Alutech Levigato LG Series Installation and operating instructions

02.2018
www.alutech-group.com
Assembly and operation manual
Drives for garage doors Levigato (LG series)
English
Montage- und Betriebsanleitung
Antriebe für Garagentore Levigato (Serie LG)
Deutsch
Manuel d’Installation et d’Utilisation
Commandes de portes de garages Levigato (série LG)
Français

LEVIGATO DRIVES LG SERIES |LEVIGATO ANTRIEBE SERIE LG |COMMANDES LEVIGATO SERIE LG 1
Fig.|Abb.1
5
55
40
19
105
30
max110*
19
33
64
110
73
130
70
135
max 2000*
235
330
6890
90 330
90
LGR-3300B/LGR-3300C — 2590 mm LGR-3600B/LGR-3600C — 2890 mm LGR-4200B/LGR-4200C — 3490 mm
LGR-3300B/LGR-3300C — 3300 mm LGR-3600B/LGR-3600C — 3600 mm LGR-4200B/LGR-4200C — 4200 mm
120
68
LG R
-
3300B
/
LG R
-
3300C
—
3630mm
LGR-3600B/LGR-3600C — 3930 mm LGR-4200B/LGR-4200C — 4530 mm
5
55
40
19
105
30
max110*
19
33
64
110
73
130
70
135
max 1400*
235
330
6890
90 330
90
120
68
°
YSizes in gures are given in millimeters.
Abmessungen auf den Zeichnungen sind in mm angegeben. Les dimensions référencées sur les dessins sont en millimètres.

LEVIGATO DRIVES LG SERIES |LEVIGATO ANTRIEBE SERIE LG |COMMANDES LEVIGATO SERIE LG2
Fig.|Abb.2
5
4
3
2
1
D
E
C
A
B
A— Electric drive
B— Remote control
C— Photocells
D— Key-switch
E— Lamp
(with built-in antenna)
A— Elektroantrieb
B— Funkhandsender
C— Lichtschranke
D— Schlüsseltaster
E— Lampe
(mit der eingebauten Antenne)
A— Commande électrique
B— Télécommande
C— Photocellules
D— Interrupteur à clé
E— Lampe
(intégrée à l’Antenne)
CIRCUIT LENGTH 1…20 LENGTH 20…50
1RX photocells receiver 4×0.5mm24×1mm2
2TX photocells transmitter 2×0.5mm22×1mm2
3Key-switch 2×0.5mm22×1mm2
4Lamp 2×0.5mm22×1mm2
5Antenna RG58 max 20m
KETTE LÄNGE 1 M…20M LÄNGE 20 M…50M
1Empfänger von RX Fotoelementen 4×0,5mm24×1mm2
2Empfänger von TX Fotoelementen 2×0,5mm22×1mm2
3Schlüsseltaster 2×0,5mm22×1mm2
4Lampe bzw. Signalleuchte 2×0,5mm22×1mm2
5Antenne RG58 max. 20m
CIRCUIT LONGUEUR 1…20 LONGUEUR 20…50
1Récepteur de photocellules RX 4×0,5mm24×1mm2
2Emetteur de photocellules TX 2×0,5mm22×1mm2
3Interrupteur à clé 2×0,5mm22×1mm2
4Lampe 2×0,5mm22×1mm2
5Antenne RG58 max 20m

LEVIGATO DRIVES LG SERIES |LEVIGATO ANTRIEBE SERIE LG |COMMANDES LEVIGATO SERIE LG 3
Fig.|Abb.3Fig.|Abb.4
Fig.|Abb.5Fig.|Abb.6
Fig.|Abb.7Fig.|Abb.8
Fig.|Abb.9Fig.|Abb.10

LEVIGATO DRIVES LG SERIES |LEVIGATO ANTRIEBE SERIE LG |COMMANDES LEVIGATO SERIE LG4
Fig.|Abb.11
L
Fig.|Abb.12 Fig.|Abb.13
Fig.|Abb.14 Fig.|Abb.15

