Amana Distinctions DCF3305A User manual

Owners Manual
Contents
Important Safety Information ......... 3
Adjusting Burner Flame ................. 6
Cookware Suggestions ................. 8
Using t e Range............................ 9
Custom Features ......................... 12
Displays and Signals ................... 13
Using t e Oven Control ............... 14
Cooking
Baking ...................................... 19
Broiling ..................................... 22
Roasting ................................... 23
Braising .................................... 24
Care and Cleaning....................... 25
Troubles ooting ........................... 28
Amana Warranty ......................... 30
Manuel du propriétaire ................. 31
TM
Gas Range
Keep instructions for future reference.
Be sure manual stays with range.
36-32076801-0
Covering DCF3305A
and TMACF3325A

2
Recognize Safety Symbols, Words, Labels
DANGER
!
DANGERImmediate azards w ic WILL result in severe personal
injury or deat .
WARNING
!
WARNINGHazards or unsafe practices w ic COULD result in severe
personal injury or deat .
CAUTION
!
CAUTIONHazards or unsafe practices w ic COULD result in minor
personal injury or product or property damage.
What You Need to Know
about Safety Instructions
Warning and Important Safety
Instructions appearing in this manual
are not meant to cover all possible
conditions and situations that may
occur. Common sense, caution, and
care must be exercised when installing,
maintaining, or operating range.
Always contact your dealer, distributor,
service agent, or manufacturer about
problems or conditions you do not
understand.
Please take t e time to complete t e registration card and return promptly.
If registration card is missing, call Amana Consumer Affairs Department.
W en contacting Amana, provide product information from serial plate found
on rig t side of storage door opening:
Model Number __________________________________
Manufacturing (P) Number _________________________
Serial Number (S/N) ______________________________
Purc ase Date __________________________________
Dealer Name ___________________________________
Dealer Address _________________________________
Dealer P one ___________________________________
Keep this manual and your sales re eipt together in a safe pla e for
future reference or if warranty service is required.
For answers to questions or to locate an aut orized servicer, call
1-800-NAT-LSVC (1-800-628-5782) inside USA or 319-622-5511 outside
USA. Warranty servi e must be performed by an authorized servi er.
Amana Appliances also recommends contacting an aut orized servicer if
service is required after warranty expires.
To register your product electronically, get more
information on your range or other mana products,
visit our Web site
www.amana.com
or
call Consumer ffairs Department at
1-800-843-0304
sure Extended
Service Plan
Amana Appliances offers long-term
service protection for this new range.
Asure™Extended Service Plan,
covering functional parts, labor, and
travel charges, is specially designed to
supplement a strong warranty.
Call 1-800-528-2682 for information.
Parts and ccessories
Purchase replacement parts and
additional accessories such as cleaning
supplies by phone. To order accessories
for your Amana product, call
1-800-843-0304 inside USA or
319-622-5511 outside USA.
Save Time and Money
If something seems unusual, please
check “Troubleshooting” section,
which is designed to help you solve
problems before calling service.
If you have a question, call us at
[phone] or write us at:
Consumer Affairs Department
Amana Appliances
2800 - 220th Trail
Amana, Iowa 52204
Remember to include model number
of your appliance and your phone
number.
Thank you for buying an Amana Range!
5DWLQJ
3ODWH

3
IMPORTANT SAFETY INFORMATION
SAVE THESE INSTRU TIONS
WARNING
!
To redu e risk of the applian e tipping, it must be se ured by a
properly installed anti-tip bra ket. To verify bra ket has been
installed properly, remove the storage drawer or panel and look
under the range with a flashlight. Bra ket must be engaged in
the rear orner of the range.
WARNING
!
To avoid personal injury, do not
sit, stand or lean on oven door
or oven drawer.
WARNING
!
To avoid risk of electrical s ock,
personal injury, or deat , verify
your range as been properly
grounded and always
disconnect it from main power
supply before servicing.
 ALL RANGES CAN TIP
 INJURY TO PERSONS
COULD RESULT
 INSTALL ANTI-TIP
BRACKET PACKED
WITH RANGE
 REFER TO
INSTALLATION
INSTRUCTIONS WARNING
!
If t e information in t is manual is
not followed exactly, a fire or
explosion may result causing
property damage, personal injury
or deat .
 Do not store or use gasoline or
ot er flamable vapors and
liquids in t e vicinity of t is or
any ot er appliance.
 What To Do If You
Smell Gas
 Do not try to lig t any
appliance.
 Do not touc any electrical
switc .
 Do not use any p one in your
building.
 Immediately call your gas
supplier from a neig bors
p one. Follow t e gas
suppliers instructions.
 If you cannot reac your gas
supplier, call t e fire
department.
 Installation and service must
be performed by a qualified
installer, service agency or t e
gas supplier.
CAUTION
!
DO NOT TOUCH SURFACE BURNERS OR AREAS NEAR BURNERS
Areas near surface burners may become ot enoug to cause burns.
During and after use do not touc , let clot ing or ot er flammable
materials touc or contact surface burners or areas near surface burners
until t ey ave ad enoug time to cool. T ese areas include t e
rangetop and backguard.
CAUTION
!
DO NOT TOUCH GAS BURNERS OR INTERIOR SURFACES OF
OVENInterior surfaces of an oven become ot enoug to cause burns.
During and after use do not touc , let clot ing or ot er flammable
materials touc , or contact eated interior surfaces of t e oven until t ey
ave ad enoug time to cool. Ot er range surfaces t at may become
ot enoug to cause burns are t e oven door and oven vent at t e
backguard.
CAUTION
!
To avoid fire or smoke damage,
 remove any flammable materials from storage drawer. Items like
plastic containers and paper manuals can melt or burn.
 clean excess spills before starting a self-clean cycle.

