Alva Cibo User manual
IMPORTANT SAFETY INFORMATION
As with all gas appliances, misuse of this appliance or failure to fully
follow these instructions may cause re, injury or death. Please read
all the instructions before using your Gas Pizza Oven.
• Please read these instructions carefully before installing and
using your Gas Pizza Oven.
• The operator must understand all safety requirements as de-
tailed in this manual before using the unit.
• The operator is responsible for the safety of all third parties
while the appliance is in use.
• The manufacturer’s warranty will be voided by incorrect use of
this product.
• If you have any queries regarding these instructions, contact
your local dealer for clarication before you use your Gas Pizza
Oven.
• The unit must be correctly installed before use.
• Failure to follow the manuals instructions could result in damage
or serious injury.
• DO NOT use indoors. The Gas Pizza Oven is designed for
OUTDOOR USE ONLY.
• Ensure that the Gas Pizza Oven is positioned on an even and
secure surface before operating.
• Leak test all gas lines and connections before use.
• DO NOT store ammable materials near the Gas Pizza Oven.
• DO NOT place or use aerosol sprays near the Gas Pizza Oven.
• Use only with LPG gas.
• DO NOT leave the Gas Pizza Oven unattended when it is alight.
• Onlookers should keep a safe distance away from the
Gas Pizza Oven when it is in use.
• Keep children and animals well away while the Gas Pizza Oven
is in use.
• Parts of the Gas Pizza Oven will get extremely hot and could
cause serious burns - test every surface before touching it.
• Be very careful when operating the Gas Pizza Oven. The opera-
tor should pay constant attention to the food being cooked and
should remain at the appliance at all times when it is lit.
• Ensure that the gas supply is turned OFF after use and while
the Gas Pizza Oven is unattended.
• Neither the manufacturer nor their Agents can accept any
liability for the unsuitability of, or any damage to, any food
cooked on this appliance.
• Modifying or tampering with any part of this Gas Pizza Oven is
illegal and unsafe and will void your warranty.
• DO NOT move the appliance when in use.
• The Gas Pizza Oven must not have any overhead obstruction.
e.g. trees, shrubs and lean to roofs.
• The Gas Pizza Oven must be used with a clearance of 1m on
all sides.
• Close the valve of the gas cylinder after use.
Please read the
instructions carefully
before use.
Retain this manual for
future reference.
• The use of this Gas Pizza Oven in enclosed areas can be
dangerous and is PROHIBITED.
• Ensure that the primary air intakes, located on the burner tubes
are not obstructed or the airow restricted.
• DO NOT place items or other appliances close to or adjacent to
the inlets.
• If you smell gas immediately turn the gas supply off at the
cylinder.
• Turn off the gas supply at the gas cylinder after use.
• DO NOT use the appliance if it has a leak, worn, deteriorated or
damaged seals.
• Handle the appliance with care, even after brief use. Always
pick up using the handle and not the cylinder.
• DO NOT use adaptors or modify the appliance to t other con-
nectors or cylinders, not only is this dangerous but it will void the
warranty.
• For use as a cooking appliance only.
• FOR OUTDOOR USE ONLY.
• CLEARANCE FROM COMBUSTIBLES: Sides 18cm, Rear
16cm, Top 61cm and only non-combustible oors.
Please read the
instructions carefully
before use.
Retain this manual for
future reference.
2
2
3
3
5-6
6
7
8
9
9
10
11
11
11-12
13
13-14
14
14
INDEX
INDEX
WARRANTY
GENERAL INFORMATION
USE AND CHARACTERISTICS
PRODUCT VIEW
ASSEMBLY
SELECTING A LOCATION
CONNECTING THE GAS CYLINDER TO THE APPLIANCE
LEAK TEST
LIGHTING YOUR GAS PIZZA OVEN
FLASHBACK (FLAME IN BURNER TUBE)
OPERATION
REGULATOR AND HOSE
STORAGE
CLEANING AND CARE
WARNING
FREQUENTLY ASKED QUESTIONS
SPECIFICATIONS
AFTER SALES SERVICE
KEY
Important information
Cautions and
warnings.
Danger
Contact an approved
ALVA technician.
Do It Yourself
WARRANTY
PLEASE RETAIN YOUR PROOF OF PURCHASE FOR
WARRANTY CLAIMS.
ALVA warrants this appliance to be free of defects in material and
quality for a period of 12 months from date of original purchase.
This warranty covers the intended use of this appliance – within
a domestic setting and not for commercial or industrial purposes.
Any damage caused by willful abuse, tampering, modication or
unauthorized repair will not be warranted.
