AMAZE 420SS-SOLO User manual

INSTALLATION(INSTRUCTIONS(FOR(SOLO(SMART(&(DUAL(
SMART(WALL(PANEL(HEATERS(
(
INSTALLATIE(INSTRUCTIES(VOOR(SOLO(SMART(&(DUAL(
SMART(MUURPANEEL(VERWARMING(
(
INSTRUCTIONS(D'INSTALLATION(POUR(LE(CHAUFFE-
PLANCHER(SOLO(SMART(&(DUAL(SMART(
(
(
(
(
(
-(Please(keep(this(instructions(in(a(safe(place(
-(Bewaar(deze(instructies(op(een(veilige(plaats(
-(Veuillez(garder(ces(instructions(dans(un(endroit(sûr(
(
EN#
FR#
NL#

EN
AMAZE#420W#ELECTRIC#SMART#WALL#PANEL#HEATERS#
READ(AND(SAVE(THESE(IMPORTANT(SAFETY(INSTRUCTIONS(
BEFORE(YOU(START(INSTALLING(YOUR(NEW(AMAZE(PRODUCT(
WELCOME to the AMAZE family. Thank you for choosing and purchasing our product.
Amaze Smart Panel Heaters provide efficient room heating at a low cost. Using Natural Convection
technology, heat is generated behind the heater in the space between the panel and the wall, which
leads to an efficient updraft of heat circulated into the room creating comfortable warmth throughout
the room.
DO#NOT#COVER#
Please take note of the step-by-step instruction supplied in this
booklet to ensure a hassle free installation.
Model:'420SS'-'SOLO'
Model'420SS'-'DUAL'
Product'Code:'AH420EUS'/'AH420UKS'
Product'Code:'AH420EUDS'/'AH420UKDS'
'

WARNINGS
•The appliance surface is HOT when in use so please use with caution, as it is a heating appliance.
•DO NOT RUN THE CORD BEHIND THE HEATER.
•
In order to avoid overheating, do not cover the heater with anything, including wet or dry washing.
Covering the panel could result in a fire hazard.
•
Amaze Wall Panel Heaters are for wall mount only and should under no circumstances be used as
freestanding heaters.
•
The surface of the appliance is “safer” to touch due to its low thermal conductivity. However, an infant or
a baby or any person with reduced physical, sensory or mental capabilities or lack of experience or
knowledge should not be left unattended as prolonged contact with the surface may result in an injury as
the surface is still hot.
•This is appliance is NOT suited for use in a bathroom.
•
The appliance is fitted with a 2-core cable only, any modification of the cable or removal of the factory
fitted plug voids the warrantee of the product.
•
Before drilling into the wall, check that the area is free of pipes or electrical wires embedded into the wall.
•The appliances should not be located below or in front of an electrical socket.
•
When switching on the heater for the first time, there may be a slight odor during the first day or two. This
is quite normal and is caused by the residual moisture in the panel and does not present any health
hazard.
•
This product is not intended for use by persons (including children) with reduced physical, sensory or
mental capabilities or lack of experience and knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for their safety.
•Children should be supervised to ensure that they do not play with the appliance.
•
The Amaze Panel Heaters are manufactured to withstand a consistent electricity supply of between 230 –
240VAC. Customers in regions that frequently experience surges/spikes or erratic power supply are
advised to use a surge protector with our appliance. Our warrantee does not cover damage as a result.
•
AMAZE-HEATERS HAS NO USER SERVICEABLE PARTS INSIDE and should only be opened by
authorized agent.
•
To disconnect the heater from the wall socket, please only pull on the plug socket and not the cord to
remove the socket from the wall.
•
ONLY USE EXTENTION CORDS where needed of 10Amps or more and do not run the extensions under
carpeting, throw rugs, runners or similar coverings and arrange the cord in such a way to avoid tripping
over the cord or extension.
•
This product is ONLY for indoor use and only for heating a room with no flammable material or substance
in close proximity to the heater.
•Only the provided fixing holes and brackets should be used for mounting.
•
In the rare instance that a heater develops very minor hairline cracks this will NOT normally be
considered a warrantable item. If this does occur, the Safety and performance of the heater will not be
affected by cosmetic defects.
•
The customer shall be responsible for all costs incurred in the removal or reinstallation of the products,
including but not limited to labor costs and shipping costs to return the heater to the Amaze-Heaters
service center. Within the limitations of this warranty and at the discretion of Amaze-Heater LLC, we will
repair or replace the heater.
EN
DO#NOT#COVER#THE#HEATER#

