AmaMedic Silo User manual

OPERATION INSTRUCTIONS
Silo MASSAGE CHAIR
With 3 gears adjustment,
1,2,3 cyclic switching
1
2
3
Function Gear
Button Description Display

01
Before Use
Safety Precautions
Installation Parts
Place Massage Chair
Before Use
Product Structure
02-04
05
06-07
08-09
10-15
Usage Method
Operation Instructions 16-22
Maintain
Cleaning and Maintenance 23
Important
Troubleshooting
Product Specifications
24
25
Thank you for purchasing this product. Please read this manual instruction carefully
in order to know how to use this product correctly before operation. Please pay more
attention to some important safety warning and keep this manual book properly for
future use.
Note: Our company reserves the right to change and explain the design of the
product. If there is some difference between the product function in market
circulation and the description in the manual, it is a normal update of the product,
and our company will not inform you otherwise. The specific product function and
color shall prevail in kind.
CONTENTS
With 3 gears adjustment,
1,2,3 cyclic switching
1
2
3
Function Gear
Button Description Display

03
02
Safety Precautions must be observed
Warning Indicates that serious injury or death may result from
improper use.
■Please pay attention to the symbol before each safety item.
Forbidden
■Please read all relevant instructions carefully before use.
■The notes marked here will help you to use the product safely and correctly.
■In order to clearly indicate the extent of harm and damage, precautions are
divided into "Warning" and "Caution" that may be caused by incorrect use.
Both of them are important for safety and must be followed.
Caution
■The device is not intended for use by persons (including children)
with physical disabilities, sensory or neurological impairments or
who lack experience and common sense, unless they are
supervised and instructed in the use of the device by those
responsible for their safety. Children must be supervised to ensure
they do not play with instruments.
■Patients with osteoporosis.
■Patients with heart disease or wearing electronic medical devices
such as a pacemaker.
■People who have a fever.
■Pregnant women .
■Patients who are injured or have a skin disease.
■When unsupervised, any children are under the age of 14 and
those unconscious are not allowed to use this product.
■People who are told by their physicians to have rest or who feel
unwell.
■People whose bodies are wet are forbidden to use this product.
■This product has a hot surface. Persons insensitive to heat must
pay attention when using this product.
■If the supply cord is damaged, to avoid danger, it must be replaced
by a professional from the manufacturer, its maintenance
department or similar department
Indicates that misuse may cause minor injury or property
damage.
Absolute prohibition
The following populations should not use this product
Important safety warnings
■Do not allow children to touch any movable part of this product.
■Use the well-grounded power supply unit suitable for this product.
■Pull out the plug after use or before cleaning to avoid any physical
injury or damage to the product.
■Operate this product as instructed in this manual.
■Do not use any parts or accessories which are not recommended.
■Do not use this product outdoors.
■Please read the Operation Instructions carefully before operation.
■Never use this product for any other purpose not listed herein.
■20 minutes of usage each time is recommended.
■Do not use this product if the cover or leather is broken or
damaged.
■Do not drop anything into this product.
■Never fall asleep while using this product.
■Do not use this product if you are drunk or feel unwell.
■Do not use this product within one hour after a meal.
■Do not use this product with excessive force to avoid any injury.
Safety Precautions must be observed
Storage conditions
■Storage room temperature: 41°F to 104 °F.
■Relative humidity (RH) between 20% and 80%; free of corrosive
gases, and a well-ventilated room.
Forbidden
Warnings
■Check whether voltage is consistent with the specification of this
product.
■Never insert or pull out the plug with a wet hand.
■Do not let water flow into this product to avoid electric shock or
cause damage to this product.
■Do not pull the power cord when plugging or unplugging it. Rough
handling is forbidden.
■Do not damage the wire or modify the circuit of this product.
■Do not clean live parts of this product with a wet cloth such as a
power switch and plug.
■Be away from this product in case of power failure to avoid any
injury if power is restored suddenly.
■Stop using this product at once while it works abnormal, and
consult your local supplier.
■Stop using this product if you feel unwell, and consult your health
care practitioner .
Safety precautions
Caution
Caution
With 3 gears adjustment,
1,2,3 cyclic switching
1
2
3
Function Gear
Button Description Display

