Amana RHE60A2A User manual

®
Amana
Fayetteville, TN 37334
NOTE: It is important to electrically connect the unit and
properly size fuses/circuit breakers and wires in accor-
dance with all national and/or local electrical codes. Use
copper wire only.
Standard Features
• Bi-Flow Liquid Line Filter-Drier (Shipped Loose)
• Front Seating Valves
• Scroll Compressor
• 5 Minute Anti-Short Cycle Protection
• Automatic Reset High Pressure Switch
• Dual Defrost Sensors
• Automatic Reset Loss Of Charge Switch
• Adaptive Demand Defrost
• Spring Loaded Check Valves
• Eight Pole Motor
Accessories
• Fossil Fuel Kit (FFK02A)
• Compressor Sound Blanket (CSB08A)
• Ambient Temperature Kit (ATK05A)
• Hard Start Kit (HSK12A)
• Freeze Protection Kit (FSK01A)
(Installed On Indoor Coil)
NOTE: When mix matching with restrictor orifice indoor
coil, use restrictor orifice part number B1443819 or
11076315, 0.098 diameter.
Heat Pump Performance Data
For ARI Performance Data: See the ARI Directory, Product Data Booklet (PDB), or the product Service Manual.
March 2000 11070191
Above information is for nominal CFM and 70° F indoor dry bulb.
All pressures are PSIG.
All temperatures are °F.
RHE60A2A / BHA60TB002A
Outdoor Ambient Temperature (° F)
65 60 55 50 47 45 40 35 30 25 20 17 15 10 5 0 -5 -10
∆T 3836343230292725232220191816141311 9
Amps 30.2 27.9 26.1 24.6 23.7 23.2 21.9 20.8 19.9 19.0 18.1 17.6 17.4 16.5 15.4 14.5 13.4 12.0
HI PR 296 284 273 261 255 250 240 231 221 211 203 198 194 187 180 172 166 160
LO PR 75 69 65 60 56 54 50 44 40 36 31 29 28 24 21 17 15 12
Specifications
Cooling Capacity, BTUH (Nominal) 59,500
Compressor
R.L. Amps 28.8
L.R. Amps 169.0
Condenser Fan Motor
Horsepower 1/3
R.L. Amps 2.3
L.R. Amps 3.6
Liquid Line, Inches O.D. 3/8
Suction Line, Inches O.D. 1 1/8
Refrigerant Charge (oz) 288
Power Supply 208/230-60-1
Min Circuit Ampacity 38.2
Max Overcurrent Device 60.0
Electric Conduit Size (in)
Power Supply 1/2 or 3/4
Low Voltage 1/2
Approximate Shipping Weight (Lbs) 345
RHE60A2A
Remote Heat Pump
Specification Sheet
Due to policy of continual product improvement,
the right is reserved to change specifications and
design without notice.

2
Cooling Performance Data For ARI Performance Data: See the ARI Directory, Product Data Booklet (PDB), or the product Service Manual.
Outdoor Ambient Temperature (F°)
65 75 85 95 105 115
Entering Indoor Wet Bulb Temperature (°F)
IDB*Airflow 596367715963677159636771596367715963677159636771
Delta T 18 16 12 - 18 16 12 - 18 16 12 - 18 16 12 - 18 16 12 - 17 15 11 -
2090 AMPS 16.6 17.0 17.5 - 17.9 18.3 18.9 - 19.4 19.9 20.5 - 20.7 21.2 21.9 - 22.0 22.6 23.3 - 23.3 23.9 24.7 -
HI PR 135 145 153 - 152 163 172 - 172 185 196 - 196 211 223 - 221 238 251 - 244 263 277 -
LO PR 59 63 68 - 62 66 72 - 65 69 75 - 68 72 79 - 71 76 83 - 74 78 86 -
Delta T 19 16 12 - 19 16 12 - 19 16 12 - 19 16 12 - 19 16 12 - 18 15 12 -
70 1900 AMPS 16.5 16.9 17.4 - 17.8 18.2 18.8 - 19.3 19.8 20.4 - 20.6 21.1 21.8 - 21.9 22.4 23.2 - 23.2 23.8 24.6 -
HI PR 134 144 152 - 150 162 171 - 171 184 194 - 195 210 221 - 219 236 249 - 242 261 275 -