4
ALL APPLIANCES
1. Proper InstallationBe sure your
appliance is properly installed and
grounded by a qualified tec nician.
2. Never Use Your Appliance for
Warming or Heating t e Room.
3. Do Not Leave C ildren Alone
C ildren s ould not be alone or
unattended in t e area w ere t e appliance is in
use. T ey s ould never be allowed
to sit or stand on any part of t e appliance.
4. Wear Proper ApparelLoose fitting or anging
garments s ould never be worn w ile using
appliance.
5. User ServicingDo not repair or replace any part
of t e appliance unless specifically recommended
in t e manual. All ot er servicing s ould be referred
to a qualified tec nician.
6. Storage in or on ApplianceFlammable materials
s ould not be stored in an oven or near surface
units.
7. Do Not Use Water On Grease FiresSmot er fire
or flame, or use dry c emical or foam-type
extinguis er.
8. Use Only Dry Pot oldersMoist or damp pot olders
on ot surfaces may result in burns from steam.
Do not let pot older touc elements. Do not use a
towel or ot er bulky clot .
SURFACE BURNERS
1. Use Proper Pan SizeT is
appliance is equipped wit one
or more surface burners of different sizes. Select
utensils aving flat bottoms large enoug to cover
t e surface burner. T e use of undersized utensils
will expose a portion of t e burner to direct contact
and may result in ignition of clot ing. Use of
oversized utensils concentrates eat on cooking
surface and can cause damage to range. Proper
relations ip of utensil to burner improves efficiency.
2. Never Leave Surface Burners UnattendedBoilover
causes smoking and greasy spillovers t at may ignite.
3. Make Sure Reflector Pans or Drip Bowls Are in
PlaceAbsence of t ese pans or bowls during
cooking may subject wiring or components
underneat to damage.
4. Protective LinersDo not use aluminum foil to line
surface burner drip bowls or oven bottom, except as
suggested in t e manual. Improper installation of t ese
liners may result in a risk of electric s ock, or fire.
5. Glazed Cooking UtensilsOnly certain types of
glass, ceramic, eart ware, or ot er glazed utensils
are suitable for rangetop service wit out breaking
due to sudden c ange in temperature.
6. Utensil Handles S ould Be Turned Inward and Not
Extended Over Adjacent Surface BurnersTo
reduce t e risk of burns, ignition of flammable
materials, and spillage due to unintentional contact
wit t e utensil, t e andle of a utensil s ould be
positioned so t at it is turned inward, and does not
extend over adjacent surface burners.
IMPORTANT SAFETY INFORMATION (contd)
SAVE THESE INSTRU TIONS
CAUTION
!
Do not store items of interest to hildren in
abinets above a range or on the ba kguard of a
rangec ildren climbing on t e range to reac items
could be seriously injured.
California Safe Drinking Water
and Toxi Enfor ement A t (Proposition 65)
T e Governor of California is required to publis a
list of substances known to t e state of California to
cause cancer or reproductive arm and requires
businesses to warn customers of potential exposures
to suc substances.
T is appliance may contain or produce a c emical or
c emicals w ic can cause deat or serious illness
and w ic are known to t e State of California to
cause cancer, birt defects, or ot er reproductive
arm. To reduce t e risk from substances in t e fuel
or from fuel combustion, make sure t is appliance is
installed, operated and maintained according to t e
instructions provided.
CAUTION
!
To avoid delayed or improper ignition, do not obstruct
t e flow of combustion or ventilation air.

5
OVENS
1. Use Care W en Opening
DoorLet ot air or steam
escape before removing or
replacing food.
2. Do Not Heat Unopened Food
ContainersBuild-up of
pressure may cause container to burst and
result in injury.
3. Keep Oven Vent Ducts Unobstructed.
4. Placement of Oven RacksAlways place oven
racks in desired location w ile oven is cool. If rack
is removed w ile oven is ot, do not let pot older
contact ot eating element in oven.
5. Protective LinersDo not use aluminum foil to line
drip bowls, oven racks or oven bottoms. Improper
installation of t ese liners may result in a risk of
electrical s ock, or fire.
SELF-CLEANING OVENS
1. Do Not Clean Door GasketT e door gasket is
essential for a good seal. Care s ould be taken
not to rub, damage, or move t e gasket.
2. Do Not Use Oven CleanersNo commercial oven
cleaner or oven liner protective coating of any kind
s ould be used in or around any part of t e liner.
3. Clean Only Parts Listed in Manual.
4. Before Self-Cleaning t e OvenRemove broiler pan,
oven racks, and ot er utensils.
5. Remove All Items From Rangetop and Backguard.
VENTILATION HOODS
1. Clean Ventilating Hoods FrequentlyGrease s ould
not be allowed to accumulate on ood or filter.
2. W en flaming foods under t e ood, turn t e fan on.
In Case of Fire
Fires can occur as a result of over
cooking or excessive grease. T oug a
fire is unlikely, if one occurs, proceed as
follows:
Surfa e Burner Fire
1. Smot er t e fire wit a nonflammable lid or baking
soda, or use a Class ABC or BC extinguis er.
Not water. Not salt. Not flour.
2. As soon as it is safe to do so, turn t e surface
controls to OFF. Turn off power at main circuit
breaker or fuse box. Turn off gas supply.
Oven Fires
1. If you see smoke from your oven, do not open
oven door.
2. Turn off oven.
3. As an added precaution, turn off power at main
circuit breaker or fuse box. Turn off gas supply.
4. Turn on vent to remove smoke.
5. Allow food or grease to burn itself out in oven.
6. If smoke and fire persist, call fire department.
7. If t ere is any damage to components, call an
aut orized servicer before using range.
IMPORTANT SAFETY INFORMATION (contd)
SAVE THESE INSTRU TIONS
!Precautions
 Do not cook food directly on
rangetop surface, always use
cookware.
 Do not mix ouse old cleaning products. C emical
mixtures may interact wit objectionable or even
azardous results.
 Do not put plastic items on warm cooking areas.
T ey may melt and stick.
 Oven door contains a glass window. W ile t e
window is built to be sturdy and strong, it is still glass
and needs to be treated wit care.
 Do not lift or move range by grasping oven door
andle. T is can result in window glass breaking or
s attering.
 Do not slide roug metal objects across rangetop
surface. Scratc ing or metal marking can result.
 Do not leave fat eating unless you remain nearby.
Fat can ignite if over eated by spilling onto ot
surfaces.
 Do not allow pots to boil dry as t is can cause
damage to cooking surface and pan.
 Do not use rangetop surface as a cutting board.
 Do not use range for storage or as a display counter.
DELA ED IGNITION
Surface burners
Burner s ould ignite wit in 4 seconds. If burner does not
ignite wit in 4 seconds, turn control knob to OFF and
follow directions for installing burner caps in Adjusting
Surface Burners. Try again. If burner still does not ignite
wit in 4 seconds, contact an aut orized servicer.
Bake and broil burner flame
Allow no more t an 40-60 seconds before burner ignites
and eat is felt. To c eck for eat, open oven door to first
stop and place and over oven door. If eat is not felt,
turn temperature control knob to OFF. If burner
repeatedly fails to ignite, contact an aut orized servicer.

