Altronix AL125220 User manual

*Note: When unit is powered by a battery back up (AC Fail condition), the voltage range is 9.3V-13.2V and
19.55V-26.4V for 12 and 24 volt operation respectively.
Power Supply Output Specifications: (AL125220, AL125X220)
Output VDC Switch Position Max. Stand-by Load DC Max. Alarm Load DC Battery (optional)
12VDC SW2 - Open 1 amp 1 amp 12VDC
24VDC SW2 - Closed 1 amp 1 amp 24VDC
Stand-by Specifications:
Output 4 hr. of Stand-by &
5 Minutes of Alarm Output 4 hr. of Stand-by & 5 Minutes of Alarm
12VDC / 4AH Battery 0.5 amp / 1 amp 12VDC / 7AH Battery 1 amp / 1 amp
24VDC / 4AH Battery 0.5 amp / 1 amp 24VDC / 7AH Battery 1 amp / 1 amp
Installation Instructions:
The units should be installed in accordance with article 760 of The National Electrical Code and NFPA 72 as well as all
applicable Local Codes.
See Terminal Identification Chart on page 2 for a description of each terminal function.
1. Mount unit in the desired location. Mark and predrill holes in the wall to line up with the top two keyholes in the
enclosure. Install two upper fasteners and screws in the wall with the screw heads protruding. Place the enclosure’s
upper keyholes over the two upper screws; level and secure. Mark the position of the lower two holes. Remove the
enclosure. Drill the lower holes and install two fasteners. Place the enclosure’s upper keyholes over the two
upper screws. Install the two lower screws and make sure to tighten all screws (Enclosure Dimensions, pg. 4).
2. Power connections: Connect secondary (blue and yellow leads) from the transformer to the Power Supply Board
terminals marked [XFMR] (Fig. 1 - Board Installation Diagram, pg. 3). Connect 220VAC 50/60Hz to the black and
white flying leads of the transformer. Secure green wire lead to earth ground. Use 18 AWG or larger for all power
connections (Battery, AC input, DC outputs). Use 22 AWG to 18 AWG for power limited circuits (Trigger inputs,
Dry outputs, DC outputs).
3. Measure output voltage before connecting devices. This helps avoiding potential damage.
4. Set the desired DC output voltage by setting switch SW2 to the appropriate position
(Power Supply Output Specifications Table, pg. 1, Fig. 1a, pg. 3).
Input:
• 220VAC50/60Hz,0.3amp.
Output:
• Two(2)12VDCor24VDCoutputs.
• 1amptotalsupplycurrent@12VDCor24VDC.
• Filteredandelectronicallyregulatedoutput.*
Battery Backup:
• Built-inchargerforsealedleadacidorgeltypebatteries.
• Maximumchargecurrent:400mA.
• Automaticswitchovertostand-bybatterywhenACfails.
Special Features:
• ACpowerandunitstatusindicatoronthefrontpanel.
• NormallyOpen[NO]triggerinput.
Special Features (cont’d):
• SupervisedFireAlarmDisconnect(Latchingw/reset
or Non-Latching).
• Unitsinclude power supply, transformer, cam lock and
enclosure
Enclosure Dimensions (H x W x D approx.):
• AL125220-8.5”x7.5”x3.5”
 (215.9mmx190.5mmx88.9mm).
Accommodates one (1) 12VDC/4AH battery.
• AL125X220-13.5”x13”x3.25”
 (342.9mmx330.2mmx82.55mm)
Accommodates up to two (2) 12VDC/7AH batteries.
Overview:
AL125220 and AL125X220 are power supply/chargers that convert 220VAC 50/60Hz input into two individual PTC
protected 12VDC or 24VDC outputs (see specifications).
Specifications:
AL125220 • AL125X220
Access Control Power Supply/Chargers