LO PR 59 62 68 - 62 66 72 - 64 68 75 - 68 72 78 - 71 75 82 - 73 78 85 -
Delta T 20 17 13 - 20 17 13 - 20 17 13 - 20 17 13 - 20 17 13 - 18 16 12 -
1710 AMPS 16.2 16.6 17.1 - 17.5 17.9 18.5 - 19.0 19.5 20.1 - 20.3 20.8 21.5 - 21.6 22.1 22.8 - 22.8 23.4 24.2 -
HI PR 132 142 150 - 148 159 168 - 168 181 191 - 192 206 218 - 216 232 245 - 238 256 271 -
LO PR 58 61 67 - 61 65 71 - 63 67 73 - 66 71 77 - 70 74 81 - 72 77 84 -
DeltaT211916112119161121191611212016112119161120181510
2090 AMPS 16.7 17.1 17.7 18.3 18.1 18.5 19.1 19.8 19.6 20.1 20.7 21.5 20.9 21.4 22.1 23.0 22.3 22.8 23.6 24.4 23.6 24.1 25.0 25.9
HI PR 136 147 155 162 153 165 174 181 174 187 198 206 198 213 225 235 223 240 253 264 246 265 280 292
LO PR 60 63 69 74 63 67 73 78 65 70 76 81 69 73 80 85 72 77 84 89 74 79 86 92
DeltaT222016112220161122201611222017112220161120191511
75 1900 AMPS 16.6 17.0 17.6 18.2 17.9 18.4 19.0 19.7 19.5 19.9 20.6 21.4 20.8 21.3 22.0 22.8 22.1 22.7 23.4 24.3 23.4 24.0 24.8 25.7
HI PR 135 146 154 161 152 164 173 180 173 186 196 205 197 212 224 233 222 238 252 263 245 263 278 290
LO PR 59 63 69 73 62 66 73 77 65 69 75 80 68 73 79 84 71 76 83 88 74 79 86 91
DeltaT232117122321171223211712232117122321171221201611
1710 AMPS 16.4 16.8 17.3 17.9 17.7 18.1 18.7 19.4 19.2 19.6 20.3 21.0 20.5 21.0 21.7 22.5 21.8 22.3 23.0 23.9 23.1 23.6 24.4 25.3
HI PR 133 143 151 158 149 161 170 177 170 183 193 201 194 208 220 229 218 234 247 258 241 259 273 285
LO PR 58 62 67 72 61 65 71 76 64 68 74 79 67 71 78 83 70 75 82 87 73 77 84 90
DeltaT232219152322201623222016242320162322191621211814
2090 AMPS 16.9 17.3 17.8 18.5 18.2 18.6 19.3 20.0 19.8 20.2 20.9 21.7 21.1 21.6 22.3 23.2 22.5 23.0 23.8 24.7 23.8 24.4 25.2 26.1
HI PR 138 148 157 163 155 166 176 183 176 189 200 208 200 216 228 237 225 242 256 267 249 268 283 295
LO PR 60 64 70 74 64 68 74 79 66 70 77 82 69 74 81 86 73 77 84 90 75 80 87 93
DeltaT242320162423201624232016252420 16 24 23 20 16 23 22 19 15
80 1900 AMPS 16.8 17.2 17.7 18.4 18.1 18.5 19.1 19.8 19.6 20.1 20.8 21.6 21.0 21.5 22.2 23.0 22.3 22.9 23.6 24.5 23.6 24.2 25.0 26.0
HI PR 137 147 155 162 154 165 174 182 175 188 198 207 199 214 226 236 224 241 254 265 247 266 281 293
LO PR 60 64 69 74 63 67 73 78 66 70 76 81 69 73 80 85 72 77 84 89 75 79 87 92
DeltaT252421172625211726252117262522172624211724232016
1710 AMPS 16.5 16.9 17.4 18.1 17.8 18.2 18.8 19.5 19.3 19.8 20.5 21.2 20.7 21.2 21.9 22.7 22.0 22.5 23.3 24.1 23.3 23.8 24.6 25.6
HI PR 135 145 153 159 151 162 172 179 172 185 195 203 195 210 222 232 220 237 250 261 243 262 276 288
LO PR 59 62 68 73 62 66 72 77 64 69 75 80 68 72 79 84 71 75 82 88 73 78 85 91
RHE60A2A / BHA60TB002A
*Entering Dry Bulb Temperature.
NOTE: Darker shaded area with white lettering is ARI rating conditions, (95° ambient, 80° IDB + 67° IWB).
Lighter shaded area with black lettering is ACCA rating conditions, (95° ambient, 75° IDB + 63° IWB).
All Pressures are PSIG. All temperatures are in °F.
Low and high pressure are measured at gauge port.
Amps are total unit amps at a rated voltage of 230 VAC.