Please retain all packaging material, as items returned without
original packaging material may be subject to a withholding fee.
Where this appliance is found to be defective, damaged, broken,
or does not work correctly for the intended purpose, you must
return the appliance to the retailer from where it was purchased.
The warranty will only be effected with valid proof of purchase.
Failure to provide the proof of purchase will most likely result in
the repair or service required being chargeable.
Rust is not covered under the warranty.
If you have any questions while setting up or using this Gas
Pizza Oven, please visit www.alva.co.za or call 086 100 ALVA
(2582) or e-mail info@stingray.co.za
GENERAL INFORMATION
Before using this Gas Pizza Oven, please read through this
manual and make sure you understand everything. If you are not
sure, call 086 100 ALVA (2582) or visit www.alva.co.za for help.
This Gas Pizza Oven is a safe and efcient appliance when used
according to these instructions.
Reading and understanding this manual should give you a good
indication of what to expect from your Gas Pizza Oven. If this
product is not what you want or need, please help Alva and the
environment by not damaging or destroying any part of the pack-
aging. Always keep your proof of purchase. Keep these instruc-
tions for future use. If you lose this copy, you can obtain a new
copy from your dealer or online at www.alva.co.za.
Thank you for your
purchase of this
Gas Pizza Oven .
Please read these
instructions carefully
before use and keep
them in a safe place,
for future reference.
Failure to follow these
instructions may result
in serious bodily injury
and/or property
damage.
If you have any
questions concerning
assembly or
operation, consult your
local dealer.
DO NOT move the
Gas Pizza Oven while
in operation.
The Gas Pizza Oven
and cylinder must
be placed on a level
surface.
2
3
USE AND CHARACTERISTICS
This Gas Pizza Oven is safe and easy to use. The specied gas
for this Gas Pizza Oven is LPG. Please ensure you only use your
Gas Pizza Oven with a 2.8kPa approved regulator.
Regulator and hose supplied.
Adequate ventilation is vital for combustion and efciency
performance of the Gas Pizza Oven. This will ensure the safety
of the user and other people in the vicinity of the area where the
Gas Pizza Oven is being used. Never use the Gas Pizza Oven in
any enclosed covered area.
PRODUCT VIEW
No. PART NAME QTY No. PART NAME QTY
1 Pizza Plate 1 5Body 1
2Grid 1 6 Legs 4
3Cooking Grill 1 7Screws M5 x8 5
4Chimney 1 8 M5 Nuts 4
4
ASSEMBLY
STEP 1
STEP 2
Install the leg set by fastening directly into the body - with screws provided
inside the leg as illustrated above
Fasten the chimney cap to the chimney by using the - M5x8 - 1pcs
M5*8 1 PCS
5
STEP 3
STEP 4
Attach the chimney using the - M5x8 screws and the 4x M5 Nuts
Insert the cooking grid into the oven - place pizza stone on top of the grid
M5*8 4 PCS
M5 4 PCS
Pizza Stone Grid
Grid Cooking
The Gas Pizza Oven is for outdoor use only and should be
placed in a well-ventilated area.
We advise that placement needs to exceed the height of 950mm
off the ground in order to view the burner ame.
The Gas Pizza Oven consumes oxygen. It is dangerous for the
health and safety of the occupants to use this appliance in areas
that are not properly ventilated.
Take care to ensure that it is not placed under or on any
combustible surface.
Keep the Gas Pizza Oven away from any ammable materials.
6
STEP 5
Install the door (Fig 1)
SELECTING A LOCATION
(Fig 1)
How to Install
(Fig 2)
Door Installed
PRECAUTIONS
Should you need to change the gas cylinder, ensure that the
cylinder valve is closed, the appliance is switched off and there
are no sources of ignition (cigarettes, open ames, sparks, etc)
nearby before proceeding.
Inspect the gas hose to ensure it is free of any twisting or
tension. The hose should hang freely with no bends, folds, or
kinks that could obstruct the free ow of gas. Apart from the
connection point, no part of the hose should touch any hot
Gas Pizza Oven parts.
Always inspect the hose for cuts, cracks, or excessive wear
before use. If the hose is damaged, it must be replaced with a
hose suitable for use with LPG and which meets the national
standards for the country of use (South Africa: SANS 1156-2 or
EN16436). The length of the hose shall not exceed 1,5m.
CONNECTING THE GAS CYLINDER TO THE APPLIANCE
This appliance is only suitable for use with LPG. This appliance
is tted with a 2.8kPa low pressure regulator.
BEFORE USE PLEASE CHECK FOR LEAKS
Never check for leaks with a naked ame, always use a soapy
water solution.
