Altronix ALTV248HI User manual

Rev. 081204
Isolated Series
CCTV Power Supplies
Installation Guide
Models Include:
•ALTV248HI •ALTV248CBHI
- 24VAC @ 14A total output. - 24VAC @ 14A total output.
- Eight (8) 1.75A Fuse Protected - Eight (8) 1.75A PTC Protected
Isolated Outputs. Isolated Outputs.
•ALTV248MI •ALTV248CBMI
- 24VAC @ 12.5A total output. - 24VAC @ 12.5A total output.
- Eight (8) 1.6A Fuse Protected - Eight (8) 1.6A PTC Protected
Isolated Outputs. Isolated Outputs.
•ALTV2416I • ALTV2416CBI
- 24VAC @ 28A total output. - 24VAC @ 28A total output.
- Sixteen (16) 1.75A Fuse Protected - Sixteen (16) 1.75A PTC Protected
Isolated Outputs. Isolated Outputs.

Overview:
Altronix Isolated CCTV Power Supplies provide 24VAC distributed via eight (8) or sixteen (16) fuse or PTC protected
isolated outputs for powering CCTV cameras, heaters, and other video accessories.
Isolated Power Supply Reference Chart:
Altronix
Model Number
Output
Voltage
Total
Output
Current
(Power)
Number
of
Outputs
PTC
Protected
Outputs
Fuse
Protected
Outputs
Output
Current
(max per
output)
115VAC
50/60Hz Input
Current
ALTV248HI
24VAC
14A
8
-P1.75A
2.7A
ALTV248CBHI P-
ALTV248MI 12.5A -P1.6A
ALTV248CBMI P-
ALTV2416I 28A 16 -P1.75A 5.4A
ALTV2416CBI P-
Specifications:
Installation Instructions:
1. Mount unit in the desired location.
2. Set power switch to the OFF positon on all models (Figs. 1-3, pgs. 3-5).
3. All units are factory set for 24VAC operation.
4. Connect AC power to the black and white flying leads of the transformer(s) (Figs. 1-3, pgs. 3-5).
Use 18 AWG or larger for all power connections.
5. Measure output voltage before connecting devices. This helps avoiding potential damage.
Terminals marked [1A - 8A] and [1B - 8B] are of the same polarity (phase).
6. Connect CCTV cameras to the output terminals using the following procedure:
Camera 1 to output 1A and 1B. Camera 5 to output 5A and 5B.
Camera 2 to output 2A and 2B. Camera 6 to output 6A and 6B.
Camera 3 to output 3A and 3B. Camera 7 to output 7A and 7B.
Camera 4 to output 4A and 4B. Camera 8 to output 8A and 8B.
7. Set power switch on all models to the “RESET” (ON) position (Figs. 1-3, pgs. 3-5).
8. Upon completion of wiring secure enclosure door with screws (supplied).
CAUTION: Equipment to be installed/serviced by authorized/trained personnel only.
Shut branch circuit power before installing/servicing equipment.
WARNING: To reduce the risk of fire or electric shock, do not expose the unit to rain or moisture.
This installation should be made by qualified service personnel and should conform to the National
Electrical Code and all local codes.
Features:
• Illuminated master Power ON/OFF switch
w/built in circuit breaker.
• Unit maintains camera synchronization.
• Ease of installation saves time and eliminates costly labor.
• Spare fuses included (on fuse protected models).
Enclosure Dimensions (H x W x D):
ALTV248MI, ALTV248CBMI:
8.5” x 7.5” x 3.5” (215.9mm x 190.5mm x 88.9mm)
ALTV248HI and ALTV248CBHI:
12.25” x 7.25” x 4.5” (311.15mm x 184.15mm x 114.3mm)
ALTV2416I and ALTV2416CBI:
13.5” x 13” x 3.25” (342.9mm x 330.2mm x 82.55mm)
- 2 - CCTV Isolated Series

Terminal Identification:
PD8I - Power Distribution Module
1A - 8A Phase 1
1B - 8B Phase 2
Fig. 1 ALTV248HI • ALTV248CBHI
1A
F1 F2 F3 F4 F5 F6 F7 F8
2A 3A 4A 5A 6A 7A 8A
1B 2B 3B 4B 5B 6B 7B 8B
115VAC input
50/60 Hz
Power
Switch
115VAC input
50/60 Hz
XFMR*
1A
F1 F2 F3 F4 F5 F6 F7 F8
2A 3A 4A 5A 6A 7A 8A
1B 2B 3B 4B 5B 6B 7B 8B
Used on PTC Models
(example: ALTV248CBI)
CCTV Isolated Series - 3 -

