Altronix Netway Spectrum NetWaySP1A User manual

Overview:
Altronix NetWaySP1A PoE powered media converter/repeater converts 10/100/1000 Mbps ethernet to Fiber
(1000Base-X/SX/LX).
Features:
NetWaySP1A
PoE Powered Media Converter/Repeater
Installation Guide
Agency Listings:
• UL/cUL Listed for Information
Technology
Equipment (UL 60950-1).
• CE European Conformity.
Input:
• PoE IEEE 802.3AF compliant.
• Power consumption: 2W.
Fiber Ports:
• One (1) 1Gb SFP port.
• Use with SFP module 1000Base-X (1Gb),
compliant to Class 1 laser product (not included).
Ethernet:
• IEEE 802.3af (15W) compliant.
• Wire type: 4-pair CAT5e and higher.
• Connectivity: RJ45, auto-crossover.
• Speed: 10/100/1000Mbps.
• Distance: up to 100m.
LED Indicators:
• PoE Green LED: Indicates PoE present
(unit is powered).
• Link Signal Green LED: Indicates SFP connection.
Environmental:
• Refer to Environmental Conditions on page 4.
Dimensions (W x L x H approx.):
2.5” x 3.8” x 1” (63.5mm x 96.52mm x 25.4mm).
Installation Instructions:
Unit is powered via CAT5e by midspan or endspan. NetWaySP1A is not intended to be connected to outside
plant leads and should be installed indoors within the protected premises.
1. Mount NetWaySP1A in desired location utilizing the mounting hole (Fig. 1a, pg. 2). Use a proper fastener
and/or wall anchor when securing NetWaySP1A with screw through its mounting hole to the wall.
Note: Earth ground can be used, if needed, for high transient or outdoor environments. If used,
insert an Earth ground wire (included with product) into the internal ground terminal until secured
(a slight tug can check stability) & fasten the free end to a chassis earth ground.
If earth ground is not attached and needed, refer to Fig.1b, pg.2 for manual placement.
2. Connect structured cable from port marked [PoE 10/100/1000 In] on NetWaySP1A to the corresponding
input of an UL Listed ethernet switch or a midspan. PoE LED will illuminate indicating normal operation
(Fig. 1, pg. 2).
3. Connect fiber optic cable to a fiber SFP module. Connect the module to the port marked [SFP] on the
NetWaySP1A. Connect the other end of fiber cable to an SFP module of a remote device.
SFP LED will illuminate indicating data connection (Fig. 1, pg. 2).
Interconnecting Multiple Fiber/Ethernet Devices:
NetWaySP1A can be used for daisy-chaining two (2) Fiber/Ethernet devices such as Altronix
NetWaySP3 Series or NetWay4EX Series hardened switches.
Refer to NetWaySP3WPN / NetWay4EWPN Installation Instructions.
1. Connect one end of a CAT5 cable to one of the Ethernet ports of the hardened PoE switch,
e.g., NetWaySP3WPN or NetWay4EWPN (Fig. 3, pg. 3).
2. Connect the other end of structured cable to the port marked [PoE 10/100/1000 In] on NetWaySP1A (
Fig. 3, pg. 3, Fig. 1b pg. 2).
3. Connect fiber optic cable to a fiber SFP module. Connect the module to the port marked [SFP] on the
NetWaySP1A. Connect the other end of fiber cable to an SFP module and connect that module to Fiber
input of the next NetWaySP3WPN or NetWay4EWPN (Fig. 3, pg. 3, Fig. 1 pg. 2).
I.T.E. 43KC

- 2 - NetWaySP1A Installation Guide
Structured
Cable from
Midspan/
Endspan
PoE
Present
LED
SFP LED
Indicates
data connection
One (1) Gb SFP port
to Fiber Switch,
NetWaySP3WPN/SP4WPN,
NetWay4EWPN
Optional Earth Ground
If needed, insert approx 0.25” into this location until secured in the ground terminal.
Ground
Terminal
NetWaySP1A
Media Converter/Repeater
Input: PoE Class 1 or Higher
Data: 10/100/1000
PoE /
10/100/1000 InPoE
Fiber
Signal
SFP
Brooklyn, NY, U.S.A.
www.altronix.com
I.T.E. 43KC
Fig. 1
Fig. 1a
Typical Applications:
Fig. 2
Midspan/Endspan
Fiber Transceiver or
Outdoor Remote
(ex. NetWaySP3WP/4WP/8WP)
Fiber (Single/Multi-Mode)
CAT5e
CAT5e
NetWaySP1A
PTZ
NetWaySP1A
Media Converter/Repeater
Input: PoE Class 1 or Higher
Data: 10/100/1000
PoE /
10/100/1000 InPoE
Fiber
Signal
SFP
Brooklyn, NY, U.S.A.
www.altronix.com
I.T.E. 43KC
Fig. 1b

NetWaySP1A Installation Guide - 3 -
Interconnecting Two Switches:
Fig. 3
Composite Cable
(Fiber & Power)
or
Standard Fiber Application
NetWaySP1A
mounted inside Enclosure
for additonal Fiber Port
CAT5e or Higher Fiber
CAT5e
or Higher
Edge Devices
Data & PoE
30W/60W
CAT5e
or Higher
Edge Devices
Data & PoE
30W/60W
NetWaySP4
Transceiver
Netway Spectrum
Hardened PoE Switch
Netway Spectrum
Hardened PoE Switch
NetWaySP1A
Media Converter/Repeater
Input: PoE Class 1 or Higher
Data: 10/100/1000
PoE /
10/100/1000 InPoE
Fiber
Signal
SFP
Brooklyn, NY, U.S.A.
www.altronix.com
I.T.E. 43KC
NetWaySP1A
Media Converter/Repeater
Input: PoE Class 1 or Higher
Data: 10/100/1000
PoE /
10/100/1000 InPoE
Fiber
Signal
SFP
Brooklyn, NY, U.S.A.
www.altronix.com
I.T.E. 43KC

- 4 - NetWaySP1A Installation Guide
Technical Specifications:
Parameter Description
Ports One (1) 1Gb SFP port and one (1) Ethernet port 10/100/1000
Indicators PoE Green LED: Indicates PoE present (unit is powered).
Link Signal Green LED: Indicates SFP connection.
Environmental
Conditions
Operating: -40ºC to 75ºC (-40ºF to 167ºF).
Storage: -40ºC to 75ºC (-40ºF to 167ºF).
Relative Humidity 85% +/-5%.
Operating Altitude: -304.8 to 2,000m.
Regulatory
Compliance
UL/cUL Listed for Information Technology Equipment
(UL 60950-1)
CE European Conformity.
Weights (approx.) Product weight: 0.15 lb. (0.07 kg) | Shipping weight: 0.5 lb. (0.22 kg).
Recommended Altronix SFP Modules:
Altronix P1MM, P1SM10, P1AB2K and P1GCE are hot-pluggable SFP fiber transceiver modules and are readily
usable with all Altronix Spectrum fiber optic equipment for 1Gb transmission rates.
P1MM - For use with Multi-Mode Fiber for distances up to 550m.
P1SM10 - For use with Single-Mode Fiber for distances up to 10km.
P1AB2K - For use with Single Strand Single-Mode Fiber for distances up to 2km.
P1GCE - For use with CAT5e or better for distances up to 100m.
I.T.E. 43KC
