QUICK REFERENCE GUIDE
Portable Navigation System
GUIDE DE RÉFÉRENCE RAPIDE
Système de Navigation Portatif

WARNING
This product is designed to assist you while you drive your vehicle. It should not be used as a
substitute for your personal judgment. Road conditions and regulations take precedence over
information contained on the map display; observe actual traffic restrictions and circumstances
while driving. For safety, users should stop vehicle before operating the system.
Please read the complete Owner’s Manual before operating this product; please see Page 10 of
this Quick Reference Guide for instructions on accessing the Owner’s Manual.
INSTALLATION NOTE
Certain state and local regulations may prohibit the placement of any object on windows or the
dash. See your authorized Alpine dealer for other installation options.
MAPS
All map coverage includes only roads and regions that have been mapped in a digitized format.
Product information listed in this brochure is based upon current information at the time of printing, but cannot be guaranteed.
All designs, features, specifications and delivery dates are subject to change without notice. For updated product information,
please visit www.alpine-usa.com or www.alpine-canada.com | ©2008 Alpine Electronics, Inc. All rights reserved.
IMPORTANT INFORMATION INSTALLATION
HOW TO MOUNT THE PND-K3
BEFORE YOU START
Before you start, charge the
PND-K3 for at least three hours,
using the included AC charger.
HOW TO REMOVE THE PND-K3
>>
>
1Find a spot suitable for the
navigation device. Stick the
suction cup against the desired
mounting location. Press the
lever to secure the suction cup.
2Guide the navigation device onto
the cradle.
3Gently push until a click sound
is heard and the device is locked
in place.
1Press on the button immediately
behind the navigation device.
This will release the unit forward.
Gently lift the device from its cradle.

INSTALLATION
COMMENT INSTALLER LE PND-K3
AVANT DE COMMENCER
Avant de commencer, rechargez
le PND-K3 pendant au moins
trois heures, à l’aide du chargeur
c.a. fourni.
COMMENT RETIRER LE PND-K3
>>
>
1Trouvez un emplacement
convenable pour l’appareil de
navigation. Collez la ventouse
à l’emplacement de montage
désiré. Appuyez sur le levier
pour fixer la ventouse.
2Placez l’appareil de navigation sur
le socle.
3Poussez délicatement jusqu’à ce
qu’un son soit entendu et que
l’appareil soit verrouillé en place.
1Appuyez sur le bouton situé
directement à l’arrière de l’appareil
de navigation. Cela provoquera le
relâchement de l’appareil vers
l’avant. Soulevez délicatement
l’appareil de son socle.
AVERTISSEMENTS
Ce produit est conçu pour vous aider lors de la conduite de votre véhicule. Il ne doit pas être utilisé
en tant que substitut de votre jugement personnel. Les conditions de la route et les règlements
remplacent tous les renseignements contenus à l’affichage de la carte; conformez-vous aux
restrictions et aux circonstances de trafic actuelles pendant la conduite. Par mesure de sécurité, les
utilisateurs doivent arrêter le véhicule avant de faire fonctionner le système.
Veuillez lire le Manuel de l’utilisateur en entier avant d’utiliser le produit; veuillez consulter
la page10 de ce Guide de référence rapide au sujet des directives pour accéder au Manuel de
l’utilisateur.
NOTE D’INSTALLATION
Certains règlements d’État et locaux peuvent interdire l’installation d’objet sur les vitres ou sur
le tableau de bord. Consultez votre concessionnaire autorisé Alpine au sujet d’autres options
d’installation.
CARTES
Toute la couverture de la carte n’inclut que les routes et les régions qui ont fait l’objet d’une
cartographie en format numérisé.
Les renseignements sur le produit inscrits dans cette brochure sont basés sur les renseignements à jour au moment de l’impression,
mais leur exactitude ne peut pas être garantie. Toutes les conceptions, caractéristiques, spécifications et dates de livraison sont
sujets à des changements sans avis préalables. Pour obtenir des renseignements sur le produit mis à jour, veuillez visiter le site
www.alpine-usa.com ou www.alpine-canada.com | ©2008 Alpine Electronics, Inc. Tous droits réservés.
RENSEIGNEMENTS IMPORTANTS

