TOP AND CONSOLE PARTS
1
For Model: NGD7200TW10
(White)
11−07 Printed in U.S.A. (LT) Part No. W10177854 Rev. A
27" GAS DRYER

TOP AND CONSOLE PARTS
2
For Model: NGD7200TW10
(White)
W10177854
Illus. Part
No. No. DESCRIPTION
1 Literature Parts
W10161016 Use & Care Guide
16026881 Tech Sheet
W10161760 Installation,
Instruction
2
W10177364 Top
3
6009−001476 Screw−Hex (2)
4
W10177362 Panel−Console
Assembly
5 35001162 Frame−Plate
6
6006−001174 Screw−Tapping (2)
7 35001232 Support−Panel
8
6002−000470 Screw−Tapping (4)
9
6002−000213 Screw−Tapping (5)
10 35001269 User−Interface
11
6006−001170 Screw−Tapping (1)
12 35001229 Panel, Control
13 35001231 Bracket−Panel
14 34001419 Lever−Power
15
6002−000231 Screw−Tapping (4)
16
W10175952 Button, Power
17
W10175949 Knob, Control
18 35001264 Harness, Main

CABINET PARTS
3
For Model: NGD7200TW10
(White)
W10177854

CABINET PARTS
4
For Model: NGD7200TW10
(White)
W10177854
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 35001157 Cover,
Terminal Block
2
6006−001174 Screw−Tapping
3 34001481 Terminal−Block
4
6002−000231 Screw−Tapping
5 35001167 Strain−Relief
Power Cord
6 35001170 Cabinet
7 35001276 Bracket−Idler
Assembly
8 35001084 Tri−Ring
9
6009−001342 Retainer−Idler
10 35001180 Motor Assembly
60 Hz.
11 35001137 Belt−Drive
12 35001081 Clamp−Motor (2)
13 35001107 Screw−Tapping (1)
14 35001082 Switch,
Broken Belt
15 35001278 Spring−Idler
16 35001106 Bracket−Motor
17 35001153 Board, Control
18 35001168 Bracket,
Control Board
19
W10177396 Panel−Front
20 35001125 Door−Switch
21
W10177398 Seal−Front Panel
22
6002−001006 Screw−Tapping (4)
23 35001112 Catch−Door
Assembly
24
6002−000213 Screw−Tapping (2)
25 35001255 Kit,
Stack Assembly
26
6002−000213 Screw−Tapping
27 35001156 Bracket,
Dryer Foot
28 34001158 Foot−Dryer
29 Y059131 Elbow−4"
30 35001216 Vent−Cap
31 35001204 Duct−Exhaust (A)
32 35001205 Duct−Exhaust (B)
33 35001200 Power−Cord
34 213121 Screw−Tapping
Optional Parts Not Included
Dryer Exhaust Kit
(For Side & Bottom Venting)
35 12002641 White

BULKHEAD PARTS
5
For Model: NGD7200TW10
(White)
W10177854

BULKHEAD PARTS
6
For Model: NGD7200TW10
(White)
W10177854
Illus. Part
No. No. DESCRIPTION
1 W10177426 Screen−Lint
2 35001144 Housing−Outlet
3 35001243 Grille, Outlet
4 34001214 Screw−Tapping
5
W10177409 Drum−Assembly
Complete
6 35001146 Channel−Bracket
Rear Bulkhead
7
W10177410 Bulkhead−Rear
8
6002−000239 Screw−Tapping
9 35001145 Bracket−Upper
Rear−Bulkhead
10 35001240 Assembly,
Air−Duct
11 35001132 Nut−Hex
12 35001133 Washer−Support
13
W10177428 Assembly,
Roller−Support
14
6002−000132 Screw−Tapping
15 35001245 Assembly,
Guide−Sensor
16 35001241 Plate−Sensor
17 35001242 Guide−Sensor
18 35001244 Bulkhead−Front
19
6002−000231 Screw−Tapping
20 35001246 Assembly,
Cover Plate
21 35001140 Assembly,
Lint−Duct
22 35001079 Nut−Inch
23 35001220 Wheel−Blower
24 35001089 Housing−Blower
25
6002−000470 Screw−Tapping
26 35001087 Thermostat
27 35001191 Thermister
28 35001105 Bracket−Thermister
29 35001088 Blower−Housing
Rear
30 35001155 Clip−Exhaust
31 35001092 Thermostat
32 35001096 Sensor−Radiant
33 35001225 Duct−Cone (F)
34 35001249 Duct−Cone (B)
35 35001131 Baffle−Drum (3)
36 34001159 Pipe−Exhaust

7
BURNER ASSEMBLY
For Model: NGD7200TW10
(White)
W10177854
Illus. Part
No. No. DESCRIPTION
1 35001095 Tube−Burner
2
6009−001476 Screw−Hex
3
6006−001174 Screw−Tapping
4 35001190 Valve−Gas
5
6002−000524 Screw−Tapping
6
6021−001130 Nut−Circular
7 33002789 Heater−Ignitor
8 35001117 Absorber−Ignitor
9 35001103 Bracket−Valve
10 35001093 Pipe−Assembly

DOOR PARTS
8
For Model: NGD7200TW10
(White)
W10177854
Illus. Part
No. No. DESCRIPTION
1 35001235 Door−Outer Ring
2 35001236 Door−Safety
3 35001182 Door−Glass
4 35001250 Seal−Door
5
W10177441 Holder−Glass
6
6002−001286 Seal, Window
7 35001111 Door−Catch
8
6002−000475 Screw−Tapping
9 35001129 Bracket−Hinge
(Heater)
10
W10177442 Hinge−Door
11 35001120 Support−Hinge
12 35001127 Bearing−Hinge
13
6001−001773 Screw−Machine
14
6002−000213 Screw−Tapping

OPTIONAL PARTS (NOT INCLUDED)
9
For Model: NGD7200TW10
(White)
W10177854
Illus. Part
No. No. DESCRIPTION
PAINT, TOUCH−UP (1/2oz.)
72017 White
PAINT, PRESSURIZED SPRAY
(12 oz.)
350930 White
350938 Primer, Gray
PAINT, BULK (1 qt.)
799344 White (Uncut)
ACCESSORY PARTS
35001151 Assy−Flat Wire
(Harness)
35001152 Assy−Wire Harness
35001248 Assy−Wire Harness
(Gas)
12002643 Anchor−Bracket Kit
35001164 Assy−Wire Harness
(Touch Sensor)
Y306195 Conversion Kit
(Gas To LP)
306204 Conversion Kit
(LP To Natural)
