Overview:
Altronix NetWaySP1P converts 10/100/1000 Mbps ethernet to Fiber (1000Base-X/SX/LX)
and provides PoE.
Features:
Rev. 070717
Installation Guide
NetWaySP1P
Powered Media Converter/Injector
Agency Listings:
• UL/cUL Listed for Information Technology
Equipment (UL 60950-1).
• CE approved.
Input:
• 24VDC @ 1.5A, 56VDC @ 0.75A (30W).
• 24VDC @ 1.0A, 56VDC @ 0.5A (15W).
Fiber Port:
• One (1) 1Gb SFP port.
• Use with SFP module 1000Base-X (1Gb),
compliant to Class 1 laser product
(not included).
Ethernet:
• IEEE 802.3at (30W) compliant.
• Wire type: 4-pair CAT5e and higher.
• Connectivity: RJ45, auto-crossover.
• Speed: 10/100/1000Mbps.
• Distance: up to 100m.
LED Indicators:
• Yellow and Green LEDs (RJ45 jack):
IP Link status, 10/100/1000 Base-T/active.
• Green Pwr In LED:
Indicates unit is powered.
• Green PoE LED:
Indicates PoE present.
• Green SFP (Fiber) LED:
Indicates SFP connection.
Environmental:
• Refer to Environmental Conditions on page 3.
Dimensions (W x L x H approx.):
3.375” x 3.8” x 1”
(85.7mm x 96.52mm x 25.4mm).
Installation Instructions:
Unit is powered via 24VDC-56VDC. NetWaySP1P is not intended to be connected to outside
plant leads and should be installed indoors within the protected premises.
1. Mount NetWaySP1P in desired location utilizing the mounting hole (Fig. 1a, pg. 2).
Use a proper fastener and/or wall anchor when securing NetWaySP1P with screw through
its mounting hole to the wall.
2. Connect 24VDC-56VDC power source to terminals marked [24-56VDC – Input +].
Terminals accommodate up to 12 AWG wires.
3. Connect structured cable from port marked [PoE+ Output] on NetWaySP1P to a
PoE device (Fig. 2, pg. 2).
4. Connect fiber optic cable to a fiber SFP module. Connect the module to the port marked
[SFP] on the NetWaySP1P. Connect the other end of fiber cable to an SFP module of a
remote device. SFP LED will illuminate indicating data connection (Fig. 2, pg. 2).
I.T.E. 43KC
All manuals and user guides at all-guides.com
all-guides.com

- 2 - NetWaySP1P
Fig. 1
Fig. 1a
Typical Applications:
Fig. 2
Fig. 3
115/230VAC
Input
NetWaySP1P
Converts Ethernet
to Fiber & Provides PoE
Fiber
CAT5e/6
PoE+ (30W) PTZ
24-56VDC
Input
DC
Power
Supply
I.T.E. 43KC
PoE+ (30W) PTZ
115/230VAC
Input
NetWaySP1P
Converts Ethernet
to Fiber & Provides PoE
NetWaySP1
A
Media
Converter/
Repeater
Fiber
CAT5e/6
CAT5e/6
24-56VDC Input
DC
Power
Supply
NetWaySP1A
Media Converter/Repeater
Input: PoE Class 1 or Higher
Data: 10/100/1000
PoE /
10/100/1000 InPoE
Fiber
Signal
SFP
www.altronix.com
Made in
U.S.A.
NetWay8E
or Midspan/Endspan
I.T.E. 43KC
Structured
Cable to
PoE Device
24VDC to
56VDC
Input
-- +
SFP LED
Indicates
data connection
PoE LED
Indicates
PoE
present
One (1) Gb
SFP port
for Fiber
Power In
LED
Indicates
unit is
powered
NetWaySP1P
Media Converter/Injector
Input: 24VDC–56VDC
Output: IEEE 802.3at (30W) and
IEEE 802.3af (15.4W)
compliant.
Made in U.S.A.
www.altronix.com
24-56VDC
-- Input + PoE+ Output PoE Out
Pwr
In Fiber SignalSFP
I.T.E. 43KC
All manuals and user guides at all-guides.com

NetWaySP1P - 3 -
Fig. 4
Technical Specifications:
Parameter Description
Ports One (1) 1Gb SFP port.
One (1) Ethernet port 10/100/1000.
Input power
requirements
24VDC @ 1.5A, 56VDC @ 0.75A (30W / PoE+).
24VDC @ 1.0A, 56VDC @ 0.5A (15W / PoE).
Indicators
Green Pwr In LED: Indicates unit is powered.
Green PoE LED: Indicates PoE present.
Green SFP (Fiber) LED: Indicates SFP connection.
Environmental
Conditions
Input Output (Watts) Temperature
24VDC
15W -40ºC to 65ºC (-40ºF to 149ºF)
20W -40ºC to 60ºC (-40ºF to 140ºF)
25W -40ºC to 55ºC (-40ºF to 131ºF)
30W -40ºC to 45ºC (-40ºF to 113ºF)
56VDC 25W -40ºC to 75ºC (-40ºF to 167ºF)
30W -40ºC to 70ºC (-40ºF to 158ºF)
Storage: -40ºC to 75ºC (-40ºF to 167ºF).
Relative Humidity: 85% +/-5%.
Operating Altitude: -304.8 to 2,000m.
Regulatory
Compliance
UL/cUL Listed for Information Technology Equipment
(UL 60950-1).
CE approved.
Weights (approx.) Product: 0.25 lb. (0.11 kg) | Shipping: 0.3 lb. (0.14 kg).
PoE+ (30W) PTZ
NetWaySP1P
Converts Ethernet
to Fiber & Provides PoE
CAT5e/6
Composite
Fiber/Copper
NetWaySP4 Series
I.T.E. 43KC
I.T.E. 43KC
Recommended Altronix SFP Modules:
Altronix P1MM and P1SM10 are hot-pluggable SFP fiber transceiver modules and are readily usable
with all Altronix Spectrum fiber optic equipment for 1Gb transmission rates.
P1MM - For use with Multi-Mode Fiber for distances up to 550m.
P1SM10 - For use with Single-Mode Fiber for distances up to 10km.
All manuals and user guides at all-guides.com

- 4 - NetWaySP1P
Altronix is not responsible for any typographical errors.
140 58th Street, Brooklyn, New York 11220 USA | phone: [phone] | fax: [phone]
website: www.altronix.com | e-mail: [email protected] | Lifetime Warranty | Made in U.S.A.
NetWaySP1P K29Q MEMBER
