Aluratek Abt05f User manual

Package Contents Product Highlights Product Application

Operation Operation

WARNING!!! This equipment has been tested and found to comply with the limits of a

Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to

provide reasonable protection against harmful interference in a residential installation.

This equipment generates, uses and can radiate radio frequency energy and, if not

installed and used in accordance with the instruction, may cause harmful interference to

radio communications. However, there is no guarantee that interference will not occur in

a particular installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment off and on, the

user is encouraged to try to correct the interference by whatever measures may be

required to correct the interference.

Radio and TV Interference Statement

aluratek.com

model ABT05F

Quick Start Guide

Universal Bluetooth Audio Transmitter

Technical Support and Warranty

If you need further assistance, please contact the Aluratek support department for

troubleshooting prior to returning this device.

E-mail: [email protected]

Web: www.aluratek.com/helpdesk

Local (Irvine, CA): 714-586-8730

Toll free: 1-866-580-1978

Control Functions

Function Operation

Power ON When OFF, slide power button to ON side,blue LED light flashes once

Pairing

Clear Pairing

List:

Short press pairing button to enter pairing mode, blue and red led light

flashes alternately (short press pairing button can enter pairing mode to

pair 2nd device when 1st device is connected and the 1st device will be

disconnected).

When OFF, long press pairing button around 8 seconds until blue and

red LED flash once at the same time

Connect with the

last two devices:

ABT05F will automatically reconnect to the last two connected devices

when it is powered on. Red light flashes 1-2 times if connected successfully.

Power OFF When ON, slide power button to OFF side,red LED light flashes once

Streaming while

charging

ABT05F is able to stream when it is charging.

Pairing

1. Make sure ABT05F is turned off

2. Activate your device’s Bluetooth function and set your device to search for Bluetooth

device.

3. Slide power button to ON side,blue LED light flashes once (When ABT05F is powered

on, it will enter pairing mode directly if there is no pairing record.)

4.Short press pairing button to enter pairing mode, blue and red Led light flashed

alternately.

5. ABT05F and your Bluetooth device will pair automatically. (Please make sure they are

next to each other.)

6. After connecting successfully, the blue LED will flash.

Note: After the initial pairing of your Bluetooth device with ABT05F, it is recommend that you power on your Bluetooth

device first before you power on ABT05F for subsequent uses for faster reconnection.

Your order has been carefully packaged and inspected. The following accessories should

be included in your package. Please inspect the contents of the package to ensure that

you have received all items and that nothing has been damaged. If you discover a problem,

please contact us immediately for assistance.

Operation

LED Indicators

LED Indicator Status

When connected via aptX-LL

When connected via aptX

When connected via SBC

Blue LED flashes 3 times every 5 seconds.

Blue LED flashes 2 times every 5 seconds.

Blue LED flashes 1 times every 5 seconds

Standby statusFlashing Blue Twice (Every 10 Seconds)

Flashing Red Three times (Every 60 Seconds)

Charging The Battery

The battery is not fully charged and it is highly recommended that you charge ABT05F

before you begin using it.

Note: Using ABT05F “out of the box” will not harm the device. You will experience

reduced battery life as the unit will not be fully charged.

Connect the larger USB end of the cable provided to your PC or USB power adapter or

powerbank (not included). Plug the smaller Micro USB to the charging port of ABT05F.

Please charge the battery for a minimum of 3 hours. The red LED will be on while

charging. When charging is complete, the red LED will turn OFF.

Operation

Transmit

audio up

to 50 feet

(15 m)

Bluetooth

Headphones

Bluetooth

Earbuds

Bluetooth

Speakers

Pair With Two Devices At The Same Time

This unit could connect with two stereo Bluetooth speaker or Bluetooth headset to play

music simultaneously.

1. Follow the previous instructions in the “Pairing” section to pair ABT05F with your first

device.

2. After the first device is connected, short press the pairing button to enter pairing mode

again.

3. Power on the second device and activate its pairing mode.

4. The second device will pair automatically

Note: If there is no sound after the second pairing, please power OFF and ON ABT05F to reconnect

Aluratek warrants this product against defect in material or workmanship for 1 YEAR

from the date of purchase.

For more information, please visit: https://aluratek.com/warranty-return-policy

You can register your product online at: https://aluratek.com/product-registration

Troubleshooting

If both red and blue LED lights stays on or if the device is not responding, follow below

steps to reset the transmitter.

1. Press and hold the pairing button

2. While holding the pairing button, connect the USB charging cable which is connected

to either a power adapter or computer

3. Release the pairing button when the red and blue LED lights are flashing alternately

4. The transmitter is now reset and ready to pair again

Supports dual streaming.

Two devices can be used

simultaneously.

with Bluetooth 5

USB Charging Cable 3.5mm Audio Cable RCA-Y Cable

Power Button

Micro USB Charging Port

3.5mm Audio Port

LED Indicator

Pairing Button

Computer

Connect to any audio

device with an AUX OUT

(3.5 mm) port

RCA-Y

cable

Home Stereo

Receiver

3.5 mm

cable

Connect to any

device with RCA OUT

(RCA cable included)

MP3 Player

Low battery status
