setting:
1000Hz)
Output Signal Selection
Setting item: out put signal select ion
Setting content: generator/musi c output
(initial setting)
Input Lin k Settings
Select [Input link settings] from the option
page to enter th e input link settings page.
Enter the input link s ettings page
Setting items: setting the functions t h at need
to be combined with input
Setting content: channel EQ/X-Over/ch annel
phase/channel volume/channel mute
Output Li n k Settings
Select [Ou t put link settings] from the option
page to enter the output link setti n gs setting
page.
Output link s ettings setting page
Setting item: S et the functi on that needs to
be combined with the output
Setting content: chann el
EQ/X-Over/channel phase/channel
volume/channel mute
Built-in AMP
Select [Built-in AMP] from t he options page to
enter th e built-in power amplifier setting page.

11 EN
Built-in AMP page
Setting item: Built-in AMP
Setting content: on (init ial setting) / off
Firmware Update Settings
Select [Firmware Up da te] from the options
page to enter the firmware update setting
page.
Firmware upd a te page
Setting item: Firmware update
1Click the ">" button to sele ct the upgrade
file.
2Click th e "Update" bu tton to upgrade t h e
firmware. The upgrade progress reaches
100%, indicating t h at the firmware upgrade
is successful.
3Click the "OK" button to exit the firmware
update. After the update, the mach in e will
automatically restart to work.
Restore Factory S etti ngs
Select [Restore Factory Settings] from the
options pa ge to ent er the factory reset page.
Restore factory settings page
Setting item: restore factory settings
1Click the "OK" button to restore all the data
set in the mach in e to t he factory default
state.
Shutdown delay setting
Select [Shutdown Delay] from th e options page
to enter t he sh utdown delay setting page.
Shutdown dela y page
Setting item: shutdown delay
Setting content: 0~255s (initial value: 0s)
Language Settings
Setting item: language
Setting content: Chinese/English
View About
Select [Abou t ] from the options page to enter
the a bou t page.
About page
You can vi ew the version n umbe r.
Encryption Settings
Click [Encr ypti on] to enter the encry pt i on page,
and click [Decry pt] to enter the decryption
page.

12 EN
Encrypti on /decry ption page
Setting item: encr yption/decryption
1Encrypti on : Enter the password to encr ypt
the tuning data.
2Decry ption: You can enter a password, clear
data or restore factory settings.
The in i t ial password is: "888 888".
Encrypti on of EQ frequency, Q value, gain,
delay, channel, phase equa lize r and other
tuning data.
Encrypti on only encry pts a single group of
audio data cu rrentl y in use , not all data of
the whol e machin e.
The encrypted sound data data can be stored
as preset sound effects or computer files,
and copying and transmission will not affect
the en crypted state.
Master volume setting
Setting item: Master volum e
Setting content: 0~35 (ini t ial value: 27)
1You can adjust the total volume by pressing
and holdin g the left mouse button, dragging
the volume fader left or right, or scrolling
the mouse wheel.
2Click the main volume【 】button to s et the
total volume mute【 】, click again to ca n cel
the mute (it will a utomatically cancel th e
mute when the main volume is adjusted).
Function Page Selection
The funct ion page can be switched.
<Setting item>
Home page
Main source selection
Main source attenuation setting
Mix source selection
Preset sound effects
Input EQ
Type selection
Channel mute
Link settings
EQ adjustment
Equalizer settings
Channel settings
X-Over settings
Output EQ
Stereo and bridge switching
TCR
Delay value adjustment
Delay group select ion
Channel mute
Mix
Active input and passive input
switching
Combined frequency volume
adjustment
RTA
Fixed and follow switch
Signal gain selection
Sensitivit y selection
Channel selection
Home Page
Home page
Setting items:Homepage
Setting content:Main source selection/
Main source attenuation/Mix
source selection/Preset sound effects