6
Adjusting Surface Burner Flame
Placing burner caps
Burner cap must be correctly seated on t e burner base for proper operation
of t e burner. Verify cap is properly aligned and leveled by moving t e burner
cap around on burner base w ile rangetop is cool.
 T e cap s ould not be loose.
 T e pegs in t e burner base s ould fit into t e recess on t e underside
of burner cap.
 Cap s ould be t e correct size for eac burner base.
 Cap must be clean and dry for proper ignition.
 Place grate over cap and burner base once cap is properly placed.
JUDWH
EXUQHUEDVH
EXUQHUFDS
EXUQHUNQRE
SLYRWSRLQW
RULILFHKRRG
DLUVKXWWHU
Testing and adjusting surface burner flame
A properly adjusted surface burner on a ig setting as flames t at are
clean and blue wit a distinct inner cone approximately 1/4" to 1/2" inc long.
Some yellow flame is normal w en burning LP/Propane.
 See Delayed Ignition section in Important Safety Information for safety
warnings and procedures.
Flames will not be a uniform size around the ap. This distribution
around the ap and grate allows for optimal heating.
 If burner flame is blowing or noisy, airflow s ould be reduced to
t e burner (close air s utter).
 If burner flame is weak and does not old its s ape, airflow s ould be
increased to t e burner (open air s utter).
Adjusting the surface burners air shutter
1. Disconnect electrical supply
2. Turn off all surface burners.
3. Remove burner control knobs from range.
 2 screws are visible on t e burner control panel.
4. Remove bot screws from burner control panel.
 Panel will drop slig tly after screws are removed.
5. W ile grasping bottom of burner control panel, gently lift and pull
out panel until it is clear of burner valve stems.
 After burner control panel clears t e valve stems, continue to roll
t e panel until free from t e range. Set aside.
 Bot gas valve and orifice ood are visible after burner control panel is removed.
6. Slide air s utter open or closed depending on t e appearance of burner flame.
 Air s utter s ould be moved by 1/16" to 1/8" at a time.
7. Connect electrical supply.
8. C eck flame adjustment.
 Slide knob onto valve s aft and turn to lite surface
burner.
 Flame s ould be blue wit a distinct inner cone
1/4" to 1/2" long.
 S ut off burner after flame is viewed. Remove knob.
Disconnect electrical supply if furt er adjustments are
needed.
 Repeat air s utter adjustments as necessary.
9. Reassemble burner control panel in reverse order.


WR


%XUQHU
Adjustments must onform to all lo al, muni ipal and state building
odes, and lo al utility regulations.
open close

7
Testing and adjusting the bake
and broil burner flames
Properly adjusted oven burner flames are blue wit a distinct
blue inner cone approximately 1/2" long. W en using natural gas,
flame s ould not ave any yellow flame w en burning. Some
yellow flame w en burning LP/Propane gas is normal.
Flame s ould not be visible in oven cavity w en burning and s ould not
extend into t e oven cavity beyond t e removable oven bottom.
See Delayed Ignition section in Important Safety Information for safety
warnings and procedures.
Adjusting Oven Burner Flame
Adjusting bake burners air shutter
1. Disconnect electrical supply.
2. Remove oven bottom w ile still cool.
3. Remove storage drawer.
4. From front of range, locate bake burner air
s utter.
5. Loosen air s utter lock screw and open or
close air s utter.
 Air s utter s ould be moved by 1/16" to 1/8" at
a time.
 If burner flame is blowing or noisy, reduce
airflow to t e burner (close air s utter)
 If burner flame is yellow and does not old its s ape, increase airflow to
t e burner (open air s utter).
6. Tig ten air s utter screw.
7. Connect electrical supply.
8. Test oven bake burner flame for proper adjustment. If not adjusted
properly, disconnect electrical supply and repeat steps 5, 6 and 7.
9. Replace storage drawer.
10. W en oven is again cool, replace oven bottom.
Adjusting broil burners air shutter
1. Disconnect electrical supply.
2. Open oven door.
3. Loosen air s utter lock screw and open or close t e air s utter.
 Air s utter s ould be moved by 1/16" to 1/8" at a time.
 If burner flame is blowing or noisy, reduce airflow to t e burner.
 If burner flame is yellow and does not old its s ape, increase
airflow to t e burner.
4. Tig ten air s utter screw.
5. Reconnect electrical supply.
6. Test oven broil burner flame for proper adjustment. If not adjusted
properly, disconnect electrical supply and repeat steps 3 and 4.
7. Close oven door.
Adjustments must onform to all lo al, muni ipal and state building
odes, and lo al utility regulations.
1/2"
1/2"
long
Burner
Flame
RULILFH
KRRG
DLU
VKXWWHU
DLUVKXWWHU
ORFNVFUHZ
FORVH
RSHQ
DLU
VKXWWHU
open
close

