Altronix eBridge1PCRMT User manual

eBridge1PCRMT - 1 -
PLUS
Overview:
eBridge1PCRM and eBridge1PCTX are CAT5 to Coax cable Ethernet adapters/Media converters that deliver
data and power over the coax cable in a PoE+ compliant format. The paired set enables fast 10/100Base-T
Ethernet digital communication to be transmitted over Coax cable. An eBridge1PCRM receiver is powered
by a PoE midspan or endspan product, such as a NetWay8M and NetWay16M and sends its power over the
coax to the eBridge1PCTX transmitter under PoE protocol. This enables the eBridge1PCRM to be used in a
managed manner, allowing for remote camera reset. The eBridge1PCTX, in turn, delivers that PoE+ compliant
power to a PoE enabled camera or IP device. The eBridge1PCRM will not deliver power to non-compliant
devices, thus avoiding damage to improperly connected analog cameras. These plug and play units facilitate
system upgrades from analog to IP cameras/devices utilizing existing legacy Coax and eliminating the costs
and labor associated with installing new network cabling. In addition, data transmission and power over the
Coax is possible up to 457m in comparison to 100m Ethernet maximum distance (see Maximum Length of
Coax Type vs. Camera Power/PoE Class, pg. 3). A maximum range from headend to the PoE camera/device
is 610m taking into consideration that up to 100m of structured cable may be deployed at each end.
Features:
Rev. 032113
Installation Guide
eBridge1PCRMT
IP and PoE+ over Coax Solution
eBridge1PCRM Receiver and eBridge1PCTX Hardened Transceiver Kit
Agency Listings:
• UL/CUL Listed for Information
Technology Equipment (UL 60950-1).
• CE approved.
• C-Tick compliant.
Input:
• Powered by midspan or endspan.
Local Aux. Input Power for eBridge1PCRM:
• 24VDC/110mA or 24VAC/200mA.
Ethernet:
• Connectivity: RJ45, auto-crossover.
• Wire type: 4-pair CAT5 or better structured cable.
• Distance: up to 100m.
• Speed: 10/100BaseT, half/full duplex, auto
negotiation. PoE compliant to IEEE 802.3af
(15W) and PoE+ compliant to IEEE 802.3at
(30W) delivered to camera by eBridge1PCTX.
Power provided by eBridge1PCRM to
eBridge1PCTX by PoE protocol.
Coax:
• Distance: up to 457m (see Maximum Length of
Coax Type vs. Camera Power/PoE Class, pg. 3)
for power delivery of coax.
• Throughput is rated to pass 25mbps of data at
distances up to 457m. With proper headend
equipment this supports Megapixel, HD720,
HD1080.
• Connectivity: BNC, RG-59/U or similar.
LED Indicators:
• eBridge1PCRM:
Blue LED - Coax link connection (sloc).
Green - PoE ON.
Green - Power ON.
• eBridge1PCRM and eBridge1PCTX:
Yellow and Green LED (RJ45) IP Link status,
10/100Base-T/active.
LED Indicators (cont’d):
• eBridge1PCTX:
Blue LED - Coax link connection.
Green LED - PoE from eBridge1PCRM.
Environmental:
• Operating Temperature:
eBridge1PCRM:
-- 20ºC to 49ºC (-- 4ºF to 120.2ºF).
eBridge1PCTX:
For 15W: --- 40ºC to 75ºC (--- 40ºF to 167ºF).
For 30W: --- 40ºC to 49ºC (--- 40ºF to 120.2ºF).
• Storage Temperature:
-- 30º to 70ºC (-- 22º to 158ºF).
• Humidity: 20 to 85%, non-condensing.
Functions:
• Auto detection and protection of legacy
non-PoE cameras/devices.
Applications:
• Retrofit digital IP cameras in an analog
CCTV installation.
• Works with Megapixel, HD720, HD1080 and
VGA (SD) cameras (see note, pg. 2).
• Extend Network link distance in an industrial
environment over 610m (see note, pg. 2).
• Upgrade deployed CCTV Coax to a digital
network in Retail, Hospitality, Arenas, Casinos,
Airports, Schools, Hospitals, Transportation, etc.
Mechanical:
• Dimensions (W x L x H approx.):
eBridge1PCRM:
3.5” x 4.375” x 1”
(88.89mm x 111.125mm x 25.4mm).
eBridge1PCTX:
2.5” x 4.375” x 1”
(63.5mm x 111.125mm x 25.4mm).
I.T.E. 43KC
Z1409