13 EN
Main Source Selection
Setting items:Main source selection
Setting content:Optical/Coaxial/Bluetoot h /
High Level/AUX
Main Source Attenuat i on Setting
You ca n press a nd hold the left button of the
mouse to move the fader left or righ t or scroll
the mouse wheel, or press the up and down
keys of the keyboard to s et th e attenuation.
The Mix source is equi v alent to mixing. The
greater the attenuation of the main sou n d
source, the lower the main volume, a djustable
value: 0%~10 0%.
Setting items:Main source atten uation
Setting content:0% to 100% (default 100%)
Note: When the current audio sou rce mode
is selected, the audio source mode ca n no
longer be superimp osed, otherwise the
Mix source is invalid, and the optical fiber
and coaxial cannot be mixed and
superimposed.
Mix Source Selection
Setting items:Mix source
selection
Setting content:Optical/Coaxial/Bluetooth/
High Level/AUX/OFF
Preset Sound Effect S ettings
1Click [Call] to recall the pre-stored sound
effects.
2Click [Save] to store the adjusted sound
effect data.
3Click the right mouse button to delete the
preset sound effects.Or [Save] 6 groups of
preset sound effects can be set
Setting items:Preset sound effect settings
Setting content:Call/save/delete
Enter EQ
Enter EQ page
Setting items:Enter EQ
Setting content:Type selection/channel
mute/link setting/EQ adjust ment /equalizer
setting/channel setting/ X-Over setting
① Click to enter t h e inpu t t ype select ion box.
② Customize t he in put channel t y pe.
③ Mute button.
④ Joint adjustment button.
⑤ EQ gain step selection.
⑥ Channel display selection button.
⑦ EQ editi n g an d display area.
⑧ Equalizer s ettings.
⑨ X-Over.
⑩ Channel settings.
Type selection
Custom input channel type
You can configure your favorite channel type
accordin g to your hobby.
Input type custom page

14 EN
1Click the channel type cu stom box.
2Select the input ch a n n el t y pe in th e pop-up
window. Set the input type in the input t ype
setting dialog box. There are tweeter,
midrange, woofer, subwoofer and full-range
options in t h e front; tweeter, midrange,
woofer, subwoofer a n d full-range options
are available in the rear; F/C-tweeter,
F/C-midrange, R/C-tweeter and
R/C-midrange options are available in the
center; L-subwoofer, R-subwoofer a n d
C-subwoofer options a re available in the
subwoofer; L-surro und and R-surround
options are a vailable in the surroun d;
Input type selection
Input type selection page
1Select the desired ch a n n el type.
2Click the [Ent er] button to configure the
channel type. At th is time, the input cha n n el
type is fixed a n d cannot be configured.
3Select Customized or [Clear] to clear all in put
channel ty pes. At this time, you can
customize the inpu t chann el types.
Channel Mute Setting
Setting items:Channel mut e
Setting content:Mute/off
Link Settings
Link group page
1Select th e input link function in th e options,
refer to "Inp ut link settings" (refer to page
10).
2Click the link button.
3Select the link group on the link selection
page.
Setting items:Link
Setting content:Joint debugging 1/
joint debugging 2/j oint 3/j oint 4/joint 5/ joint
6/joint 7/ j oint 8/cancel link
EQ Adjustment
The input h a s 10 bands of EQ adjustable, and
there are two i n terfaces of graphic equalization
and parametric equa lization.
PEG page

15 EN
GEQ page
EQ gain step
Setting items:EQ gain step
Setting content:0.1 (init ial setting)/0.5/1
EQ curve display
Click th e cha n nel displ a y selection bu tton to
display the cu r v e of the channel.
EQ settings
1Select the inpu t ch a nnel to be adjusted.
2When the mouse moves to the serial
number position, hold down, drag up a nd
down to adjust the equalizer gain, drag
left a nd right to a djust the equalizer
frequency; when the mouse moves to the
left a nd right blue boxes, hold down and
drag to adjust the equa lizer Q value. You
can also set the frequency, Q value a nd
gain by directly inputting the value,
scrolling the mouse wheel, and the up
and down keys on the keyboard.
Adjustable frequency range: 20Hz~40kHz;
Adjustable range of Q value: 0.404~2 8. 8 52;
Gain adju stable range: -12.0 dB ~+12.0 dB.
Note: Th e gain is adjustable in the graph i c
equalization interface, and th e frequency
and Q value are not adjustable. In the
parameter equalization interface, th e
frequency, Q value and ga i n are
adjustable.
Equalizer Settings
1. When there is EQ adjustment, th e direct
equalization button appears.
2. Throug h Equalization: When the current
channel equalizer is turned on, th i s button
will be displayed [ ], click [Through
Equalization] or the through dot to make all
equalizers of the current channel inactive
(through).
3. After clicki ng t h e "Yes" button, the button
will be restored to the [Restore Balance]
state [ ]. Then click [R estore
EQ] and all equalizers of t he current channel
will return to the last activated state.
4. Click [Reset EQ], the parameters of all
equalizers of the current channel return to
the initial state: th e freque ncy is evenly
distributed, the input Q value i s 2.515 , the
output Q value is 1.007 , and th e gain is
0.0dB.
5. Click [Para metric Equalization] to pop up a
warning box "Confirm GEQ to PEQ mode?",
press OK to switch to [Graphic Equalization],
click [Graphic Equalization] to pop up a
warning box "Confirm PEQ to GEQ mode?",
press OK to confirm Switch [parameter
equalization]. In the parametric
equalization mode, the frequency, Q value
and gain are adju stable, while in th e graphic
equalizer mode, the frequency and Q value
are fixed, and only the equalizer gain can be
adjusted.

