Specification Sheet
14 SEER
RHF TempAssure™
Split System Heat Pump
High-efficiency Copeland Scroll Compressor with a Factory-
installed Sound Blanket. Fewer compressor parts mean less
wear and tear to give your unit longer life. This compressor is
hermetically sealed and features safeguards to protect it from
excessive temperatures, pressure and abnormal electrical
currents. In addition, an energy-saving design reduces internal
resistance and friction and increases operating efficiency.
Internal parts are spring isolated, and the entire compressor is
mounted on rubber cushions to help absorb vibrations. A heavy-
gauge sound blanket is factory installed to further reduce sound.
Efficiency and Performance. Simplicity of design and
construction make this unit economical to operate. The
balance of economy and efficiency makes RHF units ideal for
replacement or new construction. The RHF line delivers SEERs up
to 15 and Heating Season Performances (HSPF) up to 8.5 when
paired with high-efficiency Amana®brand blower coils, which
can help reduce your cooling and heating costs.
System Protection. Compressor internal overload, high-pressure
switch, and a pressure-relief valve protects the compressor
and other components from damage. A low-pressure cutoff
switch has been added on the suction line to detect a loss of
refrigerant charge. A protective time delay works to prevent
short cycling. A 5-minute delay occurs whenever the power
supply or the indoor thermostat’s signal is interrupted.
Factory-installed Bi-Flow Liquid Line Filter Drier. Standard
protection adds to reliability by helping to keep refrigerant clean
and dry. Clean and dry refrigerant ensures longer life for the
compressor and expansion devices.
Quiet Condenser Fan with Vertical Air Discharge. Quiet, efficient
fan and motor reduce operating sounds and large blades move
high volumes of air with lower power requirement. Draw through
air flow directs operating sound and hot air away from neighbors,
shrubs and buildings for increased installation versatility.
Efficient Cubed Coil. This space-saving design provides more
active square feet of cooling surface for increased cooling
efficiency. The compact cubed coil forms the body of the unit.
The unit's compact footprint allows for versatile applications.
Matched Indoor Blower Coils and A-Coils. These coils, in
combination with Amana®brand systems, make for optimum
operating performance and efficiency. Plastic drain pans used
on the indoor section are threaded for easy attachment of drain
lines. All coils are fully leak tested before leaving the factory.
Service Valves. Solid brass service valves and gauge port are
angled at 30° with enough clearance to easily and quickly
service unit. The service panel swings open at the corner for
effective service from 2 directions. Inside, a pre-wired control
panel speeds installation. Minimal quantity of numbered and
color-coded wires to assure fast field wiring. Compressor and
tubing access from side and top give plenty of internal room for
installation and removal of parts.
Cabinet and Construction. The high-quality sheet metal cabinet
has a long-lasting, corrosion-resistant painted finish. A premium
coil grille adds rigidity to better protect the unit as well as
improving appearance. When properly anchored, meets
the 2001 Florida Building Code unit integrity requirements for
hurricane-type winds.
LIMITED WARRANTY
• Lifetime—Compressor
• 10-Year—Parts
The Amana™ brand RHF TempAssure™ Heat Pumps
offer energy efficiencies and operating sound
levels that are among the best in the heating and
cooling industry. Our pioneering cubed-coil design
provides superior heating and cooling comfort.
Reliable components, quality manufacturing, high
efficiency, easy installation and maintenance,
make this unit one of the best values on the market.