8
ookware Recommendations
COOKWARE
MATERIAL USES
Aluminum Heats and cools quickly. Use for frying, braising,
and roasting.
Stainless Steel Heats and cools at moderate rate. Use for soups,
sauces, vegetables, general cooking.
Copper Clad /
Tin Lined Heats and cools quickly. Use for gourmet cooking,
wine sauces, egg dishes.
Cast Iron Heats and cools slowly. Use for low heat cooking,
frying.
Enamelware Heating speed depends on base metal in the
cookware. Use for low heat cooking.
Ceramic (Glass) Heats and cools slowly. Use for low heat cooking.
Flat Pan Test
For best cooking results, use a pan
wit a flat bottom. To determine if
pan as a flat bottom:
1. Rotate a ruler along bottom
of pan. If pan is not flat, gaps
between bottom of pan and
edge of ruler can be seen.
2. A small groove or mark on a
pan does not affect cooking
times. However, if a pan as
a gap, formed rings, or an
uneven bottom, it does not
cook efficiently and in some
cases may not boil liquid.
Can I can?
Canning is not recommended with
any of the Amana gas ranges or
cooktops due to the intense heat and
large cookware required to can.
The high, sustained heat generated by
the canning cookware overheats both
the burners and the surface of the range
or cooktop. This may cause damage to
burners, knobs, or finish, and may even
cause overheating of surrounding walls.
Damage incurred by canning, or
attempting to can, is not covered under
warranty.
What Should ou Consider in Cookware?
SELECT AVOID
Flat bottomed cookware. Cookware with rounded or warped bottoms.
Heavy gauge metal cookware. Light gauge metal cookware.
Handles that are secure, that are not
heavy enough to tilt pan. Cookware with loose or broken handles or heavy handles that tip pan when empty.
Proper pan size. Cookware that is smaller than or greater than
burner grate by 1 inch.
Flat bottomed wok Wok with a ringstand on bottom.
More than 1 inch
overhang
Does not cover burner

9
Using the Range
WARNING
!
To avoid risk of serious personal
injury, property damage, or fire,
do not leave surface burners
unattended w ile in operation.
Grease and spillovers can ignite
causing a fire.
Setting Surface Burner Controls
Burner s ould ignite wit in 4 seconds. If burner does not ignite wit in
4 seconds, turn control knob to OFF position and follow directions in
Placing Burner Caps section.
1. Pus in and turn knob to LITE.
 Burner s ould ignite wit in 4 seconds.
2. After gas ignites, turn control to desired setting.
 Knobs do not ave distinct clicks.
 Use HI to bring food to boiling temperatures.
W en food is boiling temperature setting
s ould be reduced.
 After lig ting burner do not operate for long
periods of time wit out cookware on grate.
T e finis on t e grate can c ip wit out cookware to absorb t e eat.
 Flame size s ould matc t e size of t e pan. Do not allow t e flame
to extend up t e sides of t e pan. T is can cause clot ing to ignite,
make t e andle ot, or cause burns.
3. W en finis ed cooking, turn control to OFF position.
During a Power Outage
Although the system that lights the
burners is electric, surface burners can
be ignited during a power outage. Never
attempt to light bake or broil burners
(oven burners) during a power
failure.
1. Hold match at base of desired
surface burner.
2. Push in burner control knob and
turn to LITE position.
3. After gas ignites, remove match
from burner and turn burner control
knob to desired setting.
Adjusting Burner Flame Size
 W ile turning burner control knob, watc t e burner flame.
 Flame size s ould matc t e size of t e pan.
 Flames t at extend up t e sides of t e pan can ignite clot ing,
making t e andle ot, or cause burns.
If These Controls re
Different From Yours
The control descriptions are
intended to show the variety of features
that are available in the product line. If
your range does not have all the features
that are shown, it is not a mistake. The
information provided applies to several
of the available models.
SURFACE BURNER
CONTROL SETTINGS WHEN TO USE SETTING
LO Use to prepare food at less than boiling
temperatures or to simmer.
MED
Use to maintain boiling of larger
amounts of food, low temperature frying
and to maintain correct pressure in a
pressure cooker.
HI
Use to bring food to boiling
temperatures. When food is boiling
temperature setting should be reduced
to LO through MED.
<
G
O
F
F
E
D

10
Oven Racks and Rack Positions
Your range as 5 oven rack positions to accommodate all type of cooking
and cookware. Top oven ra k position must not be used.
Oven Ra k Pla ement
Position oven rack before turning oven on.
1. Pull rack forward to stop position.
2. Raise front edge of rack and pull
until rack is out of oven.
3. Place rack in new rack position.
 Curved edge of rack must be
toward rear of oven.
luminum Foil
WARNING
!
To avoid risk of personal injury,
property damage or fire, do not
line oven bottom, racks, or broiler
pan and grid wit aluminum foil or
any ot er material.
W en placed on t e oven bottom or
racks, aluminum foil not only creates
a azard, but also affects cooking
performance. To minimize spills in
t e oven, place a s allow pan or
cookie s eet underneat food items
t at drip or spill.
Using the Range (contd)
Broiling Hints
• Broiling does not require
preheating.
• Remove excess fat from meat
before broiling.
• Cut edges of meat to prevent
curling.
• Place food on a cold ungreased
broiling pan. If pan is hot, food
sticks.
• All food except fish should be
turned at least one time.
• Begin broiling with skin side
down.
• Season meat after it has browned.
• Begin cooking using suggested
rack levels in Cooking:Broiling
section in the back of this manual
to test broiler results. If food is not
brown enough, cook on a higher
rack position. If food is too brown,
cook on a lower rack position.
• Oven door must be closed.
RACK POSITION GUIDELINES FOR BAKING, ROASTING, BRAISING
Rack Position Food Type
2Puff pastry products, streudles, casseroles, muffins,
small pork poin, and Eye of Round roast.
3Halved chickens, whole pork tenderloin, Cornish hens,
pot pies, frozen pizzas, quick breads (corn bread,
biscuits).
4Roast tenderloin of beef, whole chicken, whole pork loin,
roasted vegetables such as spaghetti or acorn squash.
5Whole turkey, capons, tip roasts and dressings.
6Large cuts of roasts meats such as top round, standing
rib roast, crown roast of lamb and boston butts. Baked
and sweet potatoes, flat breads and cobblers.
RACK POSITION GUIDELINES FOR BROILING
Rack Position Food Type
2
Boneless pork chops, boneless skinless chicken breast,
fish fillets, tuna steaks. Use a flat or shallow edged tray.
1/2 to 3/4” thick beef or tuna steaks, or pork chops.
London Broil.
3 1 to 1 1/2” thick steaks, 1 to 2” thick pork chops.
Lobster tails.
2
3
4
5
6

