Alto-Shaam ED2-96/2S Series User manual

W164 N9221 Water Street • P.O. Box 450 • Menomonee Falls, Wisconsin 53052-0450 • U.S.A.
PHONE: [phone].558.8744 U.S.A./CANADA FA : 262.251.7067 800.329.8744 U.S.A.ONLY
www.alto-shaam.com
DUE TO ONGOING PRODUCT IMPROVEMENT,S P E C I F I C A T I O N S A R E S U B J E C T TO C H A N G E W I T H O U T N O T I C E .PRINTED IN U.S.A.
ITEM NO. _______________________
MULTI-SHELF HEATED DISPLAY CASE
The display case is constructed of 18 gauge, non-magnetic stainless steel. A curved, tempered glass top frames the
display case. emovable, sliding glass doors on the operator side are included. Sliding door tracks have a “clean
sweep” cutout allowing for easy cleaning and crumb removal. Each shelf is controlled by two (2) adjustable thermostats
with a range of 1 to 10, and includes one (1) heat-on indicator light. The two-shelf self-service display system includes a
low-profile, European style base with one (1) storage shelf. As an additional option, the base can be adapted to
accommodate two (2) 500-1D drawer warmers. Counter-top display cases include one set of 4" (102mm) legs.
Note: For use with pre-packaged foods only.
■■ED2-96/2S - 96" (2438mm) length
■■ED2SYS-96/2S - 96" (2438mm) length, with base
● HALO HEAT … a controlled, uniform heat source that gently
holds and surrounds food for better appearance, taste, and longer
holding life.
● Holds and displays hot food fresh and moist for hours.
● SELF-SERVICE HOT DISPLAY CASE
— Curved glass styling.
— Thermostatically controlled heat source radiates from the base of
each shelf in multiple heat zones.
— Top shelf incorporates thermal kinetic glass technology to provide an
evenly heated display surface.
— Bottom shelf is heated by an aluminum plate with a resistive heat pad.
— Overhead lighting on each shelf.
— Solar cool bronze sliding glass doors reflect heat back into the
products and mirror the display to enhance merchandising effect.
— Customer self-service opening is across the full width of case.
— Front-mounted heat guard on each shelf provides customer protection.
FACTORY INSTALLED OPTIONS
●The system base is not sold as a separate
item. Order the full ED2SYS/2S model to
receive the base.
●Panel Color Choices
➥Specify color choice:
■■Black, standard
■■Stainless Steel
■■Custom Color
ED2-96/2S SERIES
ED2SYS-96/2S SERIES
MULTI-SHELF HEATED DISPLAY
ED2SYS-96/2S
ED2-96/2S
#70B - 05/09

W164 N9221 Water Street • P.O. Box 450 • Menomonee Falls, Wisconsin 53052-0450 • U.S.A.
PHONE: [phone].558.8744 U.S.A./CANADA FA : 262.251.7067 800.329.8744 U.S.A. ONLY
www.alto-shaam.com
DUE TO ONGOING PRODUCT IMPROVEMENT, S P E C I F I C A T I O N S A R E S U B J E C T T O C H A N G E W I T H O U T N O T I C E .P R I N T E D I N U .S.A.
ED2SYS-96/2S Back View
ED2SYS-96/2S Profile
ED2-96/2S Profile
ED2-96/2S SERIES
ED2SYS-96/2S SERIES
MULTI-SH ELF HEATED DIS PLAY SYSTEMS
48" (1219mm)
26-1/8" (661mm)
23-11/16" (601mm)
18-15/16"
(482mm)
3" (76mm)
ADJUSTABLE
PEGS IN EACH
CORNER
ELECTRICAL
PANEL
ELECTRICAL
OUTLET
47-7/8" (1216mm)
3 ANGLE
SHELF
23-11/16" (601mm)
27-1/2" (699mm)
25-5/8" (650mm)
36-13/16" (934mm)
37-13/16" (959mm) 10-1/4"
(259mm)
47-7/8" (1216mm)
ELECTRICAL
PANEL
18-15/16"
(482mm)
3" (76mm)
ADJUSTABLE
PEGS IN EACH
CORNER ELECTRICAL
OUTLET
26-1/8" (661mm)
23-11/16" (601mm)
47-7/8" (1216mm)
72" (1829mm)
3" (76mm) ADJUSTABLE
PEGS IN EACH CORNER