LEVIGATO DRIVES LG SERIES |LEVIGATO ANTRIEBE SERIE LG |COMMANDES LEVIGATO SERIE LG 5
Fig.|Abb.16 Fig.|Abb.17
Fig.|Abb.18 Fig.|Abb.19
Fig.|Abb.20 Fig.|Abb.21
Fig.|Abb.22

LEVIGATO DRIVES LG SERIES |LEVIGATO ANTRIEBE SERIE LG |COMMANDES LEVIGATO SERIE LG6
Fig.|Abb.23
-
Antenna
+12VDC/max 120mA +24VDC/max 120mA
STEP BY STEP (NO)
STOP (NC)
PHOTOCELLS (NC)
PHOTOTEST
LAMP ~230 V/max100 W
6.3
-SBS-
SL/LL
(~230V)
-
- S -
GND-
+24V- +24V-
GND-
+12V-
SE-
-PH1-
PH.T-
-
Antenna
+12 V DC/max 120 mA +24 V DC/max 120 mA
–
STOP (NC)
PHOTOCELLS (NC)
6.3
-SBS-
SL/LL
(~230V)
-
- S -
GND-
+24V- +24V-
GND-
+12V-
SE-
-PH1-
PH.T-
A
Fig.|Abb.24
12-240V
AC-DC
-
-SBS-
SL/LL
(~230V)
-
- S -
GND-
+24V- +24V-
GND-
+12V-
SE-
-PH1-
PH.T-
-
-SBS-
SL/LL
(~230V)
-
- S -
GND-
+24V- +24V-
GND-
+12V-
SE-
-PH1-
PH.T-

LEVIGATO DRIVES LG SERIES |LEVIGATO ANTRIEBE SERIE LG |COMMANDES LEVIGATO SERIE LG 7
Fig.|Abb.25
12-24V
AC-DC
-
-SBS-
-
- S -
GND-
+24V- +24V-
GND-
+12V-
SE-
-PH1-
PH.T-
SL/LL
(~230V)
12-24V COM
AC-DC
-
-SBS-
-
- S -
GND-
+24V- +24V-
GND-
+12V-
SE-
-PH1-
PH.T-
SL/LL
(~230V)
NO NC
Fig.|Abb.26
-
-SBS-
-
- S -
GND-
+24V- +24V-
GND-
+12V-
SE-
-PH1-
PH.T-
SL/LL
(~230V)
-
-SBS-
-
- S -
GND-
+24V- +24V-
GND-
+12V-
SE-
-PH1-
PH.T-
SL/LL
(~230V)
12-24V
AC-DC
12-24V COM
AC-DC
NO NC

LEVIGATO DRIVES LG SERIES |LEVIGATO ANTRIEBE SERIE LG |COMMANDES LEVIGATO SERIE LG8
Fig.|Abb.27
-
BN GN WH
-SBS-
-
- S -
GND-
+24V- +24V-
GND-
+12V-
SE-
-PH1-
PH.T-
SL/LL
(~230V)
-
-SBS-
-
- S -
GND-
+24V- +24V-
GND-
+12V-
SE-
-PH1-
PH.T-
SL/LL
(~230V)
GN — green;
BN — brown;
WH — white
GN — grün;
BN — braun;
WH — weiß
GN — vert;
BN — marron;
WH — blanc
Fig.|Abb.28
-
8K2
-SBS-
-
- S -
GND-
+24V- +24V-
GND-
+12V-
SE-
-PH1-
PH.T-
SL/LL
(~230V)
-
-SBS-
-
- S -
GND-
+24V- +24V-
GND-
+12V-
SE-
-PH1-
PH.T-
SL/LL
(~230V)

LEVIGATO DRIVES LG SERIES |LEVIGATO ANTRIEBE SERIE LG |COMMANDES LEVIGATO SERIE LG 9
Fig.|Abb.29
Fig.|Abb.30
-
-SBS-
-
- S -
GND-
+24V- +24V-
GND-
+12V-
SE-
-PH1-
PH.T-
SL/LL
(~230V)
-
-SBS-
-
- S -
GND-
+24V- +24V-
GND-
+12V-
SE-
-PH1-
PH.T-
SL/LL
(~230V)

