ALTUS ADC70W User manual

ADC70W
EN
Dryer
User Manual
2960312937/201221.1324

2 / EN Dryer / User Manual
Please read this user manual first!
Dear Customer,
Thank you for prefering a Altus product. We hope that your product which has been
manufactured with high quality and technology will give you the best results. We advise you
to read through this manual and the other accompanying documentation carefully before
using your product and keep it for future reference. If you transfer the product to someone
else, give its manual as well. Pay attention to all details and warnings specified in the user
manual and follow the instructions given therein.
Use this user manual for the model indicated on the cover page.
Read the instructions.
Explanation of symbols
Throughout this user manual the following symbols are used:
CImportant information or useful hints about usage.
AWarning for hazardous situations with regard to life and property.
BWarning against electric shock.
Warning against hot surfaces.
Warning against fire hazard.
Warning against scalding hazard.
Packaging materials of the product are manufactured from recyclable materials in
accordance with our National Environment Regulations.
Do not dispose of the packaging wastes with the domestic waste or other wastes, discard
them to the dedicated collection points designated by the local authorities.

3 / EN
Dryer / User Manual
1Important instructions for safety and
environment
Ths secton contans safety nstructons that wll help
protect from rsk of personal njury or property damage.
Falure to follow these nstructons shall vod any warranty.
1.1 General safety
•The dryer can be used by chldren at and above 8
years old and by persons whose physcal, sensory or
mental capabltes were not fully developed or who
lack experence and knowledge provded that they are
supervsed or traned on the safe usage of the product
and the rsks t brngs out. Chldren should not play wth
the product. Cleanng and mantenance works should not
be performed by chldren unless they are supervsed by
someone.
•Chldren of less than 3 years should be kept away unless
contnously supervsed.
•Adjustable feet should not be removed. The gap between
the dryer and the floor should not be reduced wth
materals such as carpet, wood and tape. Ths wll cause
problems wth the dryer.
•Always have the nstallaton and reparng procedures
carred out by an Authorsed Servce Agent. The
manufacturer shall not be held lable for damages that
may arse from procedures carred out by unauthorzed
persons.
•Never wash the dryer by sprayng or pourng water onto t!
There s the rsk of electrc shock!
For the products wth a steam functon:
•Use only dstlled water or water condensed n the water
tank of the machne n steam programs. Do not use mans
water or addtves. When usng condensed water n the
water tank, t should be fltered and cleared of fbres.
•Do not open the door when steam programs are runnng.
Hot water may be expelled.

4 / EN Dryer / User Manual
Important instructions for safety and
environment
•Before puttng laundry n a steam program, stans on t
should be removed.
•You may only put laundry that s not drty or staned
but permeated wth unpleasant odour n steam (odour
removal) program.
•Do not use any dry cleanng sets or addtonal materals n
a steam program or n any program.
1.1.1 Electrcal safety
AElectrcal safety nstructons should be followed
whle electrcal connecton s made durng the
nstallaton.
AThe applance must not be suppled through an
external swtchng devce, such as a tmer,or
connected to a crcut that s regularly swtched on
and off by utlty.
•Connect the dryer to a grounded outlet protected by a
fuse at the value specfed on the type label. Have the
groundng nstallaton performed by a qualfed electrcan.
The manufacturer shall not be lable for any damages that
wll arse when the dryer s used wthout groundng n
accordance wth the local regulatons.
•The voltage and allowed fuse protecton s stated on the
type label plate.
•The voltage specfed on the type label must be equal to
your mans voltage.
•Unplug the dryer when t s not n use.
•Unplug the dryer from the mans durng nstallaton,
mantenance, cleanng and repar works.
•Do not touch the plug wth wet hands! Never unplug by
pullng on the cable, always pull out by grabbng the plug.
•Do not use extenson cords, mult-plugs or adaptors to
connect the dryer to power supply n order to decrease the
rsk of fre and electrc shock.