CONTROLS
PRIMARY BUTTON CONTROLS
>
POWER
Press and hold for two
seconds to turn on/off
the device.
SD CARD SLOT
For music playback.
(SD card not included.)
HEADPHONE JACK
(Headphone not included.)
RESET BUTTON
Press and hold for
two seconds (if necessary).
MINI-USB CONNECTOR
VOLUME DOWN
Controls audio volume
level down.
VOLUME UP
Controls audio volume
level up.
MAIN MENU
“GO TO” BUTTON
Press this to start entering
a destination.
“PLAY” BUTTON
Press this to go to the
music player.
“SETTINGS” BUTTON
Press this to change
system settings.
“MAP” BUTTON
Press this to go to the
map.
“INFO” BUTTON
Press this to check
information such as:
• GPS receiver status
• Speed and trip information
“HOME” BUTTON
Press this to go to a saved
home location.

CONTROLS
PRIMARY BUTTON CONTROLS
>
POWER
Press and hold for two
seconds to turn on/off
the device.
SD CARD SLOT
For music playback.
(SD card not included.)
HEADPHONE JACK
(Headphone not included.)
RESET BUTTON
Press and hold for
two seconds (if necessary).
MINI-USB CONNECTOR
VOLUME DOWN
Controls audio volume
level down.
VOLUME UP
Controls audio volume
level up.
MAIN MENU
“GO TO” BUTTON
Press this to start entering
a destination.
“PLAY” BUTTON
Press this to go to the
music player.
“SETTINGS” BUTTON
Press this to change
system settings.
“MAP” BUTTON
Press this to go to the
map.
“INFO” BUTTON
Press this to check
information such as:
• GPS receiver status
• Speed and trip information
“HOME” BUTTON
Press this to go to a saved
home location.

INPUT A DESTINATION
Select from
recent destinations.
Type in a new address.
Select from
recent streets.
Search by entering
street name.
Select from
saved destinations.
More options
(setting destination
using coordinates or
by intersection).
Select from
recent cities.
Search by entering
city name.
FIND A PLACE
Search from a list
of places (restaurants,
ATMs, gas stations, etc.).
Search within
a city.
Search near
current location.
Search along
current route.
Search near
destination.
POINT OF INTEREST (POI)
KEYWORD SEARCH
Don’t know the full POI name? Instead,
type in what you know or need and find
relevant results. This search method returns
POI names containing — not necessarily
beginning with — the search term.
>

INPUT A DESTINATION
Select from
recent destinations.
Type in a new address.
Select from
recent streets.
Search by entering
street name.
Select from
saved destinations.
More options
(setting destination
using coordinates or
by intersection).
Select from
recent cities.
Search by entering
city name.
FIND A PLACE
Search from a list
of places (restaurants,
ATMs, gas stations, etc.).
Search within
a city.
Search near
current location.
Search along
current route.
Search near
destination.
POINT OF INTEREST (POI)
KEYWORD SEARCH
Don’t know the full POI name? Instead,
type in what you know or need and find
relevant results. This search method returns
POI names containing — not necessarily
beginning with — the search term.
>

MAP
MAP WITHOUT GUIDANCE
>
Goes back to Main
Menu screen.
Zooms Map View in.
Zooms Map View out.
MAP WITH GUIDANCE
>
Changes map view (2D, 3D).
Changes map view (2D, 3D).
Change navigation mode
to arrow only mode.
Goes back to Main
Menu screen.
Zooms Map View in.
Zooms Map View out.
Press to repeat voice
guidance.
Press to view
Route Menu.
SET UP BLUETOOTH
6On the Bluetooth enabled mobile
phone, search for Bluetooth
devices.
7Once the PND-K3 is found on the
mobile phone, connect to the
PND-K3.
1Access the Settings menu. 4Select ‘Bluetooth Devices…’.
2Press the Down Arrow to access
page two of the Settings menu. 5Select ‘Discoverable Mode’.
3Enter the Bluetooth setup screen.