0504
■This product should be maintained by the service center designated
by the manufacturer only. No user should disassemble or maintain it
without permission.
■Do not forget to turn off the main power switch after usage.
■Do not use this product if the power socket becomes loose.
■If this product will be left unused for a long period of time, it is
necessary to roll up the power cord of this product and store this
product in a dry and dust-free environment.
■Do not store this product at a high temperature or near open flame.
Avoid prolonged exposure to direct sunshine.
■Please clean this product with dry cloth. Never use thinner, benzene
or alcohol.
■The mechanical components of this product are specially designed
and manufactured, so no special maintenance is needed.
■Do not use a sharp object to stab at this product.
■Do not roll or pull this product on any uneven ground. Instead, it
should be lifted before moving.
■Please use this product intermittently. Do not keep it working
continuously for a long period of time.
Product service and maintenance
Operating environment
■Do not use this product in a very moist environment such as the
bathroom.
■Stop using this product immediately when the ambient temperature
changes sharply.
■Do not use this product in any heavily-dusty or caustic environment.
■Do not use this product in a small space or a place without good
ventilation.
■If the motor sounds during operation of this product, this is the
normal operation sound.
■If the controller cannot work normally, check whether the plug and
the power socket are connected reliably, and whether the power
switch is turned on.
■If the rated working time is over, this product will automatically
activate the power-off button; If this product keeps operating for a
long period of time, the temperature protector will stop this product
automatically. The product can be used again after half an hour.
Solutions to ordinary malfunctions
Safety Precautions must be observed Installation parts
Caution
Caution
Caution
Calf installation instructions
1.Insert the wire of the calf and the air pipe into the front socket of the steel frame
assembly (Figure 1).
2.Then push the connected wire and air pipe into the hole in the backrest frame
(Figure 2).
3.After the wire docking is completed, open the calf fixing covers on both sides of
the steel frame assembly (Figure 3).
4.Lift the calf into the notch, close the fixing covers, and secure it in place with 2
pieces screws (Figure 4).
Figure 1 Figure 2
Figure 3 Figure 4
With 3 gears adjustment,
1,2,3 cyclic switching
1
2
3
Function Gear
Button Description Display

Place massage chair
Make sure there is enough
space for the massage chair can
be tilted at least 11.8 inches.
Do not expose the massage chair
directly to high temperature
environment due to sunlight(such
as: in front of heating equipment),
and place it to where can avoid
high temperature and direct
sunlight. It is recommended to lay
a soft cushion for long-term use in
a designated location. When laying
the cushion, the size of the
cushion should be enough to cover
Keep the range where the machine
touches the floor and the range
where your feet touch the floor.
Installation placement
CAUTION
CAUTION
Require team work to lift and move
the chair to avoid injury.
1. Please lift the massage chair to
move it on vulnerable ground such as
wooden floor.
2. When moving on a similar wooden
floor, it is recommended to lift it.
Avoid damage to the casters. When
the floor is lifted and moved to the
designated position, be careful to
keep your hands out of the way to
avoid injury, and be careful of your
feet being crushed. Do not let go of
the unit until the unit is completely
flat, the floor may be damaged,
therefore, it is recommended to place
mats, etc. on the floor.
Product lift instruction
Place massage chair
How to disassemble and use headrest cushion and backrest cushion
Move method
Using a headrest cushion can reduce
the intensity of kneading massage on
the neck and shoulders, and you can
decide whether to use a headrest
cushion according to your needs
(recommended to use a headrest
cushion). The backrest cushion and the
backrest are connected by a zipper (1),
and the headrest cushion and the
backrest cushion are connected by a
zipper (2).
12
Zipper Zipper
CAUTION
CAUTION
Use the rear casters to move the
massage chair.Move the chair by tilting it
down and backward about 45° as shown
in the diagram.
NOTE: Excessive force to title will cause
the chair to tip over completely and
product damage.
1.Before moving, please shut down the
machine properly to reset the whole
machine, and then cut off the power.
2.Please keep the chair vacant when
moving. (People, pets or clutter will not be
able to stay on the chair.)
3.When moving, do not cross a drop barrier
higher than 2mm or a gap greater than
5mm.
4.When using casters to move this product,
single continuous movement is not
supported; if the distance exceeds 164ft,
please make this product move slowly and
evenly.
07
06
11.8 inches
45°
With 3 gears adjustment,
1,2,3 cyclic switching
1
2
3
Function Gear
Button Description Display