- 2 - eBridge1PCRMT
Installation Instructions:
Wiring methods shall be in accordance with the National Electrical Code/NFPA 70/ANSI, and with all local
codes and authorities having jurisdiction. Wiring should be UL Listed and/or Recognized wire suitable for
the application.
eBridge1PCTX and eBridge1PCRM are not intended to be connected to outside plant leads and should be
installed indoors within the protected premises. eBridge1PCTX and eBridge1PCRM are intended for indoor
use only.
1. eBridge1PCRM installation:
a. Secure unit to desired mounting surface with a proper fastening device utilizing the unit’s
mounting hole (Fig. 2a, pg. 3). Unit should be mounted in proximity to ethernet switch/network,
NVR or video server.
Note: When installing more than one (1) eBridge1PCRM, please allow at least 1” (25mm)
distance between the receivers.
b. Connect structured cable from ethernet midspan or endspan device to RJ45 jack marked
[10/100BaseT] (Fig. 2, pg. 3).
c. Connect Coax cable to BNC connector marked [Coax] (Fig. 2, pg. 3).
d. A local AUX input 24VAC or 24VDC can be used to power the eBridge1PCRM. This will eliminate
the need for the eBridge1PCRM to draw power from the midspan/endspan, thus making the midspan/
endspan additional power available to the end PoE powered device.
2. eBridge1PCTX installation:
a. Secure unit to desired mounting surface with a proper fastening device utilizing the case’s
mounting hole (Fig. 2a, pg. 3). Unit should be mounted in proximity of camera/device.
b. Connect structured cable from IP camera/device to RJ45 jack marked [10/100BaseT] (Fig. 2, pg. 3).
c. Connect Coax cable to BNC connector marked [Coax] (Fig. 2, pg. 3).
Note: eBridge1PCRMT is designed to accommodate Megapixel, HD720, HD1080, and VGA (SD) cameras.
It is important to note that some high resolution and high frame rate cameras may demand faster headend
processing ability, such as a PC graphics card to present a quality image. If the headend processing equipment
is insufficient in speed, the image may show pixelation and latency. It is advisable to pre-test system if unsure.
Alternatively, frame rate and resolution may be reduced to accommodate system equipment.
Technical Specifications:
Parameter Description
Connections BNC for Coax link. RJ45 for ethernet link.
Input power
requirements Midspan or endspan port connected. AUX input for powering.
Indicators
Blue: Coax Link.
Yellow (RJ45 connector): On - Link, Off - No Link, Blinking - Activity.
Green (RJ45 connector): On - 100Base-TX, Off - 10Base-T.
Green: Power.
Environmental
Conditions
Operating Ambient Temperature: UL60950-1
eBridge1PCRM: -- 20ºC to 49ºC (-- 4ºF to 120.2ºF).
eBridge1PCTX:
For 15W: --- 40ºC to 75ºC (--- 40ºF to 167ºF).
For 30W: --- 40ºC to 49ºC (--- 40ºF to 120.2ºF).
Relative humidity: 85%, +/ --- 5%.
Storage Temperature: -- 30º to 70ºC (-- 22º to 158ºF).
Operating Altitude: -- 304.8 to 2000m (-- 1000 to 6,561.679 ft.).
Regulatory
Compliance
UL/CUL Listed for Information Technology Equipment (UL 60950-1).
CE approved. C-Tick compliant.
Weights (approx.) Product: 0.4 lbs. (0.181 kg), Shipping: 1 lbs. (0.45 kg).
Fig. 1 eBridge1PCRM eBridge1PCTX
Green LED
indicates
Power
Structured
Cable from
midspan/endspan
Structured
Cable from
IP Camera/Device
Blue LED
indicates
Coax Connection
Blue LED
indicates
Coax Connection
Green LED
indicates
Power
Yellow LED
indicates PoE
Coax
Cable from
eBridge1PCT or
eBridge1PCTX
Aux.
24VAC or
24VDC
Input
Coax
Cable from
eBridge1PCRM

eBridge1PCRMT - 3 -
Single PoE Camera Connection:
Fig. 2 Fig. 2a
Multiple PoE Cameras Connection:
Fig. 3
Maximum Length of Coax Type vs. Camera Power/PoE Class:
Camera
Power/
PoE Class
Coax Type
RG59/U -
23AWG
RG59/U -
22AWG
RG59/U -
20AWG
RG59/U -
18AWG
RG6/U -
18AWG
Max. Length (meters)
13W/0 260.64 335.28 457.20+ 457.20+ 457.20+
4W/1 457.20+ 457.20+ 457.20+ 457.20+ 457.20+
6.5W/2 457.20+ 457.20+ 457.20+ 457.20+ 457.20+
13W/3 260.64 335.28 457.20+ 457.20+ 457.20+
19W 152.4 198.1 315.5 457.20+ 457.20+
25W 118.9 152.4 239.3 365.8 365.8
PoC (PoE/PoE+ over Coax) 457m max.
Aux. 24VAC
or 24VDC Input PoE compliant
100m max.
100m max.
Coax
Structured Cable
Legend:
Mounting Hole
PoE Camera
eBridge1PCTX
eBridge1PCRM
www.altronix.com
SLOC Link LED
Coax
Midspan or Endspan Input Power LED PoE LED Aux. Power Input
--- +
eBridge1PCRM
Optional Power Input: 24VDC/110mA or 24VAC/200mA
Blue LED Coax link status
RJ45 LEDs Yellow - Speed, Green - Activity
Green LED Power and PoE
Z1409
EoC/PoE+ Receiver
www.altronix.com
SLOC Link LED
Coax
10/100 Base-T Power LED
eBridge1PCTX
Blue LED Coax link status.
RJ45 LEDs Yellow - Speed
Green - Activity
Green LED Power
I.T.E. 43KC
Z1409
EoC/PoE+ Transceiver
Powered Switch or NetWay MidSpan
PoE Camera
PoE Camera
PoE Camera
PoE Camera
PoC (PoE+ over Coax)
457m max.
PoC (PoE+ over Coax)
457m max.
PoC (PoE+ over Coax)
457m max.
PoC (PoE+ over Coax)
457m max.
100m max.
100m max.
100m max.
100m max.
PoE compliant
100m max.
PoE compliant
100m max.
PoE compliant
100m max.
PoE compliant
100m max.
Coax
Structured Cable
Legend:
eBridge1PCRM
eBridge1PCRM
eBridge1PCRM
eBridge1PCRM
eBridge1PCTX
eBridge1PCTX
eBridge1PCTX
eBridge1PCTX
Powered Switch or NetWay MidSpan

- 4 - eBridge1PCRMT
Altronix is not responsible for any typographical errors.
140 58th Street, Brooklyn, New York 11220 USA, 718-567-8181, fax: [phone]
website: www.altronix.com, e-mail: [email protected]. Lifetime Warranty, Made in U.S.A.
IIeBridge1PCRMT I14P MEMBER