1) Before' you' can' start' you' have' to' download' the' EWeLink'Smart'
Application'available'from'the'Apple'or'Google#Play#Store.'
'
2) Open' the'Smart' App' and' press' on' the' “REGISTER”'button' on'the' right'
bottom'corner'of'the'screen.'
'
3) Follow#the#instruction'on'the'Smart'App'on'how'to'register.'
'
4) Once' registered,' open' the' EWeLink' Smart' App' on' your' smart' device'
(phone' or' tablet)' and' login'with' your' new'username' and' password' that'
you'created.'
'
5) Click'on'the'“+”#sign'on'the'EWeLink'Smart'App'to'add#your#device.#
'
6) Plug#in#and#switch#on'your'Amaze'heater.'
'
7) When'the'yellow'light'is'flickering,'press#and#hold#the#little#black#button#
on# the# SONOFF# WiFi# Module# on# the# back# of# the# panel# for# 5# seconds#
until'it'blinks'3'times'in'a'row'continuously'as'indicated'in'the'“Add'Device'
Section”'of'the'EWeLink'Smart'App.'
'
8) Follow'the'instructions'on'the'EWeLink'Smart'App'to'link#your#device#to#
your#WiFi'and'choose#a#name'for'the'product.'
'
9) Your' Amaze' Product' is' now'linked' to' your' WiFi' and' ready# for#
programming.''You'can'now'program'your'heater'with'the'different'kind'
of'timing'settings'and'schedules'on'the'EWeLink'App'as'per'your'personal'
requirements.''
#
YOU(CAN(NOW(CONTINUE(WITH(THE(INSTALLATION(OF(YOUR((
AMAZE(PANEL(HEATER((
WiFi#Setup#Guide#–##
Please#setup#Wifi#BEFORE#you#install#your#panel#on#
the#wall# #
2)
3)
4)
1)
6)
5)
7)
8)
9)

EASY#STEP-BY-STEP#INSTALLATION#INSTRUCTIONS#
1) Use'the'template'provided'in'the' box' to'mark' the' holes'for' drilling,'please'
ensure'that'the'template'is'level'as'you'mark'the'holes'
2) Drill'the'4'X'holes'that'you'marked'
3) Insert' the' chosen' anchors'(either' masonry' wall' or' dry' wall)'inside' the' holes'
that'you'drilled.'
4) If'you'choose'a'dry'wall'anchor,'then'please'gently'screw'the'anchor'into'the'
hole'in'the'wall'with'a'Phillips'screwdriver.'
5) Insert'the'long'screw'into'the'bracket'and'screw'into'the'anchor'in'the'wall'
and'screw'until'firmly'secured'onto'the'wall.''Repeat'this'for'all'4'holes.'
6) Fit' the'heater' onto' the' bracket' by' aligning' the' brackets' with' the' holes' and'
press'the'heater'towards'the'wall'until'the'threaded'ends'appear'through'the'
holes'of'the'heater.'
7) Screw'the'end'caps'with'your'fingers'onto'the'exposed'ends'of'the'brackets'
to'hold'it'secure.'
FOR# DUAL# SMART# –# PLEASE# FOLLOW# THE# ADDITIONAL# INSTRUCTIONS#
BELOW:'
8) *If& you& are& installing& the& DUAL& SMART& Wall& Panel& Heater,& then& please&&&
& install& the& DUAL& brackets& to& the& bottom& two& brackets& and& screw& the&
& end& caps& onto& the& exposed& ends& of& the& brackets& to& hold& it& secure& only&
& before&installing&the&top&two&DUAL&brackets&
9) *Slide&the&DUAL&Heatguard&into&the&two&groves&in&the&bottom&brackets.&
10) *Now& insert& your& top& two& DUAL& brackets& onto& the& HEATGUARD& and& fit&
& them&into&the&top&two&brackets.&
11) *&Screw&the&last&two&end&caps&between&the&HEATGUARD&and&the&heater&with&
your&fingers&to&hold&the&heater&and&the&HEATGUARD&secure&in&place.&&
(
'
IMPORTANT#NOTICE:#
Please'setup'the'WiFi'BEFORE'you'install'the'panel'
on'the'wall'
1)
2 )
3 )
4 )
5 )
6 )
7 )
DO#NOT#COVER#THE#HEATER#
Included#in#your#packaging:'
What#tools#you#need:#
'
7mm Drill Bit