The hose should never be twisted and knotted and should not
exceed 1.5m.
In order to connect:
1. Ensure the control knob is in the "OFF" position before
connecting it to a gas supply.
2. Connect the oven inlet, located in the lower left quarter of
the back plate, to the gas regulator outlet.
3. Ensure the hose is correctly placed and is not being
stretched, tied or bent.
4. Ensure the hose is not close to any heat sources, especially
that of the Gas Pizza Oven back.
5. Connect the regulator to the gas cylinder and tighten by
hand till gas tight.
In order to disassemble the regulator and connecting hose:
1. After use turn the gas cylinder valve 'OFF' and wait for the
ame to extinguish.
2. Turn the Gas Pizza Oven off.
3. Remove the connecting regulator from the gas cylinder.
7
FOR YOUR SAFETY
IF YOU SMELL GAS
• Turn off the gas
supply at the
bottle.
• Extinguish all
nakedames.
DO NOT operate
any electrical
appliances.
• Check for leaks
(see LEAK TEST)
• If odour per-
sists, contact
your dealer or
local gas supplier
immediately.
WARNING:
Only use the hose
assembly as provide
with the appliance.
Avoid twisting or
kinkingtheexible
hose.
The hose should
NEVER exceed 1.5m.
8
DO NOT attempt
to use the Gas
Pizza Oven if a leak is
present.
NEVER test for leaks
withanopename.
WARNING
Take care not to
obstruct the
openings at the
sides and rear of the
appliance or restrict
airowbyplacing
other appliances or
items close to or
adjacent to the open-
ings.
DO NOT build this
appliance into an
enclosure or cavity.
Fig.B
Foamy
bubbles
indicate a
leak
Connection
in assembly
Connections to be leak tested
Regulator into cylinder
Hose to regulator
Hose to appliance
http://www.
youtube.com
/watch?v=8L
pZ1B0m23Y
&feature=plcp
How to do
a leak test
LEAK TEST
The leak test must be carried out in a well-ventilated area, free
from any ames or other sources of ignition.
• With the cylinder connected to
the Gas Pizza Oven. Open the
cylinder valve.
• Brush the connections
(Gas Pizza Oven to cylinder)
with a solution of equal parts
soap and water (must be
foamy).
• A stream of bubbles forming
indicates a gas leak. (See
Fig.B)
• If bubbles appear, turn the
cylinder valve OFF (clockwise)
and disconnect the Gas Pizza
Oven from the gas cylinder.
• Tighten the connection and
retry the leak test.
• If you are unsure or if you
cannot tighten the connection,
place the cylinder outside in a
cool, well-ventilated area and
contact Alva on 086 100 ALVA
(2582).
• A leak between the Gas Pizza
Oven and cylinder can lead to
a high pressure re, which is
very dangerous and can result
in extensive injury or even
death.
Checking the Burner ame for indication of a gas leak:
Ignite the burner and rotate the knob from HIGH to LOW. You
should see a smaller ame in LOW than in HIGH. Always check
the ame prior to each use. A good ame should be blue with
minimal yellow tipping. Some yellow tips on ames are accept-
able as long as no carbon or soot deposits appear.
9
If the burner fails to
ignite, turn the control
knob off (clockwise)
and also turn the
cylinder valve off. Wait
veminutesbefore
attempting to relight
following the correct
ignition sequence.
Iftheburnerameis
accidentally extin-
guished, turn the knob
to OFF and wait 5 min-
utes before attempting
to reignite.
LIGHTING YOUR GAS PIZZA OVEN
Lighting Instructions:
1. Connect the gas cylinder to the Gas Pizza Oven using the
LP Regulator.
2. DO NOT tilt the oven over while igniting.
3. Remove all items from the oven to create a free ow of air.
4. Keep the oven door cover open. DO NOT attempt to light
the oven with the cover closed.
5. Depress the knob and turn it anti-clockwise, keep it
depressed for 5 seconds, this will create a spark which will
ignite the burner directly.
NOTE: Try the above process several times until you light the
burner. A failure to ignite the rst time might be as a result of air
in the burner and gas tube.
6. You can view the ame to ensure the burner has ignited.
7. Adjust the knob to the desired heat setting.
8. To turn ‘OFF’ the Gas Pizza Oven, close the cylinder valve
and turn the control knob on the appliance
clockwise to the “OFF” position once the ames have
extinguished.
FLASHBACK (FLAME IN BURNER TUBE)
In the event of ash back whilst the oven is in use, turn all the
controls and the cylinder valve to the ‘OFF’ position. Wait 5
minutes before attempting to relight the oven. If the problem per-
sists, check for blocked venturi ports by removing the burner and
cleaning with compressed air or with a pipe cleaner.