11
Placing the oven bottom
T e oven bottom in your range as been screwed in to prevent any s ifting
during moving or cooking. T e oven bottom protects t e recessed bake
burner area during baking or broiling.
It is necessary to remove t e oven bottom for routine cleaning. T e oven
bottom, burner baffle, and bake burner recess will need to be cleaned of any
excess grease or soil before a self-clean cycle is started.
To remove the oven bottom:
1. Verify all controls are in t e OFF position.
2. Oven must be cool to t e touc .
3. Open oven door and adjust any low oven racks to a ig er rack position,
or remove racks temporarily from oven.
4. Locate two t umb screws olding oven bottom in place in rear of oven
cavity.
 Remove t umb screws and retain for later use.
5. Carefully remove oven bottom from oven cavity.
 Lift at rear sides and slide from front frame.
 Oven bottom can be was ed of excessive grease using a mild soap
and water.
6. Wipe out bake burner recess wit a clot dampened wit soapy water.
7. Dry t oroug ly.
8. Replace oven bottom and secure wit t umb screws.
 Place front edge of oven bottoms under front frame.
 Lower rear of oven bottom into position and install t umb screws.
 Do not overtig ten t umb screws.
 Oven bottom must be in place for oven to be used or for a self-clean
cycle to be run.
9. If oven racks were removed, replace oven racks.
WARNING
!
To avoid risk of personal injury,
property damage, or fire, clean
excess grease and soil from bake
recess before beginning a self-
clean cycle.
WARNING
!
To avoid risk of personal injury,
property damage or fire, do not
line oven bottom, racks, or broiler
pan and grid wit aluminum foil.
CAUTION
!
To avoid risk of personal injury
wear gloves to protect ands
from possible s arp edges.
Using the Range (contd)

12
Features
12-hour automatic cancel
T is safety feature prevents oven from continuing to operate if it as been
left on for over 12 ours. If a cooking function continues longer t an 12 ours
wit out any options on oven control being touc ed, t is feature turns oven
off. Any time an option is touc ed, 12- our automatic cancel is reset.
O en temperature control adjustment
Your range is calibrated at t e factory for proper temperature. Due to
individual variances and preferences, it may be necessary to adjust oven
once it as been installed.
W en first using t e oven, follow recipe times and temperatures. Before
adjusting oven baking temperature, test a recipe by setting oven temperature
ig er or lower t an t e suggested temperature. T e baking results s ould
elp you to decide ow muc of a temperature adjustment is required.
An accurate digital t ermometer is necessary to calibrate t e oven. Store
purc ased oven t ermometers do not accurately measure oven temperature.
Oven temperature can be increased or decreased by 35°F. To avoid over
adjusting t e oven, only adjust t e temperature by 5°F eac time.
NOTE: Remove aluminum foil from racks and oven bottom as t is will alter
oven performance. C eck for blocked eat vents. If it still appears
oven is not performing as expected, a calibration may be done.
1. Turn oven temperature knob to OFF.
2. Press and old bot arrow pads for approximately 5 seconds.
3. A double digit will display ranging from -35°F to 35°F.
4. Immediately, press eit er:
 to increase oven temperature by 5°F
 to decrease oven temperature by 5°F
 W en temperature is adjusted to a cooler setting, a minus sign (-) will
display wit t e offset temperature.
5. W en desired temperature c ange is displayed, release control and
c ange will be automatically saved after a few seconds. Control will
return to time of day display.
 Offset temperature c ange will be retained t roug a power failure.
Ser ice codes and tones
Electronic oven control is equipped wit a self-diagnostic system.
Self-diagnostic system alerts you if t ere is an error or problem wit t e unit.
If electronic range control sounds a series of s ort, rapid beeps for over 16
seconds and t e display s ows an F-code, record F-code s own. Some
F-codes can be cleared by disconnecting power to t e range for
approximately 3 minutes. If t e code continues to reoccur disconnect
electrical supply to range and contact an aut orized servicer.
F-
code Possible Meaning
F1 Control failure
F2 Oven over temperature
F3 Sensor open or shorted
F9 Door latch circuit failure
DOOR Door has not latched.

13
LIGHTS DESCRIPTION
&/2&. Clock pad light remains on while time of day is set.
7,0(5212)) Timer On/Off pad light remains on while the timer
counts down.
&22.&/($1
7,0(
Cook/Clean Time light is turned on when entering
cook or clean time. Light remains on during the cook
or clean cycle.
67$57
&22.&/($1
Start Cook/Clean light turns on when entering the
time a cooking or cleaning cycle is to start.
35(+($7
Preheat light turns on and remains on while oven
is heating to selected temperature. Light shuts off
when oven reaches and maintains temperature.
/2&.('
Locked light turns on and remains on when oven
door is locked. Locked light flashes when door is
automatically locking or unlocking.
29(121
Oven On light turns on and remains on while
oven is in use. Oven light does not monitor oven
cavity temperature.
29(1/,*+7 Turns on when OVEN LIGHT pad is pressed.
DISPLAY DESCRIPTION
%5/ Displays when oven is broiling or set to broil.
&/1 Displays when oven is self cleaning or
is set to self clean.
(1' Displays when oven has reached the end of a
baking or cleaning cycle.
Timer Signal
When time elapses, timer beeps
a single, three second tone.
Preheat Signal
After setting oven to bake and selecting
a temperature, oven preheats. When
oven reaches set temperature, oven
signals a one second beep and the
preheat light shuts off.
End-of-Cycle Signal
When a timed cooking cycle is
complete, the oven will beep four tones
approximately one second apart,
followed by a continuous series of one
second beeps every ten seconds until
the oven knob is turned to OFF.
Display and Signals
Clo k also
displays oven
temperature.
350