AL125220 series - 2 -
5. Connect Fail-Safe locking devices to the terminals marked [COM-- and LOCK+]. Connect Fail-Secure locking
devices to the terminals marked [COM-- and STRIKE+] (Fig. 2, pg. 3).
6. Connectnormallyopenaccesscontroldevice(i.e.cardreader,requesttoexitdevice,accesscontrolsystem)tothe
terminals marked TRG INPUT [NO, GND] (Fig. 1 - Application Diagram, pg. 3).
7. Connect FACP interface to the terminals marked [FACP1 and FACP2]. Wire the 2.2K resistor (supplied) in series
for a normally closed input or in parallel for a normally open input (Fig. 1, pg. 3). If required, set the latching FACP
interface mode by closing SW1 (Fig. 1a, pg. 3), and connect a normally open reset device to the terminals marked
RESET [NO, GND].
8. Connect battery to the terminals marked [+ BAT -- ] (battery leads included). Use two (2) 12VDC batteries connected
in series for 24VDC operation.
Note: For Access Control applications batteries are optional. When batteries are not used, a loss of AC will result in the
loss of output voltage. When the use of stand-by batteries is desired, they must be lead acid or gel type.
9. Please ensure that the cover is secured with the provided cam lock.
Maintenance:
Unit should be tested at least once a year for the proper operation as follows:
Output Voltage Test: Under normal load conditions, the DC output voltage should be checked for proper voltage level
(Power Supply Output Specifications Table, pg. 1).
Battery Test: Under normal load conditions check that the battery is fully charged, check specified voltage both at battery
terminal and at the board terminals marked [- BAT +] to ensure that there is no break in the battery connection wires.
Note:Maximumchargingcurrentunderdischargeis400mA.
Note:Expectedbatterylifeis5years;however,itisrecommendedchangingbatteriesin4yearsorlessifneeded.
Terminal Identification:
Terminal Legend Function/Description
XFMR Low voltage transformer connections.
+ AUX --- Auxpoweroutputterminals.Theseterminalswillsupply12VDCor24VDC,notaffected
by trigger, reset or fire alarm interface.
LOCK +,
STRIKE +,
COM ---
Switched power output. Fail-Safe [LOCK+] supplies positive power when unit is not triggered and
FACP interface is inactive. Fail-Secure [STRIKE+] supplies positive power when unit is triggered
and/or fire alarm interface is activated. [COM --- ] supplies negative power.
FACP1,
FACP2
Supervised by 2.2K end of line resistor FACP interface. Short or open will cause power to be
dropped to the terminal marked [LOCK+] and supply power to the terminal marked [STRIKE+].
Condition can be maintained even after restoration of the circuit (latching mode).
TRG INPUT,
NO, GND
Short between these two (2) terminals will cause power to be dropped to the terminal marked
[LOCK+] and supplied to the terminal marked [STRIKE+].
RESET,
NO, GND
Momentary short between these terminals would end latching FACP interface condition.
Feature active only if latching FACP is selected (SW1 closed).
--- BAT + Stand-by battery connections.
LED Diagnostics:

- 3 - AL125220 series
Red Power Supply Status
ON Normal condition.
OFF No DC output.
Slow Blink Loss of AC.
Rapid Blink Unit is triggered, awaiting reset. Fire alarm interface activated.
Application Diagram:
VR1
NO NOGND GND
FACP1 FACP2 STRIKE+
COM-- LOCK+
+ AUX --
TRIG INPUT RESET
SW1
+ BAT -- XFMR
SW2:
12VDC - Open
24VDC - Closed
Normal Open
Access Control
Triggering
Device
Normal Open
Reset Device 2.2K EOL
(supplied)
MAG LOCK
NC
FACP
NO
FACP
{ }
Card
Reader
Fig. 1
Fig. 1a - SW1 & SW2
OPEN SWITCH
CLOSED SWITCH
ELECTRIC
STRIKE
STRIKE+ LOCK+
Com-
Fig. 2

Altronixisnotresponsibleforanytypographicalerrors.
14058thStreet,Brooklyn,NewYork11220USA,718-567-8181,fax:718-567-9056
website:www.altronix.com,e-mail:[email protected],MadeinU.S.A.
IIAL125220 Series Rev. 102706 K18M
AL125220 series - 4 -
MEMBER
1.25”
(31.75mm)
1.25”
(31.75mm)
1.25”
(31.75mm)
1.125”
(28.575mm)
1”
(25.4mm)
1”
(25.4mm)
1”
(25.4mm)
5.25”
(133.35mm)
6.05”
(153.67mm)
6.05”
(153.67mm)
3.5”
(88.9mm)
3.5”
(88.9mm)
7.25”
(184.15mm)
2”
(50.8mm)
2”
(50.8mm)
8.125”
(206.375mm)
0.6”
(15.24mm)
1”
(25.4mm)
1”
(25.4mm)
0.6”
(15.24mm)
0.6”
(15.24mm)
1.125”
(28.575mm)
0.6”
(15.24mm)
3.625”
(184.15mm)
1.40”
(36mm)
1.40”
(36mm)
4.85”
(123mm)
4.85”
(123mm)
1.40”
(36mm)
1.40”
(36mm)
5.10”
(130mm)
5.10”
(130mm)
13.0”
(330mm)
5.10”
(130mm)
6.5625”
(167mm)
1.20”
(31mm)
1.20”
(31mm) 1.20”
(31mm)
3.25”
(83mm)
3.25”
(83mm)
3.25”
(83mm)
3.25”
(83mm)
1.0”
(25mm)
1.0”
(
25mm
)
10.5”
(
267mm
)
1.0”
(
25mm
)
1.0”
(25mm)
0.75”
(19mm)
0.75”
(19mm)
0.9375”
(24mm)
0.9375”
(24mm)
11.0”
(279mm)
12.5”
(318mm)
Enclosure Dimensions (H x W x D):
AL125220
8.5”x7.5”x3.5”
(215.9mmx190.5mmx88.9mm).
Enclosure Dimensions (H x W x D):
AL125X220
13.5”x13”x3.25”
(342.9mmx330.2mmx82.55mm)