Replace burner correctly. If problem persists do not try to rectify
the problem yourself as this could result in serious injury and/or
property damage.
Do not store your gas cylinder in doors. Store in a well ventilated
area away from direct sunlight or an electrical source.
10
NOTE:
Preheating the oven
will shorten cooking
time and result in a
more satisfying end
product.
WARNING:
The oven body will be
very hot. Keep young
children away.
NEVER touch the
oven body while in
operation.
Wear heat-protective
gloves.
DO NOT move the ap-
pliance while in use.
OPERATION
Preheating the oven:
1. Light the burner, check the ame and if satised place the
front door cover on the support.
2. Turn the ame to MAX. After 5 minutes the thermometer will
display an inner temperature of approximately 230°C.
WARNING: Remove the front cover after 5 minutes to prevent
possible injury caused by the hot outer body.
Baking Pizza:
1. Turn the knob to MIN.
2. Wearing heat protective gloves, remove the cover using the
handle. NEVER handle the cover without protective gloves.
3. Use a pizza peel (not provided with the oven) to place the
pizza on the pizza stone inside the hot oven.
NOTE: The largest size pizza that the oven can accommodate is
a diameter of 30cm (12")
4. It will take approximately 5 minutes for the pizza to cook.
The pizza's direction can be adjusted using a pizza peel.
5. The front cover can either be removed or remain in place
during operation. It is recommended to have the cover in
place in the event of a heavy wind.
6. Adjust the knob to your desired temperature.
7. Use a pizza peel to remove the pizza once ready.
8. You can immediately place a new pizza in the oven should
you wish to prepare more.
11
Switching OFF the oven:
1. Turn the gas off at the cylinder (clockwise).
2. Once the ames have extinguished turn the unit control
knob to the 'OFF' position.
REGULATOR AND HOSE
Use only regulators and hose approved for LPG in accordance to
the South African National Standards.
STORAGE
FIXINGS
Annual checking and tightening of metal xings is recommended.
STORING YOUR GAS PIZZA OVEN
THE GAS CYLINDER SHOULD BE DISCONNECTED AND
STORED OUTDOORS OR IN A WELL VENTILATED AREA.
When using the Gas Pizza Oven after extended periods of
storage, please take note once again of the care, maintenance
and safety instructions.
The appliance can be stored indoors if not connected to the
cylinder.
Store the appliance on a stable, level surface out of reach of
children.
Store the appliance in a clean dry environment.
GAS CYLINDER
A 9kg ALVA gas cylinder with a 5/8 inch BSP left hand thread is
recommended.
Cylinders must be stored in an upright position, in a well
ventilated and damp free area and out of reach of children.
CLEANING AND CARE
CARE
Regular care of your Gas Pizza Oven will help keep it operating
properly. All maintenance should be done only when the Gas
Pizza Oven is cool and with the gas supply turned off.
Occasionally inspect and tighten hardware that may become
loose. Clean when warm. While wearing gloves wipe the Gas
Pizza Oven clean.
CLEANING THE BURNER TUBE
The burner tube is tted with mesh covers to assist in
preventing insects and debris entering the tube. Insects and
debris can still cause a blockage in the burner tube. This can
be a serious problem potentially preventing gas ow and can
even cause a re at the gas control valve. Such a re can cause
operator injury and serious damage to your Gas Pizza Oven.
To prevent insect or debris related problems, inspect the burner
tube regularly and clean out any dirt. Insure that the burner tube
is relocated correctly, following any disassembly.
ANNUAL CLEANING AND MAINTENANCE
Once a year is a good practice to clean the whole Gas Pizza
Oven. As always, be certain the Gas Pizza Oven is cool enough
to touch and gas supply is turned off. Wear gloves.
Cleaning should be done where detergent won’t harm the work
surface or lawn. Disconnect the gas supply and remove the gas
supply cylinder. Tighten any loose hardware.
STAINLESS STEEL CARE
In order to preserve the stainless steel on your oven, we suggest
applying a thin lm of baby oil to the stainless steel body
components of your oven on a regular basis. This is especially
important at the coast. Once applied, you can wipe all excess
baby oil residue off with a clean cloth.
NEVER USE OVEN CLEANER
Failure to follow these instructions may cause the oven to rust
OUTSIDE SURFACE
Use a mild detergent or a baking soda and hot water solution.
Non-abrasive scouring powder can be used on stubborn stains,
then rinsed with water.
Clean thoroughly with a strong hot soapy water solution. Rinse
with water and allow to dry completely. NEVER USE OVEN
CLEANER.