U
RL
C
U
RL
Nominal Cooling Capacity:
24,000 - 60,000 BTUH
Nominal Heating Capacity:
22,700 - 45,000 BTUH
9.0 HSPF

Specification Sheet
www.amana-hac.com
2
Nomenclature
RHF 24
Product Type
System Type
H: Heat Pump
Product Family
F: 14+ SEER
(for Heat Pump
Models)
C2 
Revision
(C Indicates
Two-Tone
Color
Scheme)
Voltage
2: 208-230-1-60
Marketing Designator
C: TempAssure
R: Remote
Nominal Capacity
24: 24,000 Btuh
30: 30,000 Btuh
36: 36,000 Btuh
42: 42,000 Btuh
48: 48,000 Btuh

Specification Sheet
www.amana-hac.com 3
Specifications for C2A Models
Square Base Height
RHF24C2A 29½” 29½”
RHF30C2A 29½” 29½”
RHF36C2A 35⅝” 33½”
RHF42C2A 35⅝” 33½”
RHF48C2A 35⅝” 33½”
RHF24C2A RHF30C2A RHF36C2A RHF42C2A RHF48C2A
CAPACITIES
Nominal Cooling Capacity (BTUH) 24,000 29,000 36,000 42,000 48,500
Nominal Heating Capacity (BTUH) 22,700 28,500 34,500 39,900 45,000
COMPRESSOR
Type Scroll Scroll Scroll Scroll Scroll
R.L. AMPS 14.0 12.2 18.0 20.4 23.5
L.R. AMPS 56 67 83 95 109
CONDENSER FAN MOTOR
Horsepower 1/12 1/12 1/6 1/6 1/6
R.L. AMPS 0.6 0.6 1.1 1.1 1.1
L.R. AMPS 1.0 1.0 1.9 1.9 1.9
REFRIGERATION SYSTEM
Liquid Line (“O.D.) ⅜"
Suction Line (“O.D.) ¾" ¾" ⅞"⅞"1⅛"
Refrigerant Charge (oz.) 140 190 235 365 265
Design Subcooling Cooling Mode 9±3 9±3 9±3 9±3 9±3
Shipped With Orifice .055 .068 .076 .082 .092
ELECTRICAL
Power Supply 208/230-1
Minimum Circuit Ampacity 18.2 15.9 23.7 26.6 30.4
Maximum Overcurrent Device 30 25 40 45 50
ELECTRICAL CONDUIT SIZE
Power Supply ½ or ¾
Low Voltage ½
APPROXIMATE SHIPPING WEIGHTS
Weight (lbs.) 211 230 293 293 298
*Unit is charged with refrigerant for 15' of ⅜” liquid line. System charge must be adjusted per Installation Instructions Final Charge
Procedure.
** Installer will need to supply ⅞” to 1⅛” adapters for suction line connections.
Dimensions

Specification Sheet
www.amana-hac.com
4
Specifications for C2C Models
Square Base Height
RHF24C2C 29½” 29½”
RHF30C2C 29½” 29½”
RHF36C2C 35⅝” 33½”
RHF42C2C 35⅝” 33½”
RHF48C2C 35⅝” 33½”
RHF24C2C RHF30C2C RHF36C2C RHF42C2C RHF48C2C
CAPACITIES
Nominal Cooling Capacity (BTUH) 24,000 29,000 36,000 42,000 48,500
Nominal Heating Capacity (BTUH) 22,700 28,500 34,500 39,900 45,000
COMPRESSOR
Type Scroll Scroll Scroll Scroll Scroll
R.L. AMPS 14.0 12.2 18.0 20.4 23.5
L.R. AMPS 56 67 83 95 109
CONDENSER FAN MOTOR
Horsepower 1/12 1/12 1/6 1/6 1/6
R.L. AMPS 0.6 0.6 1.1 1.1 1.1
L.R. AMPS 1.0 1.0 1.9 1.9 1.9
REFRIGERATION SYSTEM
Liquid Line (“O.D.) ⅜"
Suction Line (“O.D.) ¾" ¾" ⅞"⅞"1⅛"
Refrigerant Charge (oz.) 140 190 235 365 265
Design Subcooling Cooling Mode 9±3 9±3 9±3 9±3 9±3
Shipped With Orifice .055 .068 .076 .082 .092
ELECTRICAL
Power Supply 208/230-1
Minimum Circuit Ampacity 18.2 15.9 23.7 26.6 30.4
Maximum Overcurrent Device 30 25 40 45 50
ELECTRICAL CONDUIT SIZE
Power Supply ½ or ¾
Low Voltage ½
APPROXIMATE SHIPPING WEIGHTS
Weight (lbs.) 211 230 293 293 298
*Unit is charged with refrigerant for 15' of ⅜” liquid line. System charge must be adjusted per Installation Instructions Final Charge
Procedure.