Before use
CAUTION
Check around
Make sure there are no foreign objects in the
gaps of the machine
Make sure that there are no people, pets and
other objects around the unit.
CAUTION
Before massaging, make sure that
no foreign objects are caught in the
legs, feet, etc.
Under no circumstances allow
hands, feet, and head to penetrate
into the area between the lower leg
mechanism and main body, or the
area between the armrest and the
capsule.
Under no circumstances should
hands, feet, or head sink under the
fabric or leather covering of the
massage area.
POWERINPUT
ON/OFF
POWERINPUT
ON/OFF
Turn on the power
Caution
Plug in power cord
Schematic diagram
of power on
Turn on the power
switch ("I" position)
Warn
■Please check whether the power cord and power plug are damaged
before use.
■Please supply power to this product in accordance with the working
power requirements of this product's calibration.
■It is strictly forbidden to use a power supply other than the nominal
power supply of this product.
■It is strictly forbidden to connect various power conversion devices to
supply power to this product without authorization.
Before Use
09
08
With 3 gears adjustment,
1,2,3 cyclic switching
1
2
3
Function Gear
Button Description Display

10 11
Head Cushion
Leg massage
Arm air
compression
assembly
Back
cushion
Head neck
to seat
Leg air
pressure
massage
Foot bump
massage
Arm air
pressure
massage
Foot Air
pressure
massage
Movement massage
Remote
controller
pocket
Armrest
cover
Armrest
Side cover
Product Structure Product Structure
Parts description Function distribution
speaker
cover
Foot massage
With 3 gears adjustment,
1,2,3 cyclic switching
1
2
3
Function Gear
Button Description Display

LOCK
Product Structure Product Structure
Ⅰ.Introduction of the remote controller
12 13
1.Pause/run button
- Pause or run all massage functions.
2.Automatic button
- Please refer to page 14 of this manual.
3.Spot massage button
- Please refer to page 16 of this manual.
4.Shoulder position up button
- Manually adjust the shoulder position upwards.
5.Auto lying button
- There are three automatic lying modes and reset and standing modes, which can
be switched cyclically according to your own needs.
6.Width adjustment button
- Adjustable in 3 modes: wide, medium and narrow.
7.Technique button
- Please refer to page 15 of this manual.
8.Linkage lift adjustment button
- Please refer to page 14 of this manual.
9.Switch power button
- Turn on or off all massage functions.
10.Lock button
- Please refer to page 16 of this manual.
11.Partial massage button
- Please refer to page 16 of this manual.
12.Shoulder position down button
- Manually adjust the shoulder position down.
13.Full body massage button
- Please refer to page 16 of this manual.
14.Air pressure adjustment button
- Adjust the strength/weakness of the pressure.
15.Speed adjustment button
- Adjust three speeds: slow, medium and fast. With 3 gears adjustment,
1,2,3 cyclic switching
1
2
3
Function Gear
Button Description Display

15
Operation Instructions Operation Instructions
Ⅱ、Start massage
①. Press the power button to start the massage, the default is rt massage.Comfo
②. Automatic angle adjustment (you can press the " " button to skip).
③. Automatic human shoulder position detection, keep the sitting posture fit with the
massage chair (you can press the " " button to skip).
④. Shoulder position fine-tuning, if the detected position deviates from the actual
shoulder position, adjust it to the appropriate position through the up and down
buttons of the shoulder position (you can press the " " button to skip), there are 11
shoulder positions in total. If there is no adjustment within 10 seconds, it will enter into
the massage function.
Press this button, backrest frame slowly rise, calf frame
slowly fall, and issued "di...di..."until it reached the top.
Press this button again in the process of sitting, then
stop sitting immediately.
Press this key, backrest frame slowly down,calf frame
slowly up, and issued "di...di..."until it stops. Press this
key again in lying down process, stop lying down
immediately.
Situp
Lie down
·Adjust lying Angle
Description
Function
·Width adjustment
Function
With 3 gears adjustment,
narrow, medium, wider
cyclic switching
Gear
Width
adjustment
Narrow
Medium
Wide
Button Description Display
14
·Automatic massage
Description
Button Auto program
Comfort
Display
Back&waist
The most comfortable massage experience.
Focus on back and waist massage.
Shoulder&neck Focus on shoulder and neck massage.
Button Description
Move the massage balls upward to a suitable position
Move the massage balls downward to a suitable position
Button
·Manual massage
Auto program
Knead
Tap
Shiatsu
Knead & tap
Button Description
Speed.
Speed, Width.
Speed.
Speed, Width.
Zero-G
Each time the button is pressed, it switches to an
automatic lying mode, with a total of four modes
(including the reset and standing mode), which can be
switched cyclically.
·Speed adjustment
Speed
adjustment
Function Gear
1
2
3
Button Description Display
With 3 gears adjustment,
1,2,3 cyclic switching With 3 gears adjustment,
1,2,3 cyclic switching
1
2
3
Function Gear
Button Description Display