5 / EN
Dryer / User Manual
Important instructions for safety and
environment
•Power cable plug must be easly accessble after
nstallaton.
BDamaged mans cable should be changed notfyng
an Authorsed Servce Agent.
BIf the dryer s faulty, t must not be operated unless
t s repared by an authorzed servce agent! There s
the rsk of electrc shock!
1.1.2 Product safety
Superheatng of the clothes nsde of the dryer can
occur f you cancel the programme or n the event
of a power falure whlst the dryer s runnng, ths
concentraton of heat can cause self-combuston and
fre so always actvate the ventlaton programme
to cool down or quckly remove all laundry from the
dryer n order to hang them up and dsspate the
heat.
Ponts to be taken nto consderaton for fre
hazard:
Below specfed laundry or tems must not be dred n
the dryer consderng fre hazard.
•Unwashed laundry tems
•Items soled wth ol, acetone, alcohol, fuel ol,
kerosene, stan removers, turpentne, paraffn or
paraffn removers must be washed n hot water
wth plenty of detergent before beng dred n the
dryer.
For ths reason especally the tems contanng the
above specfed stans must be washed very well, to
do ths use adequate detergent and choose a hgh
washng temperature.

6 / EN Dryer / User Manual
Important instructions for safety and
environment
Below specfed laundry or tems must not be
dred n the dryer due to the fre hazard:
•Garments or pllows bolstered wth rubber foam
(latex foam), shower hats, water resstant textles,
materals wth rubber renforcement and rubber
foam pads.
•Clothng cleaned wth ndustral chemcals.
Items such as lghter, match, cons, metal parts,
needle etc. may damage the drum set or may lead to
functonal problems. Therefore check all the laundry
that you wll load nto your dryer.
Never stop your dryer before the programme
completes. If you must do ths, remove all laundry
quckly and lay them out to dsspate the heat.
Clothes that are washed nadequately may gnte on
ther own and even may gnte after dryng ends.
Ol-affected tems can gnte spontaneously,
especally when exposed to heat sources such as n
a tumble dryer. The tems become warm, causng an
oxdaton reacton n the ol. Oxdaton creates heat.
If the heat cannot escape, the tems can become hot
enough to catch fre. Plng, stackng or storng ol-
affected tems can prevent heat from escapng and
so create a fre hazard.
If t s unavodable that fabrcs that contan vegetable
or cookng ol or have been contamnated by har care
products be placed n a tumble dryer they should frst
be washed n hot water wth extra detergent - ths
wll reduce, but not elmnate, the hazard.
Remove all objects from pockets such as lghters and
matches.
•You must provde enough ventlaton n order to prevent
gases extng from devces operatng wth other types of
fuels ncludng the naked flame from accumulatng n the
room due to the back fre effect.

7 / EN
Dryer / User Manual
Important instructions for safety and
environment
AUnderwear that contans metal renforcements
should not be dred n the dryer. Dryer may be
damaged f metal renforcements come loose and
break off durng dryng.
CUse softeners and smlar products n accordance
wth the nstructons of ther manufacturers.
CAlways clean the lnt flter before or after each
loadng. Never operate the dryer wthout the lnt
flter nstalled.
•Never attempt to repar the dryer by yourself. Do not
perform any repar or replacement procedures on the
product even f you know or have the ablty to perform
the requred procedure unless t s clearly suggested n the
operatng nstructons or the publshed servce manual.
Otherwse, you wll be puttng your lfe and others’ lves n
danger.
•There must not be a lockable, sldng or hnged door that
may block the openng of the loadng door n the place
where your dryer s to be nstalled.
•Install your dryer at places sutable for home use.
(Bathroom, closed balcony, garage etc.)
•Make sure that pets do not enter the dryer. Check the
nsde of the dryer before operatng t.
•Do not lean on the loadng door of your dryer when t s
open, otherwse t may fall over.
•The lnt must not be allowed to accumulate around the
tumble dryer
•The tumble dryer s not to be used f ndustral chemcals
have been used for cleanng.
•Fabrc softeners, or smlar products.should be used as
specfed by the fabrc softener nstructons.