LEVIGATO DRIVES LG SERIES |LEVIGATO ANTRIEBE SERIE LG |COMMANDES LEVIGATO SERIE LG10
ENGLISH
CONTENTS
1. General warnings and safety rules......................................................................11
2. Product description..............................................................................................11
2.1. Delivery scope ........................................................................................................................................................12
2.2. Technical specications.......................................................................................................................................13
3. Preparation for assembly..................................................................................... 13
4. Mounting...............................................................................................................15
4.1. Drive rail and drive mounting...........................................................................................................................15
4.2. Manual release........................................................................................................................................................16
5. Electrical interfaces ..............................................................................................17
6. Adjustment............................................................................................................19
7. Testing and commissioning ................................................................................. 27
8. Operation ..............................................................................................................28
9. Troubleshooting ...................................................................................................29
10. Storage, transportation and disposal ................................................................. 30
11. Warranty obligations............................................................................................31
12. Commissioning certicate ...................................................................................31
13. Information on repairs during warranty period.................................................32
14. Statement of compliance ..................................................................................... 32

LEVIGATO DRIVES LG SERIES |LEVIGATO ANTRIEBE SERIE LG |COMMANDES LEVIGATO SERIE LG 11
GENERAL WARNINGS AND SAFETY RULES
1. GENERAL WARNINGS AND SAFETY RULES
Y
This manual contains important information concerning safety. Prior to commencing installation
study closely all the information provided below. Save this manual for future reference!
Mounting, connections, nal tests of the equipment, commissioning and maintenance should
be performed only by qualied and trained specialists.
Follow the precautions provided by any active regulatory documents and by those in this manual.
Please, ensure compliance with the requirements of standards concerning the construction,
mounting and operation of automated doors (EN12604, EN12453, EN13241-1), as well as other
possible local rules and regulations.
Mounting, programming, conguration and operation of the product in violation of the require-
ments are prohibited, as this can result in damages, injuries and cause losses.
Making any changes in any elements of the product structure and unintended use of the product
are prohibited. The manufacturer is not liable for any damages, caused by unauthorised changes
in the product or its unintended use.
The product is constructed for use in dry buildings and is not intended for use in the presence
of acid, salt or explosion hazard media.
When performing any works (mounting, repair, maintenance, cleaning etc.) and connections
inside the drive, disconnect the mains circuit. If the master switch or similar device is out of
sight, then attach a safety sign stating:‘Do not turn on. People are working’and take measures
preventing the possibility of accidental restoring the power supply.
In the case of power cable (power cord) damage, it should be replaced by a manufacturer’s
specialist or maintenance department specialist.
Please, follow the safety measures when using the power cable:
• fully insert the plug into the socket;
• when taking the plug out of the socket do not pull by the cord;
• do not use a socket with bad contacts;
• do not touch a plug with wet hands;
• do not damage the power cable, do not twist the cable, do not bend and do not stretch it;
• do not place heavy objects on the power cable and do not place it near hot objects;
• ensure easy access to the socket;
• use only the power cable supplied by the manufacturer;
• it is forbidden to use a defective or damaged power cable.
The company reserves the right to introduce changes in this manual and the product construc-
tion without prior notication, but preserving the same functional capabilities and designation.
The content of this manual cannot be used as the basis for legal claims.
2. PRODUCT DESCRIPTION
LG series drive with a drive rail is designated for the automation of balanced sectional garage
doors. The drive with a drive rail establishes it as a set for the automation of a garage door.
The drive consists of a gear-motor with electric motor, 24VDC transformer, electric control unit
with built-in radio control module and LED lighting. The drive is powered from by 230V/50Hz
mains power. In the case of temporary loss of mains power the drive rail can be released, which
will allow the door leaf to be operated manually.