'
If you have any questions regarding the product, please do not hesitate to contact us via
our 24hour customer support on:
[e-mail]
Or visit our website
www.amazeappliances.com
And our team would be more than happy to assist.
ENJOY YOUR AMAZE PANEL HEATER
.
Warranty
IMPORTANT: PLEASE AFFIX YOUR PROOF OF PAYMENT/RECEIPT TO THIS LEAFLET. YOU WILL BE
REQUIRED TO FURNISH THE PROOF IF PURCHASE IN THE EVENT OF A WARRANTY CLAIM.
Amaze Appliances International warrants that your Amaze Panel Heater is free from manufacturing defects, subject to
the following conditions:
1) Such a warranty shall be to repair or replace the goods in the event of any manufacturing defects (which shall
exclude fair wear an tear) notified to Amaze Appliances International within 3 years of the original purchase.
2) Any liability on Amaze Heat International hereunder shall be conditional on the goods having been stored and
installed properly (in accordance to the Amaze Appliances installation instructions) and, from the date of delivery.
a. Having been used and maintained in accordance with Amaze Appliances Instructions and/or labeling on
the goods;
b. No repairs or alterations thereon having been carried out by the buyer or any third party.
3) The warranty is a substitution for and excludes all expressed or implied (whether by law or otherwise) conditions,
warranties or obligations of any kind relating to fitness for purpose or quality of workmanship, material or design,
save to the extent that any law prevents such exclusion. Amaze Heat International accepts no liability for any
workmanship of any approved installer (as contemplated above), the approved installers being independent
contractors. If the heater is found to be faulty, it must be returned to the outlet/retailer that the product was
purchased from.
Limitation of Liability
1) Save an expressly provided for in these Conditions of Sale, and save as may be stipulated to the
contrary in the Consumer Protection Act of the specific country of sale within Europe or the rest of the
world, Amaze Appliances shall not be liable to the Purchaser (or their employees, servants or agents,
contractors or successor purchasers) for and direct, indirect or consequential damages of any nature
howsoever caused (whether based in dialect or contract or otherwise) pursuant to or arising in respect of
the installation and/or use of goods. This means that if ANY loss, damage or harm is caused to anyone
due to the use or installation of these goods, you may not hold Amaze Appliances International (CO GB)
Ltd or any of its subsidiaries liable in law.
2) Save as may be stipulated to the contrary in the CONSUMER PROTECTION ACT in the country sold, in
respect of any liability of the Seller that has been excluded, the Purchaser herby indemnifies Amaze
Appliances International (CO GB) Ltd (Its members, employees and agents) against all actions,
proceedings and claims whatsoever brought against it (its members, employees or agents), by a third
party pursuant to, arising in respect of the installation and/or use and/or supply of the goods. This
means that if Amaze Appliances International (CO GB) Ltd or any of its subsidiaries is sued by anyone in
paragraph 1 above arising from the installation or use of the product that you as the Purchaser will
financially indemnify Amaze Appliances International (CO GB) Ltd or any of its subsidiaries against any
losses which Amaze Appliances International (CO GB) Ltd or any of its subsidiaries may suffer, as a
result of such law suit.