8 / EN Dryer / User Manual
Important instructions for safety and
environment
•Exhaust ar must not be dscharged nto a flue whch s
used for exhaustng fumes from applances burnng gas or
other fuels.
•The fnal step of the dryng cycle (cool-down cycle) occurs
wthout applyng heat to ensure that the tems are left at a
temperature that wll not damage them.
1.2 Stackng on top of a washng machne
•A fxng devce should be used between the two machnes
when nstallng the dryer above a washng machne. The
fttng devce must be nstalled by an Authorsed Servce
Agent.
•Total weght of the washng machne and the dryer -wth
full load- when they are placed on top of each other
reaches to approx. 180 klograms. Place the products on a
sold floor that has suffcent load carryng capacty!
AWashng machne cannot be placed on the dryer.
Pay attenton to the above warnngs durng the
nstallaton on your washng machne.
Installation Table for Washing Machine and Dryer
Dryer
Depth
Washing Machine Depth
62 cm 60 cm 54 cm 50 cm 49 cm 45 cm 40 cm
54 cm Can be nstalled Can be
nstalled Cannot be
nstalled
60 cm Can be nstalled Cannot be
nstalled

9 / EN
Dryer / User Manual
Important instructions for safety and
environment
1.3 Intended use
•Dryer has been desgned for domestc use. It s not sutable
for commercal use and t must not be used out of ts
ntended use.
•Use the dryer only for dryng laundry that are marked
accordngly.
•The manufacturer waves any responsblty arsen from
ncorrect usage or transportaton.
1.4 Chld safety
•Packagng materals are dangerous for the chldren. Keep
packagng materals away from chldren.
•Electrcal products are dangerous for the chldren. Keep
chldren away from the product when t s operatng. Do
not let them tamper wth the dryer. Use the chld-proof
lock n order to prevent the chldren to tamper wth the
dryer.
CChld-proof lock s on the control panel.
(See Chld lock)
•Keep loadng door closed even when the dryer s not n
use.

10 / EN Dryer / User Manual
Important instructions for safety and
environment
1.5 Complance wth the WEEE regulaton
and dsposng of the waste product
Ths product comples wth EU WEEE Drectve
(2012/19/EU). Ths product bears a classfcaton
symbol for waste electrcal and electronc equpment
(WEEE).
Ths product has been manufactured wth hgh qualty
parts and materals whch can be reused and are sutable
for recyclng. Do not dspose of the waste product wth
normal domestc and other wastes at the end of ts servce
lfe. Take t to the collecton center for the recyclng of
electrcal and electronc equpment. Please consult your
local authortes to learn about these collecton centers.
1.6 Complance wth RoHS Drectve:
The product you have purchased comples wth EU RoHS
Drectve (2011/65/EU). It does not contan harmful and
prohbted materals specfed n the Drectve.
1.7 Package nformaton
Packagng materals of the product are manufactured
from recyclable materals n accordance wth our Natonal
Envronment Regulatons. Do not dspose of the packagng
materals together wth the domestc or other wastes. Take
them to the packagng materal collecton ponts desgnated
by the local authortes.

11 / EN
Dryer / User Manual
Important instructions for safety and
environment
1.8 Techncal Specfcatons
EN
Height (Min. / Max.) 84,6 cm / 86,6 cm*
Width 59,7 cm
Depth 56,8 cm
Capacity (max.) 7 kg**
Net weight (± 4 kg) 34 kg
Voltage
See type label***Rated power input
Model code
* Mn. heght: Heght wth adjustable feet are closed.
Max. heght: Heght wth adjustable feet are opened
maxmum.
** Dry laundry weght before washng.
*** Type label s located behnd the loadng door.
CTechncal specfcatons of the dryer are subject to
change wthout notce to mprove the qualty of the
product.
CFgures n ths manual are schematc and may not
match the product exactly.
C
Values stated on markers on the dryer or n the other
publshed documentaton accompanyng wth the
dryer are obtaned n laboratory n accordance wth
the relevant standards. Dependng on operatonal and
envronmental condtons of the dryer, these values
may vary.

12 / EN Dryer / User Manual
2 Your Dryer
2.1 Overview
10
1
2
3
4
5
6
7
8
9
1. Top panel
2. Control panel
3. Loading door
4. Kick plate opening button
5. Ventilation grids
6. Adjustable legs
7. Kick plate & *water tank (*located behind
the kick plate )
8. Type label
9. Lint filter
10. Power cord
2.2 Package Contents
12 3 5
6
4
7 8
1. Water drain hose *
2. Filter drawer spare sponge*
3. User Manual
4. Drying basket*
5. Drying basket user manual*
6. Water Filling Container*
7. Pure Water*
8. Fragrance Capsules Group*
*Optional - may not be included, depends on model.