14
Using the Oven ontrol
Setting Electronic Clock
T e 12 our clock does not display AM, PM or military time. W en power
is connected or restored, display flas es until
RECALL OVEN TEMP/CLOCK pad is pressed or
temperature knob is turned.
1. Press RECALL OVEN TEMP/CLOCK pad.
2. Press + or pads until correct time-of-day
displays.
3. Time is set after 5 seconds of no adjustment.
Setting Minute Timer
T e timer is a timer only. Electronic timer does not control bake, broil or
self-clean function. Timer can be set up to 11 ours and 59 minutes.
1. Press TIMER ON/OFF pad.
2. Press + or pad until desired amount of time
displays.
 Time increases in 1 minute and 10 minute
increments.
 Timer begins counting down automatically
after time is entered.
 To view clock w ile timer counts down,
press RECALL OVEN TEMP/CLOCK pad. Timer will return after
3 seconds of no input.
3. Press and old TIMER ON/OFF pad to cancel timer signal.
 After time elapses, timer beeps a single, t ree second tone.
Resetting and Can eling Timer
To reset t e time w en remaining time is displayed, press
TIMER ON/OFF pad, t en + or pad until new time displays.
To cancel timer w en remaining time is displayed or w en signal is
beeping, press and old TIMER ON/OFF pad.
Flashing Display
When power is connected
or interrupted, oven display flashes.
Press CLOCK to reset display.
Clock may need to be reset.
Making the Numbers
Increase at a Faster Rate
Time increases in larger increments
the longer the +or pad is held.
Timer Signal
When time elapses, beep will sound.
Press TIMER ON/OFF pad to stop timer
and return to clock display.
Preheat Signal
After setting oven to bake and selecting
a temperature, oven preheats. When
oven reaches set temperature, signal
sounds. The preheat light will shut off
and remain off after oven has reached
the selected temperature.

15
Using the Oven ontrol (contd)
Preheating
In most cases, you should preheat the
oven before baking. After the range
control is set, the oven temperature
will begin to rise until the desired
cooking temperature is reached.
When cooking temperature is reached
oven signal beeps. For delicate
baking, preheat approximately 15–20
minutes before placing food inside
oven or wait 10 minutes after oven
signal beeps before placing food in
oven. The extra time creates a more
stable oven temperature.
How High or Low Can I
Set the Temperature?
Oven bake temperature can be set from
170°F to 550°F . Some minor smoking is
normal when using oven for first time.
WARNING
!
To avoid risk of personal injury,
property damage or fire, do not
line oven bottom, racks, or
broiler pan and grid wit
aluminum foil.
WARNING
!
To avoid risk of personal injury,
property damage or fire, never
leave oven unattended w ile
broiling.
Broiling
Broiling sears in natural juices and provides c arbroiled flavor.
To broil, center food on broiling grid and pan and place on proper rack in
oven. Do not place aluminum foil over boiling pan, oven rack or oven
bottom. Oven door must be fully losed. Broiling does not require
pre eating so you can place food in oven w ile it is still cool.
1. Adjust oven racks to desired position.
2. Turn oven temperature knob to BROIL.
 Oven indicator lig t will turn on and
remain on.
BRL will display.
 Display will return to time of day
approximately 15 seconds after
broiling begins.
 To recall oven temperature, press
RECALL OVEN TEMP/CLOCK pad.
2. Close oven door.
 If oven door is ajar for more t an
3 minutes, broil cycle will stop.
 If oven stops broiling due to an open door, close oven door and
wait for t e ignitor to lite broil burner.
3. After broiling, remove food and turn oven temperature knob to OFF.
Baking
W ile oven is still cool, remove any stored items from t e oven cavity.
1. Place racks in desired position and close oven door.
2. Pus and turn oven temperature knob to desired temperature.
 Oven indicator lig t will turn on
and stay on.
 Temperature is displayed in t e clock
area in 5 degree increments.
 Temperature range is 170°F to 550°F.
 Display will return to time of day after
approximately 15 seconds.
 To recall oven temperature, press
RECALL OVEN TEMP/CLOCK pad.
3. PREHEAT lig t will turn on during t e
pre eat cycle. PREHEAT lig t s uts off
w en oven as reac ed desired temperature and oven beeps.
4. Open door carefully and place food in oven.
5. After cooking time elapses, remove food and turn oven temperature
knob to OFF.

16
Using the Oven ontrol (contd)
CAUTION
!
To reduce risk of food poisoning
due to bacterial growt and
production of toxins, never old
meat, milk, fis , or eggs for more
t an 2 ours before cooking.
Timed Baking
Set oven to cook for desired amount of time. Follow recipe directions for
pre eating t e oven.
1. Place food in oven.
2. Press COOK/CLEAN TIME pad.
3. Press or pad until desired lengt of time is
displayed.
 Cook time can be set up to 11 ours and 59 minutes.
4. Pus and turn t e temperature control knob.
 Temperature displays in 5° increments starting at 170°F.
 Clock will return to time of day after approximately 15 seconds.
 To recall oven temperature, press RECALL OVEN TEMP/CLOCK pad.
5. Oven will automatically begin to eat.
 To adjust cook time, press COOK/CLEAN TIME pad w ile t e
remaining cook time is displayed. Cook time can t en be adjusted.
 W en cooking time as elapsed an end of cycle signal sounds
and END will be displayed. Oven signal sounds 4 times, t en
once every 10 seconds until oven control knob is turned to OFF.
6. Turn knob to OFF to cancel baking.
Delayed Baking
Set oven to begin baking at a later time.
1. Place food in oven.
2. Press START COOK/CLEAN button.
 Default time displayed is current time of day.
3. Press or pad until desired time displays.
 Start time can be set up to 11 ours and
59 minutes a ead of current time of day.
4. Press COOK/CLEAN TIME pad.
5. Press or pad until desired cooking time
displays.
 1 minute minimum cooking time.
END will be displayed w en cooking time as
elapsed.
6. Pus and turn oven temperature control knob to desired
temperature.
 Temperature displays in 5° increments starting at 170°F.
 Display will return to time of day after 5 seconds of no input.
 START TIME and COOK TIME lig ts will remain on, but
OVEN ON lig t will not turn on until cooking begins.
7. Oven will automatically begin to eat at selected start time.
 OVEN ON lig t will turn on w en oven begins to eat.
 To adjust cook time, press COOK/CLEAN TIME pad w ile t e
remaining cook time is displayed. Cook time can t en be
adjusted.
 W en cooking time as elapsed an end of cycle signal sounds
and END will be displayed. Oven signal sounds 4 times, t en
once every 10 seconds until oven control knob is turned to OFF.
8. Turn knob to OFF to cancel baking.
What's the difference
between TIMED and
DEL YED cooking?
When using TIMED cooking, the oven
begins to heat immediately after the
oven control is set. Then, the oven
cooks for the desired length of time set.
When using DELAYED cooking, the
oven begins to cook later in the day. Set
the time that you want to begin cooking
and the how long you want to cook. The
oven begins to heat when at the selected
time and cooks for the specified length
of time.
How Far head Can I Set
the Time?
Cook time and start time can be set up
to 11 hours and 59 minutes ahead.
To view cook time, press and hold
COOK TIME pad. When cooking time
has elapsed, an end of cycle signal
sounds, oven automatically turns off and
display returns to time of day. Oven
signal sounds 4 times, then once every
10 seconds until knob is turned to OFF.
Broil can not be set to Timed or
Delayed.
How much time is left?
For a delayed bake cycle, the cook time
can be viewed by pressing the COOK
pad. For a timed bake cycle, the stop
time can be viewed by pressing the
STOP pad.