INTERIOR OF GAS PIZZA OVEN BOTTOM
Remove residue using a brush, scraper and/or cleaning pad then
wash with a soapy water solution. Rinse with water and allow it
to dry.
PIZZA STONE
Wait for 15 minutes after turning off the oven for the pizza stone
to cool. Clean the pizza stone surface using a dry metal brush,
no water or wet cloth required.
NOTE:
Do not use any soapy solutions, this will penetrate into porous
pizza stone and cause a permanent soapy after taste to your
cooked pizza.
Visit:
https://www.stingray.co.za/pizza-stone-with-lifter-cutter.html.
On this page there is a link to show you how to clean your pizza
stone correctly.
12
Never attempt to
operate your Gas
Pizza Oven without
the burner tube being
correctly located.
A serious and
immediaterehazard
would result.
13
For use outdoors only
and in well ventilated
areas
WARNING: Accessible
parts may be very hot,
keep young children
away
Read the instructions
before using the
appliance.
DO NOT move the
appliance while in use.
WARNING
• The appliance is designed for outdoor use only.
• WARNING! Accessible parts may be very hot. Keep young
children away.
• Read the instructions before using the appliance.
• Do not move the appliance while in use.
• Turn off the appliance at the cylinder valve after use.
• The Gas Pizza Oven must not have any overhead
obstructions e.g. trees, shrubs and lean to roofs.
• The Gas Pizza Oven must not be used near ammable
materials (petroleum based products, thinners or any other
solid object that carries a ammable warning label).
• The use of this Gas Pizza Oven in enclosed areas can be
dangerous and is PROHIBITED
• It is illegal and dangerous to change or modify any part of
this appliance:
• The warranty will be voided against any and all claims if the
unit has:
a. Not been assembled and operated in accordance with
the instructions provided
b. Been used for commercial purposes
c. Been abused, misused or left exposed to the elements
d. Been damaged as a result of a fat re
e. Any repairs, modications or tampering, with this appli-
ance by an unauthorised person is not allowed and will
nullify the warranty.
f. Claims related to rust.
This Gas Pizza Oven must be assembled, installed, operated
and maintained in accordance with all applicable codes and the
instruction manual furnished with this Gas Pizza Oven.
This oven is not manufactured for commercial use.
In the unlikely event of you experiencing any faults with your Gas
Pizza Oven please contact the retailer from which you purchased
the product.
FREQUENTLY ASKED QUESTIONS
Q: How long will the gas in my cylinder last?
A: This depends on how you use your Gas Pizza Oven.
It is easy to calculate your gas consumption. Take the
capacity of the gas cylinder in grams (i.e. 9000g for a
9kg cylinder) and divide it by the gas consumption of
the appliances. The answer to the calculation is the
approximate number of hours that your gas will last for.
Q: What do I do if I have an over-lled cylinder?
A: The best method to determine if your cylinder is over-
lled is to weigh it. Subtract the ‘tare’ mass from the
cylinder weight – this gives you the weight of your gas.
If this gas weight exceeds your cylinder design weight
(9 kg) then return the cylinder to your gas
supplier.
SPECIFICATIONS
Model ALVA GPO101
Type of Gas LPG
Operating pressure 2.8kPa
Gas Consumption at max 283.9gr/hr 3.9kW
Jet Size 0.93mm
FOR USE OUTDOORS ONLY AND IN WELL VENTILATED
AREAS. TO BE USED WITH A 2.8kPa SANS 1237
APPROVED REGULATOR WITH A MINIMUM DELIVERY
CAPACITY OF 1kg/h WITH A SANS 1156-2
OR EN16436 APPROVED HOSE.
REGULATOR AND HOSE SUPPLIED.
WARNING: ACCESSIBLE PARTS MAY BE VERY HOT. KEEP
YOUNG CHILDREN AWAY.
READ THE INSTRUCTION LITERATURE BEFORE USING
THE APPLIANCE.
DO NOT MOVE THE APPLIANCE WHILE IN USE.
AFTER SALES SERVICE
MANUFACTURED FOR AND DISTRIBUTED BY
Alva Marketing (Pty) Ltd
P.O. Box 30014
Tokai, 7966
Tel: 021 442 1540
E-mail: info@stingray.co.za
www.alva.co.za
@StingrayGroupSA
www.facebook.com/AlvaGas
TOLL FREE NUMBER 086 100 ALVA (2582)
http://www.
youtube.com/
watch?v=Ya
vsYE8nzCw
&feature=plcp
How to test if
your cylinder
is overfilled
14
This manual suits for next models
1
Table of contents