** Installer will need to supply ⅞” to 1⅛” adapters for suction line connections.
Dimensions

Specification Sheet
www.amana-hac.com 5
Cooling Specifications
RHF42C2* / BBA60A2A + CHA60TCC
Conditions: 80° ID DB, 67° ID WB @ 1,400 CFM
RHF30C2* / BBA36A2A + CHA36TCC
Conditions: 80° ID DB, 67° ID WB @ 1,050 CFM
RHF36C2* / BBA48A2A + CHA42TCC
Conditions: 80° ID DB, 67° ID WB @ 1,200 CFM
RHF24C2* / BBA24A2A + CHA30TCC
Conditions: 80° ID DB, 67° ID WB @ 800 CFM
RHF48C2* / BBA60A2A + CHA60TCC
Conditions: 80° ID DB, 67° ID WB @ 1,600 CFM
Outdoor
Temp. °F Total BTUH Sensible BTUH Latent BTUH Total Watts
75° 26,400 18,480 7,920 1,790
80° 26,050 18,496 7,555 1,845
85° 25,700 18,504 7,196 1,900
90° 25,400 18,542 6,858 1,950
95° 25,100 18,574 6,526 2,000
100° 24,450 18,460 5,990 2,040
105° 23,800 18,326 5,474 2,410
110° 22,950 17,672 5,279 2,120
115° 22,100 17,017 5,083 2,160
TVA Conditions @ 95° OD DB, 75° ID DB, 63° ID WB
95° 23,300 18,407 4,893 1,920
Outdoor
Temp. °F Total BTUH Sensible BTUH Latent BTUH Total Watts
75° 30,500 20,435 10,065 2,160
80° 30,100 20,468 9,632 2,225
85° 29,700 20,493 9,207 2,290
90° 29,350 20,545 8,805 2,350
95° 29,000 20,590 8,410 2,410
100° 28,300 20,518 7,783 2,460
105° 27,600 20,424 7,176 2,950
110° 26,550 19,647 6,903 2,550
115° 25,500 18,870 6,630 2,590
TVA Conditions @ 95° OD DB, 75° ID DB, 63° ID WB
95° 26,900 20,444 6,456 2,320
Outdoor
Temp. °F Total BTUH Sensible BTUH Latent BTUH Total Watts
75° 43,600 30,084 13,516 2,970
80° 43,050 30,135 12,915 3,060
85° 42,500 30,175 12,325 3,150
90° 42,000 30,240 11,760 3,230
95° 41,500 30,295 11,205 3,310
100° 40,450 30,135 10,315 3,375
105° 39,400 29,944 9,456 4,200
110° 37,950 28,842 9,108 3,500
115° 36,500 27,740 8,760 3,560
TVA Conditions @ 95° OD DB, 75° ID DB, 63° ID WB
95° 18,200 14,378 3,822 1,460
Outdoor
Temp. °F Total BTUH Sensible BTUH Latent BTUH Total Watts
75° 38,400 25,728 12,672 2,590
80° 37,950 25,806 12,144 2,670
85° 37,500 25,875 11,625 2,750
90° 37,050 25,935 11,115 2,815
95° 36,600 25,986 10,614 2,880
100° 35,700 25,883 9,818 2,940
105° 34,800 25,752 9,048 3,600
110° 33,500 24,790 8,710 3,050
115° 32,200 23,828 8,372 3,100
TVA Conditions @ 95° OD DB, 75° ID DB, 63° ID WB
95° 33,900 25,764 8,136 2,270
Outdoor
Temp. °F Total BTUH Sensible BTUH Latent BTUH Total Watts
75° 50,000 34,000 16,000 3,480
80° 49,400 34,086 15,314 3,585
85° 48,800 34,160 14,640 3,690
90° 48,200 34,222 13,978 3,785
95° 47,600 34,272 13,328 3,880
100° 46,400 34,104 12,296 3,960
105° 45,200 33,900 11,300 5,040
110° 43,550 32,663 10,888 4,105
115° 41,900 31,425 10,475 4,170
TVA Conditions @ 95° OD DB, 75° ID DB, 63° ID WB
95° 38,500 30,030 8,470 3,180

Specification Sheet
www.amana-hac.com
6
RHF30C2* / CHA36TCC / BBA36A2A
Conditions: 000 CFM Indoor Air @ 70° db
Outdoor
Ambient
°F.