MAP
MAP WITHOUT GUIDANCE
>
Goes back to Main
Menu screen.
Zooms Map View in.
Zooms Map View out.
MAP WITH GUIDANCE
>
Changes map view (2D, 3D).
Changes map view (2D, 3D).
Change navigation mode
to arrow only mode.
Goes back to Main
Menu screen.
Zooms Map View in.
Zooms Map View out.
Press to repeat voice
guidance.
Press to view
Route Menu.
SET UP BLUETOOTH
6On the Bluetooth enabled mobile
phone, search for Bluetooth
devices.
7Once the PND-K3 is found on the
mobile phone, connect to the
PND-K3.
1Access the Settings menu. 4Select ‘Bluetooth Devices…’.
2Press the Down Arrow to access
page two of the Settings menu. 5Select ‘Discoverable Mode’.
3Enter the Bluetooth setup screen.

UPDATES AND OWNER’S MANUAL
ACCESS SOFTWARE AND/OR MAP UPDATES
Software and/or map updates can be accessed by connecting the PND-K3 to a PC. The
PND-K3’s Owner’s Manual can also be accessed the same way (internet connection required
for either function).
Periodic software and/or map updates will be available. Some may require an additional fee,
please refer to the on-screen instructions.
>
>
2Connect the PND-K3 to the PC using the provided USB cable.
4Follow the on-screen instructions.
1Turn on the PND-K3.
3Open “My Computer” on the PC. Click the “Alpine Update” icon that appears.
Software Update: When a software
update is available, this button will be
active. Follow the on-screen instructions
to access the software update.
View Owner’s Manual.
PERSONALIZE YOUR SYSTEM
CHANGE THE BACKGROUND COLORS
There are eight menu colors and eight map colors to choose from.
Select “Display” from the Settings menu to change your color scheme.
>
Press to advance
to the next
color scheme.
Press to return
to the previous
color scheme.

UPDATES AND OWNER’S MANUAL
ACCESS SOFTWARE AND/OR MAP UPDATES
Software and/or map updates can be accessed by connecting the PND-K3 to a PC. The
PND-K3’s Owner’s Manual can also be accessed the same way (internet connection required
for either function).
Periodic software and/or map updates will be available. Some may require an additional fee,
please refer to the on-screen instructions.
>
>
2Connect the PND-K3 to the PC using the provided USB cable.
4Follow the on-screen instructions.
1Turn on the PND-K3.
3Open “My Computer” on the PC. Click the “Alpine Update” icon that appears.
Software Update: When a software
update is available, this button will be
active. Follow the on-screen instructions
to access the software update.
View Owner’s Manual.
PERSONALIZE YOUR SYSTEM
CHANGE THE BACKGROUND COLORS
There are eight menu colors and eight map colors to choose from.
Select “Display” from the Settings menu to change your color scheme.
>
Press to advance
to the next
color scheme.
Press to return
to the previous
color scheme.

MUSIC PLAYER
MUSIC PLAYER
The PND-K3 is not only a navigation device, it’s also a music player! Choose
“Play” from the Main Menu, then just place an SD card with your favorite
music into the PND-K3. It’s that simple!
>
Skip to last track. Skip to next track.
Play
Back to Main Menu. Map
ShuffleMusic Library
Once music is playing, click and drag to skip to anywhere in the song.
Repeat
LECTEUR DE MUSIQUE
LECTEUR DE MUSIQUE
Le PND-K3 n’est pas seulement un appareil de navigation, il est aussi un lecteur de
musique! Sélectionner « Lire » à partir du Menu principal, puis placez simplement une
carte SD contenant votre musique préférée dans le PND-K3. C’est aussi simple que cela!
>
Passer à la
dernière piste.
Passer à la piste
suivante.
Lire
Retourner à l’écran
Menu principal.
Carte
AléatoireMusicothèque
Lorsque la musique joue, cliquez et glissez pour passer à n’importe
quelle partie de la chanson.
Répéter