Fig. 2 ALTV248MI • ALTV248CBMI
Transformer
underneath
power supply
board
Power
Switch
1A
F1 F2 F3 F4 F5 F6 F7 F8
2A 3A 4A 5A 6A 7A 8A
1B 2B 3B 4B 5B 6B 7B 8B
1A
F1 F2 F3 F4 F5 F6 F7 F8
2A 3A 4A 5A 6A 7A 8A
1B 2B 3B 4B 5B 6B 7B 8B
Used on PTC Models
(example: ALTV248CBMI)
- 4 - CCTV Isolated Series

Fig. 3 ALTV2416I • ALTV2416CBI
115VAC input
50/60 Hz.
Power
Switch
1A
F1 F2 F3 F4 F5 F6 F7 F8
2A 3A 4A 5A 6A 7A 8A
1B 2B 3B 4B 5B 6B 7B 8B
1A
F1 F2 F3 F4 F5 F6 F7 F8
2A 3A 4A 5A 6A 7A 8A
1B 2B 3B 4B 5B 6B 7B 8B
XFMR* XFMR*
1A
F1 F2 F3 F4 F5 F6 F7 F8
2A 3A 4A 5A 6A 7A 8A
1B 2B 3B 4B 5B 6B 7B 8B
Used on PTC Models
(example: ALTV2416CBI)
CCTV Isolated Series - 5 -

1.25”
(31.75mm)
1.25”
(31.75mm)
1.25”
(31.75mm)
1.125”
(28.575mm)
1”
(25.4mm)
1”
(25.4mm)
1”
(25.4mm)
5.25”
(133.35mm)
6.05”
(153.67mm)
6.05”
(153.67mm)
3.5”
(88.9mm)
3.5”
(88.9mm)
7.25”
(184.15mm)
2”
(50.8mm)
2”
(50.8mm)
8.125”
(206.375mm)
0.6”
(15.24mm)
1”
(25.4mm)
1”
(25.4mm)
0.6”
(15.24mm)
0.6”
(15.24mm)
1.125”
(28.575mm)
0.6”
(15.24mm)
3.625”
(184.15mm)
Enclosure Dimensions (H x W x D approximate) for:
• ALTV248MI • ALTV248CBMI
8.5” x 7.5” x 3.5” (215.9mm x 190.5mm x 88.9mm)
- 6 - CCTV Isolated Series

1.25”
(31.75mm)
0.5”
(12.7mm)
0.5”
(12.7mm)
1.5”
(12.7mm)
1.25”
(31.75mm)
1.5”
(12.7mm)
3.5”
(88.9mm)
3.5”
(88.9mm)
3.5”
(88.9mm)
1”
(25.4mm)
1”
(25.4mm)
5.75”
(146.05mm)
1”
(25.4mm)
1.13”
(28.7mm)
5.88”
(149.35mm)
0.88”
(22.35mm)
0.88”
(22.35mm)
1.11”
(28.19mm)
1.11”
(28.19mm)
4.5”
(114.3mm)
4.5”
(114.3mm)
4.5”
(114.3mm)
4.5”
(114.3mm)
7.5”
(190.5mm)
7.5”
(190.5mm)
2.5”
(63.5mm)
12”
(304.8mm)
12”
(304.8mm)
Enclosure Dimensions (H x W x D approximate) for:
• ALTV248HI • ALTV248CBHI
12.25” x 7.25” x 4.5” (311.15mm x 184.15mm x 114.3mm)
CCTV Isolated Series - 7 -

Altronix is not responsible for any typographical errors.
140 58th Street, Brooklyn, New York 11220 USA, 718-567-8181, fax: [phone]
web site: www.altronix.com, e-mail: [email protected]. Lifetime Warranty, Made in U.S.A.
II Isolated Series B05P MEMBER
1.40”
(36mm)
1.40”
(36mm)
4.85”
(123mm)
4.85”
(123mm)
1.40”
(36mm)
1.40”
(36mm)
5.10”
(130mm)
5.10”
(130mm)
13.0”
(330mm)
5.10”
(130mm)
6.5625”
(167mm)
1.20”
(31mm)
1.20”
(31mm) 1.20”
(31mm)
3.25”
(83mm)
3.25”
(83mm)
3.25”
(83mm)
3.25”
(83mm)
1.0”
(25mm)
1.0”
(
25mm
)
10.5”
(
267mm
)
1.0”
(
25mm
)
1.0”
(25mm)
0.75”
(19mm)
0.75”
(19mm)
0.9375”
(24mm)
0.9375”
(24mm)
11.0”
(279mm)
12.5”
(318mm)
Enclosure Dimensions (H x W x D approximate) for:
• ALTV2416I • ALTV2416CBI
13.5” x 13” x 3.25” (342.9mm x 330.2mm x 82.55mm)
- 8 - CCTV Isolated Series