13 / EN
Dryer / User Manual
3Installaton
Before the calling the nearest Authorized
Service for the installation of the dryer,
ensure that electrical installation and water
drain is appropriate referring to the user’s
manual. If they are not suitable, contact a
qualified electrician and technician to make
necessary arrangements.
CPreparation of the dryer's location
as well as the electrical and
waste water installations is under
customer's responsibility.
APrior to installation, visually check
if the dryer has any defects on
it. If the drier is damaged, do
not have it installed. Damaged
products cause risks for your
safety.
3.1 Appropriate installation
location
Install the dryer on a stable and level surface.
Dryer is heavy. Do not move it by yourself.
• Operate your dryer in a well ventilated,
dust-free environment.
• The gap between the dryer and the
surface should not be reduced by the
materials such as carpet, wood and tape.
• Do not cover the ventilation grills of the
dryer.
• There must not be a lockable, sliding or
hinged door that may block the opening
of the loading door in the place where
your dryer is to be installed.
• Once the dryer is installed, it should stay
at the same place where its connections
have been made. When installing the
dryer, make sure that its rear wall does
not touch anywhere (tap, socket, etc.).
• Place the dryer at least 1 cm away from
the edges of other furniture.
• Your dryer can be operated at
temperatures between +5°C and +35°C.
If the operating conditions fall outside
of this range, operation of the dryer
will be adversely affected and it can get
damaged.
• The rear surface of the tumble dryer
shall be placed against a wall.
BDo not place the dryer on the
power cable.
3.2 Removing the
transportation safety
assembly
ARemove the transportation safety
assembly before using the dryer
for the first time.
3.3 Connecting the water
drain hose for models with the
water tank at the bottom;
Connection pipe to water drain is at the
bottom rear of your machine.
• 1. Remove the bracket and the rubber
cap.
• 2. Attach the drain hose and replace the
bracket to its position.
AIn case of removing the drain
hose, do not forget to replace
the rubber cap and bracket to its
position back.

14 / EN Dryer / User Manual
Installation
Important:
CDuring full capacity usage, it is
advised to use the machine with
direct drain connection, since the
machine may pause with flashing
water tank warning symbol.
CMake sure that the discharge
hose is tight after it is connected
to the drain in order to obtain
a better water flow since the
machine is not equipped with a
pump. You can cut and shorten
the hose to adjust its length if
necessary.
CThe end of the hose should
never be higher than the level of
the water outlet on the machine.
Otherwise, the “tank full” light of
your machine will illuminate and
stop the programme.
CIf the dryer is mounted on the
washing machine by means
of a bracket, use of the water
drain hose is recommended. The
drain hose should be directed
downwards as shown in the
figure.
3.4 Adjusting the feet
• Turn the feet to left or right until the
dryer stands level and firmly.
3.5 Transportation of the dryer
Drain all water that has remained in the dryer.
If direct water drain connection is made, then
remove the hose connections.
A
We recommend carrying the
dryer in upright position. If it is
not possible to carry the machine
in the upright position, we
recommend carrying it by tilting
towards the right side when
looked from the front.
3.6 Changing the illumination
lamp
In case an illumination lamp is used in your
laundry dryer.To change the Bulb/LED used
for illumination of your tumble dryer, call your
Authorized Service.The lamp(s) used in this
appliance is not suitable for household room
illumination. The intended purpose of this
lamp is to assist the user to place laundry
in the tumble dryer in a comfortable way.
The lamps used in this appliance have to
withstand extreme physical conditions such
as vibrations and temperatures above 50 °C

