amadeus AHARMONY User manual

AHARMONY

GB
NO
DK
FI
SE
Please read all instructions before use for the best performance of this
product. Save these instructions for future reference.
Les alle instruksjonene før bruk for å få best ytelse fra produktet. Tavare
på instruksjonene for fremtidig bruk.
Læs alle instruktioner før brug, så du får det bedste ud af produktet. Behold
denne brugsvejledning til senere brug.
Lue kaikki ohjeet ennen käyttöä tämän tuotteen parhaan suorituskyvyn
varmistamiseksi. Säilytä nämä ohjeet tulevaa käyttöä varten.
Läs alla anvisningar innan användning för att bästa prestanda från produkten.
Spara dessa instruktioner för framtida behov.

SE
FI
DK
GB
Manual - English Page 3-9
Manuell - Norsk side 10-16
Brugsvejledning - Dansk side 17-23
Käyttöopas - Suomisivu 24-30
Bruksanvisning - Svenskasida 31-37
NO

GB
Box Contents
RCA to RCA
audio cable
Stereo RCA to
3.5mm audio cable
Digital Optical cable Power Adapter
Bookshelf Speaker Remote Control Manual
LED Indicators and Button Introduction
Standby Bluetooth Optical
Line in Coaxial
LINE
MOVIE MUSIC DIALOG
BT OPT
COAX
MUTE
VOL+
VOL-
INPUT
Active Speaker
LED Indicators
Infrared receiver

01. Power On/Off
02. Input selection
Press in to navigate between audio
sources: Bluetooth -> Optical ->
Coaxial -> LINE IN
03. Sound efects
Press in to navigate between audio
sources: Music -> Dialogue -> Movie
04. Volume control
05.Treble control
06. Coaxial input port
07. Bass control
08. Power port
09. Line in input port
10. Optical input port
11. Left speaker audio output
12. Left speaker audio in
Know Your Remote
LINE
MOVIE MUSIC DIALOG
BT OPT
COAX
MUTE
VOL+
VOL-
INPUT
Power button
Volume up
Previous track
Play/pause
Optical mode
Line mode
Movie mode
Dialogue mode
Music mode
Coaxial mode
Input mode
Bluetooth mode
Next track
Volume down
Mute/Unmute
MUTE
VOL+ VOL-
BT
INPUT
OPT
LINE
MOVIE
DIALOG
MUSIC
COAX
Passive Speaker
12
Active Speaker
EQ
LINE IN
LR
OPT
CO AX
SPEAKER OUT
DC I N
VOLUME
TREB
BASS
01 02 03
04
09
10
11
05
06
07
08
SPEAKERIN
GB
NE

Connection Diagram
Bluetooth Device
TV
Digital Optical cable (supplied)
aCoaxial cable (not supplied)
b
Bluetooth
cStereo RCA to 3.5mm audio cable (supplied)
d
RCA to RCA audio cable (supplied)
ePower Adapter (supplied)
f
Active Speaker Passive Speaker
EQ
LINE IN
LR
OPT
COA X
SPEAK ER O UT
DC IN
TREB
BASS
Bluetooth signal
up to 10 m
e
d
ac
b
f
GB

Connecting with a TV
Setting “PCM” on your TV
When all cables are connected properly, and LED indicator
lights properly, if there is no sound from tv or Soundbar, please
setting your tv as below:
BMethod 2. Connecting using a RCAto 3.5mm audio cable.
Select RCA mode.
CMethod 3. Connecting using an Coaxial cable. Select Coaxial
mode and set the TV’saudio output to “ PCM ”.
(More information on PCM page)
AMethod 1. Connecting using an Optical cable. Select Optical
mode and set the TV’s audio output to “ PCM ”.
(More information on PCM page)
Active Speaker
TV
AOptical digital
cable (supplied)
BRCA to 3.5mm audio
cable (supplied)
CCoaxial cable
(not supplied)
GB

Connecting a Bluetooth Device
1. Press “ Menu ” on the TV’s remote control.
2. Press the arrow keys on the remote to scroll to “Audio Settings ”.
3. Press “ OK ” on the remote control.
4. Scroll to “ Advanced Audio ” and press “ OK ”. Some televisions may
not have an “Advanced Audio ” menu and may list various audio
settings instead.
5. Scroll to “Audio Output Mode ” or “ Digital Audio Output Mode ” and
press “OK”.
6. Scroll until “PCM ” is displayed as the current audio output.
7. Press “OK” to save the settings.
b. Turn on Bluetooth on the Bluetooth device.
c. Select “AHARMONY ” and connect it. When your Bluetooth device is
connected, the LED indicator will be on.
d. Play music files from the device, connected via Bluetooth, through
the bookshelf speaker.
a. Press the “ BT ” button on the remote or press the “ ” button on
back panel of the active speaker, the LED indicator blinks blue.
BT
or
Bluetooth signal
up to 10 m
GB

Specifications
Power output: L/R: 29W + 29W
Signal/Noise ratio:
Frequency response: 40HZ-20KHZ
Bassunit: 4 inch (102mm)
Tweeterunit: 1 inch (25.4mm)
No sound:
Check if the power indicator light is ON.
Cannot connect via Bluetooth:
Make sure the speaker is switched to Bluetooth input, in other audio input mode
Bluetooth can not be paired or connected. Disconnect from any Bluetooth device
by long press the “ ” in Bluetooth mode, then try again.
Effective Bluetooth transmission range is 10 meter, please make sure operation is
within the range.
Try another Bluetooth device for connection.
Try to turn up the volume using either the master volume control or remote control.
Ensure the audio cables are firmly connected and the input is set correctly on the
speakers.
Check if there is signal output from the audio source.
Troubleshooting
The Speakerdoes not turn on:
Check if mains power is connected, or if the wall outlet is switched on.
GB
70 dB
L/R:

GB
T
WEEE
This symbol on the product or in the instructions means that your
electrical and electronic equipment should be disposed at the endof its
life separately from your household waste. There are separate collection
systems for recycling in the EU. For more information, please contact
the local authority or your retailer where you purchased the product.
