Alpine TIZ194BZ User manual

Owner’s Manual
Quesons?
Please See Contact Details on the Back!
Two Tier Barrel & Pump
Bronze Fountain
USA Item No: TIZ194BZ
UK Item No.: TIZ194BZ-UK
v11.0 (TEC)

1
CONTENTS
Contents ...................................................................... 1
What’s Included ........................................................... 2
Features ...................................................................... 3
Specications .............................................................. 3
Assembling & Using Your Product............................... 4
Replacement Parts...................................................... 8
Troubleshooting........................................................... 9
Caution ...................................................................... 10
Limited Warranty Information .....................................11
Notes ......................................................................... 12

2
WHAT’S INCLUDED
Large Bucket
x1
Pump
x1
*Pump may be packaged separately in an outer box located in the
outer Styrofoam packaging.
Small Bucket
x1
Pump Body
x1
Pump
Handle
x1
Large
Panel
x1
Medium
Panel
x1
Tubing
x2
Screws
x13

FEATURES
3
FEATURES
Realistic faux
wood barrels
Durable plastic
construction
SPECIFICATIONS
Country Power
Requirement
Water
Capacity
Tubing Inner
Diameter
USA 120 V, 60 Hz 2.9 gal 0.47"
UK 230V, 50 Hz 11 L 11.93 mm

4
ASSEMBLING & USING YOUR PRODUCT
Unpack all components carefully. Check the packaging to ensure all of
the parts have been removed.
*Some splashing may occur when the fountain is in use.
1. Attach the Small Bucket to the Large Panel of the fountain base
by attaching the Screws through provided holes on the bottom of
the Large Panel and mounting holes on the bottom of the Small
Bucket
1. Remove the pump from its packaging and adjust the ow control
to the lowest setting to avoid splashing until the fountain is
completely assembled.
Alpine Quick Tip #1
Switch to the Left to turn
up the water ow. Turn the
switch to the Right to turn
down the water ow.

5
ASSEMBLING & USING YOUR PRODUCT
2. Place the pump into the Large Bucket, and then place the Small
Bucket with the attached Large Panel on top. Use four Screws
to secure the Large Panel to the large Bucket. Note: Be sure the
cord is routed through the cord slot.
3. Attach the pump Handle to the Pump Body by lining up the Screw
holes and securing a Screw.

6
ASSEMBLING & USING YOUR PRODUCT
4. Now attach the Pump Body to the Small Panel with the nal two
Screws and attach the Small Panel to the top of the Small Bucket
with the last of the Screws.
5. Next Install the Tubing into the fountain. The rst one will connect
from the bottom of the Pump Body to the bottom of the Small
Bucket. The Second Tube will connect under the bottom of the
Small Bucket to the actual Pump.
1
2

7
ASSEMBLING & USING YOUR PRODUCT
7. Gently pour water into the fountain basin, being careful not to
overow and cause splashing. Make sure the water completely
submerges the pump and the water runs clear during operation.
NOTE: We recommend that you use distilled water to prevent scale
build-up. It can take up to 5 minutes for the air to be completely
expelled and water begins to ow the rst time you operate the
pump.
8. Plug the pump into your local power supply. Make sure that there
is no water around the plug & always keep the power source in a
dry place

8
REPLACEMENT PARTS
ALSO AVAILABLE FROM ALPINE
Country Fountain Care
Formula
Americana®
UV Acrylic
Sealer
Touch-Up
Paint Kit
USA PPL102 RRR106 RTD102
UK N/A N/A N/A
9. Congratulations, your fountain is now complete. Don’t forget to
add water regularly as water will evaporate over time.
REPLACEMENT PARTS
For parts or additional help with your new product,please contact
Alpine customer service.
