Alto-Shaam HALO HEAT EC2SYS-96 User manual

EC2-96 SERIES
EC2SYS-96 SERIES
HEATED DISPLAY SYSTEMS
ITEM NO. _______________________
The display case is constructed of 18 gauge, non-magnetic stainless steel. A tempered glass front encloses the display case
and can be lifted to a 90 degree angle for easy cleaning. Removable, sliding glass doors on the operator side are included.
Sliding door tracks have a "clean sweep" cutout allowing for easy cleaning and crumb removal. Framed end glass with
rubber gasket material protects glass edges from chipping and breakage. The base is divided into three (3) individually
managed heat zones with each zone controlled by a separate thermostat with a range of 1 through 10 and heat-on indicator
light. Overhead lights are controlled by ON/OFF switches in three (3) light zones. Two (2) 125V plug outlets are available
as an option on 120/208-240V units only. Counter-top display cases include one set of 4" (102mm) legs.
■■EC2-96 - 96" (2438mm) length
■■EC2SYS-96 - 96" (2438mm) length, with base
■■EC2-96/PL - 96" (2438mm) length, 23-3/4" (603mm) self-service opening on left side of case front
■■EC2SYS-96/PL - 96" (2438mm) length, with base, 23-3/4" (603mm) self-service opening on left side of case front
■■EC2-96/P - 96" (2438mm) length, 23-3/4" (603mm) self-service opening on right side of case front
■■EC2SYS-96/P - 96" (2438mm) length, with base, 23-3/4" (603mm) self-service opening on right side of case front
● HALO HEAT … a controlled, uniform heat source that gently
holds and surrounds food for better appearance, taste, and longer
holding life.
● Holds and displays hot food fresh and moist for hours —
without adding water.
● Expandable system to meet your specific requirements.
● atches profile of leading refrigerated display case.
● HOT DISPLAY CASE
— Angled flat glass profile provides maximum product visibility.
— Displays hot food without condensation on glass.
— Thermostatically controlled heat source radiates from the
base of the display case in multiple heat zones.
— Overhead light zones with shatterproof coated bulbs.
— Holds a full range of standard (gastronorm) pan sizes, full-size
or half-size sheet pans.
— Tempered sliding glass doors reflect heat back into the products
and mirror the display to enhance merchandising effect.
●DECO ATO BASE
— Standard black painted front and end panels.
●SELF-SE VICE HOT DISPLAY
— Customer self-service opening is available on right side or
left side of case.
— Front mounted heat-guard provides customer protection.
W164 N9221 Water Street • P.O. Box 450 • Menomonee Falls, Wisconsin 53052-0450 • U.S.A.
PHONE: [phone].558.8744 U.S.A./CANADA FAX: [phone].329.8744 U.S.A. ONLY
www.alto-shaam.com
P R I N T E D I N U .S.A.D U E T O O N G O I N G P R O D U C T D E V E L O P E N T, S P E C I F I C A T I O N S A R E S U B J E C T T O C H A N G E W I T H O U T N O T I C E . #78B - 03/08
ANSI/NSF 4
EC2-96
EC2SYS-96
FACTORY INSTALLED OPTIONS
●The system base is not sold as a separate
item. Order the full EC2SYS model to
receive the base.
●Panel Color Choices
➥Specify color choice:
■■Black, standard
■■Stainless Steel, optional
■■Custom Color, optional

O P T I O N S & A C C E S S O R I E S
■■BUTTING KIT CONTACT FACTORY
■■GAUGE, INTE IO AMBIENT TEMP. GU-33384
■■GLASS, NON-GLA E, F ONT (2 REQUIRED)GL-24256
■■GLASS, TEMPERED END PANE, BRONZE KIT 5008528
■■INDEPENDENT ELECT ICAL OUTLET 5001781
PANEL KIT, COUNTE TOP
■■B USHED STAINLESS STEEL 5004696
■■CUSTOM COLO 5004702
PANEL KIT, SYSTEM
■■B USHED STAINLESS STEEL 5004699
■■CUSTOM COLO 5004705
■■PLATFO M SCALE 55265
SHEET PAN DIVIDE BA PACKAGE
■■FULL-SERVICE CASES 5002805
■■SELF-SERVICE LEFT-SIDE OR RIGHT-SIDE OF CASES 5002806
■■TEMPERATURE PROBE 5004918
■■THERMOSTAT GUARD COVER PLATE 5007660
■■WORK SHELF WITH GRAVY LANE 5005638
EC2-96 SERIES
EC2SYS-96 SERIES
HEATED DISPL AY SYST EMS
D I M E N S I O N S (HXWXD)
EXTE IO , COUNTE -TOP MODEL WITH LEGS:
37-11/16" x 96" x 53-1/2" (9956mm x 2438mm x 1358mm)
EXTE IO , WITH BASE:
48" x 96" x 53-1/2" (1219mm x 2438mm x 1358mm)
WELL DIMENSIONS (WXLXD):
27-3/16" x 93-5/16" x 4-1/2" (690mm x 2370mm x 114mm)
I N S TA L L AT I O N R E Q U I R E M E N T S
Display case must be installed level. The display case must
not be installed in any area where it may be affected by steam,
grease, dripping water, high temperatures, or any other
severely adverse conditions.
Do not install a heated display case near a cold air source such
as a freezer, air conditioning vents, or in any area where
outside air fluctuation can affect performance.
W164 N9221 Water Street • P.O. Box 450 • Menomonee Falls, Wisconsin 53052-0450 • U.S.A.