Basic Unit Without
Auxiliary Heat
Capacity of Unit
With Auxiliary Heat
Capacity
Btuh
C.O.P. 4.8 kW 9.6 kW 14.4 kW
19.2,
24 &
28.8 kW
65 37,000 4.26 53,400 69,800 86,200 N/A
60 35,000 4.12 51,400 67,800 84,200 N/A
55 32,900 3.95 49,300 65,700 82,100 N/A
50 30,800 3.77 47,200 63,600 80,000 N/A
45 28,500 3.57 44,900 61,300 77,700 N/A
40 26,500 3.38 42,900 59,300 75,700 N/A
35 24,400 3.19 40,800 57,200 73,600 N/A
30 22,700 2.64 39,100 55,500 71,900 N/A
25 20,900 2.50 37,300 53,700 70,100 N/A
20 19,300 2.36 35,700 52,100 68,500 N/A
15 17,500 2.20 33,900 50,300 66,700 N/A
10 15,700 2.02 32,100 48,500 64,900 N/A
5 13,900 1.84 30,300 46,700 63,100 N/A
0 12,200 1.65 28,600 45,000 61,400 N/A
-5 10,400 8.50 26,800 43,200 59,600 N/A
-10 8,500 1.22 24,900 41,300 57,700 N/A
RHF36C2* / CHA42TCC / BBA48A2A
Conditions: 1,200 CFM Indoor Air @ 70° db
Outdoor
Ambient
°F.
Basic Unit
Without
Auxiliary Heat
Capacity of Unit
With Auxiliary Heat
Capacity
Btuh
C.O.P. 4.8 kW 9.6 kW 14.4
kW
19.2
kW
24 &
28.8
kW
65 44,700 4.06 61,100 77,500 93,900 110,300 N/A
60 42,300 3.92 58,700 75,100 91,500 107,900 N/A
55 39,800 3.76 56,200 72,600 89,000 105,400 N/A
50 37,200 3.59 53,600 70,000 86,400 102,800 N/A
45 34,500 3.39 50,900 67,300 83,700 100,100 N/A
40 32,000 3.21 48,400 64,800 81,200 97,600 N/A
35 29,500 3.03 45,900 62,300 78,700 95,100 N/A
30 28,300 2.88 44,700 61,100 77,500 93,900 N/A
25 26,100 2.72 42,500 58,900 75,300 91,700 N/A
20 24,000 2.56 40,400 56,800 73,200 74,840 N/A
15 21,900 2.38 38,300 54,700 71,100 87,500 N/A
10 19,600 2.19 36,000 52,400 68,800 85,200 N/A
5 17,400 1.99 33,800 50,200 66,600 83,000 N/A
0 15,200 1.78 31,600 48,000 64,400 80,800 N/A
-5 12,900 1.56 29,300 45,700 62,100 78,500 N/A
-10 10,600 1.31 27,000 43,400 59,800 76,200 N/A
RHF42C2* / CHA60TCC / BBA60A2A
Conditions: 1,400 CFM Indoor Air @ 70° db
Outdoor
Ambient
°F.
Basic Unit
Without
Auxiliary Heat
Capacity of Unit
With Auxiliary Heat
Capacity
Btuh
C.O.P. 4.8 kW 9.6 kW 14.4 kW 19.2 kW 24 &
28.8 kW
65 51,800 4.35 68,200 84,600 101,000 117,400 N/A
60 49,000 4.20 65,400 81,800 98,200 114,600 N/A
55 46,100 4.03 62,500 78,900 95,300 111,700 N/A
50 43,100 3.85 59,500 75,900 92,300 108,700 N/A
45 39,900 3.63 56,300 72,700 89,100 105,500 N/A
40 37,100 3.44 53,500 69,900 86,300 102,700 N/A
35 34,200 3.25 50,600 67,000 83,400 99,800 N/A
30 30,900 3.04 47,300 63,700 80,100 96,500 N/A
25 28,600 2.87 45,000 61,400 77,800 94,200 N/A
20 26,300 2.70 42,700 59,100 75,500 77,140 N/A
15 23,900 2.51 40,300 56,700 73,100 89,500 N/A
10 21,500 2.31 37,900 54,300 70,700 87,100 N/A
5 19,000 2.10 35,400 51,800 68,200 84,600 N/A
0 16,600 1.88 33,000 49,400 65,800 82,200 N/A
-5 14,200 1.64 30,600 47,000 63,400 79,800 N/A
-10 11,600 1.38 28,000 44,400 60,800 77,200 N/A
RHF24C2* / CHA30TCC / BBA24A2A
Conditions: 800 CFM Indoor Air @ 70° db
Outdoor
Ambient
°F.