15 / EN
Dryer / User Manual
4Preparaton
4.1 Laundry suitable for drying
in the dryer
Always obey the instructions given on the
garment tags. Dry only the laundry having a
label stating that they are suitable for drying
in a dryer and make sure that you select the
appropriate programme.
Do not dry with
dryer
At high
temperature
At medium
temperature
At low
temperature
4.2 Laundry not suitable for
drying in the dryer
CDelicate embroidered fabrics,
woollen, silk garments, delicate
and valuable fabrics, airtight
items and tulle curtains are not
suitable for machine drying.
4.3 Preparing laundry for
drying
• Laundry may be tangled with each other
after washing. Separate the laundry
items before placing them into the dryer.
• Dry garments having metal accessories
such as zippers, inside out.
• Fasten the zippers, hooks and buckles
and button sheets.
4.4 Things to be done for
energy saving
• Spin your laundry at the highest speed
possible when washing them. Thus, the
drying time is shortened and energy
consumption is reduced.
• Sort out the laundry depending on their
type and thickness. Dry the same type
of laundry together. For example thin
kitchen towels and tableclothes dries
earlier than thick bathroom towels.
• Follow the instructions in the user
manual for programme selection.
• Do not open the loading door of the
machine during drying unless necessary.
If you must open the loading door, do not
keep it open for a long time.
• Do not add wet laundry while the dryer is
in operation
• For models with a condenser unit: clean
the condenser once in a month or after
every 30 operations regularly. .
• For models with heat pump unit: clean
the filter drawer periodically when there
is a visible accumulation of fluff or when
the filter drawer cleaning indicator lights
up.
• For models with flue unit: comply with
the flue connection instructions and
clean the flue.
• During the drying process, air the
room well where your tumble dryer is
operating.
4.5 Correct load capacity
Follow the instructions in the “Programme
selection and consumption table”. Do not
load more than the capacity values stated in
the table.

16 / EN Dryer / User Manual
Preparation
Following weights are given as examples.
Laundry Approximate
weights (g)*
Cotton quilt covers
(double) 1500
Cotton quilt covers
(single) 1000
Bed sheets (double) 500
Bed sheets (single) 350
Large tablecloths 700
Small tablecloths 250
Tea towels 100
Bath towels 700
Hand towels 350
Blouses 150
Cotton shirts 300
Shirts 250
Cotton dresses 500
Dresses 350
Jeans 700
Handkerchiefs (10
pieces) 100
T-Shirts 125
*Dry laundry weight before washing.

17 / EN
Dryer / User Manual
5 Operatng the product
5.1 Control Panel
1. On/Off/Program selection button
2. Start/Pause button
3. End Time button
4. Audio warning level button
5.2 Symbols
Filter
cleaning
Tank
full
Mute Timer
Delay
On/O
Filter drawer /
Heat exchanger
cleaning
Child-proof
lock
Low
Temperature
5.3 Preparation of drying
machine
• Plug the drying machine.
• Open the loading door.
• Place the laundry to the drying machine
without jamming them.
• Push and close the loading door.
AEnsure that no laundry is jammed
to the loading door.
Select the desired program using the On/
Off/Program selection knob, the machine will
turn on.
CSelecting a program using the
On/Off/Program selection
button does not mean that the
program started. Press the Start
/ Stand-by button to start the
program.
1
2
3 4

18 / EN Dryer / User Manual
Operating the product
EN
Programmes Programme Description
Capacity (kg)
Spin speed
in washing
machine (rpm)
Drying Time
(minutes)
Cottons Iron Dry
You may dry your cotton laundry to be ironed in
this programme to have them slightly damp for
ease ofironing. (Shirt, T-shirt, tablecloth, etc.)
7 1000 110
Cottons Cupboard Dry
You may dry all your cotton laundry in this
programme.(T-shirt, pants, pyjamas, baby
clothes, underwear,linen, etc.) You can put your
laundry in the
wardrobe without ironing.
7 1000 129
Cottons Cupboard
Dry Plus
You may use this programme for extra dryness
in thick laundry such as pants, tracksuit.
You can put your laundry in the wardrobe
without ironing.
7 1000 150
Cottons Extra Dry
You may dry your thick cotton laundry in this
programme such as towels, bathrobe, etc. You
can put
your laundry in the wardrobe without ironing.
7 1000 160
Synthetics Iron Dry
You may dry your synthetic laundry to be ironed
in this programme to have them slightly damp
for ease of ironing. (Shirt, T-shirt, tablecloth,
etc.)
3,5 800 43
Synthetics Cupboard
Dry
You may dry all your synthetic laundry in
this programme. (Shirt, T-shirt, underwear,
tablecloth, etc.) You can put your laundry in the
wardrobe without ironing.
3,5 800 55
Sport
You may dry your sports clothes that
are appropriate for tumble drying in this
programme.
4 1000 100
Freshen up
It just provides airing for 10 minutes without any
hot air. You can air the cotton and linen laundry
that have been stored for a long time , and
eliminate the odour in them.
- - 10
Time Proggammes
You may select from time programmes between
10 and 30 and 60 minutes to achieve the
desired drying level at low temperature. In this
programme, tumble drier’s operation lasts for
the settime independently from the dryness of
laundry.
- - -
Hygienic Care Program used for baby clothing with can be
dried approval on the label. 3 1000 85
Jeans You may dry denim pants, skirts, shirts or jackets
in this programme. 4 1200 95
5.4 Programme selection and consumption tablee