96" (2438mm)
ELECTRICAL PANEL
ELECTRICAL
OUTLET
26-1/8" (661mm)
23-11/16" (601mm)
47-7/8" (1216mm)
18-15/16"
(482mm)
48" (1220mm)
8-3/4"
(223mm)
8-9/16"
(216mm)
3-11/16"
(93mm)
1" (26mm)
36-3/4" (932mm)
2"
(52mm)
26-1/2" (673mm)
3 ANGLE
SHELF
48" (1220mm)
10-5/16"
(261mm)
48" (1219mm)
26-1/8" (661mm)
23-11/16" (601mm)
18-15/16"
(482mm)
3" (76mm)
ADJUSTABLE
PEGS IN EACH
CORNER
ELECTRICAL
PANEL
ELECTRICAL
OUTLET
47-7/8" (1216mm)
3 ANGLE
SHELF
23-11/16" (601mm)
27-1/2" (699mm)
25-5/8" (650mm)
36-13/16" (934mm)
37-13/16" (959mm) 10-1/4"
(259mm)
47-7/8" (1216mm)
ELECTRICAL
PANEL
18-15/16"
(482mm)
3" (76mm)
ADJUSTABLE
PEGS IN EACH
CORNER ELECTRICAL
OUTLET
26-1/8" (661mm)
23-11/16" (601mm)
47-7/8" (1216mm)
72" (1829mm)
3" (76mm) ADJUSTABLE
PEGS IN EACH CORNER
96" (2438mm)
ELECTRICAL PANEL
ELECTRICAL
OUTLET
26-1/8" (661mm)
23-11/16" (601mm)
47-7/8" (1216mm)
18-15/16"
(482mm)
48" (1220mm)
8-3/4"
(223mm)
8-9/16"
(216mm)
3-11/16"
(93mm)
1" (26mm)
36-3/4" (932mm)
2"
(52mm)
26-1/2" (673mm)
3 ANGLE
SHELF
48" (1220mm)
10-5/16"
(261mm)
48" (1219mm)
26-1/8" (661mm)
23-11/16" (601mm)
18-15/16"
(482mm)
3" (76mm)
ADJUSTABLE
PEGS IN EACH
CORNER
ELECTRICAL
PANEL
ELECTRICAL
OUTLET
47-7/8" (1216mm)
3 ANGLE
SHELF
23-11/16" (601mm)
27-1/2" (699mm)
25-5/8" (650mm)
36-13/16" (934mm)
37-13/16" (959mm) 10-1/4"
(259mm)
47-7/8" (1216mm)
ELECTRICAL
PANEL
18-15/16"
(482mm)
3" (76mm)
ADJUSTABLE
PEGS IN EACH
CORNER ELECTRICAL
OUTLET
26-1/8" (661mm)
23-11/16" (601mm)
47-7/8" (1216mm)
72" (1829mm)
3" (76mm) ADJUSTABLE
PEGS IN EACH CORNER
96" (2438mm)
ELECTRICAL PANEL
ELECTRICAL
OUTLET
26-1/8" (661mm)
23-11/16" (601mm)
47-7/8" (1216mm)
18-15/16"
(482mm)
48" (1220mm)
8-3/4"
(223mm)
8-9/16"
(216mm)
3-11/16"
(93mm)
1" (26mm)
36-3/4" (932mm)
2"
(52mm)
26-1/2" (673mm)
3 ANGLE
SHELF
48" (1220mm)
10-5/16"
(261mm)
#70B - 05/09
D I M E N S I O N S (HXWXD)
ED2-96/2S EXTERIOR:
30-3/16" x 96" x 48" (766mm x 2438mm x 1220mm)
ED2SYS-96/2S EXTERIOR:
47-7/8" x 96" x 48" (1216mm x 2438mm x 1220mm)
TOP SHELF DIMENSIONS (WXD):
93-9/16" x 18-3/4" (2377mm x 475mm)
BOTTOM SHELF DIMENSIONS (WXD):
88-3/4" x 28-3/4" (2254mm x 730mm)
I N S TA L L AT I O N R E Q U I R E M E N T S
Display case must be installed level. The display case must not
be installed in any area where it may be affected by steam,
grease, dripping water, high temperatures, or any other
severely adverse conditions.
Do not install a heated display case near a cold air source such
as a freezer, air conditioning vents, or in any area where
outside air fluctuation can affect performance.
S P E C I F I C AT I O N S
●Four (4) florescents are enclosed in the top interior
of the case. Four (4) florescents are enclosed and
centered under the top shelf. Each set is controlled
by one (1) ON/OFF light switch.
●Two (2) 10" x 36" (254mm x 914mm) operator-side
work shelves.
P R O D U C T C A PA C I T Y
TOP SHELF
Twenty-four (24) chicken boats with dome cover
BOTTOM SHELF
Thirty (30) chicken boats with dome cover
O P T I O N S & A C C E S S O R I E S
■■WORK SHELF WITH GRAVY LANE 5005640
WEIGHT (EST.)
MODEL NET SHIP
ED2-96/2S: CONTACT FACTO Y CONTACT FACTO Y
ED2SYS-96/2S: CONTACT FACTO Y CONTACT FACTO Y
CRATED DIMENSIONS: HXWXD
ED2-96/2S: CONTACT FACTO Y
ED2SYS-96/2S: CONTACT FACTO Y
E L E C T R I C A L
VOLTAGE PHASE CYCLE/HZAMPS kW
208-240V (AGCY)1 50/60 21.8 5.2
at 208V 1 50/60 20.2 4.2
at 240V 1 50/60 23.3 5.6
NEMA L6-30P
30A, 250V PLUG