LEVIGATO DRIVES LG SERIES |LEVIGATO ANTRIEBE SERIE LG |COMMANDES LEVIGATO SERIE LG12
PRODUCT DESCRIPTION
2.1 DELIVERY SCOPE
DRIVE SET
1Drive 1pc. 10 M6 Nut 6pcs.
2Door bracket 1pc. 11 4×18 Screw 2pcs.
3
Bracket to
mount the rail
on the wall
1pc. 12 Screw 3.9×9.5
(drill-point) 2pcs.
4
Bracket to mount
the rail on the
ceiling
2pcs. 13 Dowel 8×19.5 1pc.
5
Bracket to
mount the drive
on the rail
1pc. 14 Split pin 1pc.
6Support 1pc. 15
Assembly
andoperation
manual
—1pc.
7Axis Ø8×19 1pc.
16
Remote
control
AT-4N-868
2pcs.8M6×12 bolt 6pcs.
96.3×20 screw 12pcs.
DRIVE RAIL KIT
17 Drive rail (assembled) 1pc.
18 Suspension strip 2pcs.
19 Rod 1pc.
20 Release unit part (ball-handle) 2pcs.
YUpon receipt of the product, please check the completeness of the kit and make sure all the
kit components do not have any visible damage. In case of any missing components, please
contact the product supplier.
Fixings (dowels, anchors etc.), required for xing the components to the wall and ceiling, are not
included in the kit, as their type depends on the material and thickness of the wall, on which
they are installed.
Table1

LEVIGATO DRIVES LG SERIES |LEVIGATO ANTRIEBE SERIE LG |COMMANDES LEVIGATO SERIE LG 13
PREPARATION FOR ASSEMBLY
2.2 TECHNICAL SPECIFICATIONS
PARAMETER LG600F LG800 LG1000F LG1200
Maximum pulling force, N
(force for the door to start moving) 600 800 1000 1200
Rated pulling force, N
(force to support the door movement) 300 350 400 450
Maximum door opening speed, m/s 0.2 0.15 0.2 0.15
Speed at the force 150N (corresponds to the
maximum force of the balanced door leaf), m/s 0.185 0.128 0.185 0.128
Power 230V (±10%)/50Hz
Power consumption at rated force, W 280 220 400 330
Maximum door area*, m28.4 11.2 16.0 18.6
Maximum use intensity (at the door height
upto2.43m), cycles/hour 18
Maximum time of continuous operation at the force
150N (corresponds to the maximum force of the
balanced door leaf)
20 minutes
Time of illumination after the door stops moving This parameter is regulated in the range ~0…500s;
default value is 30s
Remote control 433.92MHz/dynamic code/
maximum 64remote controls
Protection class I
Protection degree IP20
Working temperature range,°С −20…+50
Weight (NET), kg 4.9 4.6 5.1 5.4
YAll specied technical specications are valid at ambient temperature +20ºС (±5ºС).
PART NO. RAIL TYPE MAXIMUM DOOR HEIGHT, *
LGR-3300B belt 2430
LGR-3600B belt 2730
LGR-4200B belt 3330
LGR-3300C chain 2430
LGR-3600C chain 2730
LGR-4200C chain 3330
* the data shown is for standard mounting of ALUTECH sectional garage doors.
The sizes (overall, connection, mounting dimensions), which are ensured by the scope of supply,
are presented in g.1.
3. PREPARATION FOR ASSEMBLY
YPlease check the condition of all components and materials for their suitability and
compliance with the applicable regulatory documents in force. The applied instruments and
materials should be fully intact and comply with the safety norms, standards and instructions
in force.
Table2— drives
Table3— rails