17
Using the Oven ontrol (contd)
WARNING
!
To avoid risk of personal injury,
do not touc oven vents, or area
around vents, during self-
cleaning. T ese areas can
become ot enoug to cause
burns.
CAUTION
!
To avoid fire or smoke damage,
 remove any flammable
materials from storage drawer.
Items like plastic containers
and paper manuals can melt or
burn.
 clean excess spills before
starting a self-clean cycle.
Do I need to prepare?
To get the best results from the
self-clean cycle, follow these steps:
• Clean excess spills from oven
interior and oven burner
thoroughly.
•Remove birds or animals
susceptible to smoke or other
fumes from the room or
adjoining room.
• Open window if possible.
• Make sure oven light cover is
properly in place. Do not use
cleaning cycle if it is not.
• Remove oven racks and all cooking
utensils from oven.
• Remove items from range top,
backguard and storage drawer.
These areas can become hot during
self-cleaning cycle.
• The range vents from the center
bottom of the backguard. Make
sure this area is unobstructed by
removing all items from backguard
and range top.
Self-cleaning
Self-clean feature uses ig oven temperature to clean oven interior.
For t e oven to operate t roug a complete self-clean cycle, t e self-
clean must be set w en t e oven is cool.
1. Prepare oven for self-cleaning (see below left).
2. Close door.
3. Pus and turn oven temperature knob to
CLEAN position.
 T e default self-clean cycle lengt of 3
ours will display.
4. Set cycle lengt for self-clean.
 Use arrow keys to adjust time as
necessary before oven indicator lig t
turns on.
 Clean cycle can be set from two to four
ours in five minute increments.
 Default setting for t e cycle is t ree
ours.
5. Self-clean begins.
 OVEN ON indicator lig t will be on and will remain on until t e end
of t e cycle.
 At t e end of t e self-clean cycle, t e OVEN ON indicator lig t will
s ut off.
 T e LOCKED indicator lig t will remain on until oven reac es a
cooler temperature. LOCKED lig t will flas w ile door is
unlocking, and t en s ut off w en door as unlocked. Oven cavity
will be ot to t e touc . DO NOT attempt to open door prior to
LOCKED indicator lig t s utting off.
Interrupting the self-clean cycle
To stop a self-clean cycle t at as already started follow t ese steps.
If t e interruption occurs mid cycle, t e oven will remain locked, even
t oug t e cycle as stopped, until t e oven cavity as cooled to a
lower temperature.
1. Turn oven temperature knob to OFF position.
2. W en oven as cooled to a lower temperature, LOCKED lig t
turns off. Door can be unlocked. DO NOT force door.
T is can cause damage to t e latc .
Operating surface burners during a self-clean cycle.
Your range is equipped wit a safety feature to prevent it from over eating
during a self-clean cycle. A special temperature sensor s uts off t e self-
clean cycle if t e range becomes too ot. Depending on t e range and t e
lengt of cooking time on t e surface burners, t e sensor may or may not
s ut off t e self-clean cycle. To prevent any self-clean cycle disruption, it is
best not to use t e range surface burners during a self-clean cycle.

18
Using the Oven ontrol (contd)
Delayed Self-clean Cycle
Self-clean feature uses ig oven temperature to clean oven interior.
Set oven to begin and end cleaning at later time. Range control begins
t e self-clean at your specified start time.
1. Prepare oven for self-cleaning (see below rig t).
2. Close door.
3. Press START COOK/CLEAN pad.
4. Set starting time for t e cleaning cycle.
 Default time is current time of day.
 Start time can be set from current time to
current time plus 11 ours and 59 minutes.
5. Turn oven temperature knob to CLEAN.
 Default self-clean cycle lengt of 3 ours will display.
6. Set cycle lengt for self-clean.
 Use arrow keys to adjust time as necessary.
 Clean cycle can be set from two to four ours in five minute
increments.
 Default setting for t e cycle is t ree ours.
7. Self-clean cycle is set.
 Oven cannot be used until completion of t e self-clean cycle.
 Self-clean cycle will begin at selected start time.
 To view start time, press t e START COOK/CLEAN pad.
 OVEN ON indicator lig t will turn on w en t e self-clean cycle
begins and will remain on until t e end of t e cycle.
 To view t e clean cycle time, press t e COOK/CLEAN TIME pad.
 At t e end of t e self-clean cycle, OVEN ON indicator lig t s uts
off.
 T e LOCKED indicator lig t will remain on until oven reac es a
cooler temperature. LOCKED lig t will flas w ile door is
unlocking, and t en s ut off w en door as unlocked. Oven
cavity will be ot to t e touc . DO NOT attempt to open door
prior to LOCKED indicator lig t s utting off.
Interrupting the self-clean cycle
To stop a self-clean cycle t at as already started follow t ese steps.
If t e interruption occurs mid cycle, t e oven will remain locked, even
t oug t e cycle as stopped, until t e oven cavity as cooled to a safe
temperature.
1. Turn oven temperature knob to OFF position.
2. W en oven as cooled to a lower temperature, LOCKED lig t
s uts off. Door can be unlocked. DO NOT force door. T is can
cause damage to t e latc .
Do I need to prepare?
To get the best results from the
self-clean cycle, follow these steps:
• Clean excess spills from oven
interior and oven burner well.
•Remove birds or animals
susceptible to smoke or other
fumes from the room or
adjoining room.
• Open window if possible.
• Make sure oven light cover is
properly in place. Do not use
cleaning cycle if it is not.
• Remove oven racks and all cooking
utensils from oven.
• Remove items from range top
backguard and storage drawer.
These areas can become hot during
self-cleaning cycle.
• The range vents from the center
bottom of the backguard. Make
sure this area is unobstructed by
removing all items from backguard
and range top.
WARNING
!
To avoid risk of personal injury, do
not touc oven vents, or area
around vents, during self-cleaning.
T ese areas can become ot
enoug to cause burns.
CAUTION
!
To avoid fire or smoke damage,
 remove any flammable
materials from storage drawer.
Items like plastic containers and
paper manuals can melt or burn.
 clean excess spills before
starting a self-clean cycle.