Basic Unit Without
Auxiliary Heat
Capacity of Unit
With Auxiliary Heat
Capacity
Btuh
C.O.P. 4.8 kW 9.6 kW 14.4 kW
19.2, 24
& 28.8
kW
65 29,500 4.16 45,900 62,300 78,700 N/A
60 27,900 4.02 44,300 60,700 77,100 N/A
55 26,300 3.86 42,700 59,100 75,500 N/A
50 24,500 3.69 40,900 57,300 73,700 N/A
45 22,700 3.49 39,100 55,500 71,900 N/A
40 21,100 3.31 37,500 53,900 70,300 N/A
35 19,500 3.12 35,900 52,300 68,700 N/A
30 18,100 2.86 34,500 50,900 67,300 N/A
25 16,700 2.70 33,100 49,500 65,900 N/A
20 15,400 2.55 31,800 48,200 64,600 N/A
15 14,500 2.37 30,900 47,300 63,700 N/A
10 12,500 2.19 28,900 45,300 61,700 N/A
5 11,100 1.99 27,500 43,900 60,300 N/A
0 9,700 1.78 26,100 42,500 58,900 N/A
-5 8,300 1.56 24,700 41,100 57,500 N/A
-10 6,800 1.31 23,200 39,600 56,000 N/A
Heating Specifications

RHF48C2* / CHA60TCC / BBA60A2A
Conditions: 1,600 CFM Indoor Air @ 70° db
Outdoor
Ambient
°F.
Basic Unit
Without
Auxiliary Heat
Capacity of Unit
With Auxiliary Heat
Capacity
Btuh
C.O.P. 4.8 kW 9.6 kW 14.4
kW
19.2
kW 24 kW 28.8 kW
65 58,300 4.29 74,700 91,100
107,500 123,900 140,300 N/A
60 55,200 4.14 71,600 88,000
104,400 120,800 137,200 N/A
55 52,000 3.97 68,400 84,800
101,200 117,600 134,000 N/A
50 48,600 3.79 65,000 81,400 97,800
114,200 130,600 N/A
45 45,000 3.66 61,400 77,800 94,200
110,600 127,000 N/A
40 41,800 3.58 58,200 74,600 91,000
107,400 123,800 N/A
35 38,500 3.39 54,900 71,300 87,700
104,100 120,500 N/A
30 36,800 3.09 53,200 69,600 86,000
102,400 118,800 N/A
25 33,900 2.92 50,300 66,700 83,100 99,500
115,900 N/A
20 31,300 2.75 47,700 64,100 80,500 96,900
113,300 N/A
15 28,400 2.55 44,800 61,200 77,600 94,000
110,400 N/A
10 25,500 2.35 41,900 58,300 74,700 91,100
107,500 N/A
5 22,600 2.13 39,000 55,400 71,800 88,200
104,600 N/A
0 19,700 1.91 36,100 52,500 68,900 85,300
101,700 N/A
-5 16,800 1.67 33,200 49,600 66,000 82,400 98,800 N/A
-10 13,800 1.40 30,200 46,600 63,000 79,400 95,800 N/A
Heating Specifications (cont.)
Specification Sheet
www.amana-hac.com 7

Performance Ratings
Heat Pump
Model Indoor Model
Cooling
Capacity
(BTUH)
SEER
Rating
EER
Rating
47˚F
Heating
Capacity
(BTUH)
47˚F Co-
efficient
of Perfor-
mance
(COP)
HSPF
Rating
17˚F
Heating
Capacity
(BTUH
17˚F Co-
efficient
of Perfor-
mance
ARI Ref. # Decibel
RHF24C2*
ARPT032-00A-1
CCH24FCD+TXV+BDK
CCH30FCD+TXV+BDK
CHH24TCD+BDK
CHH30TCD+BDK
ARUF032-00A-1
AEPT036-00A-1
22,000
23,400
23,800
23,400
23,800
22,000
23,200
14.00
13.00
14.00
13.00
14.00
14.00
14.50
12.70
11.50
12.30
11.50
12.30
12.70
12.50
22,000
22,800
23,000
22,800
23,000
22,000
22,200
3.20
3.40
3.40
3.40
3.40
3.20
3.20
7.50
8.10
8.30
8.10
8.30
7.50
8.25
13,600
14,000
14,200
14,000
14,200
13,600
13,600
2.10
2.30
2.30
2.30
2.30
2.10
2.10
410069
411026
411027
411031
411032
468141
487906
72
RHF30C2*
ARPT042-00A-1
CCH30FCD+TXV+BDK
CHH30TCD+BDK
ARUF042-00A-1
AEPT060-00A-1
28,000
28,400
28,400
28,000
28,000
14.00
13.00
13.00
14.00
14.50
12.70
11.50
11.50
12.70
12.50
28,000
29,400
29,400
28,000
28,400
3.40
3.40
3.40
3.40