16 EN
Channel Settings
Setting items:Preset sou n d effect settings
Setting content:Gain/phas e
1. Gain setting: The gain can be a dju sted by
directly inpu ttin g the value, scrolling the
mouse wheel, the up and down keys on th e
keyboard, or clicking "-" or "+". Adjustable
range: -60dB~6dB.
2. Phase setting: normal phase or reverse
phase s wit ch .
X-Over
Setting items:X-Over settings
Setting content:Type/frequency /slop e
1. Type settings: Link-R il, Besse l and Butter-W.
2. Frequency setting: The frequency can be
adjusted by directly inputting the value,
scrolling the mouse wheel, the up and down
keys on the keyboard, or clicking "-" or "+".
Adjustable range: 20Hz~40000Hz .
3. Slope (slo pe) setti ng: th e drop-down menu
options are -6dB/Oct, -12dB/Oct, -18dB/Oct,
-24dB /Oct , -30d B /Oct , -3 6 d B /Oct , -4 2 d B /Oct ,
-48dB/ Oct is optional.
Note: When the s lope is -6 dB/Oct, the type
is displayed as "Null".
Output EQ
Output EQ page
Setting items:Output EQ
Setting content:Ty pe selection/channel
mute/link setting / EQ adjustment/ Bridge Mo de
equalizer setting/channel setting/X-Over
setting
① Click to enter t h e output type selection box.
② Stereo and handover switch.
③ Customize t h e output channel type.
④ Mute button.
⑤ Joint debugging button.
⑥ EQ gain step selection.
⑦ Channel display selection button.
⑧ EQ editi n g an d display area.
⑨ Equalizer s ettings.
⑩ X-Over.
⑪ Channel settings.
Type sele ction of out put EQ s ettings, cha n n el
mute, joint t unin g settings, EQ adjustment,
equalizer settings, chan n el settings, filter
settings refer to "Input EQ Settings" (page 13 to
page 16)
Bridge Mode
The output channel 9 can be bridged with the
output channel 11, and the output channel 11
can be bridged with t h e out put channel 12. The
power can be increased in bridge mode.

17 EN
Delay
① Delay adjust ment.
② Delay group selection.
③ Delay value display window.
Setting items:Delay setting
Setting content:Delay/delay group
1. Delay adjustment: The delay can be adjusted
by directly in putting the value, scrolling the
mouse wheel or the up a nd down keys on
the keyboard.
2. Delay group: select th e delay group, and th e
channels with the sa me delay group can be
adjusted together.
3. The dela y units a re ms (mill i s econds), inch
(inches) and cm (centimeters).
Delay range: 0.000~20.000 milliseconds;
0~692 cm;
0~273 inches.
Mix
After the HDP D90 machine sets the sound
source signal into t h e aud i o process o r, it is
divided into the volume of each output ch a n nel,
and t h e purp ose of mixing a n d mixing can be
achieved by adju sting the volume of each
sound s ou rce in t he chann el. In the passive
input mode, t h e frequen c y division is s et by the
PC t erminal; in th e active input mode, the
frequency division is set by the original vehicle
host itself.
RTA
1. Display window: The window size can be
the largest screen and can be zoomed
freely.
2. Select the display channel:
(1) Output : Clic k the drop-down list to select
the spectrum dyn am ics of th e output
channel.
(2) Fixed: Only t h e spectrum dynamics of the
currently selected outp ut ch a nnel can
be displayed, and other output
channels cannot be switched.
(3) Follow : Follow the output channel clicked
by the mouse to switch and dis pl ay th e
spectrum dynamics of the sele cted
output ch a n n el.
(4) Signa l gain: hold dow n t h e mouse and
push th e fader left and right to adjust
the s i g n a l gain.
(5) Sensit ivity: There a re high, medium and
low options. The higher the sensitivity,
the more sensitiv e th e frequency
spectrum jumps.

18 EN
Information on the dis posa l of waste electrical
and electronic equ i pm ent and batteries
(applicable to countries that adopt a garbage
collection system) If you want to dispose of t his
product, do not mix it wit h general household
waste. In accordance with regulations that
require proper disposal, recycling and
recycling, there is a separate collection system
for waste electronic products. Please contact
your local authorit ies to find the location of t he
recycling facility closest to you. Proper
recycling an d waste disposal help conserve
resources while preventing harmful effects on
human health a n d the environment.
