Service Manual
TOP NEXT
ORDER NO.HPD0011C18C1
MASSAGE LOUNGER
● EP790-C1
SPECIFICATIONS
Power source : 120V AC, 60Hz
Power consumption : 230W
Kneading speed : Approx. 28 times/min.
Tapping speed : Approx. 500 times/min.(per side)
Rolling massage speed : Approx. 1 cycle every 33 sec.
Massaging width : Shoulder/lower back section : Approx. 75mm
Back rolling width/tapping width : Narrow : Approx. 85 mm/: Wide : Approx. 110 mm
Massage heads up/down travel : Approx. 600 mm
Regional back rolling : Automatic repetition within approx. 120mm range
Intensity adjustment : Adjusts massage head protrusion steplessly within approx. 45 mm range
Shoulder position adjustment : 7 steps
Automatic shut-off : Approx. 15 min.
Leg massager - vibration : Approx. 3200 cycles/min./ Shut-off timer : Approx. 30 min.
Dimensions (H x W x D) :•Not reclined and leg rest retracted : 1,050 x 755 x 1,050 mm/ •Reclined and leg rest extended : 620 x 755 x 1,750 mm
Reclining angle : Approx. 127° to 170°
Weight : 56 kg
Accessories : Back cushion, headrest
© 2000 Matsushita Electric Works, Ltd. All rights reserved. Unauthorized copying and distribution is a violation of law.

•@
TOP NEXT

1.1 When Chair Arrives:
TOP PREVIOUS NEXT
When shipped from the factory, for efficient transport, the chair is packaged in the configuration
shown in the drawing below. In this configuration, normal reclining motion is not possible. Therefore,
upon arrival of the chair, always follow thefollowing steps to initialize operating settings.
*Check that the power switch is [On] (found at the back of the hinge cover).
(1)Plug-In
(2)Push continuously the reclining button of the operation panel to raise the seatback.
(3) Continue the process until the seatback movement comes to a stop (a clink sound should be
audible)./•The reclining mechanism is set.

•@
TOP PREVIOUS NEXT

1 Installation
TOP PREVIOUS NEXT
1.1 When Chair Arrives:
1.2 Installation Position:
1.3 Returning Chair to Packaged Configuration
•@
TOP PREVIOUS NEXT

1.2 Installation Position:
TOP PREVIOUS NEXT
To assure that the chair has enough space to recline to the rear, please install it at least 40cm from the
wall.
•@
TOP PREVIOUS NEXT

1.3 Returning Chair to Packaged
Configuration
TOP PREVIOUS NEXT
When shipped from the factory, for efficient transport, the chair is packaged in the configuration
shown in the figure on page 2.
After competing the initial operating settings of page 2, if the chair is to be returned to the packaged
configuration, please follow the following instructions.
(1) Insert the plug into the outlet, and check that the power switch is [On].
(2) While pushing down on the link release lever, please push (continuously) the
button of the operation panel. After checking that the leg rest has not extended, remove your hand
fromthe link release lever.
* When wanting to use the chair once again, please follow the directions on page 2 for initializing
operating settings.

•@
TOP PREVIOUS NEXT

2 Hand control functions
TOP PREVIOUS NEXT
CONTROLLER
Cover closed: Programmed course massage
Cover open: Manual massage

•@
TOP PREVIOUS NEXT

3 Massage range (movement range of
massage wheels)
TOP PREVIOUS NEXT
3.1 Upward massage, Downward massage, Rolling massage, Regional rolling massage
3.2 Tapping, Rolling, Regional rolling, Tapping rolling, Regional tapping rolling
•@
TOP PREVIOUS NEXT

3.1 Upward massage, Downward
massage, Rolling massage, Regional
rolling massage
TOP PREVIOUS NEXT
Width cannot be adjusted
Neck to waist : width 75mm (minimum)
Intensity adjustment
Upward and downward massage (from gentle to strong) :45mm-wide adjustability where massage
heads push out toward body as intensity increases.Others (from gentle to strong) :15mm-wide
adjustability where massage heads push out toward body as intensityincreases.
•@
TOP PREVIOUS NEXT

3.2 Tapping, Rolling, Regional rolling,
Tapping rolling, Regional tapping
rolling
TOP PREVIOUS NEXT
Width adjustment
Neck to waist : Massage range width : 3-5/16 in. or 4-5/16 in. (85mm or 110mm)
Intensity adjustment
Tapping : 45mm-wide adjustability where massage heads push out toward body as intensity increases.
Others : 15mm-wide adjustability where massage heads push out toward body as intensity increases.
•@
TOP PREVIOUS NEXT

4 Components identification
TOP PREVIOUS NEXT
4.1 PARTS IDENTIFICATION
4.2 TURNING ON THE POWER
•@
TOP PREVIOUS NEXT

4.1 PARTS IDENTIFICATION
TOP PREVIOUS NEXT
•@
TOP PREVIOUS NEXT

4.2 TURNING ON THE POWER
TOP PREVIOUS NEXT
•@

TOP PREVIOUS NEXT

5 Required tools
TOP PREVIOUS NEXT
•@

TOP PREVIOUS NEXT

6 Simplified wiring diagram