LEVIGATO DRIVES LG SERIES |LEVIGATO ANTRIEBE SERIE LG |COMMANDES LEVIGATO SERIE LG14
PREPARATION FOR ASSEMBLY
Please, make sure that the door construction is suitable for the automation.
Please, make sure that there is enough space for the drive system and its operation.
Please, make sure that the sizes of the door and the specications are within the acceptable
limits (section 2.2 ‘Technical specications’).
Please, make sure that the door leaf is balanced, i.e. it remains immobile in any position if released.
Please, make sure that the force, required to move the door leaf manually, does not exceed 150N
(~15kg). Easy movement of the door leaf should be ensured during closing and opening. Theex-
cess of the force is allowed in the beginning of the movement. The force, required to maintain
the door leaf movement during operation, should not exceed the nominal pull force. The force,
required to start the movement of the door leaf, should not exceed half of the maximum pull
force of the drive. The force reserve is required, as unfavourable weather conditions (such as
wind, icing etc.) and wear of the door components may result in the increase of the force due
to the increase of friction in the system.
Evaluate the possible risk degree (impact, compression, jamming, dragging and other dangers).
Please, identify, which additional devices (accessories) are required to prevent possible risks and
compliance with the safety provisions in force.
Please, make sure that the surface on to which the drive system is installed is solid and can
be used as a reliable and rigid support. If this is not the case, take measures to strengthen the
installation places accordingly.
Please, make sure that the installation places for the drive system components are protected
from impacts. The components must be installed at a safe distance from moving parts.
Please, make sure that foreign objects, water and other liquids are not present inside the drive
and on other open parts, otherwise disconnect the drive from the mains supply and consult the
service centre. The operation of the equipment in such conditions is not safe.
Please, make sure that the drive and its components are at a sucient distance from heat sources
and open re. The violation of this requirement can result in the damage of the product, cause
it to malfunctioning, cause re or create other dangerous situations.
Please, make sure that an easy and safe way of the drive rail manual release is ensured.
The control devices should be located within sight of the door, at a height not less than 1.5 m.
If there is no alternative means of access to the garage or wicket door within the door leaf,
installation of an emergency disconnection device must be carried out (external lock to release
the drive rail).
Please, make sure that the socket is installed in such manner that after drive installation and con-
nection, the power cable is not within the door movement area or within reach of other moving
parts.The type of the power cable is‘H0’5VV-F 3G0.75mm, power cable plug—type E/FCEE 7/7.
Please, make sure that the mains supply is equipped with protective earthing.
Please, make sure, that the section of the mains supply, to which the drive is connected, is
equipped with the short circuit protection device (Residual Current Device (RCD) automatic
switch or another equivalent device). The distance between the terminals in the protection
tripping unit should be at least 3mm.
The electric cable of the control and safety devices should be laid separately from the cables with
mains voltage.The cables should be protected from contact with any rough and sharp surfaces
by using corrugated tubes, pipes and cable ducts to lay the cables.

LEVIGATO DRIVES LG SERIES |LEVIGATO ANTRIEBE SERIE LG |COMMANDES LEVIGATO SERIE LG 15
MOUNTING
Use multicore cable with double insulation for electric connection of the drive system compo-
nents. The parameters of the electric cables used (section, number of wires, length etc.) should
comply with the connection diagram, device power, laying distance, way of laying, ambient
conditions.
Do not perform any electric connections while laying the electric cables. Make sure, that the
cables are isolated and therefore not live.
Prior to mounting:
• determine the place, where each component of the drive system will be installed.
Fig.2presents a typical diagram of the garage door automation. Together with the user,
determine the places for the installation of the control devices.
• Determine the scheme, according to which all the electric devices of the drive system will
be connected.
• Lay the electric cables to the places, where the drive system components are to be
installed, complying with the regulations in force.
• Remove unnecessary parts (ropes, angles etc.) and disconnect all the unnecessary
equipment.
4. MOUNTING
4.1 DRIVE RAIL AND DRIVE MOUNTING
Recommended mounting procedure:
• determine and mark the mounting line in the middle of the door (fig.3). If mounting
cannotbeperformed in the middle of the door, it acceptable to mount at the distance
notexceeding 100mm to left or to the right from the middle of the door.
• Install the door bracket using eight 6.3×20 screws (fig.4). Drill Ø5mm holes in the door leaf
metal.
YLimit the drilling depth during drilling. Do not allow through drilling of the door leaf.
• Install the rail fastening bracket on the wall on the drive rail using two ‘M6’×12 bolts
andtwoM6 nuts (fig.5A). The product construction allows turning of the bracket by
90° inrelation to the rail during installation (fig.5B), e.g., to mount the rail on the ceiling
without suspension strips.
• Mark the rail fastening bracket installation area on the wall (fig.6 ). The clearance between
the rail and the maximum (top) spot of the door movement should be 20–50mm.
• Fasten the rail fastening bracket on the wall (fig.7).
YFixings (dowels, anchors), required to install the rail, should be selected to comply with the
type of construction surfaces present (material and thickness of the wall or ceiling). They
are not included in the kit. The ttings should be able to bear the weight of the rail with the
drive tted and resist the force required to open and close the door. Beware of wear and
deformation, which will occur in time.
• Install the brackets, fastening the rail to the ceiling, on the drive rail (fig.8).
• Install one bracket at the distance 180…220mm from the rail edge (fig.9).
• Install the second bracket in ensuring position which ensures the best stability of the rail.
Forexample, at 1/3 from the door opening (fig.10).