17
Cleaning and Maintenance
Clean PVC leather and plastic parts
■Do not use chemicals such as thinner, gasoline, alcohol, etc. to clean the unit.
■When using commercially available leather care products (rags), please follow
the instructions for use.
■If the PVC leather is particularly dirty, wipe it by the following methods.
①Immerse a soft cloth in water or hot water containing 3% to 5% neutral
detergent, then wring it out thoroughly.
②Use the above soft cloth to wipe the leather surface.
③Wipe off the cleaning solution with a cloth soaked in clean water and
thoroughly wrung out.
④Wipe with a wrung soft cloth.
⑤Let it air dry naturally.
■When it is difficult to remove stains, please immerse commercially available
melamine foam in neutral detergent, and then wipe the machine with it.
■Do not use a hair dryer to dry the surface.
■As the color of the fabric will stain the surface of the PVC leather, be careful when
wiping the chair with denim and colored fabrics.
■Do not keep these parts in contact with plastic for a long time, as this will cause
discoloration.
■PVC leather may be discolored, so when using hair dye, please cover the
touched part with a towel.
Wipe the leather with a soft, dry cloth.
Operation Instructions
·Air pressureadjustment massage
16
Ⅵ、End the massage
Take off the power plug
Power off (“0”position) Take off the product
power cord
2. Cut off the power of the whole machine. Figure (switch power off)
1. During the massage process, press the power off key on the controller, all
massage functions immediately turn off, the backrest and leg rest will reset,
or when the massage timer expires, it will automatically turn off all massage
functions, but the backrest and leg rest will not reset.
POWERINPUT
ON/OFF
POWERINPUT
ON/OFF
·Massage interval
With 3 gear adjustment
and off gear, cyclic
switching
Air intensity
adjustment
1
2
3
Function Gear
Button Description Display
OFF
LOCK
Press and hold for 3 seconds,that lock is successful, and
other keys can not be used after being locked; press and
hold for 3 seconds in locked state,that unlock is successful
and keys function returns to normal.
Lock
Function
With 3 gears adjustment,
1,2,3 cyclic switching
1
2
3
Function Gear
Button Description Display

Solution
Fault
When the calf mechanism or the backrest reaches a certain position,
press the corresponding adjustment button and it will no longer change,
and a continuous "beep, beep" sound will be emitted.
Trouble shooting
Due to product structure design and ergonomic requirements, this product
has a limited protection design for the limit state of attitude adjustment.
At the same time, a reminder sound will sound when the limit is reached.
Solution
Fault The function does not work or some functions do not work after the
machine is turned on.
After the machine is turned on by pressing the switch key, it is necessary
to manually select an automatic massage program or other working state.
If it is not operated, the machine will automatically shut down after 20
minutes. If the manual operation mode is selected, the functions that are
not selected may be disabled, and the working mode needs to be
manually set in the manual mode.
Solution
Fault The machine makes a leather rubbing sound when adjusting its posture.
This product adopts high-grade anti-corrosion leather that meets
environmental protection requirements. Due to the inherent characteristics
of leather materials, there will be a normal slight noise when rubbing at
the relative movement, which is a normal phenomenon. Note: If you hear
fabric or leather tearing sound when the machine is running, please stop
using it immediately and seek professional maintenance.
Solution
Fault The massage wheel did not reach the shoulders or neck.
If the head does not touch the head cushion or the back does not touch
the backrest, the shoulder position may be lower than the actual position
during the body shape detection process. Sit in the deepest position of the
seat, rest your head on the headrest, and start over from the beginning.
Solution
Fault The unit is damaged.
The power cord or power plug is abnormally hot.
To prevent accidents, be sure to contact an authorized service center.
Please feel free to contact the designated service personnel for any questions or
doubts about this product.
25
24
Product Specifications
Model: Silo
Name: Massage Chair
Rated voltage: 110-120V~ 60Hz
220-240V~ 50Hz/60Hz
Rated power:70W
Rated time: 20min
Safety structure: Class I
Material description: PVC, PA, steel parts, electric and electron components
MATERIAL PU LEATHER CLOTH WOOD
With 3 gears adjustment,
1,2,3 cyclic switching
1
2
3
Function Gear
Button Description Display
Table of contents
Other AmaMedic Massager manuals
Popular Massager manuals by other brands

Human Touch
Human Touch REFLEX POPUP Use & care manual

HoMedics
HoMedics SBM-300-PA-2 Instruction manual and warranty information

Human Touch
Human Touch iJoy-2400 Use & care manual

HoMedics
HoMedics MCS-125H-THP instruction manual

Therabody
Therabody TheraFace PRO instructions

Brookstone
Brookstone BK-650 user manual