3.40
8.00
8.30
8.30
8.00
8.25
17,600
18,400
18,400
17,600
17,800
2.30
2.30
2.30
2.30
2.30
410078
411099
411105
468135
487905
72
RHF36C2*
ARPT049-00A-1
CCH36FCD+TXV+BDK
CCH48FCD+TXV+BDK
CHH36TCD+BDK
CHH48TCD+BDK
ARUF048-00A-1
ARPF048-00B-1
AEPT060-00A-1
AEPT036-00A-1
34,000
34,000
35,000
34,000
35,000
34,000
34,000
34,000
33,200
14.00
13.00
14.00
13.00
14.00
14.00
14.00
14.50
13.50
12.70
11.50
12.30
11.50
12.30
12.70
12.70
12.50
12.50
34,000
35,400
36,000
35,400
36,000
34,000
34,000
35,000
34,200
3.40
3.40
3.50
3.40
3.50
3.40
3.40
3.40
3.40
8.00
8.30
8.50
8.30
8.50
8.00
8.00
8.25
8.15
21,600
22,400
22,800
22,400
22,800
21,600
21,600
22,200
21,600
2.30
2.30
2.40
2.30
2.40
2.30
2.30
2.30
2.30
410079
411184
411185
411190
411191
468145
468781
487904
487908
73
RHF42C2*
ARPT049-00A-1
CCH48FCD+TXV+BDK
CCH60FCD+TXV+BDK
CHH48TCD+BDK
CHH60TCD+BDK
ARUF048-00A-1
AEPT060-00A-1
39,000
38,500
40,000
38,500
40,000
39,000
39,000
14.00
13.00
13.00
13.00
13.00
14.00
14.50
12.60
11.50
11.50
11.50
11.50
12.60
12.50
39,000
41,000
39,500
41,000
39,500
39,000
39,000
3.40
3.30
3.40
3.30
3.40
3.40
3.40
8.00
7.80
8.30
7.80
8.30
8.00
8.25
24,400
25,600
24,600
25,600
24,600
24,400
24,000
2.30
2.20
2.30
2.20
2.30
2.30
2.30
410080
411274
411275
411279
411280
468137
487907
74
RHF48C2*
ARPT061-00A-1
CCH48FCD+TXV+BDK
CCH60FCD+TXV+BDK
CHH60TCD+BDK
ARUF061-00A-1
ARPF060-00B-1
AEPT060-00A-1
47,000
45,000
46,000
46,000
47,000
47,000
45,000
14.00
13.00
14.00
14.00
14.00
14.00
14.00
12.60
11.50
12.30
12.30
12.60
12.60
12.50
46,000
47,000
46,000
46,000
46,000
46,000
45,000
3.40
3.10
3.40
3.40
3.40
3.40
3.40
8.00
7.30
8.30
8.30
8.00
8.00
8.15
28,000
28,600
28,000
28,000
28,000
28,000
27,000
2.30
2.10
2.30
2.30
2.30
2.30
2.30
410077
411356
411357
411360
468128
468780
487903
72
Specification Sheet
www.amana-hac.com
8
Form: PDB-RHF
Date: 8/04
Supercedes 6/04
Amana®is a trademark of Maytag Corporation and used under license to Goodman Company, L.P. All rights reserved.
Our continuing commitment to quality products may mean a change in specifications without notice.
Copyright © 2004 Goodman Company, L.P. · Houston, Texas · Printed in U.S.A.
Thermostats
Accessories
Model Description RHF24C2* RHF30C2* RHF36C2* RHF42C2* RHF48C2*
LAC03A Low Ambient Control X X X X X
FSK01A¹ Freeze Protection Kit X X X X X
ASAS Electronic Air Cleaner X X X X X
AMU Media Air Cleaner X X X X X
FFK03A Fossil Fuel Kit X X X X X
HSK10A Hard Start Kit X X X X X
OT18-60A² Outdoor Thermostat X X X X X
1) Installed on indoor coil
2) Required for heat pump applications where ambient temperatures fall below 0 °F with 50% or higher relative humidity.
1213403 1213404 1213406 1213407 1213410
Changeover Manual Manual Manual or Auto Manual Manual
Programmable No No 5+2 5+2 5+2
Cool 11221
Heat 22322
Shape Rectangular Rectangular Rectangular Rectangular Rectangular
Battery Powered No No No Yes No
Analog/Digital Analog Digital Digital Digital Digital
EM Heat Yes Yes Yes No Yes
Color White White Beige White White