LEVIGATO DRIVES LG SERIES |LEVIGATO ANTRIEBE SERIE LG |COMMANDES LEVIGATO SERIE LG16
MOUNTING
• Position (align) the rail in relation to the door construction (fig.11). Adjust the position of
the brackets of the rail and determine the necessary distance Lfrom the rail to the ceiling
(suspension distance).
• Install suspension strips on the brackets, fastening the rail to the ceiling, and align them
(fig.12). Fasten the suspension strip on the bracket using two ‘M6’×12 bolts and two ‘M6’
nuts.
• Bend the suspension strip on two sides, preserving the previously measured size Land
bend angle (fig.13). Fasten the suspension strips on the ceiling using fixings (dowels,
anchors).
YThe suspension strips ensure the maximum Ldistance is 110mm. In case of a larger Ldistance
use additional suspension strips (not supplied) and additional xings.
• Install the rod on the rail carriage using the Ø8×19 axis and two 4×18 screws (fig.14).
Fullytighten the screws.
• Install the rod in the door bracket using the 8×19.5 pin and a split pin (fig.15).
• Move the door leaf into the open position and determine the place to install the support
(fig.16). Install the support at a distance of 20mm from the rail carriage. Fasten the support
on the rail using two 3.9×9.5 screws. The support serves as the point of full opening of the
door when programming the final positions and a control point during operation in case
ofabnormal situations.
• Install the drive on the rail and fasten using the bracket and four 6.3×20 screws (fig.17).
Theproduct construction allows the drive to turn by 90° in relation to the rail during
installation (fig.1).
YManually install the drive on the rail with care, slightly press behind the star-wheel opening
on the rail and the output shaft of the drive will become aligned. Do not use force, as this can
damage the external appearance or break the drive.
In cases when the drive rail is fastened to the ceiling without suspension strips, install the
drive on the rail beforehand. Ensure its integrity during further mounting operations.
• Ensure the necessary length of the release cable. The manual release cable should be
located at a height not less than 1.8m. Make a tie on the end of the cable and clamp it with
the two halves of the ball-handle (fig.18).
• If necessary, pull and release the drive belt/chain from the rail, tightening or loosening
the nut at the flat end of the rail (fig.19). Remember that if excessive tension is applied,
increased wear of the rail components is possible, and in the case of insufficient tension,
slackness and unpleasant noise during operation are possible.
4.2 MANUAL RELEASE
The rail carriage can be released, allowing the door to be moved manually. To release the rail
carriage and move the door leaf manually, pull down the manual release cable (fig.20). To return
the carriage into the locked position, press the button on the carriage (fig.21), and then move
the door leaf until the carriage connects with the rail grip.
YUse the manual release only during installation, in case of drive failure or loss of electric power.
In the case of release activation, uncontrolled movement of the door is possible, if the door
springs are weak or broken; if the door is not balanced. Be careful and attentive!
Move the released door only at a moderate speed.