19 / EN
Dryer / User Manual
Operating the product
* : Energy Label standard program (EN 61121:2012)
All the values on the chart are identified according to EN 61121:2012 standard. Consumption
values may vary from the values in the chart depending on laundry type, wringing speed,
ambient conditions and voltage levels.
Delicates It dries the shirts in a more sensitive manner,
and causes less creasing and easier ironing. 2 600 40
Xpress Super Short Dries shirts more delicately and thus causes less
wrinkles for easy ironing. 0,5 1200 14
Energy consumption values
Programmes Capacity (kg) Energy consumption value
kWh per year
Energy rating
star
Cotton Cupboard Dry
Plus 7 310 2
* : Energy Label standard program (AS/NZS 2442) “All the filters must be cleaned prior to test
series.”
All values given in the table have been fixed according to standard laboratory conditions.
These values may deviate from the table according to the laundry type, laundry spin speed,
environmental conditions and voltage fluctuations.
During the performance test, the direct drain hose must be connected.Please see section 3.3

20 / EN Dryer / User Manual
Operating the product
5 . 5 Auxiliary functions
Audible warning
Drying machine makes an audible warning
when the program is completed. If you don’t
want it to make an audible warning, press the
“Buzzer” button. When you press the Buzzer
button, a light will illuminate and no audible
warning will be made when the program
ends.
CYou can select this function
before or after the program
starts.
End time
If you prefer to dry your laundry at a later
time, you can delay start time of the program
up to 3 hours, 6 hours or 9 hours using the
Delay function.
Open the loading door and place the laundry.
Select the drying program.
Press the End Time selection button and
set the delay time you wish. When the End
Time button is pressed once, 3 hours delay is
selected and the delay indicator will light up.
If you press the same button again, 6 hours
delay will be selected and when you press for
the third time, 9 hours delay will be selected.
If you press the End Time button once again,
the delay will be cancelled.
After the End Time selection is made, start
delayed running for the program selected
pressing the “Start/Stand-by” button.
CYou can add or remove laundry
within end time. At the end of
the Time Delay countdown, the
Time Delay warning indicator
turns off and drying begins
Changing the end time
If you want to change the duration during
the countdown:
Cancel the program by turning the On/Off/
Program selection knob. Select the program
you want and repeat the End Time selection
process.
Cancelling the end time function
If you want to cancel the end time
countdown and start the program
immediately:
Cancel the program by turning the On/Off/
Program selection knob. Select the program
you want and press the Start/Stand-by
button.
5.6 Warning indicators
CWarning indicators may vary
depending on the model of your
dryer.
Filter cleaning
When the program is completed, the warning
indicator for filter cleaning turns on.
Water tank
When the program is completed, the warning
indicator to empty the water tank turns on.
If the water tank fills up while the program
continues, the warning indicator starts
flashing and the machine goes into stand-by.
In this case, empty the water tank and start
the program by pressing the Start / Stand-
by button. Warning indicator turns off and
program resumes.
Filter drawer /Heat exchanger
cleaning
When the programme is finished, the
cleaning symbol of the heat exchanger or
filter drawer may light up.
5.7 Starting the program
Press the Start/Stand-by button to start the
program.
Drying indicator will light up, indicating that
the program has started.
5.8 Child Lock
The drying machine has a child lock which
prevents the program flow from being
interrupted when the buttons are pressed
during a program. When the child lock is
activated, all buttons on the panel except
the On/Off/Program selection knob are
deactivated.