19
Bake Pan Pla ement
 Keep pans and baking s eets 2 inc es from oven
walls.
 Stagger pans placed on different racks so one is
not directly over t e ot er.
ooking
BAKING TIME GUIDELINES
Cake Pan
Type Pan size Cups of batter Oven Temp. Minutes
Oval 7 ¾” x 5 ¾” 2 ½350°F 25 to 30
13”x 9 ¾” 8 350°F 25 to 30
Round,
2”layer 6”2 350°F 25 to 30
8 “3 350°F 30 to 35
14”10 350°F 50 to 55
Round,
3”layer 8”5 325°F 60 to 65
12”11 325°F 75 to 80
Half Round,
2”layer 18”9 325°F 60 to 65
Half Round,
3”layer 18”12 325°F 60 to 65
Square 6”2 350°F 25 to 30
10”6 350°F 35 to 40
16”15 1/2 350°F 45 to 50
Baking Guidelines
W en baking wit a new oven, keep in mind temperatures vary from oven to oven. Store-boug t t ermometers are
generally not accurate and s ould not be used to calibrate oven temperatures.
Hints for Cookies,
 S iny, flat cookie s eets s ould
be used. Avoid cookie pans wit
ig sides - t is will cause
uneven browning on t e top.
 Cookie s eet s ould not touc
t e sides of t e oven or door.
Cakes,
 Follow recipes directions for
pan size. S iny pans work best
for cakes.
 Cake baked in too large a pan
will be t in and dry. Too small a
pan will be undercooked or
unevenly cooked and may spill.
Pies
 Pies s ould be baked in dark or
dull pans to increase browning.
 Frozen pies s ould be eated
on an aluminum cookie s eet.
BAKEWARE GUIDELINES
Dark or dull pans Absorb more heat
and result in darker
browning.
Recommended for
pies and breads.
Shiny pans (no
sides) Recommended for
cookies.
Shiny pans
(sides) Recommended for
cakes
Glass pans Lower
recommended
oven temperature
by 25°F.
Preheating
In most cases, you should preheat the oven before baking. After the range control is
set, the oven temperature will begin to rise until the desired cooking temperature is
reached (approximately 8 to 10 minutes). When cooking temperature is reached
oven signal beeps. For delicate baking (such as puff pastries or souffles),
preheat approximately 15–20 minutes before placing food inside oven or wait
10 minutes after oven signal beeps before placing food in oven. The extra time
creates a more stable oven temperature.

20
ooking (contd)
3UREOHP &DXVH
Lopsided cakes
(bake unevenly) Pans touching each other or oven walls.
Batter spread unevenly in pan.
Uneven heat distribution in oven.
Oven is not level.
Cakes, cookies, biscuits
too brown on bottom or top Oven not preheated.
Pans touching each other or oven walls.
Using glass, darkened, warped or dull
finish metal pans.
Rack position too high or low.
Incorrect use of aluminum foil.
Oven temperature too high.
Pies don’t brown Incorrect rack position.
Using shiny metal pans.
Temperature set too low.
Cakes not done in center Temperature too high.
Pan too small.
Baking time too short.
Pan not centered in oven.
Cakes fall Too much shortening or sugar.
Too much or too little liquid.
Temperature too low.
Old or too little baking powder.
Pan too small.
Oven door opened frequently (peeking).
Insufficient baking.
Excessive shrinkage Too little leavening.
Mixing batter too long.
Pan too large.
Oven temperature too high.
Baking time too long.
Cakes high in middle
or cracked Temperature set too high.
Overmixing.
Too much flour.
Pans touching each other or oven walls.
Common Baking Problems
If you begin to notice consistent problems refer to t e c art below for possible solutions. If results are still poor,
contact Amana Consumer Affairs at [phone].
Test your cakes for doneness
It may not be the oven
Cake problems may be in the mixing of
the batter. Overbeating can cause cake
structure to break down and excessive
shrinkage of the cake. Underbeating
can result in lumpy cakes that may not
be cooked thoroughly. All ingredients
should be at room temperature—not
out of the refrigerator. Make sure to
follow the recipes directions for how
long the batter should be mixed.
Cake stuck?
Allow cake to cool in cake pan on a rack
for 10 minutes before removing. Larger
cakes (over 14 inches in diameter) may
take 15 minutes. If the cake has cooled
too long, reheat in the oven at 250°F for
a few minutes.
Better with butter
Make sure to follow recipe directions
and use butter or margarine when it is
listed. Using a low fat substitute will
cause a recipe to fail.
While they are still in the oven. Because
of variances across individual ovens, it
is best to test for the proper consistency
rather than solely relying on time and
visual appearance as an indicator.