LEVIGATO DRIVES LG SERIES |LEVIGATO ANTRIEBE SERIE LG |COMMANDES LEVIGATO SERIE LG 17
ELECTRICAL INTERFACES
5. ELECTRICAL INTERFACES
Prior to commencing the wiring operation, make sure that the wire is not‘live’.
When using and installing additional electric devices (accessories) follow the manuals supplied.
Incorrect connection can result in the failure of the drive.
Use only additional devices (accessories), oered by ALUTECH (including AN-Motors). ALUTECH
does not bear responsibility for unstable operation of the drive system, if additional devices,
produced by other manufacturers, are used.
If no devices are connected to terminals ‘PH1’ and ‘S’, crossovers should be installed. If a safety
device is connected to the terminals mentioned, remove the crossover.
Open the lid on the drive to access the additional device connectors, conguration and indication
elements. Press the latch and turn the lid (fig.22).
Table 4 describes the contacts of the drive connectors used to connect additional devices. The
connection diagram and symbols are presented in fig.23.
Figures 24–28 show examples of connecting additional devices (accessories), manufactured
by ALUTECH:
• Figure 24—connection of a signal lamp with built-in antenna.
• Figure 25—photocells connection.
• Figure 26—connection of photocells with PHOTOTEST function.
• Figure 27—connection of optical safety margin.
• Figure 28—connection of resistive safety margin.

LEVIGATO DRIVES LG SERIES |LEVIGATO ANTRIEBE SERIE LG |COMMANDES LEVIGATO SERIE LG18
ELECTRICAL INTERFACES
CONTACT DESCRIPTION
SL/LL
Alarm lamp or illumination lamp connection output (see fig.24). By default, the output is set to
work in the SL lamp mode (signal lamp). In settings (section‘6. Adjustment’) you can select the
output operation mode
SBS
Input for step-by-step control devices with NO contact.
Sequence of commands OPENSTOPCLOSESTOPOPEN…
Several control units are connected in parallel
S
Safety devices input STOP with NC contact.
The activation results in immediate stop of movement or preventing any movement beginning.
Several safety devices are connected consecutively
+12V Accessories output. Nominal power voltage 12VDC/max.120mA
+24V Accessories output. Nominal power voltage 24VDC/max.120mA
GND General output
SE
Optical sensors connection input or input of resistive margin of safety (8.2kOhm). In settings
(section‘6. Adjustment’) the following can be selected, depending on the connected safety
device: resistive sensor (fig.28) or optoelectronic sensor (fig.27).
The contact of the door with an obstacle during closing (activation of a sensor) causes the door
to stop moving and then fully open
PH1
Photocells connection input with NC contact. By default, the input is set to the activation of
photocells during closing (they are not active during opening). The activation of photocells
during closing results in an immediate stop, followed by full opening, or preventing further
closing beginning.
When setting the photocells to operate only during opening (section ‘6. Adjustment’) the
activation of the photocells results in immediate tripping.
Several safety devices are connected consecutively
PH.T
The output for automatic operation test (PHOTOTEST) of photocells, connected to output PH1.
The operation of the photocells is checked before movement by short-term disconnection and
then reconnection of the power to the photocells transmitter. Photocells connection diagram—
fig.26. In settings (section‘6. Adjustment’) the activation of the corresponding menu option is
performed
Connection input of the antenna screening conductor
Connection input of the antenna signal conductor
The connector (fig.29) used to connect the 24VDC/1.2Ah battery. The battery gives the
opportunity to open the door in the emergency mode (in case of supply voltage disconnection).
The full charge time of the battery is ~48hours
The operation of the devices is shown by LEDs (fig.30).
LED INDICATION DESIGNATION ILLUMINATES DOES NOT
ILLUMINATE
command from remote control board is given not given
PH1 safety device—photocells (input‘PH1’) was activated was
notactivated
Ssafety device—STOP (input‘S’) was activated was
notactivated
SBS command to open, stop, close (input‘SBS’) is given not given
YThe state of LEDs, when a command is not given, is shown in bold.
Table4
Table5
