Altronix TROVE PLUS T3M77XK1V User manual

T3M77XK1V
16 Door Kit with Fused Outputs
Accommodates one (1) Intelligent Dual Reader Controller and
seven (7) Dual Reader Interface Modules.
T3M77XK2V
14 Door Kit with Fused Outputs
Accommodates one (1) Intelligent Controller and seven (7) Dual
Reader Interface Modules.
T3M77XK3V
16 Door Kit with Fused Outputs
Accommodates up to eight (8) Dual Reader Interface Modules.
Each fully assembled kit includes:
- Trove3 enclosure with TM3 Altronix/Mercury backplane
- Two (2) eFlow104NBV - Power Supply/Charger
- Two (2) ACMS8 - Dual Input/Output Fuse Protected
Access Power Controller
- Two (2) VR6 - Voltage Regulator
- Two (2) PDS8 - Dual Input/Output Fuse Protected
Power Distribution Module
- One (1) Rocker Switch Bracket with Two (2) Rocker Switches
- Wire harnesses and finger duct
T3M77XK1DV
16 Door Kit with PTC Outputs
Accommodates one (1) Intelligent Dual Reader Controller and
seven (7) Dual Reader Interface Modules.
T3M77XK2DV
14 Door Kit with PTC Outputs
Accommodates one (1) Intelligent Controller and seven (7) Dual
Reader Interface Modules.
T3M77XK3DV
16 Door Kit with Fused Outputs
Accommodates up to eight (8) Dual Reader Interface Modules.
Each fully assembled kit includes:
- Trove3 enclosure with TM3 Altronix/Mercury backplane
- Two (2) eFlow104NBV - Power Supply/Charger
- Two (2) ACMS8CB - Dual Input/Output PTC Protected
Access Power Controller
- Two (2) VR6 - Voltage Regulator
- Two (2) PDS8CB - Dual Input/Output PTC Protected
Power Distribution Module
- One (1) Rocker Switch Bracket with Two (2) Rocker Switches
- Wire harnesses and finger duct
Access & Power Integration
Rev. T3M77XKV_071023
Installing Company: _________________________ Service Rep. Name: __________________________________________
Address: _________________________________________________________ Phone #: _________________________
All registered trademarks are property of their respective owners. More than just power.™
Installation Guide
Please refer to the included corresponding Sub-Assembly Installation Guides for further information.
Altronix/Mercury Wired Kits
Models Include:

- 2 - T3M77XKV Kit Series Installation Guide
Overview:
Altronix Trove Plus kits are pre-wired, pre-assembled and consist of Trove3M3 enclosure/backplane with factory installed Altronix power supply/
charger(s) and sub-assemblies, wire harnesses and finger duct.
Configuration Chart:
Altronix
Model Number 220VAC 50/60Hz Input Current (A) Power Supply Board Input Fuse Rating Power Supply Board Battery Fuse Rating
Nominal DC Output Voltage
Maximum Supply
Current for Main and
Aux. Outputs on
Power Supply board
and ACMS8(CB)
Access Power
Controller’s outputs Fail-Safe/Fail-Secure or Dry Form “C” Outputs Current Per ACMS8 and PDS8(CB) Output (A) ACMS8(CB) Board Input Fuse (PTC) Rating ACMS8(CB) Board Output Fuse (PTC) Rating PDS8(CB) Board Input Fuse (PTC) Rating PDS8(CB) Board Output Fuse (PTC) Rating
Power Supply 1 Power Supply 2
[DC] [Aux] [DC] [Aux]
Output Range (VDC) Output Range (VDC) Output Range (VDC) Output Range (VDC)
T3M77XK1
5.4 6.3A/
250V
15A/
32V
20.17-
26.4
20.28-
26.4
20.17-
26.4
20.28-
26.4 24VDC @ 9.4A 16
2.5 15A/
32V
3A/
32V
10A/
32V
3A/
32V
T3M77XK2
T3M77XK3
T3M77XK1D
2.0 9A 2.5A 9A 2.5AT3M77XK2D
T3M77XK3D
Hardware and Accessories:
• Two (2) tamper switches (Altronix Model TS112 or equivalent).
• Cam lock.
• Battery leads.
Mechanical:
• 16 Gauge enclosure with ample knockouts for convenient access.
• Enclosure Dimensions (H x W x D): 36.12” x 30.125” x 7.06” (917.5mm x 768.1mm x 179.3mm).
Installation Instructions:
Wiring methods shall be in accordance with the National Electrical Code/NFPA 70/ANSI, and with all local codes and authorities having jurisdiction.
Product is intended for indoor use only.
1. Remove backplane from enclosure. Do not discard hardware.
2. Mark and predrill holes in the wall to line up with the top three keyholes in the enclosure. Install three upper fasteners and screws
in the wall with the screw heads protruding. Place the enclosure’s upper keyholes over the three upper screws, level and secure.
Mark the position of the lower three holes. Remove the enclosure. Drill the lower holes and install
the three fasteners. Place the enclosure’s upper keyholes over the three upper screws.
Install the three lower screws and make sure to tighten all screws.
3. Mount included UL Listed tamper switches (Altronix Model TS112 or equivalent) in desired
location, opposite hinge. Slide the tamper switch bracket onto the edge of the enclosure
approximately 2” from the right side (Fig. 1, pg. 2). Connect tamper switch wiring to the
Access Control Panel input or the appropriate UL Listed reporting device.
To activate alarm signal open the door of the enclosure.
4. Mount Mercury boards to backplane, refer to pg. 3, 4.
5. Refer to the eFlow Power Supply/Charger Installation Guide for eFlow104NBV
and corresponding Sub-Assembly Installation Guides for PDS8(CB) and ACMS8(CB) for
further installation instructions.
6. Position Lenel/Mercury access controller module over corresponding spacers and depress onto
snap on spacers (Fig. 2-4, pg. 3-5).
7. Mount backplane to enclosure with hardware.