PHONE: [phone].558.8744 U.S.A./CANADA FAX: [phone].329.8744 U.S.A. ONLY
www.alto-shaam.com
WEIGHT
MODEL NET SHIP
EC2-96 769 lb (349 kg) 894 lb (406 kg)
EC2SYS-96 864 lb (392 kg) 989 lb (449 kg)
EC2-96/PL/PR 769 lb (349 kg) 894 lb (406 kg)
EC2SYS-96/PL/PR 864 lb (392 kg) 989 lb (449 kg)
CRATED DIMENSIONS (EST.): HXWXD
EC2-96: 45" x 85" x 55" (1143mm x 2159mm x 1397mm)
EC2SYS-96: 60" x 108" x 66" (1524mm x 2743mm x 1676mm)
S P E C I F I C AT I O N S
● Fourteen (14) overhead lights in three (3) light zones.
● Three (3) base heat zones with three (3) adjustable thermostats with
a range of 1 through 10, and three (3) heat-on indicator lights.
● Four (4) tinted, reflective, tempered glass sliding doors on
operator side.
● Two (2) 10" x 36" (254mm x 914mm) operator-side work shelves.
● Self-serve models EC2-96/PL and EC2-96/PR have a self-serve
pan insert 21-5/8" x 26-7/16" x 2" (549mm x 672mm x 51mm)
and includes one (1) Wire Pan Grid.
78B - 03/08 D U E T O O N G O I N G P R O D U C T D E V E L O P E N T , S P E C I F I C AT I O N S A R E S U B J E C T T O C H A N G E W I T H O U T N O T I C E .P R I N T E D I N U .S.A.
ELECTRICAL
CORD
96" (2438mm)
CUTTING BOARD IN “DOWN” POSITION CUTTING BOARD IN “DOWN” POSITION
6-3/4"
(172mm)
ON
OFF
ON
OFF
ON
OFF
48" (1218mm)
72" (1829mm)
CUTTING BOARD IN “DOWN” POSITION
ON
OFF
ON
OFF
48" (1218mm)
ELECTRICAL
CORD
6-3/4"
(172mm)
53-1/2" (1358mm)
43-3/4" (1111mm)
13-9/16"
(344mm)
37-11/16" (956mm)
23-7/8"
(606mm)
48" (1218mm)
10-11/16"
(270mm)
41-7/8" (1063mm)
53-1/2" (1358mm)
43-3/4" (1111mm)
48" (1219mm)
CUTTING BOARD IN “DOWN” POSITION
ON
OFF
ON
OFF
48" (1218mm)
ELECTRICAL
CORD
6-3/4"
(172mm)
ELECTRICAL
CORD
96" (2438mm)
CUTTING BOARD IN “DOWN” POSITION CUTTING BOARD IN “DOWN” POSITION
6-3/4"
(172mm)
ON
OFF
ON
OFF
ON
OFF
48" (1218mm)
72" (1829mm)
CUTTING BOARD IN “DOWN” POSITION
ON
OFF
ON
OFF
48" (1218mm)
ELECTRICAL
CORD
6-3/4"
(172mm)
53-1/2" (1358mm)
43-3/4" (1111mm)
13-9/16"
(344mm)
37-11/16" (956mm)
23-7/8"
(606mm)
48" (1218mm)
10-11/16"
(270mm)
41-7/8" (1063mm)
53-1/2" (1358mm)
43-3/4" (1111mm)
48" (1219mm)
CUTTING BOARD IN “DOWN” POSITION
ON
OFF
ON
OFF
48" (1218mm)
ELECTRICAL
CORD
6-3/4"
(172mm)
ELECTRICAL
CORD
96" (2438mm)
CUTTING BOARD IN “DOWN” POSITION CUTTING BOARD IN “DOWN” POSITION
6-3/4"
(172mm)
ON
OFF
ON
OFF
ON
OFF
48" (1218mm)
72" (1829mm)
CUTTING BOARD IN “DOWN” POSITION
ON
OFF
ON
OFF
48" (1218mm)
ELECTRICAL
CORD
6-3/4"
(172mm)
53-1/2" (1358mm)
43-3/4" (1111mm)
13-9/16"
(344mm)
37-11/16" (956mm)
23-7/8"
(606mm)
48" (1218mm)
10-11/16"
(270mm)
41-7/8" (1063mm)
53-1/2" (1358mm)
43-3/4" (1111mm)
48" (1219mm)
CUTTING BOARD IN “DOWN” POSITION
ON
OFF
ON
OFF
48" (1218mm)
ELECTRICAL
CORD
6-3/4"
(172mm)
EC2SYS-96
EC2SYS Profile
EC2 Profile
E L E C T R I C A L
VOLTAGE PHASE CYCLE/HZ AMPS kW
120/208-240 (UL)1 50/60 24.0 5.2
a 208 1 50/60 24.0 5.2
a 240 1 50/60 24.0 5.2
230 (CE)1 50/60 24.3 5.6
230 1 50/60 24.7 5.7
Tyler Huss.eps
revised 5/30/02
added L14-20P Plug Configuration
NEMA L14-30P
30A, 250V PLUG
BARE END, NO PLUG
PA N C O N F I G U R AT I O N *
PAN SIZE DIMENSIONS QTY.
FULL-IZE & ONE-THIRD**: 12" X20" X2-1/2" (GN 1/1) 7
12" X6" X2-1/2" (GN 1/3) 7
HALF-IZE & ONE-THIRD**: 12" X10" X2-1/2" (GN 1/2) 14
12" X6" X2-1/2" (GN 1/3) 7
FULL-IZE HEET PAN : 18" X26" X1" 4
MAX. CAPACITY/VOLUME:112 lbs (51 kg)
70 qts (84 L)
* Pans are not included with display case.
** Will also accept 4" (100mm) deep pans.
